Spacelabs Healthcare Lifecard CF User manual

1
Lifecard CF Service Manual
and
Lifecard 12
Firmware revision 7
Lifecard CF
18-0583 Rev. C
Service Manual

218-0583 Rev.C
This Page is intentionally Blank

3
Lifecard CF Service Manual
Contents Page
1. PRODUCT OVERVIEW 7
1.1 INTRODUCTION 7
1.2 SpeciÞcation 9
1.2.1 Standard Recording Mode – ECG Inputs 9
1.2.2 Standard Recording Mode - Pacemaker Pulse Detection 10
1.2.3 Standard Recording Mode - Data Storage 10
1.2.4 User Interface 10
1.2.5 Power Requirements 11
1.2.6 Extended Recording Mode 11
1.2.7 Additional SpeciÞcations in 12-Lead Mode 12
1.2.8 Physical and Environmental 12
1.2.9 Electro-Magnetic Compatibility 13
2. SAFETY AND REGULATORY 15
2.1 Intended Use of Equipment 15
2.2 Safety ClassiÞcation 15
2.5 Explanation of Markings 17
3. LCF BUILT-IN TESTS 21
3.1 Primary Built-in Tests 21
3.2 Second Level Built-in Tests 21
3.3 Third Level Built-in Tests 21
3.4 User Level Tests 22
3.5 Fault Protection While Recording 22
3.6 Lifecard CF Menu Options 23
3.6.1 Main Menu Options 23
3.6.2 Setup Menu 25
3.7 Lifecard CF Sounds 28
3.8 Error and Warnings Displays 29
3.9 Decontamination 32
3.10 Patient Cable 33
3.11 Battery 34
3.12 Battery Check 34
3.13 Checking the Hardware & Software Revision 34
3.14 Compact Flashcard 35

418-0583 Rev.C
4. Test Procedure 37
4.1 Checking the Patient Cable 37
4.2 LC12 Varios Yoke Assembly 37
4.3 Lifecard CF Check-out 39
5. Spares & Part Numbers 41
6. Assembly Views 43
6.1 Front Assembly - Front View - Complete 43
6.2 Front Assembly - Rear View 44
6.3 Intermediate Moulding 45
6.4 Circuit Board 46
6.5 Patient Cable Mounting with Clip 48
6.6 Short Patient Cable 49
6.7 Varios with 46-1123 Cable 46-1152 50
6.8 Varios Lead Parts 51

5
Lifecard CF Service Manual
©Copyright 2010 Spacelabs Healthcare Ltd.
1 Harforde Court, John Tate Road, Hertford. SG13 7NW

618-0583 Rev.C
This Page is intentionally Blank

7
Lifecard CF Service Manual
1. PRODUCT OVERVIEW
1.1 Introduction
The Lifecard CF is a compact Holter Ambulatory ECG Recorder
utilising a digital storage technique to store the ECG recording onto
a Compact Flash (CF) card. The Lifecard CF provides continuous
recording of 2 or 3 leads of ECG for up to 48 hours in standard mode
and up to 7 days in extended mode.
The Lifecard 12 option provides continuous recording of 12 leads of
ECG for a period of 24 hours. The recorder has a built in display for
you to monitor the ECG and pacing detection during hook-up. This
enables you to verify the ECG quality before starting the recording.
Menu options are selected using the 2 buttons on the front of the
recorder unit.
The Lifecard CF requires one AAA battery. The patient cables for the
Lifecard CF are designed to prevent accidental disconnection from the
recorder by the patient.
The Patient Event button on the front of the recorder unit enables the
patient to indicate symptomatic episodes in the recording for correla-
tion with the patient diary. Pacemaker pulse detection may be enabled
and disabled by the physician or cardiac technician. Recordings may
be analysed using a Spacelabs Healthcare PathÞnder, Impresario, or
Lifescreen Holter analysis system, if they have compatible hardware
and software. (Lifescreen is incompatible with 12-lead recordings.)
The Lifecard CF comprises two sections, the ‘Recorder Unit’ and the
‘Patient Cable Unit’.

