Spyder Wheelz E-CHOPPER User manual
USER MANUAL
SPYDER WHEELZ
E-CHOPPER
SPYDERWHEELZ.COM
WELCOME TO
> SPYDER WHEELZ
Dear Spyder Wheelz e-chopper user,
Thank you for choosing a Spyder Wheelz e-chopper.
We would like to warmly welcome you to the growing club of Spyder
Wheelz e-chopper users. This user manual contains instructions on the
use and care of your Spyder Wheelz e-chopper. For your safety, and that
of other road users, and in order to be able to use your Spyder Wheelz
to the full, we would like to advise you to read this user manual carefully
before you get going. Proper maintenance, adherence to instructions on
the care and mechanics of the moped which
are set out in this user manual, and regular inspections by your Spyder
Wheelz dealer are required for a safe trip and retention of this guarantee.
We wish you comfortable and safe travel!
COLOPHON
Spyder Wheelz E-Chopper user manual
Spyder Wheelz reserves the right to make changes to the design and/or prices without
further notice. This user manual has been put together with due care. Spyder Wheelz
cannot, however, be held liable for any inaccuracies of whatever nature.
User manual SPYDER WHEELZ | 2021 3
> > IMPORTANTINFORMATION
FOR USERS
SYMBOLS AND DRAWINGS THAT YOU WILL FIND IN THIS USER MANUAL
Important information and tips for users. Familiarise yourself with
thecontent,asthiswillcontributetotheecientandsmoothuseof
your e-chopper
The battery of the Spyder Wheelz e-chopper is subject to recycling/utilisation according
to the 2006/66/EC directive of the European Parliament and the Council of Europe of 6
September 2006 for batteries/accumulators and used batteries/accumulators, replacing
Directive 91/157/EEC. Damaged, used and inoperative batteries should be returned to the
designated KCA locations.
Because the Spyder Wheelz e-choppers scooters are authorised on public roads, you must
follow the local trac regulations.
Spyder Wheelz e-choppers are designed for use on paved roads. Spyder Wheelz is not
responsible for unsuitable use of the e-chopper.
For correct and ecient use, Spyder Wheelz recommends reading the user manual carefully.
User manual SPYDER WHEELZ | 2021 4
> SAFETY INFORMATION
BEFORE RIDING
INSPECTION PRIOR TO EACH TRIP:
The plug is out of the socket.
The battery has been suciently charged.
Lights and horn work properly.
The mirror has been adjusted correctly.
Tyres are at the right pressure and have sucient tread depth.
The brakes work properly (test when pushing).
Steering angle to the left and right is
sucient and goes without resistance.
RIDING SKILLS
Ride cautiously and sensibly.
Always keep two hands on the wheel.
> CONDITIONS
Driver must be in possession of a valid driving licence (Dutch AM level).
In the event of damage, breach of contract or a collision, please contact
the rental company immediately.
The maximum number of kilometres to be driven (operational radius): 55 - 70 km.
Maximum 1 person - maximum load: 120 kg including luggage.
User manual SPYDER WHEELZ | 2021 5
> CONTENTS
VEHICLE DESCRIPTION
OPERATING FUNCTIONS
BATTERY INFORMATION
TECHNICAL
SPECIFICATIONS
VEHICLE CARE
SERVICE TABLE
6
7
8
9
10
11
User manual SPYDER WHEELZ | 2021 6
> VEHICLE DESCRIPTION
BRAKES
EURO 4 standard road break on the brake levers.
TELEPHONE HOLDER
Telephone holder with USB charger
DISPLAY
HEADLAMP
Halogen headlight with city/high beam option.
STEERING WHEEL LOCK
Cable lock optional
ALARM CLASS 3
Alarm class 3 on remote control.
WIDE TYRES
The wide tyres give the e-chopper its tough, robust look
and also contribute to stable riding and good traction on
the road surface.
FOOT SUPPORT
Foot support for passengers.
BATTERY
20 Ah batteries with an operational radius of 70
kilometres
POWER CHARGER (EXTERNAL)
5 Ah Smart Power Charger in an aluminium casing
with a built-in cooler to prevent overheating and a
unique trendy design duo seat.
SINGLE SEAT
This spacious single seat ensures you will be
comfortable. If you’d like to take somebody
with you, that’s no problem, although we
wouldn’t recommend this for longer trips.
1
2
5
3
4
6
7
8
9
10
11
1
2
5
3
6
4
7
8
9
10
11
User manual SPYDER WHEELZ | 2021 7
>OPERATION INSTRUCTIONS
Lighting (low/high beam).
Direction indicators
Horn (green button)
Adjustable phone holder with red turning knob and
USB charging port.
Gas lever
Cruise control (red button)
Ignition lock
DISPLAY:
Speed
Battery status
Important:
The 10 diagonal stripes indicate the battery status
and your range. The voltage shown only indicates
the power consumption. A full battery
indicates 64-66V and the “tank symbol” on
the display lights up at around 54V, which means
that the battery is almost empty.
