Space-Ray WIND BLOCKER WB35-N7 User manual

Form 44201450
Oct 2018
INSTALLATION AND OPERATION INSTRUCTIONS
INFRARED RADIANT PATIO HEATER
WIND BLOCKER™
Models:WB35-N7and L7
Two Stage (or Single stage)
UNVENTED - (For all Outdoor applications
and Indoor Non-Residential Spaces)
FOR YOUR SAFETY:
If this
heater
is installed indoors, it
must be in a sufficiently ventilated space. E
xhaust fans
MUST be operating on an appropriate cycle when heaters are operating to avoid a high concentration of carbon
monoxide. When installed in insufficient ventilated spaces this heatermay give off carbon monoxide, an odorless
and poisonous gas. CARBON MONOXIDE POISONING MAY LEAD TO DEATH. Early signs of carbon monoxide
poisoning resemble the flue with headaches,dizziness and nausea. If you experience these signs, GET FRESH AIR
IMMEDIATELY! Have the heaters serviced as soon as possible and check the ventilation into the building.
!IMPORTANT: SAVE THIS MANUAL FOR FUTURE REFERENCE.
SPACE-RAY
Post Office Box 36485 (28236) 305 Doggett Street (28203) Charlotte, North Carolina
Phone [phone] Fax [phone] www.spaceray.com email: [e-mail]
OWNER /INSTALLER: For your safety this manual must be carefully and thoroughly read and understood before
installing, operating or servicing this heater. This heater is intended for use with either Natural Gas or Propane
Gas. It must be installed by a qualified service person or a licensed contractor in accordance with state and local
codes.
:Improper installation, adjustment, alteration, service, or maintenance can cause property
damage, injury or death. Read the installation, operation and maintenance instructions thoroughly before
installing or servicing this heater. For assistance or additional information, consult a qualified installer, service
agency or the gas supplier.
For Indoor Installations INSPECT all combustion air openings into the building and, if necessary, clear if they
become blocked.
INSTALLER:
This manual is the property of the owner. Please present this manual to the owner when you leave
the job site.
IF YOU SMELL GAS: DANGER
1.
Shut off gas to the
appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier.
DO NOT store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
An LP-cylinder not connected for use shall not
be stored in the vicinity of this or any other
appliance.

Form 44201450 1
Oct 2018
Table of Contents
1.0) SAFETY...................................................................................................................................................................2
2.0) INSTALLER RESPONSIBILITY....................................................................................................................................2
3.0) GENERAL INFORMATION .......................................................................................................................................2
4.0) MINIMUM CLEARANCES TO COMBUSTIBLES..........................................................................................................4
INDOOR clearances to combustibles...................................................................................................................7
OUTDOOR clearances to combustibles................................................................................................................8
5.0) SPECIFICATIONS.....................................................................................................................................................9
6.0) PACKING LIST.........................................................................................................................................................9
7.0) HEATER SIZING GUIDELINES.................................................................................................................................10
8.0) TYPICAL HEATER LAYOUTS...................................................................................................................................10
9.0) DIMENSIONS........................................................................................................................................................11
10.0) ACCESSORIES.......................................................................................................................................................12
11.0) UNPACKING THE HEATER.....................................................................................................................................13
12.0) INSTALLATION .....................................................................................................................................................14
HEATERMOUNTING ANGLE.............................................................................................................................15
INDOOR INSTALLATION – HANGING METHODS.................................................................................................16
INDOOR / OUTDOOR RIGID HANGING BRACKETS..............................................................................................16
13.0) HEAT SHIELD INSTALLATION................................................................................................................................19
14.0) ASSEMBLY OF THE CERAMIC GLASS.....................................................................................................................22
15.0) GAS CONNECTIONS AND REGULATION................................................................................................................23
INSTRUCTIONS FOR PRESSURE TESTGAUGE CONNECTION.............................................................................25
INLET GASPRESSURE CHECK.............................................................................................................................25
OUTLETGASPRESSURE CHECK AND ADJUSTMENTS..........................................................................................25
16.0) ELECTRICAL CONNECTIONS..................................................................................................................................26
INTERNAL CONNECTION WIRING DIAGRAM .....................................................................................................27
FIELD CONNECTIONS AND WIRING DIAGRAMS – 2STAGE.................................................................................27
FIELD CONNECTIONS AND WIRING DIAGRAMS – SINGLE STAGE 24V.................................................................29
FIELD CONNECTIONS AND WIRING DIAGRAMS – SINGLE STAGE 120V...............................................................30
17.0) VENTILATION.......................................................................................................................................................31
18.0) LIGHTING AND SHUTDOWN INSTRUCTIONS ........................................................................................................31
SEQUENCE OF OPERATION...............................................................................................................................32
19.0) SERVICING AND ANNUAL MAINTENANCE............................................................................................................33
20.0) TROUBLE SHOOTING............................................................................................................................................34
21.0) REPLACING PARTS................................................................................................................................................36
REMOVAL OFGLASS PANEL..............................................................................................................................36
REMOVAL OFSPARKELECTRODE/FLAME SENSOR.............................................................................................37
REMOVAL OF MAIN BURNER ORIFICE (injector)................................................................................................37
REMOVAL OFGASVALVE.................................................................................................................................38
REMOVAL OF IGNITION CONTROL MODULE AND TRANSFORMER.....................................................................39
REMOVAL OFMAIN BURNER/EMITTERASSEMBLY............................................................................................39
22.0) INSTALLATION DATA............................................................................................................................................40
23.0) Replacement parts guide.....................................................................................................................................41
California Proposition 65: This product can expose you to chemicals including
ceramic fibers, which are known to the State of California to cause cancer, and
carbon monoxide, which is known tothe Stateof California to cause birth defects or
other reproductive harm. For more information go to www.p65warnings.ca.gov

