Spectrum Digital TMS320VC5505 Use and care manual

TMS320VC5505 Evaluation
Module (EVM)
2009 DSP Development Systems
Reference
Technical


TMS320VC5505 Evaluation
Module (EVM)
Technical Reference
510885-0001 Rev. B
July 2009
SPECTRUM DIGITAL, INC.
12502 Exchange Drive, Suite 440 Stafford, TX. 77477
Tel: 281.494.4505 Fax: 281.494.5310
sales@spectrumdigital.com www.spectrumdigital.com

IMPORTANT NOTICE
Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any
product or service without notice. Customers are advised to obtain the latest version of relevant
information to verify that the data being relied on is current before placing orders.
Spectrum Digital, Inc. warrants performance of its products and related software to current
specifications in accordance with Spectrum Digital’s standard warranty. Testing and other quality
control techniques are utilized to the extent deemed necessary to support this warranty.
Please be aware that the products described herein are not intended for use in life-support
appliances, devices, or systems. Spectrum Digital does not warrant nor is Spectrum Digital liable for
the product described herein to be used in other than a development environment.
Spectrum Digital, Inc. assumes no liability for applications assistance, customer product design,
software performance, or infringement of patents or services described herein. Nor does Spectrum
Digital warrant or represent any license, either express or implied, is granted under any patent right,
copyright, or other intellectual property right of Spectrum Digital, Inc. covering or relating to any
combination, machine, or process in which such Digital Signal Processing development products or
services might be or are used.
WARNING
This equipment is intended for use in a laboratory test environment only. It generates, uses, and can
radiate radio frequency energy and has not been tested for compliance with the limits of computing
devices pursuant to subpart J of part 15 of FCC rules, which are designed to provide reasonable
protection against radio frequency interference. Operation of this equipment in other environments
may cause interference with radio communications, in which case the user at his own expense will be
required to take whatever measures necessary to correct this interference.
Copyright © 2009 Spectrum Digital, Inc.
WARNING
To minimize risk of electric shock hazard, use only the following
power supply for the EVM module with Medical Development
Applications: SL Power AULT Model MW173KB0503F01.

Contents
1 Introduction to the TMS320VC5505 Evaluation Module . . . . . . . . . . . . . . . . . . . . . . 1-1
Provides you with a description of the TMS320VC5505 EVM, key features, and block diagram.
1.1 Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Development Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.3 Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.5 VC5505 GIO Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.6 VC5505 I2C Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Operation and Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Describes the operation and physical layout of the TMS320VC5505 EVM and its connectors.
2.1 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2 Connector Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.2.1 J2, I2C Probe Headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.2.2 J3, USB-B Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.2.3 J4, External JTAG Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.2.4 J5, Expansion Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.2.5 J6, Expansion Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.2.6 J7, +5 Volt In Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.2.7 J8, Battery Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.2.8 J9, MMC/SD Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.2.9 J13, RS-232 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.2.10 J14, Stereo In 1 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.2.11 J15, Stereo In 2 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.2.12 J16, Headphone Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.2.13 J17, HDR4 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.2.14 J18, Stereo Out Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.2.15 J19, Display Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
2.2.16 Daughter Card Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.2.16.1 J20, Daughter Card Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.2.16.2 J21, Daughter Card Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.2.16.3 J22, Daughter Card Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
2.2.17 J201, Embedded USB Emulation Connector . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
2.2.18 M1, Left Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.2.19 M2, Right Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.3 System LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.4 VC5505 EVM Adjustable Power Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.5 VC5505 EVM Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.5.1 SW1, WAKEUP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
2.5.2 SW2, RESET Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
2.5.3 SW3, LDO Option Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20

2.5.4 SW4, On/Off Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
2.5.5 SW6-SW15, Function Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.6 Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
2.6.1 VC5505 EVM Option Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2.6.1.1 JP5, nRESET Source Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.6.1.2 JP15, V3.3 Source Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.6.1.3 JP17, Vsel Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.6.1.4 JP22, UART Enable Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.6.1.5 JP23, Microphone Bias Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
2.6.1.6 JP25, WAKEUP Source Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
2.6.2 VC5505 EVM Power Domain Probe Points . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
2.7 Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
A Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Contains the schematics for the TMS320VC5505 EVM
B Mechanical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Contains the mechanical information about the TMS320VC5505 EVM