818-0583 Rev.C
LIFECARD CF RECORDER UNIT
Recorder Unit
Lifecard CF
Display
Yellow Button
Menu Navigation
and
Patient Event
Microphone
Green Button
Menu
Selection
and
Patient Event
Loudspeaker
Patient Cable Unit
Patient Cable
Electrode Color
Code label
Belt Clip
(long cables only)
Slot for Neck
Lanyard
Attachment

9
Lifecard CF Service Manual
Patient Cable
Varios Active Yoke
1.2 Specification
1.2.1 Standard Recording Mode – ECG Inputs
Channels 3, type BF applied part patient isolation
types 2 or 3 channel 3 electrode, 2
4 electrode, 3 channel 6 electrode with
detachable leadwires.
Input impedance > 5MȍOhms
Input DC offset ± 300 mV, with saturation
recovery circuit (3 seconds max)
CMRR > 60 dB at 10Hz, > 80 dB at 50 Hz and
above, 2 Vpp signal
Dynamic range 10 mV
Resolution 2.5ȝV

10 18-0583 Rev.C
Calibration ± 5%
Bandwidth 0.05 - 40 Hz (-3 dB)
Sampling rate 1024 samples per second per channel
Noise filter Linear phase Þlter effective from 60Hz to
> 1MHz, 128 samples per second out
put rate
1.2.2 Standard Recording Mode - Pacemaker Pulse
Detection
Sensitivity 7 mV nominal, channels 1 and 2 only
Noise rejection > 50 mVpp for sinusoids up to 200 Hz
CMRR 2 V common mode spikes are rejected
Refractory period 40 ms
1.2.3 Standard Recording Mode - Data Storage
Media type Removable card, CompactFlash Association
standard (Type 1)
Data types Full disclosure ECG, with pacing and patient
event markers. Recording Time and Date.
Patient name and record number
(PathÞnder systems), Encrypted patient record
Þle (CardioNavigator). 8 second voice recording.
Recorder serial number
Capacity req 15 Mbytes per channel per 24 hours eg.
a 48 hour three channel recording occupies
90 Mbytes
1.2.4 User Interface
Type Text menus with audio cues and keys for up, down
and select
Languages English, German, French, Italian, Spanish, Danish
and Polish languages also Hebrew patient ID support
Clock Clock and calendar (to 2098), selectable 12/24 hour
and US/European date formats. 13mm digit height for
patient use

11
Lifecard CF Service Manual
Basic features Pacing detection on/off, hook-up display,
voice recording for patient identiÞcation
Ancillary features Identify and delete unread recordings,
warning/error screens for battery and
memory card conditions
Hook-up display Real time display of each channel, with 60
ȝV/30 ms resolution and pacing annotation
Set-up options Time and date, language, display contrast,
recorder identiÞcation
1.2.5 Power Requirements
Disposable cell Single AAA alkaline (Duracell MN2400 or
equivalent), two 24 hour recordings or one 48
hour recording
Rechargable cell Single AAA nickel metal hydride (Ansmann
600 mAh or equivalent), one 24 hour
recording per charge
Battery check User is warned of poor battery condition
before recording
Clock battery Internal rechargeable cell, charged during re
cording. The clock is maintained
for > 3 months between recordings
1.2.6 Extended Recording Mode
Channels 2 channel recording, with pacing detection
Cable Types 2 channel 3 electrode or 2 channel 4 electrode
Resolution 10ȝV
Sampling Rate 256 samples per second per channel
Compression 10ȝV maximum compression error when
tested with MIT-BIH Arrhythmia and
Compression databases
Capacity required 90 Mbytes for dual channel 1 week
Disposable Cell AAA alkaline (Duracell MN2400 or equivalent)
for 1 week.
User Interface Includes an audible alarm to alert the
patient if an electrode becomes detached.
Sense current is < 10 nA.
Note: other specifications are the same as Standard Recording Mode.

12 18-0583 Rev.C
1.2.7 Additional Specifications in 12-Lead Mode
Channels Standard 12-lead, one neutral and nine active
electrodes
Cable types 10 electrode, deÞbrillation protected, IEC
or AHA code
Isolation DEFIBRILLATION-PROOF TYPE
CF APPLIED PART
Input impedance 10 Mohm
Sampling rate 4096 samples per second per channel
CMRR > 80dB per IEC and ANSI/AAMI methods
Suppression Active neutral system (‘right leg drive’)
Resolution 0.6ȝV
Noise < 0.6ȝV RMS
Pacing detection >2mV, 200ȝs to 5ms pulse in any electrode
Capacity required 256 MByte card for 24 hour recording
Battery An alkaline AAA cell is required for
24 hour recording
Fault tolerance In the event of electrode detachment
noise is suppressed, and the available leads
are recorded (differential V leads only if R, L
or F is detached)
Note: other specifications are the same as Standard Recording Mode
1.2.8 Physical and Environmental
Dimensions 96 x 57 x 17.5mm with patient cable Þtted
Weight Recorder body 55g: patient load 130g
including battery, card and typical
patient cable
User labelling Area provided is 52 x 15 mm
Temperature 0 to 45°C operation, -20 to 65°C storage
Humidity Operation or storage 5% to 95%,
non-condensing
Pressure Operation or storage air pressure
700 - 1060 mbar
Shock 1 m drop

