SPX Pearpoint Flexiprobe P340 User manual
P340 flexiprobe™
PEARPOINT’S ADVANCED DIGITAL VIDEO INSPECTION SYSTEM
90/P340-OPMAN-ENG/05 ISSUE 5 01/2014 READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING THE SYSTEM
OPERATION MANUAL
i
Preface
Before you begin
Please read this operation manual before attempting to use the P340 flexiprobe system. Note that this
manual and all its contents are subject to change. Pearpoint products are under continuous development.
Pearpoint reserves the right to modify any product, including this manual, without notice and some product
changes may have taken place after publication of this user manual.
Contact your local Pearpoint dealer or visit www.radiodetection.com for the latest information about the
P340 flexiprobe product family, including all accessories, documentation and software updates.
The P340 system is a modular system that can be purchased as a full system package, or as individual
components. Contact your local Pearpoint representative to ensure you are purchasing the appropriate
product for your needs.
Important safety notices
Please observe all safety notices and warnings in this manual before operating any Radiodetection or
Pearpoint product.
Warnings, Cautions and Notes
WARNING!: Warnings alert you to possible personal injury.
CAUTION: Cautions alert you to possible equipment damage.
NOTE: Notes contain useful information.
Key to symbols used
General Warning: Refer to Manual for specific instruction or advice.
Electrical Hazard: Observe safe practices and exercise extreme caution.
Heavy object: Take additional care when lifting.
Biohazard: Disinfect after use. Wear appropriate personal protective equipment (PPE).
Hot Surface: Allow to cool or use appropriate protection when handling.
General
Pearpoint has taken care to provide the necessary information in this manual for the safe installation,
operation, maintenance and disposal of this equipment. However, perform a risk assessment prior to
commencing work as it may highlight additional safety issues specific to the application.
P340 flexiprobe Operation Manual ii
Installation, operation and safety precautions
WARNING: The P340 flexiprobe, including its component parts are heavy. If available, use the wheels
to assist transport. Observe heavy-lifting safety practices when lifting any component of this system. Refer
to the specifications in Appendix 11.5 for a description of the system’s dimensions and weights.
WARNING: If system connects to mains operated equipment then the external equipment must be
earthed in accordance with the manufacturer’s instructions. Failure to comply with this may cause the unit
to become live and a LETHAL HAZARD.
Please observe your company, region and country’s Standard Code of Practice for surveying underground
utilities with CCTV equipment, if applicable, when using this equipment.
WARNING: Foul systems can be a source of serious biological hazards. Wear appropriate protection
(PPE) when handling the P340 flexiprobe.
WARNING: The camera will get hot with use. This is normal. Exercise care when handling the camera,
consider gloves.
WARNING: System components must NOT be connected or disconnected when the power is on.
Do not touch any connectors while the system is live
Take care to ensure that video and power cables don’t become entangled in the reel. Cable ties are
recommended and will not impede system performance.
Always store the P340 flexiprobe system in a clean and dry environment.
WARNING: Always carry out a risk assessment of the site to be inspected. This equipment is NOT
approved for use in areas where potentially explosive (or otherwise hazardous) gases, vapors, liquids or
solids may be present.
Ensure that standard safety precautions for working in hostile environments are followed. Including manual
handling, biological hazards and personal injury.
The P340 flexiprobe system requires connection to a protective earth; if in doubt, consult a qualified
electrician. Electrical equipment is factory tested for electrical safety. Routine inspection is recommended
(and may be required by law) to maintain this level of protection. If you are unsure, contact your local safety
authority for advice.
Always use heavy-duty industrial gloves when withdrawing rod from a sewer.
The distance counter should only be used as an estimation, Radiodetection recommends the use of a
sonde and a Radiodetection cable locator to accurately locate positions of interest. Especially prior to
construction works.
Always ensure that cabling is properly connected.
Always switch the system on and off using the controller switch.
P340 flexiprobe Operation Manual iii
WARNING: This coiled rod retains a large amount of energy when coiled and can cause injury if not
correctly handled. Only competent personnel should handle this product. Radiodetection and Pearpoint
recommend that a risk assessment is undertaken before the rod is handled, the bindings are cut or when
using, loading, unloading, uncoiling or coiling rod. Appropriate Personal Protective Equipment must be
worn, such as eye and hand protection. Radiodetection accepts no liability for injury or damage to
equipment incurred whilst using, loading, unloading, uncoiling or coiling rod.