About This Manual
This document describes the board level operations of the TMS320VC5505
Evaluation Module (EVM). The EVM is based on the Texas Instruments
TMS320VC5505 Digital Signal Processor.
The TMS320VC5505 EVM is a table top card to allow engineers and software
developers to evaluate certain characteristics of the TMS320VC5505 DSP to
determine if the processor meets the designers application requirements. Evaluators
can create software to execute on board or expand the system in a variety of ways.
The TMS320VC5505 EVM can be used to develop TMS320VC5504 applications since
the TMS320VC5504 processor is a subset of the TMS320VC5505.
Notational Conventions
This document uses the following conventions.
The TMS320VC5505 will sometimes be referred to as the C55XX.
The TMS320VC5505 EVM will sometimes be referred to as the EVM.
Program listings, program examples, and interactive displays are shown is a special
italic typeface. Here is a sample program listing.
equations
!rd = !strobe&rw;
Information About Cautions
This book may contain cautions.
This is an example of a caution statement.
A caution statement describes a situation that could potentially damage your software,
or hardware, or other equipment. The information in a caution is provided for your
protection. Please read each caution carefully.
Related Documents
Texas Instruments TMS320VC55XX DSP CPU Reference Guide
Texas Instruments TMS320VC55XX DSP Peripherals Reference Guide

Table 1: Hardware History
Revision History
A Prototype Release
B Alpha Release
C Beta Release
D Production Release
Table 2: Manual History
Revision History
A Alpha Release
B Production Release

1-1
Chapter 1
Introduction to the
TMS320VC5505 EVM
Chapter One provides a description of the TMS320VC5505 EVM
along with the key features and a block diagram of the circuit board.
Topic Page
1.1 Key Features 1-2
1.2 Development Tools 1-3
1.3 Memory Map 1-3
1.4 Power Supply 1-3
1.5 VC5505 GIO Schedule 1-3
1.6 VC5505 I2C Addressing 1-5

Spectrum Digital, Inc
1-2 TMS320VC5505 EVM Technical Reference
1.1 Key Features
The VC5505 EVM is a standalone development platform that enables users to
evaluate and develop applications for the TI TMS320VC5505 Digital Signal Processor
(DSP). The EVM also serves as a hardware reference design for the TMS320VC5505
DSP. Schematics, logic equations and application notes are available to ease
hardware development and reduce time to market.
The EVM comes with a full complement of on-board devices that suit a wide
variety of application environments. Key features include:
• A Texas Instruments TMS320VC5505 operating up to 100 Mhz.
• Flexible/variable power supply for each VC5505 power rail and scalable
power supply core
• TLV320AIC3254 stereo codec
• MMC / SD connector
• User USB port via VC5505
Figure 1-1, TMS320VC5505 EVM

Spectrum Digital, Inc
1-3
• I2C EEPROM (256Kbits) and SPI EEPROM (256Kbits)
• EMIF, I2S, I2S, UART, SPI interfaces on expansion connectors
• External JTAG emulation interface
• Embedded JTAG controller
• Color LCD Display
• 10 User push button switches
1.2 Development Tools
The EVM is designed to work with TI’s Code Composer Studio (CCS) Integrated
Development Environment (IDE). Code Composer Studio communicates with the EVM
board through the external emulator header, or on board emulation. An EVM specific
version of Code Composer Studio ships with the EVM.
1.3 Memory Map
Refer to the TMS320VC5505 device documentation for a more specific memory
information on the VC5505 device.
1.4 Power Supply
The EVM operates from a +5V external power supply or battery.
1.5 VC5505 GIO Schedule
The VC5505 has multiple GIO signals that can be used for system level tasks. The GIO
signals are connected to various jumpers on the EVM. By using jumper plugs, these
GIO signals can be used to control different functions on the VC5505 EVM. Refer to the
discussion of the jumper setting later in this document for details of the jumper locations
and options they provide. The table below describes how the GIO lines are used on the
EVM.
WARNING
To minimize risk of electric shock hazard, use only the following
power supply for the EVM module with Medical Development
Applications: SL Power AULT Model MW173KB0503F01.

