Spirit T-COM VB User manual

Contents:
Warranty Details
Welcome
2
General Safety Instructions
2
Motorcycle BluetootlfProduct Features
3
Parts List
4
Technical Specification
4
Product Controls
5
Fitting to your helmet
6
T-COMVB functions
g
TCOM-SC functions
12
Troubleshooting
17

Helmet BIuetootI1’Intercom Kit
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 6 months from the date of purchase. Defects that occur
within this warranty period, under normal use and care, will be repaired or
replaced at our discretion.
You are entitled to replace or repair the goods within warranty period and
get compensation for any other resonable foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the it fails to
be of acceptable quanlity and the failure occurs under normal use.

Welcome
Congratulations on choosing to buy T-COMVB / TCOM-SC. By doing so you now
have the assurance and peace of mind that comes with purchasing a product
made by one of the leading manufacturers. All products brought to you are
manufactured to the highest standards of performance and safety and, as part of
our philosophy of customer service and satisfaction, are backed by our
comprehensive 6 months Warranty. We hope you will enjoy using your purchase for
many years to come.
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place for future
reference, along with the warranty card, purchase receipt and carton. The safety
precautions enclosed herein reduce the risk of fire, electric shock and injury when
correctly adhered to. Follow all instructions and take notice of all warning to
reduce the risk of fire or electric shock.
•
Do not remove the cover or the back of this product. There are no user-
serviceable parts inside this product.
• Do not repair the unit yourself. Only have it serviced by qualified personnel.
Supervise young children to ensure they do not play with the product.
•
Do not submerge the product in liquids.
•
Do not place the product near other items that may damage it, such as naked
flame sources (lit candles) or excessive heat (Bar radiator).
WARNING: Using headphones while operating a motorcycle, motor vehicle,
watercraft or bicycle can be dangerous, Use caution while using your motorcycle
Helmet Bluetooth”Kit when you are engaging in any activity that requites your full
attention.

Motorcycle Helmet BIuetooth”Kit
Product Features
• Complete system for all your communications needs while riding your
motorbike.
• The Bluetooth’function will keep you connected to your mobile phone, play
music and connect with BIuetooth°GPS systems.
• The intercom means you can communicate with your pillion or other riders
within 800m while you ride. With simple set up and clear sound
quality you will always be in touch.

Parts List
1.
1(2)=Bluetooth”Receiver 5. 4(8)•FeIted Adhesive Earphone Pads
2.
1(2)=USB Cable 6. 1(2)•Ear Speaker & Microphone Headset
3.
1 Screw Driver 7. 1•Headset Clip & Fastening Screws
4.
1(2)=Power Adaptor
Note: Different country may have different power adaptor.
1.
3.
, e
Technical Specifications
BIuetootI1”Version:2.1+EDR
Frequency:2.4GHz
Supports:A2DP and AVRCP
Supported BT Profiles:
BIuetooth’Headset and Hands free
Profiles with Automatic Detection
Operating Range: Up to 10m for cell
phones; up to 800m for intercom
function.
Weight: 45grams(excluding
accessories)
Size:81mm(L)•31mm(W)=25mm(H)
Battery Type: Rechargeable
Polymer 400mAh
Stand by: Up to 300hrs
Talk Time
-Phone: Up to 10 hours
-Intercom: Up to 7 hours
Charging Time: About 4 hours
Headset: High Power ultra slim
speaker with integrated boom
Power Adaptor: DC 5V 500mA

+
SKIP/VOL
FM RADIO
SKIP/V O L
-

Instructions
Fitting the Bluetooth°receiver to your helmet
1.
Using the provided screw driver, loosen the
Headset Clip screws.
2. Slide the Headset Clip onto the left side of the
helmet (when on your head).Take care to
place the inside of the Headset Clip under the
helmet padding.
3. Adjust the clip until you find the best location
for your helmet. Ensure that the slots in the
headset clip mount are facinp away from the
helmet.
4.
Tighten the screws to hold the clip firmly in
place. WARNING: Excessive tightening may
damage the clips.
5.
Slide the Bluetooth’receiver down into the
slots on the headset clip mount. Make sure
that it is locked in securely.
6.
To attach the ear speaker & microphone
headset, test which part of the helmet will be
the best location by putting your helmet on
and locating the place closest to your ears.
You will need to put the helmet on a few times
to find the optimum position to apply the pad.
when the correct position is found, remove the
adhesive protective strip and apply the felted
earphone pad.

