Spear & Jackson TLEG05A User guide

ORIGINAL
INSTRUCTION
MANUAL
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your rotovator, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
AFTER SALES SUPPORT
0345 605 2067
800W
Electric Rotovator
TLEG05A

2
AFTER SALES SUPPORT 0345 605 2067
SPEAR & JACKSON SINCE 1760
For more than 250 years gardeners have enjoyed high quality performance and
great results using Spear & Jackson tools.
Our garden power tools combine continuous innovation and the latest in
manufacturing technologies with a proud heritage.
Each product is carefully designed with performance, comfort and durability
rmly in mind, which has earned Spear & Jackson an enviable reputation as a
maker of tools to trust.
As a testament to the quality of our products, we offer a 3 year manufacturers war-
ranty and a comprehensive after sales service.
The warranty covers manufacturing faults, however in the event that the item has
been deliberately damaged, used in a commercial environment or disassembled then
the warranty will be null and void.
Please retain proof of purchase.
We want you to get the best out of your products. Our easy-to-read instruction manu-
al guides you with best practice use and maintenance tips. Please call 0345 605 2067
for technical support, we can solve around 80% of questions directly over the phone.
We hope you enjoy your product and we look forward to any feedback, as this allows
us to develop even better products for the future.
3 YEARS GUARANTEE
7 DAYS A WEEK TECHNICAL SUPPORT

3AFTER SALES SUPPORT 0345 605 2067
CONTENTS
Safety Information 04
Description of symbols 04
General safety 05
Prepare 05
Work area safety 06
Personal safety 07
Electrical safety 08
Power tool use and care 08
Operate 09
Maintenance and storage safety 11
Service 12
Intended use 12
Box Content / Parts 13
Assemble 14
Unpacking 14
Assemble the frame 14
Assembling the handles 15
Clamping the cable with cable clip 15
Prepare 17
Connecting the extension cord to a suitable socket 17
Switch on/off 17
Operate 18
Maintenance and repair 19
General 19
Cleaning the device 20
Storage 21
Transportation 21
Recycling and disposal 21
Technical Data 22
Troubleshooting 24
Warranty 25

AFTER SALES SUPPORT 0345 605 2067
Please read these instructions fully before operating or maintaining your machine
4
SAFETY INFORMATION
The following warning symbols appear throughout this manual and indicate the appropriate
safety measures you should take when operating and maintaining the rotovator.
SWITCH OFF! Remove plug
from mains before cleaning or
maintenance.
Danger from damaged mains cable.
Keep mains cables away from
blades!
Danger of injury from rotating parts.
The blades will continue to rotate
after the tool has been switched off.
Wait for them to stop moving.
Guaranteed sound power level
value in 93dB.
Double insulation.
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check your Local
Authority or retailer for recycling
advice.
The product complies with the
applicable European directives and
an evaluation method of conformity
for these directives was done.
Read instruction handbook before
operating this machine.
WARNING!
This is a warning symbol. This
symbol is used throughout the user
guide whenever there is a risk of
personal injury. Ensure that these
warnings are read and understood
at all times.
Wear eye protection.
Wear ear protection.
Wear protection gloves.
Wear proper safety shoes.
WARNING! Remove plug from the
mains immediately if the cable is
damaged or cut.
Keep bystanders away.
Do not expose and operate the tool
in rain.
DESCRIPTION OF SYMBOLS
93

Please read these instructions fully before operating or maintaining your machine
5
IMPORTANT!
Read all instructions. Failure
to follow all instructions
listed below may result in
electric shock, fire and/
or serious injury. The term
“power tool” in all warnings
listed below refers to your
mains operated power tool.
■Read the instruction
carefully. Be familiar
with the controls and
the correct use of the
appliance. Read and
understand the operator’s
manual and observe the
warnings and instruction
labels affixed to the
appliance.
■Never allow children or
people unfamiliar with
these instructions to use
the electric rotovator. Local
regulations can restrict the
age of the operator.
■Never use the tool while
people, especially children,
or pets are nearby. Keep
in mind that the operator
GENERAL SAFETY
SAFETY INFORMATION
or user is responsible
for accidents or hazards
occurring to other people
or their property.
■
This appliance is not
intended for use by people
(including children) with
reduced physical, sensory
or mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
■
Do not touch the rotating
blades until they are
stopped.
PREPARE
■
THIS MACHINE CAN
CAUSE SERIOUS
INJURIES. Read the
instruction carefully for
the correct handling,
preparation, maintenance,
AFTER SALES SUPPORT 0345 605 2067

