Speco ZIP2D Installation guide

Safety Information
This symbol indicates that dangerous voltage consisting a risk of electric shock is presentwithinthis unit.
This exclamation point symbol is intended to alert the user to the presence of important operating andmaintenance
(servicing) instructions in the literature accompanying the appliance.
To prevent damage which may result infire or electric shock hazard, donot expose this appliance to rain or
moisture.
1. Be sure to use only the standard adapter that is specified in the specification sheet.
Using anyotheradapter could cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or
damage to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal
heat generation or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
5. When installing the camera, fasten it securely and firmly. A falling camera may cause personal injury.
6. Do not place conductive objects (e.g. screw drivers, coins, metal things, etc.) or containers filled with
water ontop of the camera. Doing so may cause personal injurydue to fire, electric shock, or falling
objects.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DONOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TOQUALIFIED SERVICE PERSONNEL.
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
WARNING
WARNING
7. Do not install the unitin humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
8. If any unusual smells or smoke come from the unit, stop using the product. Insuch case, immediately
disconnect the power source and contact the service center. Continued use in such a condition may
cause fire or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never disassemble or
modify this product in any way.
10. When cleaning, do not spray waterdirectly onto parts of the product. Doing so may cause fire or
electric shock.
1. Do not drop objects on the product or apply strong shock to it. Keep away from a
location subject to excessive vibrationor magnetic interference.
2. Do not install in a location subject to high temperature (over Replace with 122 degrees F), low temperature
(below Replace with 14 degrees F), or high humidity. Doing so may cause fire or electric shock.
3.
then move or reinstall it.
4. Remove the power plug from the outlet when then there is a lightning. Neglecting to
do so may cause fire or damage to the product.
5. Keep out of direct sunlight and heat radiation sources. It may cause fire.
6. Install it in a place with good ventilation.
7. Avoid aiming the camera directly towardsextremely bright objects such as sun, as this
may damage the CMOS image sensor.
8. Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
9. The Mains plug is used as a disconnect device and shall stay readily operable at any
time.
CAUTION
Important Safety Instructions
12. apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or
objects have falleninto the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. Agrounding type plug has two
blades and a third grounding prong. The wide blade orthe third prong is providedfor your safety.
your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinchedparticularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11.
WARNING
Quick Manual
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the userwill be required to correct the interferenece at his own expense.
11. To disconnect power from the mains, pull out the mains cord plug. When install the product, ensure
that the plug is easily a ccessible.
Ver. 0.5 / 2013.11
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Indoor/Outdoor Flat Dome Camera
2.0MP Full-HD IP
1. Product & Accessories 3. Disassemble the Camera 4. Installation
2. Part Name
Template Sheet
Camera Cable
Screw &
Plastic Anchor-3pcs
Manual CD
Quick Manual
Template Sheet
for installing by Plate
Mount Bolt & Nut Mount Plate
Template Sheet
for installing by Bolt & Nut
Torx Wrench
Plate Hook
Mount Plate
DC Power Cable
Lens
Bottom Case
Gimbal
Reset Button
Tilt Stopper Screw
Dome Cover
RJ-45 Cable
2
3
4
5
6
7
Reset Button
1
2
6
7
3
4
5
Disassemble the camera. See the section
‘3. Disassemble the camera’ for details.
Using the template sheet, make the cabling
holes on the wall/ceiling.
Connect the network cable and power cable
respectively. See the section '7. Cabling' for
details.
Fix the bottom case on the ceiling.
To achieve desired view direction and
setting, tighten the tilt stopper screw.
Attach the dome cover to the bottom case.
cover.
1Detach the dome cover using the torx wrench
before installing
the camera.
Before installing your camera, you have to read the following cautions.
2. Don’t let the cable get caught in an improper place or the electric line cover get damaged. Otherwise it may
3. When installing your camera, don’t allow any person to approach the installation site.
If you have any valuable things under the place, move them away.
Reset to the Factory Default
Press the reset button for 5 seconds to return
the setup to the factory default.
Warning:
If you press the ‘Reset’ button, you will lose all
setting data.
If needed, please, make a note for further
installation.
