Spectrum Digital TMS320C5517 Use and care manual

TMS320C5517 Evaluation Module
Technical Reference
Spectrum Digital, Inc.
12502 Exchange Drive, #440
Stafford, TX. 77477
T: 281.484.4500
F: 281.494.5310
www.spectrumdigital.com
514665-0001 Rev A, March 2014
PreliminaryMar27,2014

IMPORTANT NOTICE
Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any product or service
without notice. Customers are advised to obtain the latest version of relevant information to verify that the data
being relied on is current before placing orders.
Spectrum Digital, Inc. warrants performance of its products and related software to current specifications in
accordance with Spectrum Digital’s standard warranty. Testing and other quality control techniques are utilized to
the extent deemed necessary to support this warranty.
Please be aware that the products described herein are not intended for use in life-support appliances, devices, or
systems. Spectrum Digital does not warrant nor is Spectrum Digital liable for the product described herein to be
used in other than a development environment.
Spectrum Digital, Inc. assumes no liability for applications assistance, customer product design, software
performance, or infringement of patents or services described herein. Nor does Spectrum Digital warrant or
represent any license, either express or implied, is granted under any patent right, copyright, or other intellectual
property right of Spectrum Digital, Inc. covering or relating to any combination, machine, or process in which such
Digital Signal Processing development products or services might be or are used.
WARNING
This equipment is intended for use in a laboratory test environment only. It generates, uses, and can radiate radio
frequency energy and has not been tested for compliance with the limits of computing devices pursuant to subpart
J of part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency
interference. Operation of this equipment in other environments may cause interference with radio
communications, in which case the user at his own expense will be required to take whatever measures necessary
to correct this interference.
Copyright © 2014 Spectrum Digital, Inc.

Contents
Chapter 1 Introduction to the TMS320C5517 Evaluation Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Provides you with a description of the TMS320C5517 Evaluation Module, key features, and block diagram.
1.1 Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3 I2C Addresses . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Chapter 2 Board Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Describes the operation of the major board components on the TMS320C5517 Evaluation Module.
2.1 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4 Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.5 Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Appendix A Mechanical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Contains the mechanical information about the TMS320C5517 Evaluation Module

About This Manual
This document describes the board level operations of the TMS320C5517 Evaluation Module
(EVM). The EVM is based on the Texas Instruments TMS320C5517 Processor.
The TMS320C5517 Evaluation Module is a table top card that allows engineers and software
developers to evaluate certain characteristics of the TMS320C5517 processor to determine if the
processor meets the designers application requirements. Evaluators can create software to execute
on board or expand the system in a variety of ways.
Notational Conventions
This document uses the following conventions.
The TMS320C5517 Evaluation Module will sometimes be referred to as the C5517 EVM or EVM.
Program listings, program examples, and interactive displays are shown in a special italic typeface.
Here is a sample program listing.
equations
!rd = !strobe&rw;
Information About Cautions
This book may contain cautions.
This is an example of a caution statement.
A caution statement describes a situation that could potentially damage your software, or hardware,
or other equipment. The information in a caution is provided for your protection. Please read each
caution carefully.

1-1
Chapter 1
Chapter one provides a description of TMS320C5517 EVM along with the key features
and a block diagram of the board.
Title Page
1.1 Key Features . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3 I2C Addresses . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Spectrum Digital, Inc
1-2 TMS320C5517 EVM Technical Reference
1.1 Key Features
The TMS320C5517 EVM is a standalone development platform that enables users
to evaluate and develop applications for the TMS320C5517 processor. Additional
information regarding this product can be found on the following web page:
http://support.spectrumdigital.com/boards/evm5517
The EVM comes with a full complement of on board devices that suit a wide variety
of application environments. Key features include:
• A Texas Instruments TMS320C5517 fixed point processor running at 100 MHz
• A Texas Instruments MSP430F5529 microcontroller running at 25 MHz
• 8 MB Mobile SDRAM
• 4 MB NAND Flash memory
• 2 MB NOR Flash memory
• 1 MB SPI Flash memory connected to C5517 via SPI
• 1 MB SPI Flash memory connected to C5517 via McSPI
• 1 MB SPI Flash memory connected to MSP430F5529
• USB 2.0 Interface
Figure 1-1, Block Diagram TMS320C5517 EVM
I
2
C Bus
P1 P2
Mini
USB
EMIF
Analog
Input 1
Embedded
XDS100 JTAG
HPI
5V
PWR
ON/
OFF
Mini
USB
TI JTAG
USB
Device
Reset
Reset
MSP430
SPI
Flash
IR IN
IR OUT
UART
NAND
Flash NOR
Flash
SW3
SW11
SW4
SW5
SW6
Embedded
XDS100 JTAG
MMC0 / MMC1
Front MMC0
SD Card
Back MMC1
MicroSD
USB
UART
SPI
I2C
GPIO
SPI
Flash
UART
Codec 1
AIC3204
I2S0
Mobile
SDRAM
HPI
HP Out
Line In
Mic In
Amp Out
Codec 2
AIC3204
HP Out
Line In
Mic In
Amp Out
I2S2
TMS320
C5517
SPI
Color
LCD
128 x 128

Spectrum Digital, Inc
1-3
• Two TLV320AIC3402 Stereo codecs (stereo in, speaker output, 2 microphone
inputs, headphone out)
• Two microphones
• Expansion connectors for Bluetooth
• HPI connector
• 128 x 128 bit mapped color LCD Interface
• MMC/SD card interface
• Micro SD card interface
• UART Interface
• Optional battery power
• Configurable boot load options
• Single voltage power supply (+5V)
• Embedded JTAG Interface
• TI 14 pin JTAG Interface

Spectrum Digital, Inc
1-4 TMS320C5517 EVM Technical Reference
1.2 Memory Map
The C5517 EVM supports on chip DARAM, off chip SDRAM, off chip NOR flash,
and off chip NAND Flash. The addressing for each of these memory blocks is
shown in the figure below.
1.3 I2C Addresses
The following table shows the I2C addresses for devices on the TMS320C5517
EVM.
Table 1: I2C Addresses
Address Device Function
0x18 TLV320AIC3204 Audio CODECs, muxing required
0x21 TCA6416PW I2C GPIO
0x50 CAT24WWC256X I2C Interface EEPROM
MEMORY BLOCKS
Internal DARAM
Internal DARAM
Mobile SDRAM
NOR Flash
Not Used
NAND Flash
Not Used
ROM
(if MPNMC=0) External-CS5 Space (if MPNMC=1)
External-CS0 Space
External-CS2 Space
External-CS3 Space
External-CS4 Space
External-CS5 Space
CPU Byte
Address
000000h
0000C0h
010000h
050000h
800000h
C00000h
E00000h
F00000h
FE0000h
FFFFFFh
(MMR Reserved)
DFFFFFh
BFFFFFh
E03FFFh
00FFFFh
7FFFFFh
04FFFFh
FDFFFFh
Figure 1-2, TMS320C5517 EVM Memory Map

Spectrum Digital, Inc
1-5
Figure 1-3, TMS320C5517 EVM (top)
Figure 1-4, TMS320C5517 EVM (bottom)

Spectrum Digital, Inc
1-6 TMS320C5517 EVM Technical Reference

2-1
Chapter 2
Chapter Two provides a description of the major components on the
TMS320C5517 EVM.
Title Page
2.1 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4 Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.5 Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Spectrum Digital, Inc
2-2 TMS320C5517 EVM Technical Reference
2.1 Connectors