Spectrum Digital, Inc
1-4 TMS320VC5505 EVM Technical Reference
Table 1: VC5505 GIO Schedule
VC5505 EVM Function
Description
VC5505 Default
Multiplexed
Function GPIO Pin Wired To
Wakeup core from power off External Interrupt Wakeup SW1, Expansion connector
User interrupt input INT0 INT0 Low battery from U4 Expansion connector.
User interrupt input INT1 INT1 Interrupt from J22-15, Expansion connector
S00 MMC0_CLK GPIO0 J22-12, MMC/SD connector
S01 MMC0_CMD GPIO1 J22-8, MMC/SD connector
S02 MMC0_D0 GPIO2 J22-22, MMC/SD connector
S03 MMC0_D1 GPIO3 J22-21, MMC/SD connector
S04 MMC0_D2 GPIO4 J22-1, MMC/SD connector
S05 MMC0_D3 GPIO5 TP27, MMC/SD connector
S10 MMC1_CLK GPIO6 J22-5
S11 MMC1_CMD GPIO7 J22-9
S12 MMC1_D0 GPIO8 J22-19
S13 MMC1_D1 GPIO9 J22-14
S14 MMC1_D2 GPIO10 J22-6
S15 MMC1_D3 GPIO11 J22-2
PD2 LCD_D2 GPIO12 Expansion connector, LCD connector
PD3 LCD_D3 GPIO13 Expansion connector, LCD connector
PD4 LCD_D4 GPIO14 Expansion connector, LCD connector.
PD5 LCD_D5 GPIO15 Expansion connector, LCD connector
PD6 LCD_D6 GPIO16 Expansion connector, LCD connector.
PD7 LCD_D7 GPIO17 Expansion connector, LCD connector.
PD8 LCD_D8 GPIO18 Expansion connector, LCD connector, AIC3254 (I2S2_CLK),
SPI EEPROM (SPI_CLK), J22-3 (SPI_CLK)
PD9 LCD_D9 GPIO19 Expansion connector, LCD connector, AIC3254 (I2S2_FS),
SPI EEPROM (SPI_CS0), J22-7 (SPI_CS0)
PD10 LCD_D10 GPIO20 Expansion connector, LCD connector, AIC3254 (I2S2_RX),
SPI EEPROM (SPI_RX), J22-13 (SPI_RX)
A15 EMIF_A15 GPIO21 Expansion connector
A16 EMIF_A16 GPIO22 Expansion connector
A17 EMIF_A17 GPIO23 Expansion connector
A18 EMIF_A18 GPIO24 Expansion connector
A19 EMIF_A19 GPIO25 Expansion connector
A20 EMIF_A20 GPIO26 Expansion connector
PD11 LCD_D11 GPIO27 Expansion connector, LCD connector, AIC3254 (I2S2_DX),
SPI EEPROM (SPI_DX), J22-11 (SPI_DX)
PD12 LCD_D12 GPIO28 Expansion connector, LCD connector,
RS232 connector (UART_RTS)
PD13 LCD_D13 GPIO29 Expansion connector, LCD connector,
RS232 connector (UART_CTS)
PD14 LCD_D14 GPIO30 Expansion connector, LCD connector,
RS232 connector (UART_RX)
PD15 LCD_D15 GPIO31 Expansion connector, LCD connector,
RS232 connector (UART_TX)

Spectrum Digital, Inc
1-5
1.6 VC5505 I2C Addressing
The VC5505 EVM has multiple I2C devices for different purposes. The table below
shows the addresses of these devices on the I2C bus.
Table 2: VC5505 GIO Schedule
EVM I2C Device I2C Address Wired To
TPS62354 0x4A Core Power Supply, I2C EEPROM
CAT24WC256X 0x50
TLP320AIC3254 0x18 CODEC ADS J22,
Expansion connector J2, Test Point

Spectrum Digital, Inc
1-6 TMS320VC5505 EVM Technical Reference

2-1
Chapter 2
Physical Description
This chapter describes the physical layout of the TMS320VC5505 EVM
and its connectors.
Topic Page
2.1 Board Layout 2-3
2.2 Connector Index 2-5
2.2.1 J2, I2C Probe Headers 2-6
2.2.2 J3, USB-B Connector 2-6
2.2.3 J4, External JTAG Interface 2-7
2.2.4 J5, Expansion Connector 2-8
2.2.5 J6, Expansion Connector 2-9
2.2.6 J7, +5 Volt In Connector 2-10
2.2.7 J8, Battery Holder 2-10
2.2.8 J9, MMC/SD Connector 2-11
2.2.9 J13, RS-232 Connector 2-12
2.2.10 J14, Stereo In 1 Connector 2-12
2.2.11 J15, Stereo In 2 Connector 2-13
2.2.12 J16, Headphone Connector 2-13
2.2.13 J17, HDR4 Connector 2-14
2.2.14 J18, Stereo Out Connector 2-14
2.2.15 J19, Display Interface 2-15
2.2.16 Daughter Card Interfaces 2-16
2.2.16.1 J20, Daughter Card Interface 2-16
2.2.16.2 J21, Daughter Card Interface 2-16
2.2.16.3 J22, Daughter Card Interface 2-17
2.2.17 J201, Embedded USB Emulation Connector 2-17
2.2.18 M1, Left Microphone 2-18
2.2.19 M2, Right Microphone 2-18
2.3 System LEDs 2-18
2.4 VC5505 EVM Adjustable Power Rails 2-19

