Sourcetronic MPK-204e User manual

3
MPK-204e
200 A digital micro-ohmmeter
User guide
GU-1334
© 2009 SOURCETRONIC. All rights reserved.

4

Safety Precautions
• This equipment should be operated only by qualified and duly trained people,
closely observing the corresponding safety regulations and instructions
contained in the present User Guide.
• It should be checked that the item to be measured is voltage free.
• Before starting with the measurements, be sure that the battery is well charged
and that the line voltage is between specified limits.
• Do not connect or disconnect the test leads during the measurement.
• There are no adjustable parts or parts that can be replaced by the user within the
equipment. Taking out the Control Panel in order to have an access to the
internal parts may be dangerous as there are high voltages inside, capable of
causing fatal accidents.
• Cleaning of this instrument should be carried out using a soft cleaning liquid,
after verifying that it doesn't attack the plastic parts used in the case and in the
Control Panel of this equipment.
This equipment should be used only by a trained and competent
person, strictly applying suitable safety rules.
Used symbols

Caution, refer to User Guide.

Equipment complies with current EU Directives.

5
Index
1. Description...........................................................................................................6
2. Operating principle...............................................................................................6
3. Operating instructions..........................................................................................6
3.1. Use of test probes.........................................................................................6
3.2. Control panel.................................................................................................7
3.3. Power supply ................................................................................................8
3.4. Measurement................................................................................................9
3.5. Display messages.......................................................................................13
4. Some notes about accuracy...............................................................................14
5. Protections.........................................................................................................15
5.1. Start with I = O............................................................................................15
5.2. Temperature protection...............................................................................15
6. Battery condition ................................................................................................16
6.1. Battery and charger.....................................................................................16
7. RS232 output.....................................................................................................17
9. Cleaning.............................................................................................................18
10. Technical specifications...................................................................................19
11. Warranty ..........................................................................................................21

6
1. Description
The SOURCETRONIC MPK-204e high-current micro-ohmmeter is a
portable, microprocessor-controlled instrument, used to accurately
measure very low contact resistances of breakers and switches, busbars,
transformers winding and engines, etc, with test currents from 1 mA to
200 A.
• Kelvin architecture (four-terminal method).
• Digital reading, alphanumeric display.
• Up to 4½ digits readings.
• Powered by rechargeable battery or mains supply.
• 0.1 µΩresolution.
• 200 Ωmaximum reading.
• Overheating protection.
2. Operating principle
This device uses the Kelvin Bridge architecture, with four terminals,
avoiding testing leads resistance to cause error during measurement.
Test current may be chosen by the operator and the reading is obtained
by comparison through internal high-stability standards. The result
appears in the alphanumeric display which is very easy to read.
3. Operating instructions
3.1. Use of test probes
Select the suitable test probes for the measurement you intend to perform
taking into account the current chosen for the test (Cables for up to 10 A
or 200 A). If you use the cables corresponding to 200 A, please verify that
the test probes are tightly fit in their corresponding connectors.

7
3.2. Control panel
On/Off switch.
Stop button.
Start button.
Hold button. It retains the last measurement in the display.
Button to measure the Battery charge condition.
Alphanumeric display that shows both the measured resistance
value and messages to the operator.
Power cord connector.
Fuse.
Ground.
200 A (C1) current output terminal.
10 A (C1) current output terminal.

8
RS232 data output.
Potential (P1) terminal.
Potential (P2) terminal.
10 A (C2) current output terminal.
200 A (C2) current output terminal.
Range and test current Selector
Battery charge led.
Thermal protection led.
Test Current control.
3.3. Power supply
Mains supply or internal battery powered
Battery: rechargeable, 12 V.
Internal battery is useful for up to 10 A.
Mains: 220 - 240 V~ 50 Hz
Mains power is useful for any test current, including 200 A.

9
3.4. Measurement
Warning
• Before to use this instrument the User guide and Safety warnings
must be read
and understood.
•
Safety procedures and rules for working near high voltage energized systems
must be observed during the use of this equipment. The generated voltages and
currents may be dangerous.
1. Before power-on the equipment, connect the test probes to the item
to be measured and to the front panel terminals, as shown in figure 2
for current up to 10 A or in figure 3, for the 200 A range.
The clamps in the drawings are only for illustration.

10
2. Switch the equipment On using
the On/Off switch.
3. Using the Range
selector,choose the range and
the current to use
4. Be sure that the Test current
control is at the start position
(counter-clockwise completely
rotated).
Otherwise, Start button will be
inhibited and the display will show
the message:
5. The PRESS START message will
appear showing that
measurement can be started.

