ElEctric StEam
tri-lEg KEttlE
SPECIFICATIONS:
Shall be a Southbend Model_________________________, self-
generating, electric, tri-leg kettle, ASME Code stamped, National Board
Registered, c-CSA-us and NSF certied. A double wall kettle interior
shall form a steam jacket around the lower 2/3 of the kettle. The jacket
enclosure shall contain distilled water which is factory sealed. The
bottom of the kettle shall be of hemispherical design for superior heat
circulation. Kettle will be mounted on 3 stainless steel tubular legs tted
with a 4-hole adjustable foot for securing unit to the oor.
Construction shall be all welded #4 nish stainless steel type 304. The
liner on the 20, 30 and 40 gallon models shall be standard 316 for high
acid content cooking. The controls shall be integrally mounted and shall
include a power switch, thermostat, pilot light, low water light, vacuum/
pressure gauge, safety valve, and low water shut off.
The kettle shall be standard with removable elements. The 20, 30 and
40 gallon models are supplied with a hinged, counter-balanced, stainless
steel, domed cover. The 60, 80 and 100 gallon models are supplied
with a spring-assist, hinged, stainless steel, domed cover. The kettle
shall include a 2” (50 mm) draw-off valve.
The kettle shall operate in a temperature range of 165°F to 285°F (74°C
to 140°C) at a maximum pressure of 50 psi (345kPa).
OPERATION SHALL BE BY:
Electrically, self-generating closed steam system equipped for operation on:
 208 VAC, 1 Phase, 50/60 Hz. (20 and 30 gallon only)
 208 VAC, 3 Phase, 50/60 Hz.
 240 VAC, 1 Phase, 50/60 Hz. (20 and 30 gallon only)
 240 VAC, 3 Phase, 50/60 Hz.
OPTIONAL ITEMS AT EXTRA COST:
 Type 316 stainless steel liner (60, 80 and 100 gallon models)
 3" (76 mm) draw-off valve (TVT-3)
 2" (50 mm) dairy valve (DDO-2T)
 3" (76 mm) dairy valve (DDO-3T)
 24 kw on 40, 60, 80 gallon
 33 kw on 60, 80, 100 gallon
 220 VAC, 1 Phase, 50/60 Hz (20 and 30 gallon only)
 220 VAC, 3 Phase, 50/60 Hz.
 380 VAC, 3 Phase, 50/60 Hz.
 415 VAC, 3 Phase, 50/60 Hz.
 480 VAC, 3 Phase, 50/60 Hz.
 600 VAC, 3 Phase, 50/60 Hz.
 380/220 VAC, 3 Phase, 50/60 Hz. 4 wire
 415/240 VAC, 3 Phase, 50/60 Hz. 4 wire
 Spring assist hinged cover for 20, 30 or 40 gallon models (CH-)
 Two piece hinged stainless steel cover (2PHC-)
 Etched gallon markings (GM-)
 Etched litre markings(LM-)
 Correctional package
ACCESSORIES:
 Single pantry faucet with swing spout (SF-18)
 Double pantry faucet with swing spout (DF-18)
 One piece lift off cover (C-)
 Triple basket assembly (TBA-)
 Perforated strainer for draw-off valve (TPS-)
 Solid stainless steel disc for draw-off valve (TSS-)
 Graduated measuring strip (CMS-)
 Strainer hook (SH)
 Draw-off valve hose kit (DVHK-2)
 Calibrated thermostat dial “F”
 Calibrated thermostat dial “C”
Model kW CapaCity
KELS-20 12 20 Gallon 76 Liter
KELS-30 15 30 Gallon 114 Liter
KELS-40 18 40 Gallon 152 Liter
KELS-60 18 60 Gallon 227 Liter
KELS-80 18 80 Gallon 303 Liter
KELS-100 24 100 Gallon 379 Liter

1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
[phone] www.southbendnc.com
Models:
Form KELS Rev 1 (November/2010)
 KELS-20  KELS-30  KELS-40  KELS-60  KELS-80  KELS-100
INTENDED FOR COMMERCIAL USE ONLY.
NOT FOR HOUSEHOLD USE.
Model CapaCity Units a B C d e F(2”) F(3”) G(2”) G(3”) H J k l
KELS-20 20 gallons
(76 liters)
in
(mm)
21”
(533)
18”
(457)
38”
(965)
23.75”
(629)
18.5”
(470)
14.75”
(375)
15.5”
(394)
18”
(457)
17.5”
(445)
14”
(356)
21”
(533)
60.5”
(1537)
16.75”
(425)
KELS-30 30 gallons
(114 liters)
in
(mm)
24”
(610)
20”
(508)
38”
(965)
27.75”
(705)
20”
(508)
16”
(406)
16.5”
(419)
15.75”
(400)
15.25”
(387)
12.5”
(318)
19”
(483)
63.5”
(1613)
18.31”
(465)
KELS-40 40 gallons
(152 liters)
in
(mm)
26”
(660)
22.5”
(572)
38”
(965)
29.75”
(756)
21”
(533)
17”
(432)
18”
(457)
13.5”
(343)
13”
(330)
9”
(229)
17”
(432)
65”
(1651)
19.94”
(506)
KELS-60 60 gallons
(227 liters)
in
(mm)
29.5”
(749)
26”
(660)
42”
(1067)
33.75”
(857)
19”
(483)
18”
(457)
19.25”
(489)
14”
(356)
13.5”
(343)
11”
(280)
17.25”
(438)
75”
(1905)
23.13”
(587)
KELS-80 80 gallons
(303 liters)
in
(mm)
33”
(838)
28”
(711)
45”
(1143)
36.75”
(933)
20.5”
(521)
19.5”
(495)
20.5”
(521)
15”
(381)
14.5”
(368)
12.75”
(324)
18”
(458)
81”
(2058)
26.25”
(667)
KELS-100 100 gallons
(379 liters)
in
(mm)
35.5”
(902)
30”
(762)
48”
(1219)
40”
(1016)
22”
(559)
21.5”
(546)
22.5”
(572)
15”
(381)
14.5”
(368)
13”
(330)
20.5”
(521)
87”
(2210)
29.44”
(748)
SERVICE CONNECTIONS
– ELECTRICAL CONNECTION : to be specied on data plate
ELECTRICAL CHARACTERISTICS
DIMENSIONS
Model sHippinG WeiGHt MiniMUM ClearanCe
KELS-20 196 lbs. [89 kg]
SIDES
BACK
3” [ 76 mm]
3” [ 76 mm]
KELS-30 226 lbs. [103 kg]
KELS-40 255 lbs. [116 kg]
KELS-60 390 lbs. [177 kg]
KELS-80 445 lbs. [202 kg]
KELS-100 480 lbs. [218 kg]
aMps per line
kW pHase 208V 220V 240V 380V 415V 480V 600V
12 1 57.7 54.5 50.0 N/A N/A N/A N/A
3 33.3 31.5 28.9 18.2 16.7 14.4 11.6
15 1 72.1 68.2 62.5 N/A N/A N/A N/A
3 41.6 39.4 36.1 22.8 20.9 18.0 14.5
18 3 50.0 47.2 43.3 27.3 25.0 21.7 21.7
24 3 66.6 63.0 57.7 36.5 33.4 28.9 23.1
33 3 91.6 86.6 79.4 50.1 45.9 39.7 31.8
aVailaBle kW
Model standard optional
KELS-20 12 N/A
KELS-30 15 N/A
KELS-40 18 24
KELS-60 18 24 or 33
KELS-80 18 24 or 33
KELS-100 24 33
