Installation, Operation & Maintenance Instructions
RAINIER COLLECTION COMBINATION SERIES
DESCRIPTION
Speakman Rainier Collection Combination Series unites the best products included in our Rainier Series.
The combination begins with our anti-scald balanced pressure valve with integral stops, featuring a brass
body and adjustable temperature limit stop. The metal construction wall plate and handle are designed with
definitive Rainier Collection styling. Piston type pressure balancing/ceramic regulating cartridge assembly
with built-in check valves. Meets ASME A112.18.1 / CSA B125.1 & ASSE 1016 standards.
SPECIFICATIONS
SM-8001-P ANTI-SCALD BALANCED PRESSURE VALVE:
CONNECTIONS: ½” Female Copper Sweat Inlets & Shower Outlet
½” NPT Female tub outlet
FLOW RATE: For use with Shower Heads rated at 2.0 gpm (7.6 L/min.) or higher.
MEETS: ASME A112.18.1 / CSA B125.1 & ASSE 1016 standards
INSTRUCTIONS
See individual product manuals for installation of the components and warranty information.
ROUGH-IN
190mm
71
2
"
190mm
71
2"
79mm
31
8"
79mm
31
8"
24mm
1"
113mm
41
2"
121mm
43
4"

INSTRUCTIONS FOR MODELS
92-CPV-P-03
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
[email protected]
www.speakman.com
CPV-P-IS
CPV-P-DV
CPV-3000
CPV-3000-IS
CPV-3400
HELPFUL TOOLS & SUPPLIES:
TOOLS AND SUPPLIES
Pencil Keyhole
Saw
Adjustable
Wrench
Thread Seal
Tape
9/16”Deep Well
Socket
Socket
Wrench
Solder Kit
Phillips
Screwdriver
Measuring
Tape
Safety
Glasses
Tubing
Cutter
13/16”Deep Well
Socket
Level
Additional warranty information can be found at:
www.speakman.com
WARRANTY
Your new Shower/Bath Valve is designed for years
of trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of
harsh chemicals and abrasives on any of the
Speakman custom finish products may damage the
finish and void the product warranty. Please be sure
to only use approved cleaners. Please contact
Speakman for any clarification of acceptable
cleaners.
MAINTENANCE
Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.
SAFETY TIPS
IMPORTANT
• Be sure to read instructions thoroughly before
beginning installation.
• Be sure to have properly adjusted the Temperature
Limiting Stop (TLS) as outlined in this Installation
Manual.
• Inspect all connections after installation of valve.
• This valve has an operating range of 20-80 Psi.
• This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate.
• NOTE: This installation manual covers several
models of valves. While the appearance of your
valve may differ from those shown, the installation
method is the same.
1Referencing the supplied rough-in dimensions
(located at the end of this manual), determine the
preferred location of valve. Align the supplied
rough-in template with this location and trace
outline of template onto wall.
1’-9” (533mm)
TO CENTERLINE
OF TUB SPOUT
(FOR TUB INSTALLATION)
4’-6” (1.4m)
TO FLOOR
(SHOWER INSTALLATION)
2Using a keyhole saw or similar tool, cut along
traced line and remove this section of wall.
3If your model of shower valve has Integral
Stops, unthread and remove them using a
socket wrench equipped with a 9/16” deep
well socket.
Socket
Wrench 9/16”Deep Well
Socket
+
4If your Shower Valve is equipped with an
integral diverter, remove the Diverter Nut using
a socket wrench and a 13/16” deep well
socket. Remove Diverter Cartridge to prevent
damage during soldering.
Socket
Wrench
+
13/16”Deep Well
Socket
5Install the Rough-In Template over the Shower Valve being sure the Rough-In Template sits flush against Shower Valve Bonnet. Following the rough-in
dimensions for your model of valve (located ot the end of this manual) as well as the markings on the supplied rough-in template, install valve at proper
depth. The distance from the centerline of the inlet/outlet ports of the valve assembly to the finished wall MUST be between 2½” - 3½”. See images below
for reference.
SHOWER OUTLET
TUB OUTLET
ROUGH-IN TEMPLATE
THE BACK EDGE OF THE
ROUGH-IN TEMPLATE IS
FLUSH WITH OR INSIDE
THE VALVE ACCESS HOLE.
FINISHED WALL SURFACE
2½” MINIMUM
MOUNTING DEPTH
MINIMUM MOUNTING DEPTH
SHOWER OUTLET
TUB OUTLET
ROUGH-IN TEMPLATE
THE FRONT SURFACE OF
THE ROUGH-IN TEMPLATE
IS FLUSH WITH OR OUTSIDE
THE VALVE ACCESS HOLE.
FINISHED WALL SURFACE
3½” MAXIMUM
MOUNTING DEPTH
MAXIMUM MOUNTING DEPTH