Form 44201450 2
Oct 2018
SAFETY
This heater is a self-contained infrared radiant ceramic heater. Safety information required during installation and
operation of this heater is provided in this manual and the labels on the product. The installation, service and
maintenance of this heater must be performed by a contractor qualified in the installation and service of gas fired
heating equipment.
All personnelincontact withthe heater must read and understand all safety information, instructions and labelsbefore
operation. The following symbols will be used in this manual to indicate important safety information.
Warning
instructions must be followed to prevent or avoid hazards which
may cause serious injury, property damage or death.
Caution
instructions must be followed to prevent incorrect operation or
installationoftheheaterwhichmaycauseminorinjuryorproperty damage.
INSTALLER RESPONSIBILITY
The installer is responsible for the following:
The heater installation, electrical and gas supplies must be installed in accordance with these installation
instructions and any applicable codes and regulations.
Every heater shall be located with respect to building construction and other equipment so as to permit access to
the heater.
Each installer must follow the clearances to combustible materials for the heaters.
It isimportanttoreadandunderstandsection4.0)whereoutdoorspacesaredefinedanyspaceother than outdoors
is an indoor installation.
Install the heater so that the supportsand hangers are correctly spaced in accordance with these instructions. The
heater must be supported by materials having a workingload limit of at least 115 lbs.
To install theheater inan adequate freearea to allowtheproducts ofcombustion to freely escape from the heater.
The heater must not be installed in recessed spaces or enclosure and alcoves.
Supply the owner with a copy of these Installation and Operation Instructions.
If the heater is installed indoors, ventilation by gravity or mechanical means shall be provided to supply at least 4
CFM of exhaust air per 1,000 Btu/hr of operating heat input.
Never use the heater as a support for a ladder or other access equipment. Do not hang anything from the heater.
Supply all installation materials necessary that are not included with the heater.
Check the nameplate to make sure that the burner is correct for the gas type in the building.
Use theprovided anglegauge (seeSection12.1) toensure the heateris installedat theapproved installation angles
of 00, 150, 300, 450and 600degrees with the heat shield installed.
GENERAL INFORMATION
This heater is a self-contained infrared radiant ceramic patio heater for use in locations where flammable gases or
vapors are not generallypresent and is intended for space heating non-residential spaces.
This patio heater model is approved to two different heater standards:
A “Patio Heater” for Outdoor Use in Residential and Commercial/Industrial Applications.
And as a “Gas-Fired High Intensity Infrared Heater” for Indoor Spaces of Commercial/ Industrial Applications.
Not for use in residential dwellings.
Note: A residential dwelling is a domicile intended for use by one or more persons and that
includes one or more areas, such as those used for cooking, eating, living, sleeping, or a sanitary
facility. A residential dwelling does not include a workshop, or outdoors.