WARNING: To avoid risk of burns, do not touch the camera when switched on or immediately after
switch off. Leave ample time for it to cool before handling.
WARNING: The camera’s LEDs are very powerful. Do not look directly at the LEDs or point them at
other people.
Only use charging equipment provided by Radiodetection Ltd. The use of alterative chargers may cause a
safety hazard and / or reduce the life of the battery.
CAUTION: Do not tamper with, or attempt to disassemble the battery.
CAUTION: If battery failure is suspected return the entire unit to an authorized repair center for
investigation and repair. Local, national or IATA transport regulations may restrict the shipment of faulty
batteries. Check with your courier for restrictions and best practice guidelines. Talk to a Pearpoint sales
representative for authorized repair centers.
The P340 flexiprobe external battery pack contains lead-acid batteries. Contact your local Pearpoint
representative for instruction on correct removal and handling of the batteries. Follow local regulations for
correct disposal of the battery box. Batteries may be subject to shipping regulations, consult your courier if
unsure.
The following safety precautions apply to the P340+ controller only, which contains a Li-Ion rechargeable
battery:
WARNING: Exposing the battery to a high temperature above 60°C (140°F) may activate safety
systems and cause a permanent battery failure.
CAUTION: Waste Li-Ion batteries must be disposed of properly, use an approved recycling facility for
electronic waste.
NOTE: The battery is designed to protect itself against over-discharge, overcharge and short circuit
between charge terminals. Other batteries may not provide these safety circuits.
Contact your local Radiodetection representative for information on purchasing battery packs and chargers.
P340 flexiprobe Operation Manual iv
Maintenance
Clean and sanitize the P340 flexiprobe system at regular intervals and after conducting an inspection.
Consider the work environment and clean / sterilize appropriately before shipment, following any applicable
laws and guidelines.
Always keep all connectors covered with their protective caps when the equipment is not in use to prolong
the life of your product. Do not apply grease, lubricants or other fluids to any of the connectors or pogo
pins in the system (especially to the camera connection). The supplied grease is provided to apply in small
doses to any o-rings in order to keep the waterproof seal.
Do not dismantle any component of this system unless directed by this operation manual. Dismantling
components not specified by this manual may void the product warranty.
Pearpoint recommends that only authorized service centers carry out service of this product. Service
elsewhere will void the warranty.
CAUTION: The rod guide assembly (see below figure 0.1) must be reviewed regularly to determine whether
a replacement is needed. If the rod wears through the guide it will begin to wear through the metal
structure. Wear to the metal components of the system may cause potential hazards to the user (typically
sharp edges or electrical malfunction). Spare rod guides can be purchased and fitted by competent
mechanical technicians using a screwdriver. Spare rods and various components are available to
purchase as repair kits.
Figure 0.1 Rod guide assembly
For information regarding any service needs, please visit www.radiodetection.com or contact your local
Radiodetection or Pearpoint representative or dealer.
P340 flexiprobe Operation Manual v
Disposal
Do not dispose of this product in municipal waste facilities. Please check local regulations for disposal of
electronic products, batteries and type of waste / whether any hazards are contained.
Pearpoint complies with the requirements of 2002/96/EC Waste Electrical and Electronic Equipment.
Compliance
EU Compliance
This equipment complies with the following EU Directives:
Low Voltage Directive: 2006/95/EC
Machinery Directive: 2006/42/EC
EMC Directive: 2004/108/EC
FCC Compliance Statement
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
The equipment may not cause harmful interference.
The equipment must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the manufacturer’s instruction manual, may cause harmful interference with radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case you
will be required to correct the interference at your own expense.
Modifications: Any modifications made to this equipment not approved by Pearpoint may void the authority
granted to the user by the FCC to operate this equipment.
Industry Canada Compliance Statements
ICES-003 Class A Notice:
This Class A digital apparatus complies with Canadian ICES-003.
Avis NMB-003, Classe A: Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada
P340 flexiprobe Operation Manual vi
Trademarks
The following are considered trademarks of Radiodetection Ltd.: P340, GatorCam, flexitrax, flexiprobe,
FlexiSight Manager and RD7000. Copyright © 2014 Radiodetection Ltd. All rights reserved.