6If your installation is for a shower only, apply
thread seal tape to the included ½” Pipe Plug
and install into the lower port of the shower
valve. Wrench tighten.
7Ensure Valve is positioned plumb and level.
Remove Rough-In Template from Valve. Plumb
and solder all joints and fittings. Take care to
protect surrounding area when soldering.
Secure piping to surrounding structure.
8Make piping connections for all accessories.
Take care to protect surrounding area when
soldering. Secure piping to surrounding
structure.
9If your model of shower valve has Integral
Stops, reinstall them using a socket wrench
equipped with a 9/16” deep well socket or
crescent wrench.
Socket
Wrench 9/16”Deep Well
Socket
+
10 If your Shower Valve is equipped with an
integral diverter, reinstall the Diverter
Cartridge taking care to align mounting posts
of cartridge with the corresponding holes in
the valve body. Install Diverter Nut and tighten
with a Ratchet Wrench and 13/16” Socket.
Take care to not over-tighten connections.
Socket
Wrench
+
13/16”Deep Well
Socket
11
If you are performing a Standard
Installation, please proceed to Step 14
If you are performing a Back to Back
Installation, or have reversed inlet
supplies, please proceed to Step 12
OR
Your Shower Valve has the ability to be mounted
back-to-back with another Valve in a shared
space. This means the hot and cold inlets may
be reversed. Please see the following steps to
adapt your valve for back-to-back mounting or
reversed inlet supplies.
BACK-TO BACK INSTALLATION 112
To adapt your shower valve for back to back installation, remove spindle O-ring , TLS plate , and four (4)
Bonnet Screws . Then remove Bonnet and Cartridge Assembly from valve body.
Phillips
Screwdriver
BACK TO BACK INSTALLATION 2
13
Rotate Valve Cartridge 180˚ and reinstall into Valve Body. The “H” marking on the blue Valve Cartridge cover
should now be on the right hand side. Reinstall Bonnet and four (4) Bonnet Screws , making sure the Large
Bonnet O-Ring is in place within the Valve Body. Reinstall TL S Plate and Spindle O-Ring .
ROTATE
180˚
Phillips
Screwdriver
The maximum hot water temperature setting adjustment (Temperature Limit Stop (TLS)) of the valve has
been factory set at 110° F. Important- Check each valve installation with a thermometer to make sure
the maximum hot water temperature is set to the recommended setting of 110° F maximum. To lower
the limit of the maximum hot water temperature the valve delivers, adjust the valve’s temperature limit
stop (TLS) plate.
• Slip the retaining O-ring and the TLS plate
towards the end of the spindle.
• With the water supplies on, rotate the
valve spindle clockwise to the maximum
desired hot water temperature.
• Position the TLS plate so it contacts the lug
on the valve bonnet and therefore restricts
the clockwise rotation of the spindle.
• Slip the retaining O-ring back into the
groove of the spindle to hold the TLS plate in
place.
• Rotate the spindle counter-clockwise to the
“Off” position.
TEMPERATURE LIMIT ADJUSTMENT15
BONNET LUG
TLS PLATE
O-RING
14 Ensure the Valve is in the “OFF” position. Turn “ON” water supplies and check all connections for leaks.
16 Reinstall Rough-In Template over Valve to protect it during final wall preparation.