13
Lifecard CF Service Manual
1.2.9 Electro-Magnetic Compatibility
General Complies with EN60601-1-2:1993 and ANSI/
AAMI EC38:1998
ESD (1) 4 kV air and 2 kV contact discharges: no inter
ruption in recorder function
ESD (2) 8 kV air and 6 kV contact discharges: no
damage to the recorder, recording
resumes automatically in < 10 s
Radiated emissions CISPR 11:1997, EN55011:1998 Group 1
Class B
Radiated immunity 3 V/m 26 MHz - 1 GHz, 80% AM modulated
at 5 Hz. Keyed carrier immunity to
EN50082:1996
This equipment has been tested and found to comply with the limits
for a class B computing device in accordance with the speciÞcations
in Subpart J of Part 15 of FCC Rules, which are designed to provide
reasonable protection against interference to radio and television
reception.
This equipment generates and uses radio frequency energy and if not
installed and used in accordance with the instructions it may cause
interference. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be determined
by turning the equipment off or on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient the receiving antenna
• Relocate the equipment with respect to the receiver
• Move the equipment away from the receiver
If necessary, the user should consult Spacelabs Healthcare or an
experienced radio/television technician for additional suggestions. The
user may Þnd the following booklet prepared by the Federal
Communications Commission helpful:
“How to Identify and Resolve Radio-TV Interference Problems”
This booklet is available from the U.S. Government Printing OfÞce,
Washington, DC 20402, Stock No. 004-000-00345-4.

14 18-0583 Rev.C
This Page is intentionally Blank

15
Lifecard CF Service Manual
2. SAFETY AND REGULATORY
2.1 Intended Use of Equipment
The Lifecard CF Holter recorder is to be used for the non-invasive
ambulatory recording of two or three channel electrocardiograms on a
standard commercial compact ßash card.
The Lifecard 12 option is to be used for the non-invasive ambulatory
recording of 12-lead electrocardiograms on a standard commercial
compact ßash card.
The recorder allows data to be collected over a continuous period of
up to 7 days whilst allowing the subject to perform most of their nor-
mal daily activities.
The recordings can be analysed on compatible analysis systems from
Spacelabs Healthcare.
This device has been designed and supplied speciÞcally for the long
term recording of electrocardiograms in ambulatory patients using
standard Holter monitoring techniques. It shall not be used for any
other purposes.
The device shall be operated only be suitably competent personnel
trained in the use and procedures of Holter electrocardiography for
diagnostic purposes.
The Lifecard CF comprises two sections; the ‘Recorder Unit’ and the
‘Patient Cable Unit’.
2.2 Safety Classification
This device has been designed in accordance with EN60601 - 1 ,
“Medical
electrical equipment, Part 1: General requirements for safety”, as fol-
lows:
1. EQUIPMENT with an INTERNAL ELECTRICAL POWER
SOURCE. The equipment is designed to be battery operated only.
Under NO circumstances shall a mains powered battery elimina-
tor or any other external power source be used with the equip-
ment.

16 18-0583 Rev.C
2. EQUIPMENT having a TYPE BF APPLIED PART. or
3. EQUIPMENT having a TYPE CF APPLIED PART if so marked.
4. IPX4 EQUIPMENT protected against the ingress of splashing
water, if so marked. Otherwise, ORDINARY EQUIPMENT, without
protection against ingress of liquid.
5. Not suitable for use in the presence of a ßammable anesthetic
mixture with air or with oxygen or nitrous oxide, or ßammable
cleaning agents.
6. Rated for CONTINUOUS OPERATION.
7. EQUIPMENT with an APPLIED PART, speciÞcally designed for
application where a CONDUCTIVE CONNECTION is made to the
PATIENT, but not directly to the heart. According to ANSI/AAMI
EC38:1998.Lifecard CF is Type 1 ambulatory ECG device.
2.3 Adjustment, replacement of parts,
maintenance and repair
The device requires no routine adjustments to maintain its operation.
The device contains no user serviceable parts. It shall be serviced
only by Spacelabs Healthcare or by an agent accredited by them to
service device of this type. Unauthorised repairs or dismantling of the
device will invalidate the guarantee.
2.4 Defects and abnormal stresses
For continued safety the device must not be maltreated, used outside
its speciÞed operation conditions, or stored outside its speciÞed stor-
age conditions.
Lifecard CF contains protection against electrostatic discharge, but
there is no protection against deÞbrillators. To avoid damage the
device should be removed before deÞbrillating. The Varios active yoke
and 46-1123 / 46-1127 patient cables have deÞbrillator protection.
(The protection is a combination of the cable and the yoke).

