Spectronics MiniMo User manual

Sending a MiniMO or MightyMO card in for a software upgrade
Before sending in a MiniMO or MightyMO card for a software upgrade you will
need to save your pages as a package. All changes you have made will be lost
during the upgrade unless you do this. A simple backup will not save your voice
recordings, so your pages need to be saved as a package or otherwise you will
need to re-do your recordings. Please follow the steps below to make a
package. If you are unable to successfully do this please inform us of this when
you send the card in to be upgraded.
If at any stage you have difficulties with any part of this process please feel free
to call us for further assistance.
To package your pages on a MiniMO or MightyMO
1. Put your USB stick in one of the USB ports on the device.
2. Press the blue Setup button on the title bar to open the Mo Setup window.
3. Press Page Browser to open the Page Browser menu.
4. Select the folder that contains pages that will be included in the package
in the left side of the window.
5. In the right sides of the window select the check box beside each page
that will be included in the package OR put a cross in the Select All option
if all pages in the selected folder will be a part of the package.
6. Select Sharing Operations to open the Sharing Operations menu.
7. Select Package from Pages to open the Enter Package Name menu.
8. Put a cross in the Show All Directories check box. Additional storage will
be displayed in the left viewport. The USB stick will show up as
UMS_FOLDER. Make sure you select this. It should turn grey when it has
been selected.
9. Press in the empty text box down the bottom next to Name to open the
system keyboard window.
10. Use the system keyboard to enter a name for the package.
11. Select OK to create the package.
12. The Select Files for Package menu will close. A window will open with the
message: “Creating package. Please wait.” Then, the window with the
message will close.
13. Select OK to close the window with the message.

14. Select OK to close the Page Browser menu.
15. Select OK to close the Mo Setup menu.
16. Put your USB stick in a computer to check that the package has been
saved on the stick.
Removing the card
1. Use the power button to turn the device off.
2. Use a regular flathead screwdriver to loosen the two screws on the dark
plastic panel on the top front of the device.
3. Remove the dark plastic panel.
4. Remove the top storage card from the top slot in the device. Generally,
this is a 256MB storage card.
5. Replace the black plastic panel and tighten the screws.
You will now not be able to use the device until the card is returned to you.
Please put bubble wrap around the card to protect it and send the card and
your return postage details to:
Spectronics
Attn: Mikaela Kroesen
PO Box 88
ROCHEDALE QLD 4123
We will then return the card to you, leaving us on the same day that we receive
it.
Stage 2!
Once the card is back with you follow these steps.
Replacing the card
1. Do NOT turn the device on.
2. Use a regular flathead screwdriver to loosen the two screws on the dark
plastic panel on the top front of the device.
3. Remove the dark plastic panel.
4. Replace the storage card in the top slot in the device.
5. Replace the black plastic panel and tighten the screws.

Hard resetting the device
1. Get a paper clip and unfold it so you have a long, thin piece of metal.
2. Turn the device over.
3. On the left hand side are holes for the speaker to project through. At the
top of these is a slightly larger hole with the letter R next to it.
4. Use the paper clip to press the reset button which is in this hole. You will
feel it move when you press it.
5. The device will now go through a restarting process. You do not need to
do anything until the device has completely restarted and then you can
restore your pages following the instructions below.
Restoring your custom pages
1. Put your USB stick in one of the USB ports on the device.
2. Press the blue Setup button on the title bar to open the Mo Setup window.
3. Press Page Browser to open the Page Browser menu.
4. In the left side of the window, select the folder called Top level.
5. Now press the New Folder button and type in a name for the folder into
which you are going to put your custom pages e.g. John
6. Press Sharing Operations.
7. Press Import Package. The Select Package window will open.
8. Put a cross in the Show All Directories check box. Additional storage will
be displayed in the left viewport. The USB stick will show up as
UMS_FOLDER. Make sure you select this. It should turn grey when it has
been selected.
9. Select the package you previously made from the right side of the
window.
10. Press OK.
11. The Select Files for Package menu will close. A window will open with the
message: “Importing package. Please wait.” Then, the window with the
message will close.
12. Select OK to close the window with the message.
13. Select the folder you have just made and choose the page you wish to
go to.
14. Press GoToPage.
15. All windows will now close and you should be at one of your custom
pages.