7.
Attach ear speaker to the felted pad. Run the
microphone arm along the inside wall of the
helmet, to where your mouth will be. the
microphone arm is flexible and should to adjusted
so it sits in the bast position in front of your mouth.
Some helmet have removable to run the speaker
and microphone under the padding.
B. Connect the headset to the Bluetooth’receiver.The
plug can only be inserted in one orientation.
WARNING: Inserting the plug backwards will cause
damage to the Bluetootlfreceiver. Use caution
when assembling.
Secure the cord of the headset plug inside the
helmet. Tuck any extra wire into the helmet.
Ensure that only few centimetres of the cord
comes out.
You have successfully mounted the
motorcycle helmet Bluetooth”

T-COMVB
..........page8-11
Charging the BluetootlYDevice
Before using this device, fully charge the Bluetooth“device.
1.
Insert the USB plug of the charging cable into the small USB jack on the
headset. Insert the other end of the charging cable into the Power Adaptor or
your computer’s USB port.
2. While charging, the red LED on the headset module will illuminate, when the
charging is finished, the red LED will switch off. A normal charge from a low
battery will take about 4 hours.
Tip: To maintain long life from the internal polymer battery, charge your
device at least once each month.
Powering 0n and Off
1.
To turn the device on, press the Power/Intercom button for 3 seconds until
you hear a beep. a blue light will flash quickly 3 times and then continue short
flashes at regular intervals.
2.
To turn the device off, press the Power/intercom button for 5 seconds until
you hear a beep. The headset and LED lights will turn off.
Pairing to your BluetootéEnabled
Mobile Phone
1. Place your Bluetooth”enabled phone and the Bluetootlfreceiver near each
other (within 1m).
2.
Make sure the Bluetooth°receiver is turned off.

3.
Press and hold down the Power/Intercom bukon for 8 seconds to turn on
the Bluetooth”devices until you see a red & blue lights flashing. You will also
hear a “DuDu” tone when the unit enters pairing mode.
4. Activate the Bluetooth”function on your mobile phone and search for the
device. You may need to refer to your phones instructions to do this.
5. Choose the Bluetooth”device named T-COM then choose to pair this device
with your phone. If your phone asks for password, it is 0000.
6. The Bluetooth”device will beep twice, your phone will confirm that pairing
was successful.
Pairing 2 Devices In Intercom Mode
1.
Place both receivers near each other(within 1m).
2.
Make sure both receivers are turned off.
3. Press and hold down the Power/Intercom buhon on both units at the same
time for approx 6 seconds, until the receivers beep twice. The red & blue
lights will flash alternately.
4. Quickly press the Power/Intercom button on one of the receivers. This will
now search for the other receiver so they can be paired.
5. When they have successfully paired, the red & blue lights will then change to
blue only(fIashing)and the receiver will beep once.
Pairing 3 Devices In Intercom Mode
1. Follow the above procedure for each combination of the three units. (A-B, A-C,
B-C).
2.
Firstly, pair two devices A and B as described above. Secondly, turn off A and
B, pair A and C as described above. Thirdly, turn off C and A, pair B and C.
At Last, Turn on A.
3.
Any one of them can connect one of the two by press Power/intercom button
once or twice. From Standby press the Power/intercom button 1 time for one of the
pairings to be called, or 2 times for the other pairing to be called.
4. The pairing for 1 or 2 presses will depend on the sequence in which you paired
the 3 helmets, but once paired the relevant pairings will maintain the number.
5.
Pressing the Power/Intercom button of A 1 time to call C and 2 times to call
B. Pressing the button of B 1 time to call C and 2 times to call A. Pressing the
button of C 1 time to call B and 2 times to call A.