Form 44201450 3
Oct 2018
SAFETY REQUIREMENTS
The heater area must be kept clear and free from combustible materials, gasoline and other flammable vapors
and liquids.
This heater is designed for use with one type of gas (LPG or Natural). Make sure that the type of gas to be supplied
to this heater matches that shown on the heater rating plate.
DO NOT install this heater directly onto an LPG container or propane cylinder. LPG containers (propane cylinders)
must not be stored indoors or in the vicinity of any gas-burning appliance.
DO NOT Store flammable materials near the heater.
DO NOT locate gas and electric supply lines directly above the heaters path of flue products. The path of flue
products will change if an optional lowclearance heat shield is installed.
Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid
burns or clothing ignition.
Young Children should be carefully supervised when they are in the area of the heater.
DO NOT spray aerosols or flammablematerials in the vicinity of this appliance while it is in operation.
Clothing or other flammable materials should not be hung from the heater or placed on or near the heater.
NEVER attempt to servicethe heater while it is plugged in, operating or hot.
Any guard or other protective device removed for servicing a heater must be replaced prior to operating the heater.
DO NOT Install the heater in a recess, alcove or enclosure.
Installation and repair should be done by a licensed contractor qualified in the installation and service of gas
heating equipment. The heater should be inspected before use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary. It is imperative that the control compartment, air
passageways andburner of the heater be kept clean.
If any changes are made to the patio or building structure after the heaters are installed such as adding plastic
curtains to enclose the patio the modified design must be checked by a qualified person to ensure that the
clearance combustibles and ventilation requirements are maintained.
DO NOT paint any surface of the heater.
DO NOT throw objects at the heater.
Avoid inhaling fumes emitted from the heater’s first use. Smoke and odor from the burning of oils used in
manufacturing will appear. Both the smoke and odor will dissipate after approximately 30 minutes.
INSTALLATION REQUIREMENTS
Installation of this heater must conform with local building codes or, in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1 In Canada, the
installation must conform to current CSA B149.1 (The Natural Gas and Propane Installation Code) in the absence of
local codes. Heaters shall be installed by a licensed contractor or licensed installer. Clearances to combustibles as
outlined in this manual should always be observed. In areas used for storage of combustible materials where they may
be stacked below the heater, NFPA54 requires that the installer must post signs that will “specify the maximum
permissible stacking height to maintain the required clearances from the heater to combustibles.”
Every heater shall be located with respect to building construction and other equipment so as to permit access to the
heater. Each installer shall use quality installation practices when locating the heater and must give consideration to
clearances to combustible materials, vehicles parked below, lights, overhead doors, storage areas with stacked
materials, sprinklerheads, gas and electrical lines, and any other possible obstructions or hazards. Considerationalso
must be given to service accessibility.
Space-Ray will not recognize the warranty for any use other than space heating.

Form 44201450 4
Oct 2018
This heater is for Indoor and Outdoor Installation and is used in Unvented mode. The term Unvented actually means
Indirect Vented. While the products of combustion are expelled into the building, national codes require 4 CFM/1000
BTU of heater input ventilation in the building to dilute these products of combustion. This ventilation may be provided
by gravity or mechanical means.
This heater is not an explosion proof heater. Where the possibility of exposure to volatile and low flash point materials
exists, it could result in property damage or death. This heater must not be installed in a spray booth where the heater
can operate during the spraying process. Consult your local fire marshal or insurance company.
This heater must be applied and operated under the general concepts of reasonable use and installed using best
building practices.
It is the responsibility of the qualified installer to supply the appropriate lifting equipment to safely install the radiant
heater. Tools required for the safe installation, startup and maintenance are various screwdrivers, wrenches, pipe
wrenches, voltmeter, air and gas manometer, level and required tools to safely install the chosen hanging materials.
Do not installthis heater indoors in a structure with no insulation inthe roof—condensation will occur.
The heater, when installed in aircraft hangars and public garages, must be installed in accordance with ANSI/NFPA
409-latest edition (Standard for Aircraft Hangars), ANSI/NFPA 88a-latest edition (Standard for Parking Structures), and
ANSI/NFPA 88b-latest edition (Standard for Repair Garages) with the following clearances:
a. At least 10 feet above the upper surfaces of wings or engine enclosures of the highest aircraftthat maybe housed
in the hangar and at least 8 feet above the floor in shops, offices, and other sections of hangars communicating
with aircraft storage or service areas.
b. At least 8 feet above the floor in public garages. ▲WARNING: Minimum clearances marked on the heater must be
maintained from vehicles parked below the heater.
(FOR CANADA ONLY)
a.
Installation of this appliance is to be in accordance with latest edition of
CSA
B149.1 (
Natural Gas and Propane
Installation Code).
b. For installation in public garages or aircraft hangars, the minimum clearances from the bottom of the infrared
heater to the upper surface of the highest aircraft or vehicle shall be 50 percent greater than the certified
minimum clearance, but the clearance shall not be less than 8 feet.
MINIMUM CLEARANCES TO COMBUSTIBLES
A critical safety factor to consider before installation is the clearances to combustible materials. Clearance to
combustibles is defined as the minimum distance you must have between the surfaces of the heater and the
combustible item. Considerations must also be made formoving objects around the infrared heater.
This heater must not be installed where the products of combustion can build up and prevent them
being exhausted to the atmosphere. This includes applications such as; enclosures, recessed ceilings and alcoves.
This heater can be equipped with a heat shield to reduce the clearances to combustibles towards
the ceiling. Due to the variety of possible heater mounting angles the heat shield must be mounted in the correct
location to match the heater mounting angle. See section 13.0 heat shield installation.
Approved installation angles are 0, 15, 30, 45 and 60 degrees with the heat shield installed.