Radiodetection is a subsidiary of SPX Corporation.
Radiodetection and Pearpoint are trademarks of Radiodetection Ltd. SPX is a trademark of SPX
Corporation Inc.
Microsoft Word, Microsoft Office 97, Windows XP, Windows Vista, Windows Explorer and Windows 7 are
either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
QuickTime is a trademarks of Apple Inc., registered in the U.S and other countries.
Other trademarks or registered trademarks mentioned in this document belong to their respective owners.
Disclaimer
Any third-party products (including hardware, software and services) mentioned in this manual are for
instructional purposes only and are not an endorsement by Radiodetection Ltd, Pearpoint or SPX
Corporation.
Radiodetection Ltd does not accept any liability for loss of data or damage to equipment when using any
third-party products.
Copyright statement
© 2014 Radiodetection Ltd. All rights reserved. Radiodetection is a subsidiary of SPX Corporation. SPX,
the green “> ” and “X” are trademarks of SPX Corporation Inc.
Radiodetection, Pearpoint, flexiprobe, flexitrax, GatorCam and flexicoiler are considered trademarks of
Radiodetection Ltd.. Due to a policy of continued development, we reserve the right to alter or amend any
published specification without notice. This document may not be copied, reproduced, transmitted,
modified or used, in whole or in part, without the prior written consent of Radiodetection Ltd.
The Bluetooth word, mark and logos are registered trademarks of Bluetooth SIG, Inc. and any use of such
trademarks by Radiodetection is under license.
P340 flexiprobe Operation Manual vii
Training
Radiodetection provides training services for most Pearpoint products. Our qualified instructors will train
equipment operators or other personnel at your preferred location or at Radiodetection facilities. Training in
best practices can lead to improved efficiency, avoid workplace accidents, how to diagnose and repair
simple issues, as well as facilitating longer product lifetimes.
For more information go to www.radiodetection.com or contact your local Pearpoint representative.
P340 flexiprobe Operation Manual viii
P340 flexiprobe Operation Manual ix
Contents
Preface i
Section 1: Introduction 1
1.1 About this manual 1
1.2 Overview 1
1.3 Safety notices 2
1.4 Latest updates and information 2
Section 2: System Overview 3
2.1 Controller 3
2.2 Pushrod reels and cameras 6
Section 3: Quick start guide 8
3.1 Quick start procedure 8
Section 4: System Assembly 9
4.1 Controller 9
4.1.1 Mounting 9
4.1.2 Power 9
4.1.3 Compact Flash card 9
4.1.4 USB flash drive 9
4.1.5 Keyboard 10
4.1.6 Headset 10
4.2 Pushrod reel 10
4.3 Cameras and accessories 10
4.3.1 Camera 10
4.3.2 Focusing the cameras 11
4.3.3 Flexisondes and solid sonde 11
4.3.4 Universal flexi 11
4.3.5 Skids and brushes 12
4.3.6 W-Skids 13
4.4 P340+ Internal Rechargeable Battery 14
4.5 External Rechargeable Battery Packs 15
4.6 External Video Equipment 16
Section 5: Controller and system set-up 17
5.1 Overview 17
5.2 Powering up 17
5.3 Getting help 18
5.4 Welcome screen 18
5.5 On-Screen Information 19
5.6 System Menu 20
5.6.1 General Navigation and text entry 20
5.6.2 Entering text with the keyboard 21
5.6.3 Entering text with the keypad 21
5.7 Setup menu 21
5.8 Setting up your controller 22
5.8.1 Basic Settings 22
5.8.2 Recording options 23
5.8.3 Video Quality 25
5.9 Setting up your Reel 26
5.10 On-Screen Information Settings 27
5.11 Company details 29
5.11.1 To set your company details: 29
5.12 Maintenance (including software updates) 30
Section 6: System operation 34
6.1 Before you begin 34
6.2 Calibration 34
6.3 Deploying the camera 35
6.4 Video recording 35
6.5 Still pictures 36
6.6 Digital image controls 37
6.7 Retrieving the camera 37
Section 7: Memory Storage and File management 38
7.1 Supported storage devices 38
7.2 File browser 39
7.3 Viewing JPEG pictures 42
7.4 Playing videos 43
7.5 PC USB connections 44
Section 8: Adding text - Text pages 46
8.1 Video Text Pages 46
8.2 Text Menu 46
Section 9: Jobs, observations and reporting 49
9.1 Introducing JOBS 50
9.2 One-click recording and Quick Job start 51
9.3 Job Browser 52
9.4 Job Reviewer 52
9.5 Job details (Creating a new Job) 54
9.6 Inspection Details 57
9.7 Observations 57
9.8 Other Comments (Freetext) 60
9.9 Condition code lists 60
P340 flexiprobe Operation Manual x
9.10 HTML Report 60
Section 10: Digital Video 63