6
AFTER SALES SUPPORT 0345 605 2067
Please read these instructions fully before operating or maintaining your machine
starting and stopping
of the appliance. Be
familiar with the controls
and the proper use of
the appliance. Read and
understand the operator’s
manual and observe the
warnings and instruction
labels affixed to the
appliance.
■Users. Never allow
children or people
unfamiliar with these
instructions to use
the appliance. Local
regulations may restrict
the age of operator. Never
operate the tool under
the influence of alcohol,
medication or drugs.
■Use appropriate tool. This
device is only intended for
break up topsoil in private
house and hobby gardens.
Do not force small tools or
attachments to do the job
of a heavy duty tool.
■Keep work areas clean.
Check the terrain on which
will be using the tool, and
remove stones, sticks,
wires or other foreign
objects that may be
caught up and spun off.
■Consider work area
environment. Do not
expose your tool to high
humidity or rain. Do not
use your tool in damp and
wet conditions. Keep the
work area well lit.
■Keep all bystanders,
children, and pets at least
50 feet away. The operator
or user is responsible
for accidents or hazards
occurring to other people
or the property.
■Do not operate power
tools in explosive
atmospheres, such as in
the presence of flammable
liquids, gases or dust.
Power tools create sparks
which may ignite the dust
or fumes.
SAFETY INFORMATION
WORK AREA SAFETY

7
AFTER SALES SUPPORT 0345 605 2067
Please read these instructions fully before operating or maintaining your machine
■Use personal protective
equipment (PPE). Always
wear eye protection.
Protective equipment such
as dust mask, non-skid
safety shoes, hard hat, or
hearing protection used
for appropriate conditions
will reduce personal
injuries.
■Dress appropriately. Do
not wear loose clothing or
jewellery, as these can be
caught in moving parts.
Preferably wear non-slip
footwear when working
outdoors. Wear protective
hair covering to keep long
hair out of the way.
■Stay alert, watch what
you are doing and use
common sense when
operating a power tool. Do
not use a power tool while
you are tired or under the
influence of drugs, alcohol
or medication. A moment
of inattention while
operating power tools may
result in serious personal
injury.
■Prevent unintentional
starting. Ensure the switch
is in the off-position
before connecting to
power source and/or
battery pack, picking
up or carrying the tool.
Carrying power tools with
your finger on the switch
or energising power tools
that have the switch on
invites accidents.
■Keep all parts of the body
away from the blades.
Make sure the switch is
off when clearing jammed
material. A moment of
inattention while operating
the electric rotovator may
result in serious personal
injury.
■Do not overreach. Keep
proper footing and
balance at all times. This
enables better control
of the power tool in
unexpected situations.
SAFETY INFORMATION
PERSONAL SAFETY

AFTER SALES SUPPORT 0345 605 2067
8
SAFETY INFORMATION
Please read these instructions fully before operating or maintaining your machine
■Power tool plugs must
match the outlet. Never
modify the plug in any
way. Do not use any
adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and
matching outlets will
reduce risk of electric
shock.
■Avoid body contact with
earthed or grounded
surfaces, such as pipes,
radiators, ranges and
refrigerators. There is an
increased risk of electric
shock if your body is
earthed or grounded.
■Do not expose power tools
to rain or wet conditions.
Water entering a power
tool will increase the risk of
electric shock.
■Do not abuse the cord.
Never use the cord
for carrying, pulling or
unplugging the power
tool. Keep cord away from
heat, oil, sharp edges or
moving parts. Damaged or
entangled cords increase
the risk of electric shock.
■When operating a power
tool outdoors, use an
extension cord suitable for
outdoor use. Use of a cord
suitable for outdoor use
reduces the risk of electric
shock.
■Do not force the power tool.
Use the correct power tool
for your application. The
correct power tool will do
the job better and safer at
the rate for which it was
designed.
■Do not use the power
tool if the switch does
not turn it on and off. Any
power tool that cannot be
controlled with the switch
is dangerous and must be
repaired.
■Disconnect the plug from
the power source and/
or the battery pack from
POWER TOOL USE AND CARE
ELECTRICAL SAFETY