To Start A Conversation Via Intercom
1. Once the two headsets are paired with each other, press the Power/Intercom
button on either receiver to begin.
2. Use the Jog wheel to increase or decrease the headset volume.
Tip: You only need to press the Power/lntercom button once to establish a
connection; conversation between the two paired headsets can now be carried
out hands free.
To End A Conversation Via Intercom
Press the Power/Intercom button on either of the receiver.
Tip: If the intercom headset is also paired with a mobile phone, the intercom
conversation will be automatically disconnected to answer the phone when there
is an incoming call. The intercom function will resume once the has ended.
To Answer An Incoming Mobile Phone Call
1.
Press the Multi-function button on the receiver while the phone is ringing.
2.
Use the Jog Wheel to increase or decrease the headset volume.
Tip:The incoming call will answer automatically once the phone has rung for 15
seconds.
Rejecting A Mobile Phone Call
When you hear the phone ringing, immediately press and hold the Multi-function
button on the headset until you hear a beep.
Ending A Mobile Phone Call
Press the Multi-function button to end the call.
Redial The Last Number
Press and hold the Multi-function button for 2 seconds or until it beeps. It will
then dial you last number called.

To Play Music Via Bluetootl1”Mp3 Player
If you are using a dedicated Mp3 player, the player must be a Bluetooth”enable
device and be paired your Motorcycle Bluetooth°receiver.
1. Select music to play directly from your music device (check your Mp3 player
instructions for how to do this).
2.
Play music through the headset press the Multi-function button once.
3.
Pause music press the Multi-function button again.
4.
Skip songs forward by quickly flicking the Jog Wheel in a clockwise direction.
5.
Rewind songs backward by quickly flicking the Jog Wheel in a
anticlockwise direction.
6.
Volume Up by turning the Jog Wheel anticlockwise and holding until the
volume is at the right level.
7.
Volume Down by turning the Jog Wheel clockwise and holding until the
volume is at the right level. you will hear a long beep if the volume is at the
highest or lowest level.
Tip: To improve the performance of your headset, make sure the volume is
set to the highest on your music device.
To Answer A Call While Listening to Music
1. Calls will automatically come through the headset while music is playing. To
reject a call hold the multi function button down until you hear a beep.
2. Music will hold over the call duration and resume automatically once the call
has ended.
To Use FM Function
1.
Headset idle status, press Multi-function button twice to turn FM on.
2.
When FM is on, turn the Multi-function button clockwise or counterclockwise
and it will seek out the next or previous FM station and begin playing.
3.
When FM is on, press Multi-function button twice to turn FM off.

TCOM-SC
..........page12-16
Charging the BluetootPDevice
Before using this device, fully charge the Bluetooth”device.
1.
Insert the USB plug of the charging cable into the small USB jack on the
headset. Insert the other end of the charging cable into the Power Adaptor or
your computer's USB port.
2.
While charging, the “battery” icon is displayed one the screen and will be
flashing.When the battery is fully charged,the “battery”icon will stop flashing.
The charging time is about 4 hours.
Tip: To maintain long life from the internal polymer battery, charge your device at
least once each month.
Powering 0n and Off
1. To turn the device on, press the Power/lntercom button for 3 seconds until
you hear a beep. The display will show “LOUIS ON”. Then the state of the
battery will be show. When turned on, the TCOM-SC headset automatically
establishes hands-free phone and streaming music connections with the last
connected Bluetooth” devices(phone and/or music device). The “phone
connecting” icon and “CONNECT” will be shown on the display screen.
2.
To turn the device off, press and hold the Power/lntercom button for 5
seconds until you hear “DuDu Di--”. The display screen will show “LOUIS OFF”.
Adjusting the Volume
The TCOM-SC headset has a volume control dial: VOL+ and VOL- (the MFB is