10.1 Video Specification 63
10.2 Video Quality settings 63
10.3 Video playback 63
10.4 Distributing your recordings 65
10.5 Converting digital videos 69
10.6 Advanced video editing 71
Section 11: Appendix 73
11.1 Shortcuts 73
11.2 Clamp assembly 74
11.3 Care and maintenance 75
11.4 AVC Video license 76
11.5 Specifications 77
P340 flexiprobe Operation Manual 1
Section 1: Introduction
1.1 About this manual
This manual provides comprehensive operating instructions for the P340 flexiprobe pipeline video
inspection system. Before attempting to operate the P340 flexiprobe system, it is very important that you
read this manual, noting all safety warnings and procedures in the Preface, Section 1.3 and throughout the
rest of the manual.
Once you have read this manual, we recommend that you retain it for reference purposes. A printed
version of this manual is available on request. Please contact your local Pearpoint representative for more
information. The rest of the manual is detailed as follows:-
Section 2 is a system overview that includes annotated illustrations of the controller, pushrod reels and
selected accessories.
Section 3 provides users with quick start instructions to operating the controller.
Section 4 provides a detailed guide to assembling the system ready for conducting inspections.
Section 5 provides a comprehensive introduction to using and configuring the controller.
Section 6 introduces the basics of pipeline inspections and describes how to deploy the rod, create video
recordings and control the camera during an inspection.
Section 7 introduces the Compact Flash card / USB flash drive browser and provides a detailed guide to
managing survey files.
Section 8 introduces the Text Page overlay functionality, explaining how to edit, import and display text.
Section 9 introduces the way the controller stores information, including Jobs, Observations and Reporting.
Section 10 provides a comprehensive guide to digital video options and settings. Section 10 also includes a
guide to converting and distributing videos for playback on computers and other video equipment.
Section 11 is an appendix that includes reference and other important information as well as instructions on
caring for and maintaining your P340 system.
NOTE: For instructions about FlexiSight Manager, refer to the FlexiSight Manager Operation Manual.
1.2 Overview
The P340 flexiprobe is an advanced pipeline video inspection system that is ideal for a broad range of
applications. This system allows operators to identify and document pipeline faults using the latest in digital
video recording technology. The P340 flexiprobe is a fully modular system; the controller can drive any
combination of the P340 flexiprobe range of pushrod reels and cameras.
P340 flexiprobe Operation Manual 2
P340 flexiprobe features
•One-Touch recording using industry standard H.264 video and AAC audio format.
•Internal and external rechargeable battery options
•Record up to 50 minutes of high-quality video per gigabyte of memory. For more information about
video recording settings and quality, please refer to Section 5.8.
NOTE: Recording length for a given file size is not fixed and depends on a large number of factors
including, among other things, the live picture being recorded. Constant movement in the camera focus, for
example, will produce larger file sizes per minute of recorded footage. The unit can record up to 4.5 hours
per gigabyte using the low quality setting.
•Pan, zoom and rotate live video or live recordings.
•Still image capturing using industry standard jpeg format.
•Integrated reporting. Reports are generated by the P340 flexiprobe controller in HTML format
compatible with most web browsers. FlexiSight Manager can produce a customizable report,
providing you have a Microsoft Office 97 or higher installed (trial versions may not work).
1.3 Safety notices
Caution must be taken when conducting any pipeline or drainage system inspection. Please observe all
safety warnings detailed in the Preface and throughout this operation manual.
Before you attempt to operate the P340 flexiprobe system, it is recommended that you familiarize yourself
with any additional health and safety requirements that may be defined by company policy and any
applicable local or national laws. Contact your company’s or local government’s health and safety officer for
further information.