9
AFTER SALES SUPPORT 0345 605 2067
the power tool before
making any adjustments,
changing accessories, or
storing power tools. Such
preventive safety measures
reduce the risk of starting
the power tool accidentally.
■Store idle power tools out
of the reach of children
and do not allow persons
unfamiliar with the power
tool or these instructions
to operate the power tool.
Power tools are dangerous
in the hands of untrained
users.
■Maintain power tools.
Check for misalignment or
binding of moving parts,
breakage of parts and any
other condition that may
affect the power tool’s
operation. If damaged,
have the power tool
repaired before use. Many
accidents are caused by
poorly maintained power
tools.
■Keep cutting tools sharp
and clean. Properly
maintained cutting tools
with sharp cutting edges
are less likely to bind and
are easier to control.
■Use the power tool,
accessories and tool bits
etc. in accordance with
these instructions, taking
into account the working
conditions and the work to
be performed. Use of the
power tool for operations
different from those
intended could result in a
hazardous situation.
■Be certain the parts are
fully tightened before
operating the tool. Check
it periodically for tightness
during use to avoid serious
injury.
■Risk of cut. Do not touch
or try to stop the rotating
parts when they are
moving.
■Disconnect the plug.
Please read these instructions fully before operating or maintaining your machine
SAFETY INFORMATION
OPERATE

10
AFTER SALES SUPPORT 0345 605 2067
Disconnect plug from the
tool when not in use or
when servicing or cleaning.
■Check for damaged parts.
Before further use, carefully
check the tool for damage.
Check for alignment of
moving parts, binding of
moving parts, breakage of
parts, mounting and any
other condition that may
affect its operation. Do not
use the tool if any parts are
damaged or defective. Have
any damaged or defective
parts repaired or replaced
by an authorized service
agent. Never attempt any
repairs yourself.
■Grip the tool securely.
Always hold the tool
securely in both hands while
working with it.
■Keep handle dry, clean and
free from oil and grease.
Slippery handles do not
allow for safe handling
and control of the tool in
unexpected situations.
■Keep cable away from
cutting area. During
operation the cable may be
hidden in shrubs and can
be accidentally cut by the
blade.
■Do not overload the
tool. Only work in the
performance range stated.
Do not use tools that do
not have sufficient power
for heavy jobs. Do not use
the tool for any use other
than that intended by the
manufacturer.
■If there is any danger of
slipping on sloped ground,
have a second person
secure the tool with a rod or
cable. The second person
should stand up the slope
at a safe distance from the
tool.
■Avoid damage to the tool.
Do not apply extra weight
and do not drag the tool
over hard surfaces such as
tiles or steps.
■Do not use the tool on
excessively steep slopes.
Make sure that you are
SAFETY INFORMATION
Please read these instructions fully before operating or maintaining your machine

11
AFTER SALES SUPPORT 0345 605 2067
standing firmly when
using the tool, especially
on slopes. If working on
a slope, work along the
slope, not upwards or
downwards. Be particularly
careful when changing
direction on the slope.
■Do not use the power
tool if the switch does
not turn it on and off. Any
power tool that cannot be
controlled with the switch
is dangerous and must be
repaired.
■Disconnect the plug from
the power source before
making any adjustments,
changing accessories, or
storing power tools. Such
preventive safety measures
reduce the risk of starting
the power tool accidentally.
■The use of a residual
current device (R.C.D)
with a tripping current of
not more than 30mA is
recommended.
■Maintain tools with care.
Keep tools clean and in
good condition for better
and safer performance.
Follow the instructions for
maintenance and changing
accessories. Keep handles
and switches dry, clean
and free from oil and
grease.
■Be careful in handling
the tool. Keep the blades
sharp and clean to improve
its working safety and
effectiveness.
■Store idle power tools out
of the reach of children
and do not allow persons
unfamiliar with the power
tool or these instructions
to operate the power tool.
Power tools are dangerous
in the hands of untrained
users.
Please read these instructions fully before operating or maintaining your machine
SAFETY INFORMATION
MAINTENANCE AND STORAGE

12
AFTER SALES SUPPORT 0345 605 2067
SERVICE
■Have your tool repaired
by an authorized
service agent. This
tool is manufactured
in accordance with the
relevant safety regulations.
To avoid danger, electrical
appliances must only
be repaired by qualified
technicians.
This product designated for
small gardens and flower
beds, this device effectively
loosens and turns over new
soil. It may also be used to
mix coarse soil with fertilizer,
peat, and compost. This
product may not be used to
till extremely dry or wet soil.
The use of this product in
rain or wet conditions is
prohibited.
This product is intended for
private domestic use only.
It is not intended for any
commercial trade use. It must
not be used for any purposes
other than those described.
SAFETY INFORMATION
Please read these instructions fully before operating or maintaining your machine
INTENDED USE