Form 44201450 5
Oct 2018
Certain materials or objects, when stored under the heater, will be subjected to radiant heat and
could be seriously damaged. Observe the Minimum Clearances to Combustibles listed in the manual and on the heater
at all times.
For maximum safety the building must be evaluated for hazards before installingthe heater system.
Examples include, but are not limited to:
Gas and electrical lines
Combustible and explosive materials
Chemical storage areas
Areas of high chemical fume concentrations
Provisions for accessibility to the heater
Adequate clearances around the openings
Combustion and ventilating air supply
Vehicles parking areas
Vehicles with lifts or cranes
Storage areas with stacked materials
Lights
Sprinkler heads
Overhead doors and tracks
Dirty, contaminated environment
This heater is approved for both INDOOR and OUTDOOR installation. Both installation options have different clearances
to combustibles as described below. Thesemust be observed.
INDOOR clearances to combustibles are defined as a surface temperature of 90°F above ambient temperature.
OUTDOOR clearances to combustibles are defined as a surface temperature of 117°F above ambient temperature.
OUTDOOR Spaces are defined as a shelter no more inclusive than:
a) with walls on all sides,but with no overhead cover.
b) within a partial enclosure which includes an overhead cover and no more than two side walls. These side
walls may be parallel, as in a breezeway, or at right angles to each other.
c) Within a partial enclosure which includes an overhead cover and three side walls, as long as 30 percent or
more of the horizontal periphery of the enclosure is permanently open.
For the purposes of clearances to combustibles and ventilation all applications not classified as
outdoors according to the definitions above shall comply with the requirements for indoor installations.
Minimum clearances shall be measured from the outer surfaces of the heater or heat shield if installed, as shown in
the diagrams for the different installation positions.
Fire sprinkler heads must be located at an appropriate distance from the heater. This distance may
exceed the published clearance to combustibles. Certainapplications will require theuse of high temperature sprinkler
heads or relocation of the heaters.
Sprinkler systems containing propylene glycol or other flammable substances are not to be used in conjunction with
thisheaterwithoutcarefulconsiderationforandavoidanceofpotentialfireorexplosionhazards.Forfurtherinformation
consult the authority having jurisdiction. Always observe applicable state and local codes.
Always maintain minimum clearances and post signs where needed. This heater is supplied with a
wall mounted sign shown below. It is the installers responsibility to ensure that the sign is completed with the correct
clearance to combustible distances for the installation and that the sign is posted in a location where it is easily
accessed.

Form 44201450 6
Oct 2018
Clearances to combustibles are posted on the heater. In areas used for storage of combustible
materials where they may be stacked below the heater the installer must post signs that will “specify the maximum
permissible stacking height to maintain the required clearances from the heater to combustibles.” Space-Ray
recommends posting these signs adjacent to the heater thermostat or other suitable location that will provide
enhanced visibility.

