Spectra Logic DAStape 100 Manual

FirmwareHistory
• Spectra2KLibrary
• Spectra2KiSCSILibrary
• DAStape
• iSCSItape

FirmwareHistory
2
Notices
Spectra Logic corporation provides the unit “as is” without warranty of any kind, either
expressed or implied, including but not limited to the implied warranties of
merchantability or fitness for a particular purpose. In no event shall Spectra Logic
corporation be liable for any loss of profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or consequential damages of
any kind, even if Spectra Logic corporation has been advised of the possibility of such
damages arising from any defect or error.
Information furnished in this Firmware History Document is believed to be accurate
and reliable. However, no responsibility is assumed by Spectra Logic Corporation for
its use. Due to continuing research and development, Spectra Logic Corporation may
revise this publication from time to time without notice, and reserves the right to
change any product specification at any time without notice.
Copyright © 2006 Spectra Logic Corporation. All rights reserved.

Contents
3
Notices.......................................................... 2
Spectra2KLibraryFirmwareHistory................................. 5
Firmware Level T1020.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Firmware Level T1019.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Firmware Level T1018.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Firmware Level T1017.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Firmware Level T1016.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Firmware Level T1015.00 and TE1015.00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Firmware Level T1014.00 and TS1014.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Firmware Level 1010.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Firmware Level 1008.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Firmware Level 1007.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Firmware Level 1005.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Firmware Level 1004.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Firmware Level 1002.02 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Firmware Level 1002.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Firmware Level 1001.05 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Firmware Level 1000.20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Firmware Level 1000.09 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Firmware Level 1000.07 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Firmware Level 1000.05 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Firmware Level 1000.02 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Contents
4
FibreChannelandEthernetFirmwareHistory ....................... 15
Firmware Level: 4.2.82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Firmware Level: 4.2.71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Firmware Level: 4.2.44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Firmware Level: 4.2.25.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Firmware Level: 4.1.37.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Firmware Level: 4.1.37.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Firmware Level: 4.1.35.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Firmware Level: 4.1.33.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Firmware Level: 4.1.31.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Firmware Level: 4.1.28.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Firmware Level: 4.1.8.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Firmware Level: 4.0.0.4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Firmware Level: 3.0.1.28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firmware Level: 3.0.1.24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firmware Level: 3.0.1.14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firmware Level: 2.20.1.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Firmware Level: 2.25.0.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Spectra2KLibraryFirmwareHistory
This section documents firmware from July 1997 (initial release) through 2004.
For information on firmware released after 2004, see the Release Notes for your
product, which are available on Spectra Logic’s web site.
To make sure that you have the most current versions of all product documentation,
check the electronic versions available on the Spectra Logic Web site at:
http://www.spectralogic.com/support/index.cfm/fuseaction/
displayProductDocs.
Note: You must disable backup software or disconnect the host before
performing a firmware update.
FirmwareLevelT1020.00
Released:November2002
ImprovementsandRepairedDefects
• Library no longer answers good to several LUNS. This was causing multiple
libraries to show to host.
• Stopped the carousel from occasionally hitting picker when rotating.
• Short Axis Robotics Error no longer appears with M2 drive firmware version V07.

Spectra2KLibraryFirmwareHistory
6
FirmwareLevelT1019.00
Released:July2002
ImprovementsandRepairedDefects
• Fixed 30-slot over rotation problem.
FirmwareLevelT1018.00
Released:April2002
ImprovementsandRepairedDefects
• The TCM code now has volume tag support.
FirmwareLevelT1017.00
Released:March2002
ImprovementsandRepairedDefects
• Serialization data is now returned correctly.
• Added CoD support.

Spectra2KLibraryFirmwareHistory
7
FirmwareLevelT1016.00
Released:December2001
ImprovementsandRepairedDefects
• AIT-3 Support (SDX-700C).
• Added new manufacturing tests.
• Fixed problem where inventory was corrupted if door open during initialization.
• This is required firmware for AIT-3 Treefrogs, but is not required for other
Treefrogs.
FirmwareLevelT1015.00andTE1015.00
Released:July2001
ImprovementsandRepairedDefects
• Host initiate unload command now performs the correct set of steps in stacker
mode (The robot moves the tape to the highest available slot and then gets the
next highest tape and puts it in the drive).
• Unit no longer hangs when receiving a reset during a non-immediate command.
FirmwareLevelT1014.00andTS1014.00
Released:May2001
ImprovementsandRepairedDefects
• Fixes inquiry string problem with SDX 500c tape drive reporting as Sony SDX
300c.