11
6. Press the Start button.
The LOW CURRENT message
will turn up:
7. Turning the Test current control
clockwise, increase current until
obtaining the desired value or
until the current bargraph reads
100 divisions. The bargraph will
show the test current value as
the percentage of the nominal
value selected by using the
Range selector.
8. The equipment should be connected to the mains supply in order to
work with 200 A.
9. The lowest current for measuring is 10% of the range nominal value.
It is important to consider that the measurement errors increase while
test current decreases. The error is specified for test currents higher
than 80%.
10. The Display will show the resistance value measured and the unit
used (Ω[ohms], mΩ[milli-ohms] or µΩ[micro-ohms]).
11. The value can be retained in the
second line of the display by
pressing the button Hold. If you
press this button again, the value
will be erased.

12
12. Press the red button Stop in
order to finish the measurement.
13. Finally, when finishing
measurements, turn the
equipment off using the On/Off
switch.
Precaution: Do not connect or disconnect
the test leads during the
measurement.

13
3.5. Display messages
When turning the equipment on using the
On/Off switch, this introduction message
appears for a while.
This message appears each time the
equipment needs to adjust any parameter
in order to optimize the readings.
Warns the operator that to be able to start
a test, the Test current control must be
at the zero position (fully counter-
clockwise). Otherwise, Start button will be
inhibited.
The equipment is ready to start a
measurement, thus the operator has to
press the Start button.
Indicates that the test current is not
enough to carry out the reading. It
appears at the beginning of each test and
it keeps on being there up to the operator
rotates the Test current control
clockwise.
Indicates that the measured resistance is
higher than the maximum value readable
in the selected range.
Indicates that some part of the equipment
has achieved the critical temperature.
Thus the system will cut the high current
generation.

14
It appears at the second line of the
display, showing that the value is the one
retained in the display when pressing the
Hold button.
It shows that the battery is quite
discharged. It is necessary to recharge
the battery.
4. Some notes about accuracy
In order to obtain the specified accuracy, the operator has to adjust the
test current to a value higher than the 80% of the nominal value. If it were
necessary, it is possible to use a lower current, but by doing this the
accuracy will be affected.
MPK-204e has an auto-compensation system that automatically
eliminates the error produced by internal offset. Thus, it is not necessary
to carry out measurements by reversing the polarity in order to compute
the average value. Nevertheless, if the operator suspect that there is a
difference of temperature between the contact points that would can
generate thermoelectric voltages, it is necessary to carry out two
measurements by reversing the current cables and so, the circulation
sense of the current through the resistance under measurement. The
resistance value to be measured will be the average between the values
in one sense and in the contrary (direct and inverse current).

15
5. Protections
5.1. Start with I = O
Very quick variations of the current may cause damages to sensible
items. In order to avoid them, the equipment has a protection that
imposes to start the test with zero current. You can only start the
measurement if the current adjust control is at the start of its course. If
this were not the case, the Start would be inhibited and the message
would say START WITH I=O. If the operator sharply increases the test
current by quickly rotating the Test current control clockwise, the
equipment will impose a slow current growth, in order the current to softly
come to the selected value.
5.2. Temperature protection
The time of MPK-204e continuous use is limited by thermal
considerations. Some internal sensors measure the temperature of the
sensitive parts and trigger the protection that will cut the current
circulation, if any of them exceeds the limit temperature, thus avoiding
any damage. The Thermal protection led will light on and the
OVERHEATING message will appear in the display. Under these
conditions, measurements will be inhibited in the 200 A range.
Measurements in other scales may be carried out normally, though the
LED indicator keeps on being displayed up to the temperature decreases
sufficiently.

16
6. Battery condition
The charge condition of the battery can be verified before or during the
resistance measurement. In order to achieve that, the operator has to
press the battery button while the equipment is turned on. The bargraph
shows remaining charge as a percentile value.
If during measurement the charge of the battery achieves a critical level,
the display will show the BAT message notifying that the charge level is
low. After a few minutes the measurement will be automatically
interrupted in order to preserve the battery from a deep discharge that is
prejudicial for its expected useful life.
6.1. Battery and charger
Battery description
The SOURCETRONIC MPK-204e micro-ohmmeter uses a rechargeable
12 V battery.
Charging procedure:
• Check that the On/Off key is OFF.
• Connect the equipment to the mains supply.
• The Battery charging indicator ( ) will keep on
lightning with a red light up to completing the charge. At that point, it will
change to a green light, being like this up to the equipment
disconnection from the mains supply.