17
Lifecard CF Service Manual
Whenever it is likely that protection has been impaired, the device
shall be made inoperative and secured against any unintended opera-
tion. The protection is likely to be impaired if, for example, the device
shows visible damage.
a) shows visible damage
b) fails to perform the intended measurements
c) has been subjected to prolonged storage under unfavorable
conditions
d) has been subjected to severe transport stresses
e) the device has been connected to a patient during deÞbrillation.
2.5 Explanation of Markings
CE Mark
Date of Manufacture
Manufacturer
Consult Documents
This symbol means you should read the
accompanying documents
EQUIPMENT having a TYPE BF APPLIED PART
EQUIPMENT having a DEFIBRILLATION-PROOF
TYPE CF APPLIED PART
Battery Eject symbol

18 18-0583 Rev.C
Protected against ingress of splashing water when
the patient cable is Þtted.
AECG- Type 1 ambulatory ECG device according to ANSI/
AAMI EC38:1998
This product must be sent to separate collection
facilities for recovery and recycling
12 LEAD 9Compatible with Varios Active Yoke & 10-electrode
cable
2.6 Warranty
Subject to the conditions set out below, Spacelabs Healthcare (“The
Company”) warrants that its Products will be free from defects in
material and workmanship for a period of 12 months from delivery.
This warranty is given by The Company subject to the following
conditions:
1. The Company shall be under no liability in respect of any defect arising from fair
wear and tear, willful damage, negligence, abnormal working conditions, failure
to follow instructions (whether oral or in writing), misuse, improper installation or
alteration or repair of the Products without The Company’s approval.
2. The above warranty does not extend to parts, materials or devices not manufactured
by The Company, in respect of which the Customer shall only be entitled to the
beneÞt of any such warranty or guarantee as is given by the manufacturer to The
Company.
3. Subject as expressly provided here, all warranties, conditions or other terms
implied by statute or common law are excluded to the fullest extent permitted by
law.
4. Any claim by the Customer which is based on any defect in material or
workmanship of the Products shall be notiÞed to The Company immediately after
discovery of the defect. If the Customer does not notify The Company accordingly,
the Customer shall not be entitled to reject the Products and The Company shall
have no liability for such defect.
5. Where any valid claim in respect of any of the Products which is based on any
defect in the material or workmanship of the Products is notiÞed to The Company,
The Company shall be entitled to replace or repair (at The Company’s sole
discretion, either at the Customer’s premises or at The Company’s premises in
the United Kingdom) the Products (or part in question) but The Company shall
have no further liability to the Customer.

19
Lifecard CF Service Manual
6. The Company shall not be liable to the Customer by reason of any representation,
or implied warranty, condition or other term, or any duty at common law, or for
any consequential loss or damage (whether for loss of proÞt or otherwise), costs,
expenses or other claims for consequential compensation whatsoever arising
out of or in connection with any act or omission of The Company relating to the
manufacture or supply of the Products or use by the Customer.
7. Spacelabs Healthcare recommends the use only of approved accessories and
parts. The use of third party accessories may result in damage to recordings or
equipment, and may invalidate your warranty.
2.7 Contact Details
Spacelabs Healthcare Ltd
1 Harforde Court
John Tate Road
Hertford
SG13 7NW
United Kingdom
Tel: [phone]
Fax: [phone]
Spacelabs Healthcare Inc.
5150 220th Ave. SE
Issaquah,
WA 98029
USA
Tel: [phone]
Fax: [phone]
Web site: www.spacelabshealthcare.com
2.7
Modifications
For continued safety, the device shall not be subjected to any
Unauthorised modiÞcations and must be used only for the purpose for
which it was originally supplied.

20 18-0583 Rev.C