Form 44201450 7
Oct 2018
INDOOR CLEARANCES TO COMBUSTIBLES
The stated clearance to combustibles represents a surface temperature of 90º F (50º C) above
room temperature. Building materials with a low heat tolerance (such as plastics, vinyl siding, canvas, tri-ply, etc.)
may be subject to degradation at lower temperatures. It is the installer’s responsibility to assure that adjacent
materials are protected from degradation.
See below the possible surface temperature at the clearance to combustible distance for different ambient
temperatures within the heated space.
Ambient
Temperature
7
0°F (
21.1
°C)
65
°F (
18.3
°C)
60°F (15.5°C)
Surface Temperature
1
6
0°F (
71.1
°C)
15
5
°F (
68.3
°C)
150°F (6
5
.6
°C)

Form 44201450 8
Oct 2018
OUTDOOR CLEARANCES TO COMBUSTIBLES
The stated clearance to combustibles represents a surface temperature of 117º F (65º C) above
room temperature. Building materials with a low heat tolerance (such as plastics, vinyl siding, canvas, tri-ply, etc.)
may be subject to degradation at lower temperatures. It is the installer’s responsibility to assure that adjacent
materials are protected from degradation.
See below the possible surface temperature at the clearance to combustible distance for different ambient
temperatures within the heated space.
Ambient
Temperature
7
0°F (
21.1
°C)
65
°F (
18.3
°C)
60°F (15.5°C)
Surface Temperature
1
87
°F (
86.1
°C)
1
82
°F (
83.3
°C)
1
77
°F (
80.6
°C)

Form 44201450 9
Oct 2018
SPECIFICATIONS
Model No.
Btu/hr
High
Input
(2
-
stage)
Btu/hr
Low
Input
Orifice Size
Recommended*
Mounting Height
Natural Gas Propane Gas @ 0 º
@
5
º
to 30 º
@
30
º
to 60 º
WB
35
-
N7
35
,000
24,000
#41
0.
096
inch #51
0.0
67
inch 8 to 11 ft 7 to 9 ft 6 to 8 ft
WB
35
-
L7
35
,000
24,000
* For mounting heights outside the recommended distances consult your local Space-Ray Representative.
Model Identification:
Control Option Suffix
Gas Type
Description
N7
Natural
Two Stage White
-
Rodgers 36J
Gas Valve
–
High/Low Fire
L7
Propane
Two Stage
White
-
Rodgers 36J
Gas Valve
–
High/Low Fire
Two stage heaters are supplied with a jumper to enable single stage (high fire only) operation. See electrical section
16.0 for instructions.
Type
Gas
Gas Pipe
Connection
Electrical
Supply
Current
Rating Weight
Natural
or Propane ½” NPT (Male) 120 Volt,
60Hz,
1 Phase 0.1 Amp 55 lbs
Module Electrical Rating: Ignition System (direct spark):
Input
-
Control: 18
-
30 VAC 50/60 Hz (class 2 transformer)
Input Power-Line: 120 VAC (L1, IND contacts only)
Flame Sensitivity: 0.7 µA (microamps) minimum
10
second trial for ignition period
7 second pre-purge period
15 second inter-purge period
3 tries for ignition
separate flame sensor
potted, 100% water protected
Approved installation angles are 0, 15, 30, 45 and 60 degrees with heat shield installed.
PACKING LIST
Package contents are listed below:
Model
Part Number
Gas Type
WB
35
-
N7
44575220
Natural
WB
35
-
L7
44575230
Propane
Number
Part Number
Description
Qty Per
1
See Above
Patio Heater
1
2
41373050
Ceramic Glass 4mm Black
1
3
43344990
Space
-
Ray Clearances sign
1
4
44568039
Angle Mounting Gauge Plate
1