1.4 Latest updates and information
Pearpoint may have released new system software, user documentation or other information after you
purchased your system.
You can download the latest software, documentation and application notes from www.radiodetection.com.
For more information about checking and upgrading your system’s software, please refer to Section 5.12.
P340 flexiprobe Operation Manual 3
Section 2: System Overview
The P340 flexiprobe pushrod inspection system comprises of a controller, pushrod reel, camera and
accessories. This subsection provides a detailed, illustrated overview of these components.
2.1 Controller
The P340 command module unit acts as the controller and digital video recorder and playback device.
Video is displayed on an 8" industrial LCD. Video, pictures and inspection reports are stored on a
compatible high-speed Compact Flash card or USB flash drive. See Figures 2.1 to 2.3.
1. On/Off Switch: Switches power ON or OFF.
2. Keypad and function keys: Allows the operator to control the system, select functions and edit
text entries.
3. Keyboard: Provides enhanced text entry capabilities and shortcuts to access system functions.
4. Display: LCD Screen shows video, still images and various on-screen system information.
5. Link cable socket: To connect the pushrod reel to the controller with a link cable.
6. Controller support clamp: To mount the controller onto the reel (optional on the Mini model).
7. Fuse holder: 5mm x 20mm T3.15A 250V cartridge fuse.
8. VIDEO IN and VIDEO OUT Connectors (RCA Video Jacks): Provide secondary input and
output options for external composite video equipment.
9. Power socket: DC power input from vehicle supply, internal or external batteries (optional), or
mains adaptor.
10. On/off switch: Switches power ON or OFF.
11. Audio socket: Connects the optional headset to record/playback audio over videos.
12. USB socket: The controller can use a USB flash drive to store video recordings, reports and
pictures. Most stored files can be viewed or played on the controller or transferred to PC. Also
used to store and upload software upgrades
13. Internal battery power port and charger (P340+ only). Dual-use connector, used to supply
power to the controller, or charge the internal battery.
14. PC socket. USB (type B) connection to transfer files to computers.
15. Keyboard socket: Connects the keyboard
16. Compact Flash card slot: The controller can use a Compact Flash card to store video
recordings, reports and pictures. Most stored files can be viewed or played on the controller or
transferred to PC. Also used to store and upload software upgrades.
17. Battery status indicator (P340+ only): Provides an estimation of the internal battery charge
when the Battery Check button (item 18) is pressed.
P340 flexiprobe Operation Manual 4
18. Battery Check button (P340+ only): Activates the battery status indicator (item 17).
Figure 2.1: Controller Module
Figure 2.2 Controller Rear View
Figure 2.3 Controller I/O socket
P340 flexiprobe Operation Manual 5
Keypad
See Figure 2.4
19. Function keys: Use to select menu items or activate short cuts.
20. Camera key: Press to take screen captures.
21. Text key: Press to access the Onscreen-Text and Report menu.
22. Play: Enters the card browser menu. Starts or continues video playback of selected file.
23. Pause: Press to pause or restart video playback or recording.
24. Record: Press to begin a new video recording.
25. Stop: Press to stop video playback or recording.
26. Crawler stop key: Not functional on this model.
27. Arrow keys: Use for navigation and system parameters.
28. OK: Press to select or confirm choices in the menu system.
29. LED brightness/camera focus keys: not functional on this model.
30. Rotate/pan keys: Press to rotate the camera view. Fn + Rotate to pan left or right.
Simultaneous press will re-center the view.
31. Function key (Fn): Press and hold in combination with other keys to activate alternate
functions.
32. Zoom/Iris keys: Press to zoom in or out of the camera’s subject. Fn + Zoom to modify the Iris.
(Iris not functional on this model). Simultaneous press will reset the zoom to unity.
Figure 2.4: Controller Keypad
P340 flexiprobe Operation Manual 6
2.2 Pushrod reels and cameras
See Figures 2.5 to 2.8.
1. Pushrod Reel: Holds the
pushrod on a revolving reel. The
pushrod can be up to 500ft
(150m) in length (depending on
reel type).
2. Pushrod Guide: Guides the rod
on and off the reel.
3. Brake: Adjustable to control the
movement of the reel, or to lock
it.