in the center of it). You can adjust the TCOM-SC headset speaker volume by
turning the dial during a call or adjust the rinp volume when you are not engaged
in a call.
Volume Decrease
(turn counter clockwise)
+
SKIP/VOL
Volume Increase
(turn clockwise)
FM RADIO
SKIP/ V OL
-
Pairing to your BIuetootI1’EnabIed
Mobile Phone
1. Place your Bluetooth°enabled phone and the Bluetooth°receiver near each
other (within 1m).
2.
Make sure the Bluetooth4eceiver is turned off.
3.
Press and hold down the Power/Intercom button for 6 seconds to turn on
the Bluetooth°devices until “PAIRING” is displayed on the screen. You will
also hear a “DuDu” tone when the unit enters pairing mode.
4. Activate the Bluetooth”function on your mobile phone and search for the
device. You may need to refer to your phones instructions to do this.
5. Choose the Bluetooth”device named TCOM then choose to pair this
device with your phone. If your phone asks for password, it is 0000.
6. After paired succeed with your mobile phone, you will see “CONNECT”, then
“LOUIS” on the screen. Pairing should be done only once. Each time you turn
on your TCOM-SC system, it will be automatically connected to your phone.
Tip: Before enter pairing mode, please make sure other nearby Bluetooth”
devices are switched off.
To Use TCOM-SC with your Mobile Phone
1.
To answer a call. When the headset rings, the coming number will show on
the screen, press the Multi-function button to answer the incoming call.
2.
To terminate a call. Press the Multi-function buhon to terminate call.
3.
To reject a call.When the headset rings, press and hold the Multi-function
button for about 2 seconds and release the Multi-function button to reject an
incoming call.
4.
To use last number redial. If the headset is idle, press and the Multi-function
button for about 2 seconds and release the Multi-function button to redial.
“CALLING” is displayed on the screen.

5.
To transfer the sound back to your mobile phone. During a call using your
headset, press the Multi-function button for about 2 seconds. if your headset
woks with Headset Profile, you just need turn down your headset.
6.
To transfer sound from mobile phone to headset. If you make a call using
your phone, you can transfer the sound to the headset if the headset is on by
pressing the Multi-function button for about 2 seconds.
7.
Talking a phone call while in intercom mode. While speaking though the
intercom function to another device, a phone call will be heard through the
headset speaker. Press the Multi-function button to pick up the phone call and
stop the intercom simultaneously.
Pairing 2 Devices In Intercom Mode
1.
Before pairing, make sure there is no BIuetootI1°device active in your area.
2.
Make sure both receivers are turned off.
3.
Press and hold down the Power/Intercom button on both units at the
same time for approx 6 seconds, until “PAIRING” is displayed on the screen.
4.
Quickly press the Power/Intercom button on either of the receivers. it will
now search for the other receiver.
5. When they have successfully paired, and the receiver will beep once.
“INTERCOM” is displayed on the screen.
Pairing 3 Devices In Intercom Mode
1. There are three units, such as A, B, C units; A-B(A start intercom), A-C(A start
intercom), B-C(B start intercom) all of the pair successfully, and not respond to
any request of any other headset.
When A and B intercom, C press intercom button once, B headset will hear
connection request sound of “Du” three times. If C press intercom button twice,
A headset will hear of the beep of connection request.
When A and C intercom, B press intercom button once, C headset will hear
connection request sound of “Du” three times. If B press intercom button twice,
A headset will hear of the beep of connection request.
When B and C intercom, A press intercom button, C headset will hear
connection request sound of “Du” three times. If A press intercom button twice,
B headset will hear of the beep of connection request.
2. When A-B,A-C,B-C all of pair successfully, but without any intercom.
Press B once » and connect C » B and C begin to intercom.
Press B twice > and connect A > A and B begin to intercom.
Press A once > and connect C » A and C begin to intercom.