Form 44201450 10
Oct 2018
HEATER SIZING GUIDELINES
Radiant heaters work like the sun to emit radiant heat directly to the space to increase the comfort of the patio
guests. Suitable applications include patios, porches, outdoor shopping areas and pathways.
The amount of temperature increase in outdoor patio spaces will be dependent on the following factors:
1. The number of heaters in the space is important to provide good coverage of the area to be heated.
2. Take care not tomount the heaters too low or too closetogether this can makepeopledirectly below the heaters
uncomfortable.
3. It is recommended to use a suitable windbreak to reduce the effects of direct wind on the patio. If an area is
going to be unprotected and is a breezy location then heaters may needto located closer together. Wind breaks
must be designed to allow fresh air for ventilation.
4. Angling the heaters greater than 30 degrees should be avoided unless the mounting height is low, when the
heaters are angled more than 30 degrees the radiant intensity is lower and will reduce the amount of heat felt
by the guests.
5. It is recommended to place the heaters in the area of greatest heat loss facing into the patio area.
The table below shows minimum area coverage per heater for outdoor patio heating based on a 5 to 10°F (2.8 to
5.6°C) temperature rise.
Mounting Angle
Mounting Height
Breezy
Exposed
Location
Moderately
Protected
Well
Protected
Horizontal
8ft.
–
1
1
ft.
(2.5 – 3.0m)
8
x
8
ft
(2.5 x 2.5m)
10
x
10
ft.
(3.0 x 3.0m)
1
2
x 1
2
ft.
(3.7 x 3.7m)
Up to 30 Degrees Angled
7
ft.
–
9ft.
(2.1 – 2.7m)
8
x
8
ft
(2.5 x 2.5m)
9
x
9
ft.
(2.7 x 2.7m)
1
1
x 1
1
ft.
(3.3 x 3.3m)
30 to 60 Degrees Angled
6
ft.
–
8
ft.
(1.8 – 2.5m)
Not Recommended
8
x
8
ft.
(2.5 x 2.5m)
Note: When sizing the number of heaters to warm the patio, the area coverage given above may not provide the
stated temperature rise under all weather conditions and will be dependent on heater placement. Minimums are
shown as a guideline for human comfort. For moreassistance with patio heater sizing and layout please contact your
local Space-Ray representative.
TYPICAL HEATER LAYOUTS
The diagram below shows the recommended spacing layout between heaters.
Dimension
Horizontal
15 to 30 degree
angle
Above 30 degree angle
M
i
n
.
Max
.
Min
.
Max
.
Min
.
Max
.
A. Mounting Height
8ft (2.5m)
11ft (3.4m)
7ft (2.1m)
9ft (2.7m)
6ft (1.8m)
8ft (2.5m)
B. Distance to the end of
the patio
0ft (0m)
6ft (1.8m)
0ft (0m)
6ft (1.8m)
0ft (0m)
6ft (1.8m)
C.
Distance between
heaters.
8ft (2.5m)
12ft (3.7m)
7ft (2.1m)
11ft (3.4m)
6ft (1.8m)
10ft (3.0m)
D. Distance between
heaters*
8ft (2.5m)
16ft (4.9m)
8ft (2.5m)
18ft (5.5m)
8ft (2.5m)
16ft (4.9m)
*Note the distance D for angled heaters applies when they are facing towards each other.

Form 44201450 11
Oct 2018
Note: Local codesmay have specialrequirements regardinghead clearance requirements. Some local codes require
all portions of overhead radiant heatersto be located at least 8 feet above the floor.
Below are examples of patio heating applications.
DIMENSIONS

Form 44201450 12
Oct 2018
ACCESSORIES
Below are the optional accessories available for the Wind Blocker Patio heater.
PN
Description
P
i
cture
44560350
Wall / Ceiling TelescopicMounting
Bracket Kit- 15"-22" overhead
space (check clearances to
combustibles space above the
heater before ordering)
44560351
Ceiling Telescopic Mounting
Bracket Kit- 22"-30" overhead
space (check clearances to
combustibles space above the
heater before ordering)
44560352
Wall / Ceiling
TelescopicMounting
Bracket Kit- 15"-30" overhead
space (check clearances to
combustibles space above the
heater before ordering) includes
both the 15-22” and 22-30”
extension legs.
44560353
Ceiling Mount Bracket Kit
-
10"
fixed installation for minimum
overhead clearance. This bracket
is only for horizontal mounting
with the heat shield
4456630
0
Heat Shield Kit
–
Reduced
clearances to combustible option
when installed. Mounting angles
are restricted to 0, 15, 30, 45 and
60°.

