SportRack CREST DELUXE 2 User manual

506-7094
EN
CREST DELUXE 2 BIKE
LOCK-AND-TILTING
PLATFORM HITCH RACK
EN PARTS INCLUDED
EN = North American English
EN Bicycle Installation EN Weight Limitation EN Receiver Installation EN Tighten Well
EN 2 bike maximum
EN
- 70 lb. total or 35 lb. per tray
A x1
B x1
E x2
H x1 I x5
T x4 R x1 S x2 K x2 J x4 L x1 Q x1 O x1 P x1
G x1
N x1
F x1
D x2
C x2

506-7094
EN
WARNINGS / LIMITATIONS:
- Fits 20-29" wheels up to 3" wide and fat
bikes up to 4.5" wide with accessory strap
sold separately.
- 2 Bike maximum carrying capacity =
70 lbs./32 Kg.
- Compatible with bike with fenders.
- Do not use for off-road use.
- Do not use for tandems or recumbents.
- Do not use on trailer or towed vehicle.
EN part EN description EN item number EN qty.
A — 1
B
EN hook collar top
EN hook collar bottom — 1
CEN wheel loop B — 1
DEN wheel loop A — 1
EEN mast liner 8527888001 2
FEN mast tube — 1
GEN arm tube and central bracket assembly — 1
HEN bolt std 1/2"-13 x 3 1/4" 051029100020 1
IEN M8 - 1.25 x 55 bolt 915085554 5
JEN wheel tray knob 8527889001 4
KEN arm position knob 8527910001 2
L056003612020 1
N— 1
O8537489 1
P853578702 1
Q05003800000 1
R938080054 1
S908102054 2
T
EN hitch pin clip
EN stinger
EN stinger adapter
EN stinger adapter fastener
EN keyed pin assembly
EN M8 lock nut
EN M10 x 20 hex head bolt
EN M10 flat washer 951102054 2

506-7094
1
2 3
EN
IMPORTANT:
- Tighten knobs by hand only.
- Do not over tighten.
- Do not use power or pneumatic tools.
G
G
N
G
G T
S
17 mm
E
EN Tighten Well

506-7094
4
5
F
I
F
Q
6

506-7094
I
8
C
C
D
D
A
A
C
B
D
B
7
J
C & D
EN
- Insert bolt through bracket and slides.
EN
- Thread knob on, but do not over tighten.
EN
- Slide wheel loop onto bike arms.

506-7094
10 EN THE RACK IS NOW READY TO LOAD BIKES.
3
1
2
9EN FOOT INSTALLATION FOR 1 1/4" RECEIVERS
EN Receiver Installation EN Receiver Installation EN Tighten Well
A B C D E
EN
- Insert safety pin through
hole.
EN
- 11/4" receiver installation.
EN
- 2" receiver installation.
A B

506-7094
11
12
EN Bicycle Installation
EN
- Raise the hooks by depressing the grey buttons and sliding the hooks upward on the mast.
2
3
2
EN Tighten Well
13
EN
- Place the bike on the bike tray with the wheels in the
wheel trays and push down hook firmly until top tube
fits snug against top bend of hook underside. If loading
two bikes, load the first bike (heaviest bike) onto the tray
closest to the vehicle.
EN
- Push down hook firmly.
A
A B
B

14
EN
- Try to position smaller bicycle between support and bumper, combined bicycle weight should not exceed
70lbs. or 35lbs. per bike.
EN
- Attach wheel straps to front and rear wheels as shown. Check security of
bike. Tighten down hook or wheel straps if needed.
EN Tighten Well
15
EN
- To lock the bikes to the carrier.
A
A B C
B
