Spectrex SharpEye 40 Series User manual

Manual
00909-0100-4975, Rev AC
September2023
Spectrex SharpEye™ 40/40C and 40/40D
Series
Flame Detectors

Legal notice
The device described in this document is the property of Emerson.
No part of the hardware, software, or documentation may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or by any means, without prior
written permission from Emerson.
While great efforts have been made to ensure the accuracy and clarity of this document, Emerson assumes no liability
resulting from any omissions in this document or from misuse of the information obtained herein. The information in
this document has been carefully checked and is believed to be entirely reliable with all of the necessary information
included. Emerson reserves the right to make changes to any products described herein to improve reliability,
function, or design and reserves the right to revise this document and make changes from time to time in content
hereof with no obligation to notify any persons of revisions or changes. Emerson does not assume any liability arising
out of the application or any use of any product or circuit described herein; neither does it convey license under its
patent rights or the rights of others.
Safety precautions
WARNING
Follow installation guidelines.
Failure to follow these installation guidelines could result in death or serious injury.
Ensure that only qualified personnel perform the installation.
WARNING
Do not open the housing while the power is on.
WARNING
Physical access
Unauthorized personnel may potentially cause significant damage to and/or misconfiguration of end users’
equipment. This could be intentional or unintentional and needs to be protected against.
Physical security is an important part of any security program and fundamental to protecting your system. Restrict
physical access by unauthorized personnel to protect end users’ assets. This is true for all systems used within the
facility.
NOTICE
Disconnect external devices, such as fire alarms and automatic extinguishing systems, before performing
maintenance.
•Do not expose the detector to radiation of any kind unless required for testing purposes.
•Do not open the electronic compartment. Keep this part closed at all times. It can only be opened in the factory.
Opening the electronic component side invalidates the warranty.
•Only access the wiring compartment to wire or remove the detector or access RS-485 terminals for maintenance.
2

Abbreviations and acronyms
Abbreviation or acronym Definition
ATEX Atmospheric explosives
AWG American wire gauge
BIT Built-in test
EMC Electromagnetic compatibility
EOL End of line
FOV Field of view
HART®Highway addressable remote transducer - communication protocol
IAD Immune at any distance
IECEx International Electrotechnical Commission Explosion
IPA Isopropyl alcohol
IR Infrared
JP5 Type of jet fuel
Latching Refers to relays remaining in the ON state even after the ON condition has
been removed.
LED Light emitting diode
LPG Liquified petroleum gas
mA Milliamps (0.001 amps)
Modbus®Master-slave messaging structure
N/A Not applicable
NFPA National Fire Protection Association
NPT National pipe thread
RS485 Communication protocol allowing bi-directional communication
PN Part number
SIL Safety integrity level
UNC Unified coarse thread
VAC Volts alternating current
VDC Volts direct current
3

4

Contents
Chapter 1 Introduction...............................................................................................................................7
1.1 Product overview.........................................................................................................................7
1.2 Models.......................................................................................................................................... 7
Chapter 2 Installation...............................................................................................................................11
2.1 Installation guidelines.............................................................................................................. 11
2.2 Preparation for use................................................................................................................... 11
2.3 Attach detector to tilt mount................................................................................................... 16
2.4 Open the back cover................................................................................................................. 17
2.5 Wire terminals and ground cable............................................................................................19
2.6 Install the protective cover.......................................................................................................24
2.7 Aim the detector........................................................................................................................24
2.8 Changing default detector settings ....................................................................................... 25
Chapter 3 Operation................................................................................................................................. 27
3.1 Power up the detector.............................................................................................................. 27
3.2 Testing procedures................................................................................................................... 27
Chapter 4 Initial setup..............................................................................................................................29
4.1 Continuous feature test............................................................................................................29
4.2 Response to fault indication.................................................................................................... 29
4.3 Built-in test (BIT)........................................................................................................................ 30
Chapter 5 Maintenance............................................................................................................................31
5.1 Keeping maintenance records.................................................................................................31
5.2 Clean the detector.....................................................................................................................31
Chapter 6 Troubleshooting...................................................................................................................... 33
6.1 Light-emitting diode (LED) is off, fault relay is open, 0-20 mA shows 0 mA, analog
voltage output is 0 V...................................................................................................................33
6.2 Light-emitting diode (LED) flashes yellow at 4 Hz, fault relay is open, 0-20 mA
shows 1 mA................................................................................................................................. 33
6.3 Light-emitting diode (LED) flashes yellow at 4 Hz, relay is open, 0-20 mA shows 2 mA.. 33
6.4 Light-emitting diode (LED) constantly red, alarm relay energized, 0-20 mA
indicates alarm............................................................................................................................34
6.5 No HART® communication, 0-20 mA shows 0 mA.................................................................34
Chapter 7 Specifications...........................................................................................................................35
7.1 Technical specifications............................................................................................................ 35
7.2 Electrical specifications.............................................................................................................39
7.3 Mechanical specifications.........................................................................................................41
Appendix A Reference data........................................................................................................................ 43
A.1 Ordering information, specifications, dimensional drawings, and installation
drawings...................................................................................................................................... 43
A.2 Product certifications................................................................................................................43
Manual Contents
00909-0100-4975 September2023
SharpEye 40/40 5