Spectra2KLibraryFirmwareHistory
8
FirmwareLevel1010.00
Released:January2001
ImprovementsandRepairedDefects
• Corrects length mismatch in call to test LunFlgLink.
• Corrects read element status returns.
• Request sense now returns correct data.
• Corrects barcode scanner sweep problems.
• Corrects jams when picker jaws are extended.
• Ecrix VXA-1 and Exabyte Mammoth2 drives now supported.
• Fixes picker problems created by implementation of new drives.
FirmwareLevel1008.00
Released:May2000
ImprovementsandRepaireddefects
• Jaws no longer slipping off tapes causing short axis retries to accumulate beyond
acceptable levels.
• Corrects long axis re-calibration.
FirmwareLevel1007.00
Released:November1999
ImprovementsandRepairedDefects
• Corrects problems with Dantz Retrospective software - read element status not
returning data if less than requested available.
• Returns move error if drive reports error on unload command.

Spectra2KLibraryFirmwareHistory
9
FirmwareLevel1005.00
Released:September1999
ImprovementscontainedinVersion1005.00
• Integrates AIT configurations.
• Adds support for drive S/N in read element status.
• Fixes reserve command breaks mode sense-detection problem in BackUpExe.
FirmwareLevel1004.00
Released:June1999
ImprovementsandRepairedDefects
• Corrects problem when library disconnected from drive.
• Adds AIT 2 support.
• Disconnected command now aborting on SCSI reset.
• Changes copyright to 1999.
• Supports fan control for TCM-3.
• Corrects problem with multiple initiators.
• Changes park problem with tapeware time-out on read element status.
FirmwareLevel1002.02
Released:February1999
ImprovementsandRepairedDefects
• Odds unload drive returns 02,30,00.
• Force code selects slot count when rotary flag is set
• Corrects stacker mode key switch problem.

Spectra2KLibraryFirmwareHistory
10
FirmwareLevel1002.00
Released:January1999
ImprovementsandRepairedDefects
• No longer fails to put tape in bottom drive.
• Correctly detects upside down tape during initialization.
• Changes all non-media movement SCSI commands to not disconnect.
• Resets stacker mode on door open.
• Allows stacker mode to do an inventory sweep before move attempt.
• Corrects manual stack operation problems.
• Stacker mode now stops on last tape.
• Corrects stacker mode parks between moves.
• Corrects short axis recalls on door open/close.
• Changes SCSI to polling and integrates soft reset.
• Makes barcode retry operation window smaller.
• Improves robotic step ramping.
• Removes open/closed loop detection on drive F/W.
• Race condition between disconnect and command process no longer causes hang.
• Issues soft reset on drive that returns check condition on unload.

Spectra2KLibraryFirmwareHistory
11
FirmwareLevel1001.05
Released:October1998
ImprovementsandRepairedDefects
• Corrects multiple initiator problem.
• Corrects clear log function.
• Corrects infinite retries on slipped off cartridge.
• Corrects library crash due to fast repeating SCSI commands.
• Enables library to easily recognize and recover from tapes entered upside down.
• Fixed move from drive with 3, 52, 0 sense hang.
• Corrects missing selections during initialization.
• Now recognizes tapes in slots 1 and 16 via serial port.
• Passes power-up with tape in picker.
• Enables prevent/allow media to report correctly.
• Allows SCSI reset to re-calibrate short axis on an open door status.
• Adds a drive read/write diagnostic test.
• Detects drive code version and runs a closed loop test if supported.
• Corrects log sensor output.
• Configuration in ASCII.
• Changes delay between load TUR.
• Finds missing SCSI selections.
• Drive load now waits when a busy response occurs.
• Eliminates unnecessary SAX retry noise.
• Corrects failures on unsuccessful unload attempts.
• Changes SCSI time-outs.
• Add a EXB-210 inquiry information barcode present status byte 55 bit 0.
• Detects tapes in drives at power-up.
• Corrects short axis error during pick at tape contact.
• Waits for drive ready after tape load.
• Detects drives at power-up with open door.

Spectra2KLibraryFirmwareHistory
12
FirmwareLevel1000.20
Released:May1998
ImprovementsandRepairedDefects
• Adds burn diagnostic test for opto-isolators.
• Corrects wrong axis error recovery.
• Removes check for tape in drive via SCSI after door close operations.
• Allows stacker mode to park on magazine un-mount request.
• Corrects undesirable retries on multiple SCSI move commands without park.
• Corrects rotary unit jams on drive reprogram.
• Integrates Sony AIT-1 drive.
• Corrects possible load failures with MIC media.
• Adds Spectra 4000 emulation setting switch to 14.