CPV-P-IS / CPV-P-DV / CPV-3000 / CPV-3000-IS / CPV-3400 REPAIR PARTS SPEAKMAN®
ITEM NO. PART NO. DESCRIPTION
RPG05-0718 4 SCREWS, BONNET, AND BONNET O-RING
RPG05-0884 REPLACEMENT CARTRIDGE FOR MODELS CPV-P-IS, CPV-P-DV
RPG05-0843 REPLACEMENT CARTRIDGE FOR MODELS CPV-3000, CPV-3000-IS, CPV-3400
RPG49-0005 CARTRIDGE LOWER QUAD RINGS
RPG49-0076 SPINDLE O-RINGS
RPG49-0126 LARGE BONNET O-RING
RPG05-0876 INTEGRAL STOP REPAIR KIT
RPG05-0897 REPLACEMENT DIVERTER CARTRIDGE
CPV-P-IS ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
Shower Valve ASSE1016
Hot/Cold Inlets: ½” Female Copper Sweat
Shower Outlet: ½” Female Copper Sweat
Tub Outlet: ½” NPT Threaded Connection
(Plug included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4'-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION ONLY)
51
2
"
140mm
HOLE FOR
VALVE ACCESS
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
4" [102mm]
TO TOP OF
TUB LEDGE
A
A
1/2 NPT FEMALE
37
16
"
87mm
2-1/2" MIN
[64mm]
3-1/2" MIN
[89mm]
(ADJUSTMENT)

CPV-P-DV ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
Shower Valve ASSE1016
Hot/Cold Inlets: ½” Female Copper Sweat
Shower Outlet: ½” Female Copper Sweat
Tub Outlet: ½” NPT Threaded Connection
(Plug included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate
1"
25mm
HOLE FOR
SHOWER ARM
51
2
"
140mm
HOLE FOR
VALVE ACCESS
1"
25mm
HOLE FOR
TUB SPOUT
6'-6" [2 METERS]
TO FLOOR
4'-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION ONLY)
1'-9" [533mm]
4" [102mm
TO TOP OF
TUB LEDGE
A
A
1/2 NPT FEMALE
1/2" SWEAT
CONNECTION
1/2" SWEAT
CONNECTION
2-1/2"MIN
[64mm]
3-1/2"MIN
[89mm]
(ADJUSTMENT)
415
16
"
125mm
1/2" SWEAT
CONNECTION
CPV-3000 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
Shower Valve ASSE1016
Hot/Cold Inlets: ½” Female Copper Sweat
Shower Outlet: ½” Female Copper Sweat
Tub Outlet: ½” NPT Threaded Connection
(Plug included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4'-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION ONLY)
51
2
"
140mm
HOLE FOR
VALVE ACCESS
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
4" [102mm]
TO TOP OF
TUB LEDGE
A
A
1/2 NPT FEMALE
37
16
"
87mm
2-1/2" MIN
[64mm]
3-1/2" MIN
[89mm]
(ADJUSTMENT)

CPV-3000-IS ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
Shower Valve ASSE1016
Hot/Cold Inlets: ½” Female Copper Sweat
Shower Outlet: ½” Female Copper Sweat
Tub Outlet: ½” NPT Threaded Connection
(Plug included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4'-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION ONLY)
51
2
"
140mm
HOLE FOR
VALVE ACCESS
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
4" [102mm]
TO TOP OF
TUB LEDGE
A
A
1/2 NPT FEMALE
37
16
"
87mm
2-1/2" MIN
[64mm]
3-1/2" MIN
[89mm]
(ADJUSTMENT)
CPV-3400 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
Shower Valve ASSE1016
Hot/Cold Inlets: ½” Female Copper Sweat
Shower Outlet: ½” Female Copper Sweat
Tub Outlet: ½” NPT Threaded Connection
(Plug included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 2.0 gpm (7.5 L/min)
or higher flow rate
1"
25mm
HOLE FOR
SHOWER ARM
51
2
"
140mm
HOLE FOR
VALVE ACCESS
1"
25mm
HOLE FOR
TUB SPOUT
6'-6" [2 METERS]
TO FLOOR
4'-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION ONLY)
1'-9" [533mm]
4" [102mm
TO TOP OF
TUB LEDGE
A
A
1/2 NPT FEMALE
1/2" SWEAT
CONNECTION
1/2" SWEAT
CONNECTION
2-1/2"MIN
[64mm]
3-1/2"MIN
[89mm]
(ADJUSTMENT)
415
16
"
125mm
1/2" SWEAT
CONNECTION