Form 44201450 13
Oct 2018
PN
Description
P
i
cture
44560590
Column Mounting Arm Kit
–
suitable for columns 8” and wider.
44560600
3 " Pole Mounting
Bracket
Kit
44560609
4" Pole Mounting Bracket Kit
41690120
Chain Kit, 12 ft. chain w/ 8 hooks
30302241
Gas Connector
-
Black Powder
Coated Paint to match the heater.
1/2"OD -24" Long with 1/2MIP X
1/2 FIP Connection
44604500
Gas Connection Kit
-
1/2"
-
Includes
Gas Connector, Manual Ball Valve,
Sediment Trap (Tee, Cap, Nipple),
Thread Sealing Compound
03307260
Gas regulator 2psig to 11” w.c.
½”
NPT inlet and outlet.
40147010
3 Position Switch Kit,
(High/Low/Off) for manual heater
control (N7/L7)
44195000
Two Stage Relay Kit (one per
heater required) for controlling
multiple heaters w/a single 24V
Two Stage thermostat
UNPACKING THE HEATER
The heaterand ceramic glass are shipped separatebut inthe same box. Caremustbe taken when
up-packing the heater. Carefully open the top of the heater as indicated on the labels at the side of the shipping box.
An angle gauge is attached to the heater’s control side with tape and is needed for installation (see Section 12.1).
The glass is located on top of the heater and is wrapped in cardboard cradled into the foam end pieces. Carefully
remove the top foam pieces and remove the cardboard wrapped glass. Care must be takenthat during handling the
glass does not slide out of the cardboard wrap. Store the glass in a secure location for later assembly.

Form 44201450 14
Oct 2018
It is recommended that two people lift the heater out of the carton. Do not remove from the
remaining packaging until the heater is ready to be hung.
INSTALLATION
In order to protect the ceramic glass it is recommended to only insert the ceramic glass once all the other installation
steps have been completed. The ceramic glass must be removed to wire the heater and for commissioning.
Various means of suspending the heater can be used. See the following drawings for typical examples.
a) Heaters installed outdoors or in areas subject to strong winds must be installed using the optional hanging
brackets or suitable rigid mount hardware. Chain, cable and other flexible hanging methods are not
recommended.
b) Use only noncombustible materials for suspending hangers and brackets.
c) Turnbuckles can be used with chains to allow leveling of the heater. All “S” hooks and eye bolts must be
manually crimped closed by the installer.
d) Heaters must not be supported by gas or electric supply lines and must be suspended from a permanent
structure with adequate load capacity.

Form 44201450 15
Oct 2018
e) Hanging points are a fixed length between centers. Secondary steel work may be required to span between
supporting beams.
f) The appliance should be located with respect tobuildingconstructionand other equipment to permit access
to the appliance for servicing etc.
f) The heater must be installed in an adequate free area to allow the products of combustion to freely escape
from the heater. The heater must not be installed in recessed spaces or enclosure and alcoves.
g) The heater must be suspended with its longitudinal axis horizontal, but may have its lateral axis at anangle
from 00to 600from the horizontal, as shown in the minimum clearances to combustibles section 4.0).
h) An optional heat shield may be installed to reduce the top distance of clearance to combustibles. This heat
shield should be installed prior to hanging the heater. When using the heat shield at the minimum clearance
distance the angles of installation are restricted to 0, 15, 30, 45 and 60°.
i) Use the provided angle gauge to ensure that the heater is hung at the approved installation angles.
j) The heater can be angle mounted on both sides of its lateral axis.
k) Hanging brackets should first be fixed to the wall surface by means of 4 lag bolts – not supplied (3/8” x 1-
1/2” minimum) through pre-formed holes in each of the brackets prior to installing heater.
HEATER MOUNTING ANGLE
Every heater is supplied with an angle gauge. The gauge is attached with tape to the heater control side.
The angle gauge is used in combination with a level to ensure that the heater is installed at one of the mounting
angles of 00, 150, 300, 450and 600.

Form 44201450 16
Oct 2018
Hold the side of the angle gauge without label flush against the glass surface. Hold a level against the other side of
the angle gauge and find the desired installation angle of the heater. Verify that the level is vertical, adjust heater
angle if needed.
Note: If a heat shield is installed its location must match the heaters angle (see Section 21.0).
This process must be repeated for both ends of the heater.
INDOOR INSTALLATION – HANGING METHODS
When the heater is used for an Indoor Installation then the following hanging methods may be used.
The heater can be hung from the ceiling, secondary steel work, etc. using chains, threaded rods and other approved
hanging materials. All hanging materials must have a minimum working load of 115 lbs. Any “S” hooks must be
crimped closed after installation.
Note:
When hanging the heater hanging materials which allow the heater to move the gas connection must be
established using an approved flexible gas hose of a minimum of 24” length.
Diagram below shows Horizontal mounting with chain.
Diagram below shows the possible chain methods to hang at different angles.
Notes: When suspending at 25 degrees if the heat shield is installed use the 30-degree location for the heat shield.
INDOOR / OUTDOOR RIGID HANGING BRACKETS
Fixed hanging methods which prevent the heater from swaying must be used for outdoor installations.
Below are the bracket kits which can be used for ceiling and wall mount for patio heaters installed indoors and
outdoors, with and without heat shields. The brackets provide for a range of lengths and approved mounting angles
of 150, 300, 450and 600.
44560350 KIT, BRACKET - WALL/CEILING 15"-22" CEILING - FOR USE WITH HEAT SHIELD (telescoping)
44560351 KIT, BRACKET - CEILING 22"-30" - FOR USE WITHOUT HEAT SHIELD (telescoping)
44560353 KIT, BRACKET - CEILING 10" – FIXED (for outdoor only horizontal ceilingmount with heat shield)