17
At the end of battery useful life, the battery must be recycled or
disposed of properly, in order to protect the environment.
The rechargeable battery does not show the “memory effect” and there are no
restrictions to start charging it as many times as is needed. However the battery
could be damaged if remains in deep discharge for a while.
To avoid this effect, charge the battery before
left the equipment in storage and
don’t let pass more than 30 days without recharge, even if the instrument wasn’t
used (under storage, the battery loses part of its charge).
7. RS232 output
The equipment has an RS232 output in the control panel that can be used
to register measurements in a serial printer or data collector. The outputs
are the following ones:
Pin 2: Rx ; Pin 3: Tx ; Pin 5: Gnd;
Rate: 4800 bps
8 bits - no parity - 1 stop bit (8,n,1)
Note: In order to assure the compatibility with most printers available in
the market, the resistance units are shown with the following symbols:
uR = micro-ohm
mR = milli-ohm
R = ohm

18
8. Replacement fuse 
To check the instrument fuse, remove it with a screwdriver. If the fuse is
ruptured replace it by another with the following specifications:
Fuse Schurter, model SPT 5 x 20 (Time-lag) 8A/250V.
High breaking capacity.
9. Cleaning
Cleaning of this instrument should be carried out using a soft cleaning
liquid, after verifying that it doesn’t affect the plastic parts used in the case
and in the Control Panel of this equipment.

19
10. Technical specifications
Test currents : 1 mA, 10 mA, 100 mA, 1 A, 10 A, 200 A.
Each current may be continuously adjustable from
0 to 100%
Resistance ranges :
Currents Range Resolution
200 A 0-2000 µΩ0,1 µΩ
10 A 0-20 mΩ1 µΩ
1 A 0-200 mΩ10 µΩ
100 mA 0-2000 mΩ100 µΩ
10 mA 0-20 Ω1 mΩ
1 mA 0-200 Ω10 mΩ
Output voltage : Up to 10 Vd.c. @ 1 A (open circuit).
Measurement principle : Four-terminal, Kelvin-type.
Continuous operation time : At 200 A this equipment may be used continuously
for approx. 3 minutes before the thermal protection
activates.
At 10 A or less, there is not a limited time for
continuous operation.
Thermal protection : Protects all sensitive components, avoiding any
damage due to overheating.
Basic accuracy : R < 0.5 mΩ: ± (0.50% of reading + 2 ULSD*)
R ≥0.5 mΩ: ± (0.20% of reading + 2 ULSD*)
* Units of the Least Significant Digit.
Advanced features : Digital direct reading of very low resistances in the
alphanumerical display, with up to 4½ digits. Very
fast and accurate measurements.
Test current measurement : The current is digitally measured and a bargraph
shows the result. The bargraph indication is
specially useful when measuring inductive loads,
so that the operator can verify easily when the test
current has been stabilized.
Serial data output : RS232 @ 4800 bps. Suitable for data collection in
an external serial printer, computer or data-logger.
Environmental protection : IP54 with closed lid.

20
Safety class : Meets the requirements of IEC 61010-1:1990,
IEC 61010-1:1992 amendment 2.
Power supply : Mains or internal battery powered
Battery: rechargeable, 12 V.
Internal battery is useful for up to 10 A.
Mains: 220 - 240 V~ 50 Hz
Mains power is useful for any test current, includ
ing
200 A.
Battery charger : 220 - 240 V~ 50 Hz
Operating temperature
range :
-5°C to 50°C
Storage temperature range : -25°C to 65°C
Humidity range : 95% RH (non condensing)
Equipment weight : Approx. 16 kg.
Dimensions : 502 x 394 x 190 mm
Accessories : 2 Combined current and potential leads for 10 A
(1.8 m).
2 Combined current and potential leads for 200 A
(6 m).
1 Communication cable (RS232).
1 Power cord.
1 User guide.
1 Case for the accessories.
Subject to technical change without notice.

21
11. Warranty
SOURCETRONIC warrants to the original purchaser that each equipment
it manufactures will be free from defects in material and workmanship
under normal use and service. The warranty period is valid for 12 months,
except for the built-in rechargeable battery that has 6 months, and begins
on the date of shipment. The manufacturer's warranty does not apply to
any product or accessories which, in the manufacturer's opinion, has
been misused, altered, neglected, or damaged by accident or abnormal
conditions of operation and handling.
To obtain warranty service, send the equipment, with a description of the
difficult, shipping and insurance prepaid, to SOURCETRONIC. The
manufacturer assumes no risk for damage in transit. SOURCETRONIC
will, at its option, repair or replace the defective equipment free of charge
or refund your purchase price. However, if SOURCETRONIC determines
that the failure was caused by misuse, alteration, accident or abnormal
condition or handling, you will be charged for the repair and the repaired
equipment will be returned to you transportation prepaid.
This warranty is exclusive and is instead of all other warranties, express
or implied, including but not limited to any implied warranty or
merchantability or fitness for a particular purpose or use.
SOURCETRONIC will not be responsible for any special, indirect,
incidental, or consequential damages or loss of data, whether in contract,
or otherwise.

22
Notes
