Southbend KDLS-100 User manual

Job Item#
www.yatesgd.com www.yatesgraphicdesign.com
Direct Steam
tri-Leg KettLe
Printed in USA
Form KDLS Rev 2 (November/2010)
Model CapaCity
KDLS-20 20 Gallon 76 Liter
KDLS-30 30 Gallon 114 Liter
KDLS-40 40 Gallon 152 Liter
KDLS-60 60 Gallon 227 Liter
KDLS-80 80 Gallon 303 Liter
KDLS-100 100 Gallon 379 Liter
SPECIFICATIONS:
Shall be a Southbend Model _________________________,
direct steam connected tri-leg kettle. A double wall kettle interior
shall form a steam jacket around the lower 2/3 of the kettle. The
bottom of the kettle shall be of hemispherical design for superior
heat circulation.
Unit shall be mounted on stainless steel tubular tri-legs. Each
leg shall be tted with a 4 hole, adjustable, anged foot for
securing to the oor.
Construction shall be all welded satin nish stainless steel, type
304. The liner on 20, 30 and 40 gallon models shall be standard
316 for high acid content cooking.
Convenience features shall include 2” (50mm) sanitary draw-off
valve, 20, 30 and 40 gallon models are supplied with a hinged
counterbalanced stainless steel domed cover. The 60, 80 and
100 gallon models are supplied with a spring assist hinged
stainless steel domed cover.
OPERATION SHALL BE BY:
Direct steam at a minimum of 5 PSI (34 kPa) and a maximum of 35
PSI (241 kPa).
OPTIONAL ITEMS AT EXTRA COST:
 Type 316 stainless steel liner for high acid content cooking for
60, 80 and 100 gallon models
 50 PSI (345kPa) high pressure operation for higher cooking
temperature for 20, 30, 40 and 60 gallon models
3” (76 mm) draw-off valve (TVT-3)
2” (50 mm) dairy valve (DDO-2T)
3” (76 mm) dairy valve (DDO-3T)
 Spring assist hinged cover for 20, 30 or 40 gallon models (CH-)
 Etched gallon markings (GM-)
 Etched litre markings (LM-)
 Single pantry faucet with swing spout (SF-18)
 Double pantry faucet with swing spout (DF-18)
 Two piece hinged stainless steel cover (2PHC-)
ACCESSORIES:
 Triple basket assembly (TBA-)
 Steam trap assembly consisting of steam trap, steam control
valve, check valve and line strainer (STA-2)
 Perforated strainer for draw-off valve (TPS-)
 Solid stainless steel disc for draw-off valve (TSS-)
 Strainer hook (SH)
 Graduated measuring strip (CMS-)

1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
[phone] www.southbendnc.com
Models: KDLS-20 KDLS-30 KDLS-40 KDLS-60 KDLS-80 KDLS-100
INTENDED FOR COMMERCIAL USE ONLY.
NOT FOR HOUSEHOLD USE.
Form KDLS Rev 2 (November/2010)
Model CapaCity Units a B C d e F(2”) F(3”) G(2”) G(3”) H J K
KDLS-20 20 gallons
(76 liters)
in
(mm)
21”
(533)
18”
(457)
37”
(940)
22.75”
(578)
16”
(406)
12.75”
(324)
14”
(356)
17”
(432)
16.5”
(419)
25.88”
(657)
59.75”
(1518)
17.5”
(445)
KDLS-30 30 gallons
(114 liters)
in
(mm)
24”
(610)
20”
(508)
37”
(940)
25.88”
(657)
17.5”
(445)
13.5”
(343)
15.25”
(387)
15”
(381)
14.5”
(368)
26.88”
(670)
62.88”
(1597)
20.5”
(521)
KDLS-40 40 gallons
(152 liters)
in
(mm)
26”
(660)
22.5”
(572)
37”
(940)
27.88”
(708)
18.5”
(470)
14.25”
(362)
16.5”
(419)
12.5”
(318)
12”
(305)
23.88”
(606)
64.88”
(1648)
22.5”
(572)
KDLS-60 60 gallons
(227 liters)
in
(mm)
29.5”
(749)
26”
(660)
40.5”
(1029)
31.38”
(822)
17.75”
(451)
15.5”
(394)
17.25”
(438)
12.5”
(318)
12”
(305)
24.69”
(627)
72.88”
(1851)
25.75”
(654)
KDLS-80 80 gallons
(303 liters)
in
(mm)
33”
(838)
28”
(711)
40.5”
(1029)
34.75”
(883)
19.5”
(495)
17.5”
(445)
19.25”
(489)
10.5”
(267)
10”
(254)
23.88”
(606)
75.25”
(1911)
29.25”
(743)
KDLS-100 100 gallons
(379 liters)
in
(mm)
35.5”
(902)
30”
(762)
44.5”
(1130)
37.25”
(946)
20.75”
(527)
17”
(432)
19.25”
(489)
12.5”
(318)
12”
(305)
26.63”
(676)
81.75”
(2076)
31.75”
(806)
SERVICE CONNECTIONS
– STEAM SUPPLY: 3/4” IPS (19 mm)
- CONDENSATE RETURN: 1/2” IPS (13 mm)
DIMENSIONS