Spectra2KLibraryFirmwareHistory
13
FirmwareLevel1000.09
Released:October1997
ImprovementsandRepairedDefects
• Adds message levels that enable via serial port.
• Corrects Exabyte loading jam on faceplate.
• Corrects slow slot pull due to invalid offset.
• Disables inventory sensor when not in use.
• Matches engineering changes used by manufacturing.
• Corrects SCSI hang during Cheyenne backups.
• Corrects SCSI hang on multiple send/ receive diagnostic commands.
• Adds serial command for clearing trace buffer.
• Corrects drive load jam due to tape door catching on drive heads.
• Corrects slow push logging error for drive 2 on drive 1.
• Removes position offset limit.
• Adds diagnostic menu pick to enable inventory sensors.
FirmwareLevel1000.07
Released:October1997
ImprovementsandRepairedDefects
• Corrects initial burn test failures.
• Corrects retry log.
• Corrects long axis turn around failures.
• Corrects SCSI diagnostics.
• Allows retention operations to function with Exabyte drives.

Spectra2KLibraryFirmwareHistory
14
FirmwareLevel1000.05
FirstFormalRelease:August1997
ImprovementsandRepairedDefects
• Changes park operation for temporary park position drive.
• Changes recovery from move interrupted by open door.
• Corrects diagnostic menu, random exchange now using correct drive count.
• Sets up BurnTestPass to three states - not executed/ pass/ fail.
• Changes default inquiry string to Spectra 215.
• Removes inquiry select from manufacturing information menu.
• Corrects magazine load test looping.
• Corrects demonstration mode looping.
FirmwareLevel1000.02
InitialRelease:July1997

FibreChannelandEthernetFirmwareHistory
forSpectra2KiSCSILibrariesandiSCSItape
This section documents firmware from October 2000 (initial release) through 2004.
For information on firmware released after 2004, see the Release Notes for your
product, which are available on Spectra Logic’s web site.
To make sure that you have the most current versions of all product documentation,
check the electronic versions available on the Spectra Logic Web site at:
http://www.spectralogic.com/support/index.cfm/fuseaction/
displayProductDocs.
Note: You must disable backup software or disconnect the host before
performing a firmware update.

FibreChannelandEthernetFirmwareHistory
16
FirmwareLevel:4.2.82
Released:April2004
EnhancedFeatures:
• Added DNS.
• Added Firmware Upgrade via product Web page.
IssuesResolved:
• Usermenu allows escape at all prompts.
• Ethernet based protocols will now work when DHCP server is not reachable or is
slow.
• DMON: “trace iocb err” now reports errors with iSCSI.
• DMON: the command “set port enable” now enables on a per device basis.
• DMON: issuing a “show SCSI” will no longer cause all commands to hang on
tape0.
• DMON: Enhance dmon commands including automated DUMP command
• iSCSI: Sending AuthMethod with NULL Parameter no longer returns 2 responses.
• iSCSI Login: Vendor X-keys exceeding 63 characters are now rejected.
• iSCSI: Aborted Commands not being cleared to all devices.
• iSCSI: Sending Parameter with Value = “?” no longer returns a valid option.
• SCSI tracing for a single device has been enabled.
• Device Serialization no longer resets to disabled if changer not found.
• Disabled ITP menu item in Usermenu.
• Added DNS functionality to Treck.
• Added DNS configuration to Web pages.
• DNS configuration added to the Usermenu and DMON.
• Flash parameters added and DMON GET and SET functions need updated.
• Added changes to support LCM updates to support iSCSI, iSNS, NDMP, and new
diagnostics.
• Added capability to upgrade firmware via product Web page for Treefrog (Spectra
2K) libraries and NAStape (now iSCSItape).

FibreChannelandEthernetFirmwareHistory
17
• NAStape (now iSCSItape): going to Configuration > Protocol web page no longer
crashes web server.
• Webserver no longer crashes when connected to the internet.
• WEB: Ethernet configuration no longer allows invalid Gateway address (0.0.0.0).
• WEB: Ethernet parameters no longer allow IP of 0.0.0.0 for WINS Server.
• WEB: Proxy options for Web download now working properly.
• WEB: Clicking Configuration > interface button no longer adds port for each
click.
• WEB: Added <BR> tags to Configuration > upgrade info text.
• WEB: Changed color of text in Configuration > Upgrade page when all is OK.
• WEB: With DHCP enabled, a reset enters the wrong hostname.
• Added secondary WINS server in DMON Usermenu.
• Updated Web page help for iSNS.
• iSNS no longer connecting to iSNS server when iSCSI is disabled.
• Changed firmware download to check product, interface, code level.
• WEB: fixed various problems when logged in as “USER”.
• WEB: updated the help file with the code upgrade page.
• Various DHCP issues resolved.
• Various iSCSI issues resolved.