Appendix B FM fuel test responses ...........................................................................................................45
Appendix C Immunity to false alarm sources.......................................................................................... 47
Contents Manual
September2023 00909-0100-4975
6 Spectrex.net

1 Introduction
1.1 Product overview
The SharpEye 40/40 series is based on proven Spectrex technologies, including triple
infrared (IR3) and ultraviolet infrared (UV/IR). The SharpEye 40/40 series features
QuadSense™ technology, providing the fastest response to fire, longest distance detection,
and revolutionary UV/IR technology, coupled with superior immunity to false alarms,
functioning in harsh conditions with unparalleled reliability and durability.
The series is suited to meet the challenges of wide range of industrial and commercial
applications with long distance and fast response detection, providing superior protection
of high value property and personnel to keep a SharpEye on your safety.
Detection performance can be easily adapted to all environments, applications, and
requirements, by changing the detector’s configuration parameters. Adjusting these
parameters, as well as performing other maintenance and monitoring tasks, is possible
by means of RS-485-based Modbus® communication or HART® communication.
1.2 Models
The SharpEye 40/40 Flame Detectors are electro-optical devices designed to identify fire
events, enabling alarm activation. The detectors are intended for indoor or outdoor use
and can be used stand alone or connected to an alarm or automatic extinguishing system.
The SharpEye 40/40 series comprises the following detectors:
SharpEye 40/40C-I
The SharpEye 40/40C-I Multispectrum Quad-Sense™ Flame Detector detects hydrocarbon
fuel and gas fires with enhanced performance, advanced long distance detection of
hydrocarbon fires, fast detection in under five seconds, and strengthened reliability. The
SharpEye 40/40C-I is based on proven triple infrared (IR3) technology, ensuring high
sensitivity with superior immunity to false alarms.
SharpEye 40/40C-M
The SharpEye 40/40C-M Multispectrum Quad-Sense IR Flame Detector is specifically
designed for the detection of hydrocarbon and hydrogen flames with enhanced
performance, advanced long distance detection of hydrogen and hydrocarbon fires, fast
detection in under five seconds, and strengthened reliability. The SharpEye 40/40C-M
is based on proven triple IR (IR3) technology, ensuring high sensitivity with superior
immunity to false alarms.
SharpEye 40/40C-LB
The SharpEye 40/40C-LB Dual Spectrum Ultraviolet (UV)/IR Flame Detector is designed to
provide fast detection in under five seconds of a range of fires, such as hydrocarbon-based
fuel and gas, hyrdoxyl, hydrogen, metal, and inorganic.
SharpEye 40/40C-L4B
The SharpEye 40/40C-L4B Dual Spectrum UV/IR Flame Detector is designed to provide fast
detection in under five seconds of hydrocarbon-based fuel and gas fires.
Manual Introduction
00909-0100-4975 September2023
SharpEye 40/40 7

