SPORTSARTC580RCOMMERCIALBIKE
TABLEOFCONTENTS
1.INTRODUCTION....................................................................................................
2.IMPORTANTSAFETYPRECAUTIONS...............................................................
3.ASSEMBLINGYOURBIKE
ListofParts............................................................................................................
Step-by-stepInstructions.......................................................................................
4.UNDERSTANDINGTHEDISPLAYCONSOLE
DisplayFeatures.....................................................................................................
DisplayFunctions...................................................................................................
ButtonFunctions.....................................................................................................
5.HOWTOOPERATEYOURBIKE
QuickStart.............................................................................................................
WorkoutSetup.......................................................................................................
CoolDown.............................................................................................................
6.PROGRAMS
Manual..................................................................................................................
Random.................................................................................................................
Interval(1:1,1:2,2:2)............................................................................................
FatBurn................................................................................................................
Plateau..................................................................................................................
WtLoss/Cardio/CustomHR..................................................................................
FitTest..................................................................................................................
7.USERPARAMETERSETTING............................................................................
8.AUTOMATICCHANNELSCAN............................................................................
9.MAINTAININGTHEBIKE.......................................................................................
10.GUIDELINESFOREXERCISE
HowlongshouldIexercise.................................................................................
HowoftenshouldIexercise.................................................................................
11.TROUBLESHOOTING.........................................................................................
12.WiringSchematic..................................................................................................

SPORTSARTC580RCOMMERCIALBIKE
INTRODUCTION
Congratulationsonpurchasingoneofthefinestpiecesofcommercialgradeexercise
equipmentonthemarkettoday,theSportsArtC580RRecumbentBike.Constructed
ofhighqualitymaterialsanddesignedforyearsoftrouble-freeusage,theC580Rwill
beanintegralpartofyourfitnessregimen.
BeforeusingyourC580Rbike,werecommendthatyoufamiliarizeyourselfwiththis
Owner'sManual.Whetheryouareafirsttimeuserofarecumbentbikeora
seasoned"pro,"understandingthecorrectuseoftheequipmentwillenhanceyour
abilitytoachieveyourexercisegoalssafelyandsuccessfully.
1
SeatBack
Headset
Socket
Headset
Hook HTR
LCDScreen
DisplayBackCover
BookRack
FanCover
DisplayPost
Pedal
TopEnclosure
MainEnclosure
Crank
FootPod
TransportWheel
FrontCrossBar
Handlebar
RearFrame
RearCrossBar
FloorLevelAdjustment
SeatPostCover
RearFrameCover
FootAreaCover
SeatAdjustment
Lever
SeatBack
AdjustmentLever
AccessoryTray
SeatBottom

YourSportsArtbikewasdesignedandbuiltforoptimumsafety.However,certain
precautionsapplywheneveryouuseyourbike.Pleasereadtheentiremanualbefore
assemblyandoperation.Also,pleasenotethefollowingsafetyprecautions:
Pleasereadandobservethefollowingsafetyguidelines:
Keepthisowner'smanualforfutureuseandreference.
Readthisowner'smanualandfollowtheinstructions.
Assembleandoperatethebikeonasolid,levelsurface.
Neverallowchildrenonornearthebike.
Checkthemachinebeforeeveryuse.Makesureallpartsareassembled,andall
nutsandboltsaretightened.Donotusethemachineiftheunitisdisassembledin
anyway.
Keepyourhandsawayfrommovingparts.
Wearproperworkoutclothing.DoNOTwearoverlylooseclothing.Donotwear
shoeswithleathersolesorhighheels.Tiealllonghairback.
Donotrocktheunitfromsidetosideandtakecarewhenmountingand
dismountingtheunit.
Donotstandontheunit.
Donotuseaccessoriesthatarenotspecificallyrecommendedbythe
manufacturerasthesemightcauseinjuriesorcausetheunittofail.
Allowsufficientspaceonbothsidesofthebikeforuserstomountandtodismount
theunit.
Ifanypartsfailoraredefective,pleasestopyourworkoutimmediatelyandcontact
yourauthorizeddealerforrepairs.
Workwithinyourrecommendedexerciselevel;doNOTworktoexhaustion.
Ifyoufeelanypainorabnormalsensations,STOPYOURWORKOUT.Consult
yourphysicianimmediately.
IMPORTANTSAFETYPRECAUTIONS
WARNING
2

Theweightlimitforthisbikeis150kgs(330lbs).
Beforebeginninganyexerciseprogram,youshouldconsultwithyourdoctor.Itis
recommendedthatyouundergoacompletephysicalexamination.
CAUTION
3

ASSEMBLINGYOURBIKE
INSTALLATIONREQUIREMENTS:
LISTOFPARTS:
Thankyouforpurchasingourproduct.Eventhoughwegotogreateffortstoensure
thequalityofeachproduct,occasionalerrorsand/oromissionsdooccur.Please
contactyourdealerifyoufindthisproducttobedefectiveormissingapart.
Pleasereadthisowner'smanualandfollowtheinstructions.
IMPORTANT:Thepackingforthisbikewasdesignedtoprotectitduringshipment.
Pleasestoretheoriginalpackinginasafeplaceincaseyouneedto
shiptheunitinthefuture.
Beforeassemblingyourbike,makesurethatyouhaveallofthefollowingitems.
1.Onemainframe
2.Onerearframe
3.Oneseattube
4.Onehandlebar
5.Oneseat
6.Oneseatback
7.Oneelectronicdisplayandpedestal(referredtoasa"post")
8.Pedals(right+left)
9.Onerearframecover
10.Oneseatpostcover(right)
11.Oneseatpostcover(left)
12.Onetoolkit
4