INSTRUCTIONS FOR MODELS
92-CPT-8001-P-01
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
[email protected]
www.speakman.com
CPT-8001-P
TOOLS AND SUPPLIES
Phillips
Screwdriver
Measuring
Tape
Additional warranty information can be found at:
www.speakman.com
WARRANTY
MAINTENANCE
Cover your drain to prevent loss of parts.
SAFETY TIPS
IMPORTANT
• Be sure to read instructions thoroughly before
beginning installation.
• Do not over-tighten any connections or damage
may occur.
• Be sure to have properly adjusted the Temperature
Limiting Stop (TLS) as per the Valve Installation
Instructions before installing Valve Trim.
Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.
1Clean wall surface. Place Mounting Base (1) onto the valve, align mounting holes, and secure with
supplied screws (2).
2There are two connectors included to allow for both Shallow Mount (Valve Centerline is 2.5”-3.0”
from finished wall surface) and Deep Mount (Valve Centerline is 3.0”-3.5” from finished wall
surface) applications. Please select Connector appropriate for your installation.
For Deep Mount Application For Shallow Mount Application
3Confirm that Valve is in the “Off” position. Place appropriate Connector on to the Spindle of the
Valve, making sure to orient the Connector so that one set of Splines are in a perfectly vertical
position.
Splines in Vertical Position
4
When installed correctly, the Connector (1) should protrude from the Mounting Base (2)
in-between 5/16” and 1”. Secure Connector with 8-32 screw provided (3). If your installation
does not fall within this range, try swapping Connectors.
IMPORTANT
5/16” to 1”
5Place Escutcheon (1) on Mounting Base. Take care to orient the Escutcheon as shown below.
6Align Handle Assembly with Connector (1) and Escutcheon. Keep Handle (2A) in a stationary
vertical position as you thread Handle Hub (2B) onto the Mounting Base. Tighten until snug.

CPT-8001-P REPAIR PARTS SPEAKMAN®
RPG05-0874 SCREWS AND SPLINE ADAPTERS
RPG10-104283-XX (XX=FINISH) TRIM PLATE FOR CPT-8001-P
RPG04-0392-XX (XX=FINISH) HANDLE ASSEMBLY FOR CPT-8001-P
ITEM NO. PART NO. DESCRIPTION
CPT-8001-P ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
VALVE MOUNTING IS SHOWN FOR REFERENCE ONLY.
VALVE IS NOT INCLUDED WITH CPT-8001-P
1"
25mm
HOLE FOR
SHOWER ARM
51
2
"
140mm
HOLE FOR
VAVLE ACCESS
513
16
"
147mm
1'-9"
[533mm]
4"
[102mm]
TO TOP OF
TUB LEDGE
4'-6"
[1.4 METERS]
TO FLOOR
(SHOWER INSTALL ONLY)
6'-6"
[2 METERS]
TO FLOOR
1"
25mm
HOLE FOR
TUB SPOUT
A
A
2-1/2" [64mm] MINIMUM
3-1/2" [89mm] MAXIMUM
ROUGH IN DEPTH
37
16
"
87mm
SECTION A-A
190mm
71
2
"
190mm
71
2
"
79mm
31
8
"
79mm
31
8
"
24mm
1"
113mm
41
2
"
121mm
43
4
"