13
AFTER SALES SUPPORT 0345 605 2067
BOX CONTENT
Cable and plug
Lock button
Switch trigger
Right handle
Left handle
Frame
Fixing knobs and bolts 2pcs
Lower handle
Motor housing
Safety guard
Blade 4pcs
Screws 2pcs
Cable clip, 1 pc
1 8
2 9
3 10
4 11
5 12
136
7
PARTS
If there are any parts missing, please call the customer helpline on 0345 605 2067
1
2
4
12
13
3
11
10
9
8
7
6
5

14
AFTER SALES SUPPORT 0345 605 2067
ASSEMBLE
Unpacking
Warning! Wear proper protective gloves.
i. Unpack all parts and lay them on a flat, stable surface.
ii. Remove all packing materials and shipping devices if
applicable. Box should be kept for duration of warranty.
iii. Make sure the delivery contents are complete and free of
any damage. If you find that parts are missing or show
damage do not use the product but contact your dealer.
Using an incomplete or damaged product represents a
hazard to people and property.
iv. Ensure that you have all the accessories and tools
needed for assembly and operation. This also includes
suitable personal protective equipment.
Assemble the frame
Slide the right (A) and left-hand handles (B) into the
frame (C). Secure the frame to the left and right-hand
handles with the included screws.
1
2
NOTE: Use a Philips-head screwdriver. Aligning the
holes may be difcult. We recommend fastening one
hand grip at a time to the frame.
A
B
C
D

15
AFTER SALES SUPPORT 0345 605 2067
NOTE: Make sure that the control handle is on the side of the
cable holder of the connectors.
WARNING! Before switching the tool on, make sure that
the tool is not touching any other objects and hold it rmly
in both hands.
Always keep a rm grip on the tool with both hands and
watch your feet. The blades may cause an accident. Be
careful while moving backwards danger of tripping!
Do not touch the gearbox, as it may become hot during
operation – danger of burns!
ASSEMBLE
Assembling the handles
Clamping the cable with cable clip
3
4
Align the assembled handle frame with the lower handle.
Use the nuts and knobs to fix the assembled handle frame
and lower handles firmly together.
Clamp the cable in the cable clip on the frame.
Secure the power cable to the lower handle by using the
cable clips
cable clip on
the frame
assembled
handle frame
lower
handles
bolts
knobs

16
AFTER SALES SUPPORT 0345 605 2067
WARNING! Read all of the instructions of this
manual before attempting to connection the
power supply for your tool.
WARNING! If the insulation on a power cable or
extension lead is found to be cut or damaged,
do not touch it! Disconnect the power supply
immediately and have the damaged cable
replaced by authorized service agent.
WARNING! If operating the appliance in a damp
location is unavoidable, use a residual current
device(RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
WARNING! Use only extension cords suitable for
outdoor use, preferably with a high visibility
cable colour.
Always unwind all extension cables fully, coiled
cables can overheat and reduce the efciency
of your product.
NOTE! For extension cables up to 15metres, use
a wire cross section of 1.5mm2. For extension
cables over 15 meters but less than 40 meters,
use a wire cross section of 2.5 mm2.
WARNING! This product is designed to operate
on 230-240 VAC 50Hz.The voltage and current
must comply with the information on the
ratings label!
NOTE! This electric rotovator is tted with
a non-rewireable plug. If it is necessary to
change the fuse in the plug, the fuse cover
becomes lost or damaged, the plug must
not be used until a suitable replacement is
obtained.
WARNING! A 13amp fuse must be tted.
WARNING! Make sure the on/off switch is in its
off position.
PREPARE

17
AFTER SALES SUPPORT 0345 605 2067
PREPARE
1. Connecting the extension cord to a suitable socket
Double the extension cord, about a foot from the end. Push
the loop through the hole on the rear safe guard and hook
the loop over the cord restrainer(A). Gently pull on the cord
to ensure that it is firmly attached at the handle. Connect the
cable to a proper socket.
2.Switch on/off
WARNING! Rotating blades may cause serious
injury. The blades will continue to turn for a few
seconds after the tool has been switched OFF.
Do not touch the rotating blades. Contact with
hot components (i.e. motor housing, gear box,
etc.) on the machine may
Switching on
1. Press the lock button (A).
2. Hold the switch trigger (B) and release the switch button (A).
Switching off
Release the switch trigger (B).
Note! For your safety, this tool is equipped with a double switch
system. This system prevents starting the tool inadvertently.
You must press the switch button (A) firstly, and then hold the
switch trigger (B).
Never attempt to hold the switch trigger without pressing the
lock button first!
WARNING! Always wear safety gloves when
doing any work on the electric rotovator. Always
unplug the power cord from the power source
before doing any work on the electric rotovator.
A
B