Press A twice » and connect B » A and B begin to intercom.
Press C once » and connect B » B and C begin to intercom.
Press C twice » and connect A » A and C begin to intercom.
How To Make Intercom Calls
1.
Starting intercom calls: Once the two headsets are paired with each other,
the headset will enter the intercom mode automatically.
2.
Finishing intercom calls: Press the “Power / Intercom" to terminate the
intercom call. If the TCOM-SC headset is playing A2DP music from the phone
before entering intercom mode, when the intercom call ends, the TCOM-SC
headset will reconnect to the mobile phone and the music will resume. (on
some manufacturer's phones, the headset can't restart music playing
automatically. In that case you need to restart the headset playing manually.)
3. Either of two T-COM-SC can initiate an intercom call to another by short
pressing the “Power / Intercom". You will hear a string of notes when
connection has succeeded.
Tip:
1. If the intercom headset is in the status of connection with cell phone, intercom
will be automatically disconnected and answer the phone when there is a call.
Intercom will be automatic recovery after terminating the call.
2.
Operate effectively within a limited distance.
3.
It needs 5 seconds from the status of phone call to BIuetootI1'intercom.
To Play Music Via BIuetooth’Mp3 Player
If you are using a dedicated Mp3 player, the player must be a Bluetooth”enable
device and be paired your Motorcycle Bluetooth°receiver.
1. Select music to play directly from your music device (check your Mp3
player instructions for how to do this).
2.
Play music through the headset press the Multi-function button once.
“MUSIC" is displayed on the screen.
3.
Pause music press the Multi-function button again. “LOUIS" is displayed on
the screen.
4.
Skip songs forward by quickly flicking the Jog Wheel in a clockwise direction.
5. Rewind songs backward by quickly flicking the Jog Wheel in a anticlockwise
direction.

Tip: To improve the performance of your headset, make sure the volume is
set to the highest on your music device.
To Answer A Call While Listening to Music
1. Calls will automatically come through the headset while music is playing.
To reject a call hold the multi function button down until you hear a beep.
2. Music will hold over the call duration and resume automatically once the
call has ended.
To Use FM Function
1. Turn FM ON. Headset idle status, press Multi-function button twice until display
shows “FM*****and headset turn FM on. ""” is last used radio channel's
frequency.
Tip: When placing or receiving calls or intercom, FM is automatically muted. When
the call is finished, FM is resumed.
2.
Turn FM OFF.When FM is on, press Multi-function button twice to turn FM off.
3.
Searching FM channel automatically.When FM is on, turn the Multi-function
button clockwise or counterclockwise and it will seek out the next or previous
FM station and begin playing. When you reach the highest station and turn it
again, it will return to the lowest station and begin searching upward again.

Tips & Troubleshooting
The Bluetooth“
Receiver
has no power.
The headset must be charged for at least 4 hours
prior to first use. Refer to Charging the Bluetooth”
Device on page 8(12) for further details.
My helmet is
uncomfortable to
wear after fitting the
speakers.
The placement of the speakers within the helmet
may require repositioning. Two additional felted
adhesive earphone pads are supplied for this
purpose. Note: Some helmets have removable
padding: if yours does, it is recommended to run the
speaker and microphone under the padding.
My Phone wont pair
with the Bluetooth”
Receiver.
Activate the BIuetootI1’function on your mobile
phone and search for the device, which will show up
as T-COMVB/T-COM on the Device List, Refer to
your phones instructions to do this. Refer to Pairing
to your BIuetooth°EnabIed Mobile Phone on page 8
(13) for further details.
The audio reception
breaks down.
Bluetooth°enabled device are susceptible to
occasional interference from other common devices
such as GPS units, laptops, alarms and WIFI routers
etc. Move away from potential sources of
interference if you are experiencing problems.
I can’t hear my
music/incoming calls.
Check the volume on the attached device. Setting
your phone or MP3 player to the maximum volume
usually resolves this issue.