SharpEye 40/40D-I
The SharpEye 40/40D-I Ultra Fast Multispectrum Quad-sense IR3 flame detector provides
superior, longest distance detection of hydrocarbon fires at up to 300 ft (90 m), exceptional
ultra-fast detection in under 50 msec, and unparalleled reliability. The SharpEye 40/40D-I is
based on proven Triple IR (IR3) technology, ensuring highest sensitivity with best immunity
to false alarms.
SharpEye 40/40D-M
The SharpEye 40/40D-M Multispectrum Quad-Sense IR Flame Detector provides superior,
longest distance detection of hydrogen (at up to 165 ft [50 m]) and hydrocarbon (at up
to 300 ft [90 m]) fires, exceptional ultra-fast detection in under 50 msec, and unparalleled
reliability. The SharpEye 40/40D-M is designed to deal with the challenges of invisible fires
based on proven IR3 technology, ensuring highest sensitivity with best immunity to false
alarms.
SharpEye 40/40D-LB
The SharpEye 40/40D-LB Ultra Fast UV/IR Flame Detector can detect fire in under 20 msec
and features a unique dual sensor with selectable UV and IR channels that can be used
separately or combined. The detector is designed to detect a range of fires, such as
hydrocarbon-based fuel and gas, hydroxyl, hydrogen, metal, and inorganic.
SharpEye 40/40D-L4B
The SharpEye 40/40D-L4B Ultra Fast UV/IR Flame Detector can detect fire in under 20 msec
and features a unique dual sensor with selectable UV and IR channels that can be used
separately or combined. The detector is designed to detect hydrocarbon-based fuel and
gas fires.
Table 1-1: SharpEye 40/40 Series general technical specifications
Spectral response Infrared and ultraviolet bands
Response time Varies according to model, typically under 5 seconds
Field of view Varies according to model, up to 100 degrees
Output 4-20 mA, relays, communication
Enclosure Stainless steel 316 or aluminum polyurethane painted
Operating voltage 18-32 VDC
Maximum power rating 9.6 W
Relay contacts 2A/30 VDC
Over voltage category 2
Relative humidity Non-condensing relative humidity up to 100%
Table 1-2: Typical current consumption
Typical current
consumption
40/40C-I
40/40C-M
40/40C-LB
40/40C-L4B
40/40D-I
40/40D-M
40/40D-LB
40/40D-L4B
Normal power
consumption
without heater -
mA (Watts)
60 (1.4) 90 (2.2) 60 (1.4) 90 (2.2)
Introduction Manual
September2023 00909-0100-4975
8 Spectrex.net

Table 1-2: Typical current consumption (continued)
Typical current
consumption
40/40C-I
40/40C-M
40/40C-LB
40/40C-L4B
40/40D-I
40/40D-M
40/40D-LB
40/40D-L4B
Normal power
consumption
without heater
with alarm - mA
(Watts)
90 (2.2) 120 (2.9) 90 (2.2) 120 (2.9)
Low power heater
with alarm - mA
(Watts)
N/A N/A 140 (3.4) 180 (4.3)
Standard power
mode heater with
alarm - mA (Watts)
280 (6.7) 320 (7.7) 280 (6.7) 320 (7.7)
NOTICE
•If the product is used outside of specified limits, this voids the product certification, and
our company is not responsible for any incurred warranty expense.
•Do not open this product, except for the terminal compartment as listed in this
document, under any circumstances.
•The detector is not field-repairable. Do not attempt to modify or repair the internal
circuits or change their settings, as this will impair the system's performance and void
the product warranty.
•Opening the attachment screws to dismantle the front part of the detector from
remaining parts is restricted and voids the product warranty.
Manual Introduction
00909-0100-4975 September2023
SharpEye 40/40 9

Introduction Manual
September2023 00909-0100-4975
10 Spectrex.net

2 Installation
2.1 Installation guidelines
Installation should comply with the National Fire Protection Association (NFPA) 72E or any
other local and international regulations and standards, as applicable to flame detectors
and installation of Ex approved products. To ensure optimal performance and efficient
installation, consider the following guidelines.
Sensitivity
To determine the level of sensitivity, consider the following:
•Size of fire at the required distance to be detected
•Type of flammable materials
•Proximity to false alarm sources
Wiring
The wire gauge must be designed according to the distance from the detector to the
controller and the number of detectors on the same power line.
To fully comply with EMC directive and protect against interference caused by radio
frequency interference (RFI) and electromagnetic interference (EMI), the cable to the
detector must be shielded and the detector must be grounded. The shield should be
grounded at the detector end.
Spacing and location
The number of detectors and their locations in the protected area are determined by:
•Size of the protected area
•Sensitivity of the detectors
•Obstructed lines of sight
•Cone of view of the detectors
Environment
Dust, snow, or rain can reduce the detector’s sensitivity and require more maintenance
activities.
The presence of high intensity emission sources may affect sensitivity.
2.2 Preparation for use
The installation sequence may vary according to the physical structure of the site.
Note
Installation steps are also detailed in the Spectrex 40/40 Quick Start Guide supplied with
the detector.
The following tools are required for installation. These are standard tools and are not
supplied with the detector.
Manual Installation
00909-0100-4975 September2023
SharpEye 40/40 11

