Leica CS20 User manual

Leica CS20 &
GS Sensors
Quick Guide
Version 2.0.0

de
en
fr
es
it
pt
nl
da
no
sv
fi
et
lv
lt

Leica CS20 &
GS Sensors
Quick Guide
Version 2.0
English

2
CS20, Important Information about your Instrument
en
1 Important Information about your Instrument
Read and follow the User Manual on the accompanying USB card before using the
product.
Keep for future reference!
Intended use • Remote control of product.
• Data communication with external appliances.
• Recording measurements.
• Computing with software.
• Carrying out measurement tasks using various GNSS measuring techniques.
• Recording GNSS and point related data.
• Measuring raw data and computing coordinates using carrier phase and code
signal from GNSS satellites.
Laser Products The CS20 instrument contains the following laser products:
The classification is in accordance with IEC 60825-1 (2014-05).
Laser product Laser class
DISTO module Class 2

CS20, Important Information about your Instrument 3
en
CAUTION From a safety perspective, class 2 laser products are not inherently safe for the eyes.
Precautions:
1) Avoid staring into the beam or viewing it through optical instruments.
2) Avoid pointing the beam at other people or at animals.
Labelling and
Location of Laser
Aperture
008577_001

4
CS20, Important Information about your Instrument
en
The following advice is only valid for power adapter or docking station.
WARNING The product is not designed for use under wet and severe conditions. If unit becomes
wet it may cause you to receive an electric shock.
Precautions:
Use the product only in dry environments, for example in buildings or vehicles. Protect
the product against humidity. If the product becomes humid, it must not be used!
Laser Radiation
Do not stare into the beam.
Class 2 Laser Product according to
IEC 60825-1 (2014 - 05)
Po 0.95 mW
= 620 nm - 690 nm
a) Laser beam
008468_001
a

CS20, Important Information about your Instrument 5
en
The product must not be disposed with household waste.
Conformity to
national
regulations
For products which do not fall under R&TTE directive:
Hereby, Leica Geosystems AG, declares that the product/s is/are in
compliance with the essential requirements and other relevant provi-
sions of the applicable European Directives. The declaration of
conformity can be consulted at
http://www.leica-geosystems.com/ce.

6
CS20, Important Information about your Instrument
en
Conformity to
national
regulations
• FCC Part 15, 22, 24 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the products CS20, CTR20, GS08plus,
AS05 and AS10 are in compliance with the essential requirements and other rele-
vant provisions of Directive 1999/5/EC and other applicable European Directives.
The declaration of conformity can be consulted at
http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE)
can be placed on the market and be put into service without restric-
tions in any EEA member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15 or European directive 1999/5/EC has to be approved prior to use and
operation.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
– This device is granted pursuant to the Japanese Radio Law and the Japanese
Telecommunications Business Law.
– This device should not be modified (otherwise the granted designation
number will become invalid).

CS20, Instrument Components 7
en
2 Instrument Components
Upside of CS20
a) DISTO with camera
b) Screen
c) Keyboard
d) Connector cover
e) Power socket
f) SD card slot
g) USB A host port
h) LEMO port (USB and serial)
008471_001
a
b
c
e
f
d
g
h

8
CS20, Instrument Components
en
Underside of CS20
a) Hand strap
b) Thread for screwing on hand
strap or utility hook
c) Expansion cover
d) Digital camera with flash
e) Stylus
f) Battery compartment
g) SIM card slot under the battery
h) Socket for fastening clip of the
hand strap
i) Tether for the stylus
008472_001
a
b
c
h
e
f
d
g
i

CS20, Instrument Components 9
en
Keyboard Display
a) Function keys F1 - F6
b) Arrow keys
c) ESC
d) OK
e) Home
f) Fn
g) Numeric keys
h) ± key
i) ON/OFF
j) CAPS Lock
k) Cameras
l) Favourites
m) ENTER
n) Function keys F7 - F12;
Backspace
o) Alpha keys
p) ENTER
q) SPACE
008473_001
a
b
c
e
f
d
g
h
i
j
k
l
m
n
o
p
q

10
CS20, Instrument Components
en
GS08plus
components
a) ON/OFF button
b) LEDs
c) LEMO port including USB port
d) Mechanical Reference Plane (MRP)
e) Battery compartment
004097_002
a
b
c
d
e

CS20, Technical Data 11
en
3 Technical Data
Environmental
Specifications
Temperature
Protection against water, dust and sand
IP68 (IEC 60529)
CS20 is in compliance with IP68 only when expansion cover, connector cover
and battery cover are closed.
Humidity
Up to 95 %. Up to 100 % (GS08plus).
The effects of condensation are to be effectively counteracted by periodically drying
out the instrument.
Type Operating temperature [°C] Storage temperature [°C]
CS20 -30 to +60 -40 to +80
Internal Battery -30 to +60 -40 to +70
GS08plus -40 to +65 -40 to +80

12
CS20, Care and Transport
en
4 Care and Transport
Care and transport • Carry the product in its original container or carry the tripod with its legs splayed
across your shoulder, to protect the product against shock and vibration.
• Periodically carry out test measurements and perform the field adjustments indi-
cated in the User Manual, particularly after the product has been dropped, stored
for long periods or transported.

CS20, Care and Transport 13
en
DISTO Window
008590_001

14
CS20, Operation
en
5 Operation
The battery must be charged before using it for the first time.
Turning the
Instrument ON and
OFF
ON
OFF
2
3
4
8
91
10
7b
7a
6a
6b
5b
5a
008593_001

CS20, Operation 15
en
Turning on and off
the GS08plus
12
ON
OFF
004096_002
4
3
5

Leica Geosystems AG
Heinrich-Wild-Strasse
CH-9435 Heerbrugg
Switzerland
Phone [phone]
www.leica-geosystems.com
819170-2.0.0en
Original text
Printed in Switzerland
© 2016 Leica Geosystems AG, Heerbrugg, Switzerland