4. Adaptor Clamp (optional on the
P341 models): Allows the
controller to be mounted onto
the pushrod reel.
5. Stowage Hooks: To store the
link cable on the push- rod reel.
6. Link Cable Socket: To connect
the link cable to the reel.
7. Camera: Two color camera
options are available:
a. 1” (25mm) diameter,
adjustable-focus camera
for up to 4” (100mm)
diameter pipes.
b. 2” (50mm) diameter,
adjustable-focus, self-
leveling camera for up to
9” (230mm) diameter
pipes.
8. Universal Flexi: Attaches to the
end of the pushrod to allow the
camera to negotiate small radius
bends.
9. Solid Sonde (9a) and
Flexisonde (9b): Attaches to the
end of the pushrod and
transmits a signal to allow the
position of the sonde to be
pinpointed using a RD7000DL+
receiver (optional purchase).
Not-detachable Plumbers sonde
(9c) (Plumbers reels only):
transmits a signal to allow the
Figure 2.5: P343 Pushrod Reel
7
6
1
4
5
2
3
5
Figure 2.6: P340 Cameras
7a
7b
Figure 2.7: Universal flexi and Sondes
9a
9b
9c
8
Figure 2.8: Brushes and skids
10
11
P340 flexiprobe Operation Manual 7
position of the sonde to be pinpointed using a RD7000+DL receiver (optional purchase).
10. Universal brushes and skids: Protect the camera during use and centers the camera in the pipe. See
Section 4.3 for instructions on how to install skids and brushes.
11. Plumbers skidball range for 1” (25mm) camera, allows movement around most 2” (50mm) traps and
1.25” (32mm) bends. Available in 1.4” (36mm) and 1.6” (42mm).
Accessories (not shown):
Systems Include:
•Car Adaptor: Connects the controller to your vehicle’s power supply.
•Automotive charger OR Mains charger for internal rechargeable Li-Ion battery (P340+ only).
•Mains Adaptor: Waterproof (IP67 except at interconnections with lower-rated equipment) mains
power supply.
•USB Lead: USB A to B lead. Connects the controller to your PC
•Compact Flash card.
•FlexiSight Manager software
Optional:
•External Battery Pack: Allows the use of the system where mains power is not available.
•USB flash drive: Allows video and survey recording onto modern high-speed USB drives from our
approved device list.
• Headset: Allows the user to add and review audio commentary.
As well as various other useful tools and accessories to perform a professional survey.
Compatibility:
The P350 flexitrax controller is fully compatible with the full range of P340 flexiprobe cameras, reels,
sondes and accessories, providing unmatched modularity from the small 100’ (30m) Plumbers system to
the 1000’ (305m) fully motorized P356 steerable crawler (the P340 controller cannot control a P350
Tractor system).
P340 flexiprobe Operation Manual 8
Section 3: Quick start guide
This Section provides the user with quick start instructions for operating the P340 controllers. Note this
Section is intended as a reference for experienced users; first-time users should read this manual in its
entirety before proceeding.
3.1 Quick start procedure
•Ensure the power switch is set to the Off position.
•Mount the controller on top of the reel if desired (mounting bracket is optional on the P341 models).
•Using the link cable, connect the reel to the connector on the rear of the controller.
•Insert a compatible Compact Flash card (or USB flash drive) into the controller.
•Connect the power supply to the controller power input.
•Switch the controller on. There is a delay of several seconds before the Power up screens appear.
•Press OK to clear the welcome screen.
•Calibrate the reel and zero the camera’s
position. Press F10 on the keyboard, or
and on the keypad simultaneously.
•Deploy the camera into the pipe as
required.
•On the keypad, press the ●key to start
recording the inspection. If required:
oEnter your JOB details by entering
the client name, site address,
survey start and finish references.
See Section 9.1 for more details
about JOBS or Section 5.8.1 to
disable the quick job creation
option.
oPress ●again.
Press the key to take screen captures.
If required:
•To pause a recording press key.
•To stop a recording, press the key.
NOTE: Do not extract the removable storage
device during recording or playback. Doing so
may corrupt all data on the storage device and
crash the controller.
To add text quickly on your survey, press PG UP or PG DN on the keyboard, followed by the OK button to
confirm.
Figure 3.1: Controller installed on pushrod reel.