Pleaseseethepartillustrationsbelow:
1.MainFrame2.RearFrame
3.SeatTube4.Handlebar5.Seat
6.SeatBack7.ElectronicDisplay&Post8.Pedals9.RearFrameCover
10.SeatPostCover(Right)11.SeatPostCover(Left)12.ToolKit
Somepartsmaygetmixedamongstpackagingmaterialduringshipping.Please
locateallthepartsbeforeyoudiscardthepackagingmaterial.Thoroughlyreadthe
assemblyinstructionsbeforeyoubegin.
5

STEP-BY-STEPINSTRUCTIONS
BeforeassemblingtheRearFrameandtheSeatTube,findtwopiecesofcard
boardsfromthepackagingmaterialandstackthemtogether.Placethecardboards
underneaththeMainFramesothatitleavesa60mmspacetotheground.
SeatTube
RearFrame
MainFrame
60mm
CardBoard
6

FRAMEASSEMBLY
STEP1.
STEP2.
Removescrewsandwashersfromthemainframe.Assembletherear
frame(part#2)ontothemainframe(part#1).SeeFig.1.
LooselysecurethescrewsandwashersasshowninFig.2.Atthismoment,
doNOTtightenthishardwarefully.Leaveitsomewhatloose.
Fig.1
Fig.2
MainPrame
RearFrame
7

SEATTUBEASSEMBLY
STEP1.
STEP2.
AssembletheSeatTube(part#3)ontotheRearFrame(part#2).SeeFig.
Foursetsofscrewsandwashersareprovidedtosecuretheseattubeto
therearframe.Pleasesecuretwosetsofhardwarefrombelow,then
secureonesetintoeachside(oneontheleft,andoneontheright).Atthis
moment,doNOTfullytightenthishardware.Keepthehardwaresomewhat
loose.SeeFig.4.
SeatTube
RearFrame
MainFrame
Fig.3
Fig.4
8
3.

STEP3.
STEP4.
PlacetheSeatTubeontheSeatPost.Lightlysecurescrewsandwashers
asillustratedbelow.DoNOTfullytightenthehardware.Leaveitsomewhat
loose.SeeFig.5.
WhenscrewsatA,B,andClocationsareinplaceloosely,pulltherear
frame(part#2)backwardawayfromthefrontofthebike.Usethetool
providedtotightenthesescrewsinthefollowingorder:A,B,andC.See
Fig.6.
Fig.5
Fig.6
MainFrame
D
SeatTube
RearFrame
9

STEP5. PlugthepowercordconnectorintothesocketasshowninFig.7.
Fig.7
10

HANDLEBARASSEMBLY
STEP1. PlacetheHandlebar(part#4)ontheSeatTube(part#3).Whenthefour
screwholesalign,securethemintheordershowninpartAofFig.8.
Fig.8
screw
springwasher
flatwasher
11
Handlebar
MainFrame

STEP2.
STEP3.
Pullthecableplugsthroughthegapandconnectthemintothesocketson
theframe.
ConnectcablesasshowninFig.10.
Fig.9
Fig.10
12

SEATASSEMBLY
PlacetheSeat(part#5)ontopoftheSeatTube(part#3).Whenthefourscrew
holesalign,tightenthefoursetsofscrewsandwashersfromthebottomupwardas
showninFig.11.
Fig.11
Seat
SeatTube
MainFrame
13
3
1
5

SEATBACKASSEMBLY
STEP1. Turnthescrewcovers(shownasA)asideandplacetheSeatBack(part#6)
abovetheSeatTube(part#3).Whenthefourscrewholesalign,securethe
foursetsofscrewsandwashers.Screwsshouldbeplacedfromthetop
downwardasshowninFig.12.
Fig.12
SeatBack
MainFrame
14
SeatTube
3

STEP2. Turnscrewcoversbackinplacetocoverthescrews.SeeFig.13.
Fig.13
15

ELECTRONICDISPLAY&PEDESTALASSEMBLY
STEP1. Connectalldatacablesinthepedestal(part#7)asshowninFig.14.
Fig.14
ElectronicDisplay
&Pedestal
MainFrame
16

STEP2. AssembletheDisplayPedestal(part#7)ontotheMainFrame.Loosely
securescrewBinplacebutdonotfullytightenit;LooselysecurescrewsC
inplacebutdonotfullytightenthemyet.Finally,tightenallscrews(firstB,
thenC)tosecuretheDisplayPedestal.Putthesoftcapsinplacetocover
thescrewheads.SeeFig.15.
Fig.15
Softcaps
17

PEDALASSEMBLY
Assemblebothpedalsontocranksandtightenthemwiththewrenchprovided.See
Fig.16.Notethatpedalsareside-specific.Theleftpedalthreadscounterclockwise.
Therightpedalthreadsclockwise.Rightandleftaredefinedastheexerciser'sright
andleftsides.PedalsaremarkedwithRandLfordifferentiation.
Fig.16
PedalL
PedalR
18

COVERINSTALLATION
STEP1. AssembletheRearFrameCover(part#9)ontotheMainFrame(part#1)
asshowninFig.17.
Fig.17
19
Rear
FrameCover
PostcoverR
PostcoverL
MainFrame
