SOUTHPAW 112000 User manual

Please file this Instruction Sheet in an accessible location: the Instruction Sheet must be read and familiar to
anyone who is using Southpaw Enterprises Equipment. AS THIS PRODUCT IS AN INTEGRAL PART OF
THE SUSPENSION SYSTEM OF YOUR EQUIPMENT, IT IS IMPERATIVE THAT YOU TAKE TIME TO FA-
MILIARIZE YOURSELF WITH THE USE AND MAINTENANCE OF THIS EQUIPMENT BEFORE USING,
AND THAT YOU ADHERE STRICTLY TO THE MAINTENANCE AND INSPECTION PROGRAM.
Instruction Sheet
Heavy Duty Safety Rotational Device 112000
Store these instructions along with the enclosed maintenance checklist in
a safe place. You may also access them on our website.
IMPORTANT: Please check equipment immediately for any damage
that may have resulted during shipping. If any damage has occurred,
please contact Southpaw Enterprises, Inc. immediately.
MATERIALS LIST
1 - Heavy Duty Safety Rotational Device 1 - Maintenance Checklist
1 - Safety Snap - Attached 1 - Safety Snap Instruction Sheet
1 - Instruction Sheet
MINIMUM HEIGHT REQUIREMENTS AND SPACE NEEDED
Minimum Height: All hanging equipment should be hung at 8 ft.
Space Needed: Assure a clear distance of 6 ft. from walls and other obstacles.
WORKING LOAD: 1,000 lbs.
HANGING INSTRUCTIONS
• Clip the Safety Rotational Device to your suspension system with a
Southpaw Safety Snap (# 2000) through the eye bolt on the top of the
Safety Rotational Device. The Southpaw Label should be facing in a
readable position when used in a permanent location. The Safety
Rotational Device must be hung in this manner to prevent dust, dirt,
and debris from entering the bearing area.
• Hang your suspended equipment from the Safety Snap attached to the
Safety Rotational Device.
• When using equipment with a Southpaw Safety Rotational Device
permanently attached, such as the Southpaw Bolster or Twirler, use the
Rotational Device as attached.
MAINTENANCE CHECKLIST
All of the following wear points should be checked on a monthly basis and recorded on the checklist enclosed. If re-
placement is necessary, contact Southpaw for replacement immediately.
• Remove the Rotational Device from the equipment and/or eyebolts. Remove the Southpaw Safety Snap from the
Rotational Device.
• You may use an aerosol dust remover or very clean compressed air to blow out any dust from inside the rotational
housing.
• Visually inspect the "eye" of the eyebolt. If the "eye" has a worn through 30% of the thickness of the steel, discon-
tinue use and replace.
• Visually inspect the round "pin" which goes through the housing of the rotational on the side opposite from the
"eye". If it is bent at all, discontinue use and replace. Note: This pin is made of hardened steel, and it is unlikely
that it will be worn. If it is worn, it will bend before it breaks. So a bent "pin" is worn.
• Grasp the "eye" of the Rotational Device in one hand, and the housing in the other. Pull them as if trying to sepa-
rate them and, while pulling, twist them in opposite directions a few times. The sensation you feel should be one of
smooth spinning. This indicates that the bearing is intact. If you feel any grittiness or grinding, then the bearing
may be compromised and the Rotational Device should be replaced.
Warning: Failure to properly install a forged
steel eyebolt (1/2” or 5/8”) may result in serious
injury or death. If you have any questions
about the installation of the forged steel
eyebolt, please contact Southpaw Enterprises
Customer Service at 1-800-228-1698.
Suspension Point
Safety Snap
Rotational Body
Safety Snap

Safety Precautions - The safety of your clients is dependent on the appropriate choice of activity to match, yet challenge their
physical abilities. Use appropriate spotting / safety techniques. In addition, the layout of your activity area, proper installation and
maintenance of your equipment is critical. Southpaw equipment is not intended for recreational or outdoor use. Under no condition
should this equipment be used without proper supervision.
This sheet is for example only. It is not meant to, in any way, replace local, county, state, or Federal standards. Be aware - it is
your responsibility to find all pertinent safety information that pertains to your facility.
If you have any questions or comments, please call or write
Southpaw Enterprises, Inc.
P.O. Box 1047, Dayton, Ohio 45401-1047
Toll Free - [phone]
Please visit us at www.southpaw.com
© 2020 Southpaw Enterprises, Inc.
 Check ceiling eye bolt for wear and movement. Use a Southpaw Safety Rotational Device to prevent
abnormal wear.
 Floor mats of proper thickness should be positioned properly under and around all suspended
equipment.
CAUTION
• Hold the Rotational Device by the "eye", or hang it from an eyebolt. Spin the rotational quickly. It should spin freely.
If it spins, but then abruptly stops, then there is a contaminant in the bearing mechanism and the Rotational Device
should be replaced.
• You may find that a dry bearing can squeak when turned in this fashion.. If that happens, spray a small amount of a
very light lubricant (WD-40 or a silicone spray lubricant will work fine) into the housing . Try to spray as deep down
as you can, so that the lubricant goes all the way to the bearing. Spin the Rotational Device a few time to work the
lubricant in. Now try the "Twist" test again. If the bearing feels smooth when turning and pulling, the bearing is in-
tact.
• A monthly application of a light lubricant as described above will help extend the useful life of the Rotational Device,
but is not necessary for it to function properly.
STORAGE PROCEDURES
• All suspended equipment - Store out of direct sunlight.
• Store where not accessible by clients without proper supervision.
• Must be stored away from all moisture (basements etc.).
CLEANING INSTRUCTIONS
Check with your infectious disease department before using these procedures.
• Do not wash. Can be cleaned with an air hose to blow dust out of body.
• Do not immerse in water.