Table 2-1: Required tools
Tool Function
Hex key 1.5 mm Fasten back cover security screw.
Hex key 6 mm Adjust the tilt mount.
Hex key 10 mm Affix the detector to the tilt mount.
Hex key ⅛-in Attach protective cover to detector.
Flat screwdriver 6 mm Connect ground terminal.
Flat screwdriver 2.5 mm Connect wires to the terminal blocks.
Hex key ⅜-in Stop plug ¾-in. NPT.
Open wrench 28 mm Stop plug M25 only.
2.2.1 Field of view
Figure 2-1: Horizontal field of view forSharpEye 40/40C-I, C-LB, C-L4B, D-I, D-LB, and D-
L4B
Installation Manual
September2023 00909-0100-4975
12 Spectrex.net

Figure 2-2: Vertical field of view for SharpEye 40/40C-I, C-LB, C-L4B, D-I, D-LB, and D-
L4B
•+50 ° (down)
•-45 ° (up)
Gasoline
For SharpEye 40/40C-M and D-M
•Horizontal: 80 °
•Vertical: 80 °
Manual Installation
00909-0100-4975 September2023
SharpEye 40/40 13

Figure 2-3: Vertical and horizontal field of view for gasoline
Hydrogen
For SharpEye 40/40C-M and D-M
•Horizontal: 90°
•Vertical: 90°
Figure 2-4: Horizontal field of view for hydrogen
Installation Manual
September2023 00909-0100-4975
14 Spectrex.net

Figure 2-5: Vertical field of view for hydrogen
Manual Installation
00909-0100-4975 September2023
SharpEye 40/40 15

2.3 Attach detector to tilt mount
Figure 2-6: Tilt mount
A. Tilt holding plate
B. Horizontal locking screw
C. Tilt mount
D. Vertical locking screw
E. Detector holding plate
Figure 2-7: Tilt mount with dimensions
Procedure
1. Unpack the detector.
2. The device is provided with two plastic plugs (See image below). The stainless-steel
stop plug used to seal the unused conduit will be included in the device.
Remember, seal the detector with the stainless-steel plug before use. Refrain from
losing the plug in any case
Installation Manual
September2023 00909-0100-4975
16 Spectrex.net

A. Detector with two plastic plugs
B. Product packaging with stainless-steel plug attachment
3. Insert location pins on the tilt mount into the openings on detector housing.
4. Thread the holding screw and tighten it.
Note
To change the detector field of view, release the horizontal and vertical locking
screws.
5. Point the detector toward the protected area and ensure the view of the area is
unobstructed.
6. Secure the detector in that position by tightening the locking screws on the tilt
mount.
The detector is now correctly located, aligned, and ready to be connected to the
system.
2.4 Open the back cover
Procedure
1. Loosen the back cover security screw.
Manual Installation
00909-0100-4975 September2023
SharpEye 40/40 17

A. Back cover security screw
B. Protective plug
2. Unscrew the back cover.
Note
The back cover is attached by a security cable.
3. Remove the protective plug.
Installation Manual
September2023 00909-0100-4975
18 Spectrex.net

2.5 Wire terminals and ground cable
NOTICE
Improper wiring may damage the detector.
Procedure
1. Connect the terminals according to Table 2-2.
The terminal details are also on the inside back cover.
Figure 2-8: Terminal box
Manual Installation
00909-0100-4975 September2023
SharpEye 40/40 19

Table 2-2: Terminal box
Terminal Function
T1 24 VDC (+)
T2 24 VDC (-)
T3 External built-in test (BIT) switch
T4 Fault relay - normally open (NO)
T5 Fault relay
T6 Fault relay - normally closed (NC)
T7 Alarm relay - NO
T8 Alarm relay
T9 Alarm relay - NC
T10 0-20 mA (+)
T11 0-20 mA (-)
T12 Alarm output
(40/40D models)
T13 RS-485 (+)
T14 RS-485 (-)
T15 Accessory relay - normally open
T16 Accessory relay
T17 Accessory relay - normally closed
When the fault relay wiring option is NC, the relay contact is open in normal status
(energized) and closed in fault status (de-energized).
When the fault relay wiring option is NO, the relay contact is closed in normal status
(energized) and open in fault status (de-energized).
When the alarm/accessories relay wiring option is NC, the relay contact is closed in
normal status (de-energized) and open in alarm status (energized).
When the alarm/accessories relay wiring option is NO, the relay contact is open in
normal status (de-energized) and closed in alarm status (energized).
2. Use Figure 2-9, Figure 2-10, Figure 2-11, and Figure 2-12 for typical wiring
configurations.
Installation Manual
September2023 00909-0100-4975
20 Spectrex.net