Spectrum Digital, Inc
2-2 TMS320VC5505 EVM Technical Reference
Topic Page
2.5 VC5505 EVM Switches 2-19
2.5.1 SW1, WAKEUP Switch 2-20
2.5.2 SW2, RESET Switch 2-20
2.5.3 SW3, LDO Option Switches 2-20
2.5.4 SW4, On/Off Switch 2-20
2.5.5 SW6-SW15, Function Switches 2-21
2.6 Jumpers 2-22
2.6.1 VC5505 EVM Option Jumpers 2-23
2.6.1.1 JP5, nRESET Source Select 2-24
2.6.1.2 JP15, V2.3 Source Select 2-24
2.6.1.3 JP17, Vsel Select 2-25
2.6.1.4 JP22, UART Enable Jumper 2-25
2.6.1.5 JP23, Microphone Bias Select 2-26
2.6.1. JP25, WAKEUP Source Select 2-26
2.6.2 VC5505 EVM Power Domain Probe Points 2-27
2.6 Test Points 2-28

Spectrum Digital, Inc
2-3
2.1 Board Layout
The VC5505 EVM is a 6.35 x 5.75 inch (161 x 146 mm.) ten (10) layer board which
is powered by an external +5 volt only power supply. Figure 2-1 shows the layout of the
top side of the VC5505 EVM.
Figure 2-1, TMS320VC5505 EVM (top)
J201
J4
J16
J3
J9
J7
J6
J18
J14
J15
J21
J5 SW2 SW1
SW4
J22
SW8
SW9
SW12
SW7
SW14
SW15 SW10SW13SW11
SW6
J13
SW3
J2
J17
J20
D1
D3
DS201 M1
M2
R43
R59
R64
R67
R68

Spectrum Digital, Inc
2-4 TMS320VC5505 EVM Technical Reference
Figure 2-2 shows the layout of the bottom side of the VC5505 EVM.
Figure 2-2, TMS320VC5505 EVM (bottom)
J8
J19

Spectrum Digital, Inc
2-5
2.2 Connector Index
The TMS320VC5505 EVM has twenty-two (22) connectors which provide the user
access to the various signals on the EVM.
Table 1: TMS320VC5505 EVM Connectors
Connector # Pins Function Schematic
Page Board Side
J2 3 I2C Probe Headers 2 Top
J3 4 USB Type B Connector 3 Top
J4 14 JTAG Header 4 Top
J5 66 Expansion 6 Top
J6 66 Expansion 6 Top
J7 2 +5 Volt In 8 Top
J8 2 Battery Holder 8 Bottom
J9 18 MMC/SD 11 Top
J13 9 RS-232 12 Top
J14 2 Stereo In 1 14 Top
J15 2 Stereo In 2 14 Top
J16 2 Headphones Out 14 Top
J17 4 AIC3254 Control Signals 14 Top
J18 2 Stereo Out 14 Top
J19 30 Display Interface 15 Bottom
J20 20 Daughter Card Interface 13 Top
J21 10 Daughter Card Interface 13 Top
J22 22 Daughter Card interface 13 Top
J201 5 Embedded USB Emulation Port 4 Top
M1 2 Left Microphone 14 Top
M2 2 Right Microphone 14 Top

Spectrum Digital, Inc
2-6 TMS320VC5505 EVM Technical Reference
2.2.1 J2, I2C Probe Headers
Connector J2 brings out the I2C signals from the VC5505 processor. The signals are
shown in the table below.
Shown below is a top view of the J2 connector.
2.2.2 J3, USB Type B Connector
The J3 connector is a USB Type B connector. This connector interfaces directly to the
VC5505 processor. The signals on this connector are shown in the table below.
Table 2: J2, I2C Probe Headers
Pin # Signal Name
1I2C_SDA
2I2C_SCL
3GND
Table 3: J3, USB Type B Connector
Pin # USB Signal VC5505 Signal,
Pin
1 VBUS USB VBUS, J12
2 D- USB_DM, J14
3 D+ USB_DP, H14
4GND
5GND
5GND
GND
Figure 2-3, Top View of the J2 Connector
SCL
SDA
1
J2
Table of contents
Other Spectrum Digital Motherboard manuals

Spectrum Digital
Spectrum Digital eZdsp R2812 USB Use and care manual

Spectrum Digital
Spectrum Digital XDS560v2 Use and care manual

Spectrum Digital
Spectrum Digital eZdsp F2804 Series Use and care manual

Spectrum Digital
Spectrum Digital TMS320VC5509A EVM PLUS Use and care manual

Spectrum Digital
Spectrum Digital TMS320DM6467 Use and care manual

Spectrum Digital
Spectrum Digital TMS320F240 Use and care manual

Spectrum Digital
Spectrum Digital eZdsp F28 Series Instruction Manual

Spectrum Digital
Spectrum Digital TMS320C5517 Use and care manual

Spectrum Digital
Spectrum Digital eZdsp F28335 Instruction Manual

Spectrum Digital
Spectrum Digital TMS320DM6437 Use and care manual
