Assembly Instructions
(2) 0101382
#14 x 7/8” PHSM
(1) 0107804
Sling Bracket
(2) 035728
1/4-20 x 1/2 PHMS
(2) 041943
1/4-20 x 1/2”
PHMS
(1) CPU Sling
0117848 - 24”D
0107801 - 30”D
(2) 0107595
Strap / buckle
assembly (58”)
0119551R1 Page 1 of 2
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
CPU Sling for Flex Insight Desk™
24”D desks - 38981
30”D desks - 38980
1. Remove Existing Cover Plate
1. Remove the (2) 1/4-20 x 1/2” PHM screws. Figure 1.
2. Remove cover plate.
Note: 1 sling is required on
single desks, 2 on double desks Phillips
Screwdriver
Tools Required
7/16” or
Adjustable
wrench
Figure 1
(2) 1/4-20 x
1/2” PHMS
Cover
Plate
2. Install CPU Sling
1. Install the support bracket under the shroud opening as shown with
(2) 1/4-20 x 1/2” PHM screws from behind the shroud. Figure 2A.
2. Align the support bracket holes and attach the sling to the
worksurface with (2) #14 x 7/8” PHSM screws. Figure 2B.
3. Install (2) 1/4-20 locknuts to secure the sling to the support bracket.
Figure 2B
Figure 2A
CPU Sling
#14 x 7/8”
PHSM
(2) 1/4-20
Locknuts
Shroud
opening
Support
Bracket
(2) 1/4-20 x 1/2” PHMS
(install behind shroud)
Note: Sling straps
not shown.

3. Install CPU tower
1. Using the slots, install the straps onto the sling. Figure 3A.
2. Set the CPU tower into the sling.
3. Make sure the CPU tower will be supported by both straps and
tighten the straps while keeping the buckles positioned as high as
possible to avoid interference. Figure 3B.
Note: The center slot can be used for better
support of smaller CPU towers. If the center slot
is necessary, take the rear strap out of the rear slot
and thread into the center slot shown in Figure 3B.
Thread the strap as shown in Figure 3A.
Figure 3A
Figure 3B
Strap / buckle
assembly
Sling straps
Sling
Center slot
CPU
tower
CPU
tower
0119551R1 Page 2 of 2