18
AFTER SALES SUPPORT 0345 605 2067
OPERATE
WARNING! Do not touch the gearbox, as it may
become hot during operation.
WARNING! Always keep a rm grip on the
tool with both hands and watch your feet. The
blades may cause an accident. Be careful while
moving backwards –danger of tripping!
WANRING! To avoid damage to the tool:
Never lift or drag the tool with the motor
running.
Lift the tool while moving it over hard surfaces
such as tiles or steps.
NOTE: Switch the tool off after working with it
and for transport; disconnect from the mains
and wait for the blades to stop moving.
i. Walk the tool through the soil at normal pace and in as
straight a line as possible.
ii. Always work away from the mains socket. Make sure
that the cable is kept well away from the working area.
iii. OVERLOAD Protection: The motor will cut out
immediately if overloaded. The tool cannot be used
until it has completely cooled down again.Turn off the
machine. When the machine is completely cool down,
restart it again.

19
AFTER SALES SUPPORT 0345 605 2067
MAINTENANCE AND REPAIR
WARNING! Always switch the product off and
let the product cool down before performing
inspection, maintenance and cleaning work!
WARNING! Wear safety gloves when working
on the cutting blades and close to it!
IMPORTANT! The tool is tted with four tine
wheels (blades) that can easily be changed in
pairs. Both of the tine wheel pairs can be tted
on the left or right, as required. Purchase the
blades from authorised service center.
WARNING! Make sure that the blades (d) are
set to their proper turning direction. The arrows
on the gearbox and blades should point the
same way.
General
■Clean the product with a slightly damp cloth and pH-neutral
soap. Use a brush for areas that are hard to reach.
■In particular clean the air vents after every use with a cloth
and brush.
■Remove stubborn dirt with high pressure air (max. 3 bar).
■Check for worn or damaged parts. Replace worn parts as
necessary or contact an authorised service centre for repair
before using the product again.
■Regularly check for obvious defects such as loose,
dislodged or damaged cutting devices, loose fixings and
worn or damaged components.
■Check that safety guard are undamaged and correctly fitted.
Carry out necessary maintenance or repairs before using the
product.

20
AFTER SALES SUPPORT 0345 605 2067
MAINTENANCE
• Unscrew the hex bolt (b) and the self-locking nut (a) on
the tine wheel pair (d).
• Slide the tine-wheel pair off the driveshaft (c).
• Clean the driveshaft with biological oil.
• Slide the new blades onto the driveshaft with the holes
on the axles aligned to the holes on the driveshaft (c).
• Slide the hex bolt (b) through the hole and tighten on the
self-locking nut(a).
Cleaning the device
IMPORTANT!
■Wear protective gloves when cleaning or maintaining the machine.
■Do not use cleaning fluids or solvents or spray the machine down with
water(especially water under pressure) when cleaning the machine.
NOTE: After each use, follow these steps to properly clean the unit:
• Remove soil, dirt, and foliage stuck in the tines, drive shaft, tool
surface, and vents with a brush or dry cloth.
• Spray or rub biodegradable oil onto the tines.
• Clean soiled grips with a damp cloth. Always inspect the machine
for damaged and worn parts after each use. Check that safety
features (i.e. labels, guards, etc.) are in place. Check that nuts,
bolts, and screws are tight.
WARNING! Unexpected tine movement may
cause personal injury. Before servicing, repairing,
or inspecting the unit, turn the motor OFF and
disconnect the power. Wait for the tines to
completely stop rotating before conducting
inspection, cleaning, or maintenance. Before and
after each use, check the product and accessories
(or attachments) for wear and damage. When
necessary, only use identical replacement parts
that are approved by the manufacturer.
WARNING! Contact with hot components (e.g.
motor housing, gear box, etc.) on the machine may
cause burns. Allow the machine to cool off before
handling.
a
b
c
ba
d
