Spectrum FieldScout pH 600 Meter User manual

pH 400, pH 600 Meter (item 2107, 2108)
Quick Start Guide
View full manual at
www.specmeters.com
Keypad (p. 8)
• The meter is turned on and off with the power buon (1).
• avigate through the meter screens with the arrow buons (2).
• Select, confirm, or reject op'ons with the Enter (3) and Back (4) buons.
Connect probe (p. 7)
• Align the white notches on the probe connector and meter socket, having the
notch facing towards the front side of the meter.
• The connector is pushed down un'l it clicks into the meter’s socket.
ote: Do not turn the probe connector once inserted into the meter’s socket.
When removing the probe, pull on the connector, not the cable.
Ba#eries (p. 6)
• The baery compartment is accessed by removing the screw on the back of the
meter. The meter is shipped with 3 fully charged , rechargeable AA baeries. To
ac'vate the meter for the first 'me, pull the plas'c strip (baery isolator) out of the
baery compartment and press the power buon.
• To recharge the baeries, connect the meter to the power adapter using the
supplied USB cable and place the power adaptor in a power outlet. The meter will
recharge in approximately 7 hours.
• It is possible to use non-rechargeable baeries.
Warning! Do not connect the meter to the power adaptor or to a USB when non-rechargeable, alkaline
baeries are installed. This may damage the baeries and/or meter.
For pH 600, select the Spectrum buffer set (p. 24)
• Select the Buffer Selecon op'on from the Calibrate
menu.
• Select Sentron buffers.
• Press the Home buon
OTE: pH 400 meter defaults to the Sentron buffer set.
Sentron buffers SEN
SEN

• Press the Enter buon to begin calibra'on. Meter will instruct you to immerse probe in
first calibra'on solu'on and display an OK icon.
• Place probe in first buffer solu'on and press Enter buon. The Hourglass icon will appear
while calibra'on is underway. Press the Back buon to abort the calibra'on.
• Repeat process for remaining buffers.
• When calibra'on is complete, meter will display the calibra'on report.
• Close report or press Home buon to proceed to measurement screen.
Ok
Calibrate (p. 19)
• Select the Calibrate op'on from the Calibrate menu.
• Use the toggle buons to select the number of calibra'on points. Press Enter.
• Select the ini'al buffer type. Hit Enter.
• If doing mul'-point calibra'ons, repeat the process for the other buffer types.
3600 Thayer Court
Aurora, IL 60504
[phone] or [phone]
Fax [phone]
E-Mail: [email protected]
www.specmeters.com
Take Readings
The meter automa'cally goes into measurement mode a=er it is powered up or completes a calibra'on.
Immerse probe in sample to begin sampling or logging.
Warranty
This product is warranted to be free from defects in material or workmanship for one year from the date of purchase
for the meter and 6 months from the date of purchase for the probe. During the warranty period Spectrum will, at its
op'on, either repair or replace products that prove to be defec've. This warranty does not cover damage due to
improper installa'on or use, lightning, negligence, accident, or unauthorized modifica'ons, or to incidental or
consequen'al damages beyond the Spectrum product. Before returning a failed unit, you must obtain a Returned
Materials Authoriza'on (RMA) from Spectrum. Spectrum is not responsible for any package that is returned without
a valid RMA number or for the loss of the package by any shipping company.
R - 07/15