Form 44201450 17
Oct 2018
The hanging bracketsare supplied as an optional accessory item. Below are the kit contents.
Item No. Part No. Description
44560350
Quantity
44560351
Quantity
44560353
Quantity
1 02140040 HHCS,1/4-20 x 1/2" SS 6 6 4
2 02129100 WASHER, FLAT 1/4"N SS 6 6 4
3 02167019 LOCKNUT, 1/4-20 KEPS - SS 6 6 4
4
4456025
9
HANGER BRACKET
–
RECEIVER
2
2
5
4456026
9
SLIDER ARM
–
LH
1
6
4456027
9
SLIDER ARM
–
RH
1
7
44560289
SLIDER ARM
–
LH
1
8
44560299
SLIDER ARM
–
RH
1
9
44560809
FIXED ARM
2
The tables below can be used to select the correct bracket to ensure that the heater is installed at the correct
clearance to combustible distance from the ceiling depending on whether the heater is installed indoors or outdoors,
the mounting angle and whether a heat shield is installed.
15
-
22” Bracket (With heat shield)
telescope hole positions*
22
-
30” Bracket (Without heat shield)
telescope hole positions*
Mounting Angle
INDOOR
OUTDOOR
INDOOR
OUTDOOR
0
1 to 5
1 to 5
3 to 5
1 to 5
15 and 30
2 to 5
1 to 5
3 to 5
1 to 5
45 and 60
4 or 5
2 to 5
4 or 5
2 to 5
* The above table relates to the holes positions as shown in the figure below for the two different length adjustable
brackets.

Form 44201450 18
Oct 2018
12.3.1) HANGING BRACKETS ASSEMBLY
A left-hand LH and right-hand RH bracket must be assembled. Torque screws and locknuts to 5 lbf⋅ft.
To mount the hangingbrackets to the wall/ceiling:
1. Measure and mark distances for the hanger bracket holes.
2. Hanging brackets should first be fixed to the wall or ceiling surface by means of 4 lag bolts – (not supplied)
(3/8” x 1-1/2” minimum) through pre-formed holes in each of the brackets prior to installing heater. All
hanging materials must have a minimum working load of 115lbs
12.3.2) HEATER ATTACHMENT TO HANGING BRACKETS
The heater can be attached to the hanging brackets in angles of 150, 300, 450and 600. Choose the desired heater
mounting angle and find the corresponding hole patternas per the wall and ceiling mount figures below.
Attach the heater to the brackets using (2) cap screws, flat washers and locknuts provided in the kit. Torque screws
and locknuts to 5 lbf⋅ft.
Minimum clearances to combustible must be observed. See Section 4).

Form 44201450 19
Oct 2018
HEAT SHIELD INSTALLATION
A heat shield can be used to reduce the clearance to combustible distances. Refer to Minimum Clearance to
Combustibles in Section 4). The heat shield is available as an accessory Kit No. 44566300.
Item No.
Part No.
Description
Quantity
1 02359000 #10-24 ACORN NUT 2
2
02358000
TEFLON WASHER
4
3
02186010
#10
-
24
SS LOCKNUT
NUT
2
4 02352000 PHSMS #8 x 1/2" AB POINT SS - BLK OXIDE 6
5 44568139 RAIL - HEAT SHIELD HANGER - PAINTED 1
6
44566189
HEAT SHIELD
-
ROLLED/PAINTED
1
7
44568149
HOLDER BRACKET
-
PAINTED
2