Mileage
(note down starting position for maximum
operational radius)
1
2
5
3
6
8
4
7
9
10
READY TO RIDE
Take your seat on the e-Chopper and turn the ignition key 1 click to the right;
2 clicks to the right turns the light on.
Fold up the kickstand; the engine does not work when the kickstand is extended.
Watch out: the electric motor makes no sound but the throttle is active.
Gently twist the throttle to move off and to get used to steering with the wide tyres.
Ride cautiously and responsibly. Always brake using both brake levers!
1
2
3
4
5
6
7
910
8
User manual SPYDER WHEELZ | 2021 8
>BATTERY INFORMATION
BATTERY OPERATIONAL RADIUS
What is my e-chopper’s operational radius? This varies from e-chopper to e-chopper! This
is primarily to do with the driver’s weight, the tyre pressure and driving and road conditions
such as altitude differences, headwind and possibly a lot of stopping and fast acceleration.
See technical specications for more information.
ACCU VEILIGHEIDSINSTRUCTIES
Only connect the charger supplied by Spyder Wheelz to your battery. Using any other type of
charger may damage or destroy the battery pack. Keep the battery out of reach of children
and pets. Exposed batteries and electrodes may lead to an accident. The battery cells
contain chemicals. Opening the battery cassette is strictly prohibited.
CHARGING THE BATTERY
Use only an earthed socket.
Disconnect the battery and remove it from the chopper.
Connect the charger cable to the battery pack before you plug
the charger into a wall socket.
A red LED lights up during charging.
A ashing red LED means that the battery is being brought out of sleep mode.
Then the battery automatically switches to charging
Once the battery is fully charged, a green LED lights up.
A full charge of a at battery takes around 3.5 hours.
The battery should be charged whenever possible. This will ensure your battery lasts
for longer.
Avoid riding with a low battery voltage. This will have a negative impact on your
battery’s lifespan.
There is no risk of over-charging.
Only use your charger on dry, well-ventilated surfaces. You must not cover the
charger and battery or place them in a closed cabinet.
User manual SPYDER WHEELZ | 2021 9
>TECHNICAL SPECIFICATIONS
Model: E-Chopper 2.3
Engine: 1200 watts/60 volts
Lithium battery: 20 AH/60 volts
Operational radius: 70 kilometres*
For an average rider prole (85kg load)
Weight: 57 kilograms
Brakes: Disc brakes front and rear
Motorcycle: 25 km/h
Moped: 45 km/h
Charger: 5 AH
Charging time: max. 3.5 hours
Tyre pressure: 2.5 bar
EC Type approval: e24*168/2013*00015*03
Guarantee: B2C 2 years
B2B 1 years
STANDARD ON THE E-CHOPPER
Alarm class 3, remote control, mirrors, indicators, double seat, phone holder with USB
connection, immobiliser and wheel lock, halogen headlight with city and main beam and
steering wheel lock.
User manual SPYDER WHEELZ | 2021 10
>WHO WE ARE?
VEHICLE CARE
Please note the following instructions in order to properly care for your Spyder Wheelz
e-chopper
Make sure the e-chopper battery is removed from the vehicle before cleaning.
Clean the e-chopper with a damp cloth and clean water on a regular basis.
Do not use a scouring pad or other hard object to remove insects.
Only clean plastic components using the equipment intended for that purpose.
Do not use corrosion protection spray on the brake system, painted and plastic parts
Vehicles parked outside should be protected with a breathable cover.
Standard synthetic covers cause condensation of water beneath the cover.
Avoid prolonged exposure to sun and cold weather conditions such as frost to
prevent rapid ageing of the e-chopper
MAINTENANCE
The maintenance of electric mopeds is much more limited than that of a fuel moped. This
does not mean, however, that electric mopeds require less attention. Your Spyder Wheelz
e-chopper must be inspected at least once per year and every 3000 km.
Only certied Spyder Wheelz representatives/dealers are qualied to give professional
advice, maintenance or repair.
User manual SPYDER WHEELZ | 2021 11
> SERVICE TABLE
If you wish to charge the battery, only use the battery charger supplied.
Use the battery only for your e-chopper.
Do not clean the e-chopper with a hard water jet or high-pressure spray.
If used improperly, you may endanger yourself and others.
Do not use any battery for the e-chopper other than the one supplied.
Do not insert any objects into the charger and do not expose the charger, battery or
electronics to water or other liquids, or excessive heat.
+31 (0)85 022 08 50
spyderwheelz.com
COMPANY DETAILS:
HQ - Tjalk 23
2411 NZ Bodegraven
The Netherlands
HQ - Tjalk 23
2411 NZ Bodegraven
The Netherlands
+31 (0)85 022 08 50
info@spyderwheelz.com
spyderwheelz.com
@SpyderWheelz
@spyderwheelz
Spyder Wheelz TV
According to our registered terms of delivery and warranty terms. Spyder Rent Group Nederland B.V.
Spyder Wheelz is a registered trademark. Version 2021_1
