Splash Lab TSL.680 Instruction Manual

TSL.680
Waste Drain
installation + maintenance

3Safety and Warnings
4Box Contents
5Diagram
6Technical Data
7Before you install
8How to Install
9Maintenance
10 Cleaning
11 Warranty
12 Contact Details
contents
2TSL.680 WASTE GRATE MANUAL

For more information contact:
Tel: [phone]
Email: [e-mail]
TSL.680 waste grate
Read and save these instructions
WARNING !
+ Use this unit only in the manner intended by the manufacturer. If you have
questions, contact the manufacturer (see back page for more details).
+ Ensure plumbing is installed correctly before activating water supply.
+ All plumbing is to be installed in accordance with applicable codes
and regulations.
TSL.680 WASTE GRATE MANUAL 3

box contents
1Main body
2Rubber Washer
3Fixing Nut
4TSL.680 WASTE GRATE MANUAL
1
3
2

diagram
5TSL.680 WASTE GRATE MANUAL
1
2
3
8
5
7
6
4
1
2
3
8
5
7
6
4
1
2
3
8
5
7
6
4

technical data
TSL.680 WASTE GRATE MANUAL 6
Overview
Codes Finishes Light Reflectance Value (LRV)
TSL.680CS Brushed Stainless Steel 58
TSL.680CP Brushed Copper 19
TSL.680BK Brushed Black 3
TSL.680BR Brushed Brass 40
TSL.680BZ Brushed Bronze 17
Technical Data Mechanical
Body Material AISI 304 Stainless Steel
Coating Type PVD (colours only)
Weight 0.33Kg
Stainless Steel Grade 304
Flange Diameter 62mm
Length 88mm
Pipe Connection 1 ¼” BSP
Spare Parts
There are no user serviceable parts.
Dimensions
The stainless steel waste grate is an unslotted waste grate, with 7 draining holes
and a 1 ¼” pipe connection. This requires no action by the user.
40.8
62
88
60
10
10
12

before you install
!
Caution
+ The TSL.680 parts must be put together correctly before installation.
+ All parts must be installed correctly before powering up the system.
+ Ensure that connection is to 1 ¼” standard waste pipe.
+ Ensure that the thread on the basin waste fitting is clear for trap to be
screwed tight and connection sealed.
7TSL.680 WASTE GRATE MANUAL
FRONT SIDE
Access Requirements
It is critical all components which require fixing beneath the basin are easily accessible
at all times during installation and routine maintenance.
Front access: If there is an under sink IPS unit, an access hatch is a requirement to
allow for installation and routine maintenance of the waste grate.

8TSL.680 WASTE GRATE MANUAL
1
Fit waste into basin from top.
how to install
Waste Grate Installation
2
Slide sealing washer over thread below
basin, and the attached fixing nut and
tighten. Take care not to over-tighten as
damage may result to the basin.
3
Fit waste trap to waste grate, following the
trap installation guide.

9TSL.680 WASTE GRATE MANUAL
For regular maintenance, the waste grate should be inspected periodically for any
blockages. Hairs and other obstructions should be removed from the waste grate to
ensure that water drains away. The trap may be required to be removed to allow full
access from the bottom of the waste grate. This should be done as required, if it is
observed that water is not draining away suciently.
maintenance

TSL.680 WASTE GRATE MANUAL 10
cleaning
+ Take extra care when cleaning decorative surfaces.
+ For surface cleaning of the trap use ONLY soap and water, then wipe dry with a
clean cloth or towel.
+ DO NOT use steel wool or cleaning agents containing alcohol, acid, abrasives or
the like.
+ Use of any prohibited cleaning or maintenance products or substances could
damage the surface of the trap.
+ When cleaning bathroom tiles, the traps should be protected from any splattering
of harsh cleansers.
All grades of stainless steel will stain or discolour if due care and attention is not taken.
The surface must be regularly cleaned to ensure a long service life of the trap.
Use a soft cloth or sponge with a mild solution of soapy water as part of the regular
washroom janitorial routine. Do not use abrasive or cream cleaners as these will
damage the surface finish.
If the waste grate is subjected to a highly chlorinated environment such as swimming
pools or marine coastal locations, a further treatment, in addition to the regular
cleaning as described above, is recommended by the application of a household
cleaning product containing silicone.
If further information is required, contact The Splash Lab technical team for more
detailed stainless steel care guidelines.

TSL.680 WASTE GRATE MANUAL 11
warranty
We believe the future is personal. With a global mindset, we challenge conventional
restroom norms via product innovation to create considered washroom solutions for
corporate, public and hospitality spaces. We use rich raw materials, cutting-edge
automation and considered washroom design to powerfully and positively influence the
lives of people.
Demonstrating our commitment to quality and our belief in the strength of our designs,
we offer the following warranties.
The Splash Lab warrant that its products will be free of manufacturing and material
defects during normal use and environmental conditions as detailed below:
Waste Grate: 2 years parts & labour
If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide
a replacement part or product, or make appropriate adjustments. Damage caused by
accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning
will void the warranty.
Non-operation of the product due to environmental conditions beyond our control,
installation error, incorrect maintenance, water quality, fair wear and tear, incorrect or
inappropriate installation, misuse and abuse is not covered by the warranty.
Proof of purchase (original sales receipt) must be provided to The Splash Lab with all
warranty claims.
The above warranty is valid for goods supplied within the United Kingdom.
For goods supplied outside of the United Kingdom, The Splash Lab will honour the
above stated warranty periods for the parts only.
THE SPLASH LAB DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.

TSL.680 WASTE GRATE MANUAL 12
contact
General information
[email protected]
[phone]
Technical support
[e-mail]
For further contact information visit:
www.thesplashlab.com

TSL.680 WASTE DRAIN EUR  REV 27-28/03/19