FibreChannelandEthernetFirmwareHistory
18
FirmwareLevel:4.2.71
Released:December2003
EnhancedFeatures:
• WEB: HTTP interface now has “cancel” buttons.
• iSCSI has replaced ITP as default Ethernet protocol.
IssuesResolved:
• Unit now reports BUSY during abort processing.
• Changed text in Options Enablement.
• DMON: “show performance” now shows total MB/sec. for ITP and iSCSI.
• DHCP now registering hostname on server.
• WEB: If any IP address/Gateway entered fails firmware checks, a Web message is
posted.
• WEB: USER list from DMON can now be seen and edited.
• iSCSI: Draft 8 support option has been removed.
• WEB: Interface no longer allows user names longer than 32 characters.
• WEB: Restart in Web page now returns user to login page.
• iSCSI: Display Header/Data Digest Negotiation from DMON.
• DMON: iSCSI CHAP authentication can now be disabled.
• DMON: Entering “show pci” from DMON no longer causes endless loop.
• Removed COD feature.
• WEB: After changing an ethernet parameter WINS IP addresses no longer gets
corrupted.
• WEB: Editing superuser password no longer corrupts privilege level.
• WEB: Attempting to change iSCSI Authentication and Digest via Web no longer
fails.
• DMON: DHCP WINS address now displays in “show ip” command.
• DMON: “show flash” now shows the correct “Hardware Rev”.
• WEB: It is no longer possible to edit a username longer than 32 characters.
• iSCSI: Fixed incorrect response on NO LUN inquiry.

FibreChannelandEthernetFirmwareHistory
19
• iSCSI: Data no longer aborts after b8 issued.
• PCI discovery no longer yields incorrect ethernet devices.
• Added usermenu and Web interface methods for iSNS configuration.
• iSCSI: Issuing a MODE SELECT with no list length no longer causes “Internal
Error”.
• iSCSI: Web Interface “Ethernet Port 0” link no longer shows garbled information.
• Added clear identifier for Superhawk 400 MHz and 600 MHz boards.
• iSCSI: Web Interface no longer crashes after CRC enabled.
• Added secondary WINS server in DMON Usermenu.
• iSCSI: Aborted commands are now being cleared to all devices.
• WEB: When board resets, the Web now detects and forces re-login.
• iSCSI: Sending parameter with Value = “?” no longer returns a valid option.
• Erase User Parms now affects serialization state.
• WEB: Web page help updated for iSNS.
• WEB: iSCSI and iSNS ports greater than 65535 no longer reset port to another
number.
• iSNS: Invalid iSNS server causes board to wait 60 seconds before timing out.
• iSNS: Condor is now reporting all devices to iSNS server.
• WEB: With DHCP enabled, a reset no longer enters the wrong hostname.
• iSNS: With iSCSI disabled, iSNS is no longer trying to connect to iSNS server.
• iSCSI: Invalid dataout headers are now Rejected.
• NAStape (now iSCSItape): The DVCID page no longer allows access to the change
button.
• WEB: Updated help with iSNS information and other related information.
• WEB: Logging out no longer flashes a screen that says “Access Error”.
• iSCSI: DMON: When iSNS is disabled, the command “iscsi deregister” now works
properly.
• WEB: Removed “2000h” from General Status page.
• iSCSI: Intel HBA no longer loses device after failed write.
• iSCSI: Aborted commands with Intel HBA no longer causes crash.
• iSCSI: Login - Vendor X-keys exceeding 63 chars are rejected.

FibreChannelandEthernetFirmwareHistory
20
• iSCSI: Data aborts no longer occurring after drive aborts from bad tapes.
• iSCSI: Data corruption occurs when zero copy active.
• Various MS qualification issues resolved.
• Fixed various iSCSI issues.
FirmwareLevel:4.2.44
Released:April2003
EnhancedFeatures:
• Added support for iSCSI.
IssuesResolved:
• Options enablement now consistent between for ITP, NDMP and iSCSI.
• HTML page updated for 4.2 code.
• Enabled CHAP authentication.
• Fixed AIT drive emulation.
• Added help files on new Web interface.
• XCOPY can now be enabled without having to cycle library power.