ZIP2D

Template Sheet
5. Installation Using Mount Plate 6. Installation Using Mount Bolt & Nut 7. Cabling
Power
Ethernet cable
Ethernet cable
Two Options
Use a PoE-enabled switch to connect data and power through a single cable and begin
viewing and recording images instantly. A non-PoE switch will require an adaptor for
power transmission.
1. Using a PoE-Enabled Switch
The Camera is PoE-compliant, allowing
transmission of power and data via a single
Ethernet cable.
cables
used to power, record, or control the camera.
Follow the illustration below to connect the camera
to a PoE-enabled switch using an Ethernet cable.
2. Using a Non-PoE Switch
If a PoE-enabled switch is not used, use a power
adaptor for power transmission
and non-PoE
switch for data transmission.
Follow the illustrations below to connect the
camera without a PoE-enabled Switch.
switch using an Ethernet cable.
Disposal of Old Appliance
1. All electrical and electronic products should be disposed of separately form the
municipal waste stream in accordance to laws designated by the government or the
local authorities.
2. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
3. For more detailed information about disposal of your old appliance, please contact
Disassemble the camera. See the section
‘3. Disassemble the camera’ for details.
Using the template sheet, make the cabling
hole on the wall/ceiling.
the mount plate on the template sheet.
Connect the network cable and power cable
respectively.
See the section '7. Cabling' for details.
Fix the bottom case on the mount plate. Press
the 3 bezels on the bottom case of the camera till it
clicks and locks with the mount plate.
To achieve desired view direction and
setting, tighten the tilt stopper screw.
1
2
Attach the dome cover to the bottom case.
6
7
8
3
4
5
2
3
4
Template Sheet
5
6
7
8
Disassemble the camera. See the section
‘3. Disassemble the camera’ for details.
Using the template sheet, make the cabling
hole on the ceiling panel.
1
Insert the 2 mount bolts into bottom case of
camera.
3
2
Insert the mount bolts into template holes after
connecting the cable.
Fix the camera by tightening mount nuts to
mount bolts on the ceiling panel.
4
5
To achieve desired view direction and
setting, tighten the tilt stopper screw.
Attach the dome cover to the bottom case.
cover.
6
7
8
9. Web Viewer Screen
8. IP Camera Setup via SpecoTech Multi-Client CMS Software.
The menu settings for the ZIP2D can be set over network using SpecoTech Multi-Client CMS software.
Put the cursor of the mouse on the channel, which is connected to the site and right click on the mouse to
open the submenu. Then the following window is displayed as below. Select the IP CAMERA SETUP.
Then the setup window is displayed.
The specied menu screen is displayed on the upper left of the screen.
Enter the ID and Password of the IP Camera when prompted.
(NOTE: The default ID : “admin” and Password is “1111”)
Security
Live View using Internet Explorer
VIDEO Stream (MAIN/SUB)
Open Internet Explorer and enter camera’s IP address.
The system will ask for conrmation to install Active-X control.
Once authorized, the Internet Explorer will start to display video
images from camera as shown below
USER :
User can be registered and privilege level of a user can be specied.
Stream prole :
The standard denes various sets of capabilities, which are referred
to as proles, targeting specic classes of applications.
Resolution :
Select video compression resolution.
Frame rate :
Determine the maximum number of frames of video images
to compress.
Bit rate :
Selectable video Bit rate.
Maintenance
System restart
Pressing Reboot Server button will cause the system
to reboot.
Factory Default
Set all settings to the factory default values.
Save Cong to PC
All the setting of conguration can be stored.
Load Cong from PC
Stored conguration can be browsed and restored.
System
Event
Motion Detection :
Select Motion Detection function.
SET AREA :
Congure regions for motion detection.
Sensitivity :
Set the condition to trigger an event for motion detection.
Information
Manufacturer
Model Name
Serial Number
Hardware ID
Software Version
MAC Address
Network
Network Type :
Select the Network Type(DHCP, Static)
DHCP :
The address setting mode is automatic.
STATIC :
The address setting mode is manual. Input IP, Gateway,
Subnet Mask, and DNS IP
