Spypoint TINY-WBF User manual

USER MANUAL
P INTSPY INTPSPY
SURVEILLANCE CAMERA | TINY SERIES
Adventure
series · série
expedition
series · série
summit pro
series · série
smart
series · série
TINY
series · série
LIVE
series · série
TINY4G
TINY-W3
TINY-WBF TINY-7
TINY-PLUS
v1.1

P INTSPY INTPSPY
THANK YOU FOR CHOOSING A SPYPOINT® PRODUCT.
This manual will guide you through all the features of your device
so that you will get optimal use out of your SPYPOINT®product.
Our priority is to provide outstanding customer service. If you need
support for your product, please contact the SPYPOINT®technical
service or visit our website.
CONTACT
1-888-779-7646
[email protected]
www.spypoint.com
ABOUT US
GG Telecom’s mission is to offer products that are easy
to use, innovative, affordable and of exceptional quality.
Our SPYPOINT®products are mainly used for hunting and
residential/commercial surveillance. They are distributed and
shipped all over the world and the market never stops growing.
Prosperous and respected, GG Telecom is a company that constantly
keeps abreast of new technologies and listens to its customers to
deliver cutting-edge products with practical solutions that improve
hunting and outdoor activities.
JOIN THE SPYPOINT®COMMUNITY
facebook.com/spypoint
youtube.com/spypointtrailcam twitter.com/SpypointCamera vimeo.com/spypointxcelcam
facebook.com/spypoint youtube.com/spypointtrailcam
twitter.com/SpypointCamera
vimeo.com/spypointxcelcam
facebook.com/spypoint
youtube.com/spypointtrailcam
twitter.com/SpypointCamera vimeo.com/spypointxcelcam



CAMERAS WITH CELLULAR TRANSMISSION
• If you need information or would like to subscribe to mySPYPOINTTM service, go to www.myspypoint.com.
• For the latest version of the activation procedure, go to www.spypoint.com/activation.


3
Package contents ....................................................................... 4
Components
Camera........................................................................................ 5
Receiver (BLACKBOXTM).................................................................... 7
Controller (BLACKBOXTM-D) ............................................................... 8
Power
Camera........................................................................................ 9
Receiver (BLACKBOXTM).................................................................. 10
Controller (BLACKBOXTM-D) ............................................................. 11
Memory card
Camera...................................................................................... 13
Receiver (BLACKBOXTM).................................................................. 14
Controller (BLACKBOXTM-D) ............................................................. 15
BUSY LED
Camera...................................................................................... 13
Controller (BLACKBOXTM-D) ............................................................. 15
Antenna installation (TINY-PLUS) ................................................. 13
Settings (camera)........................................................................ 16
Setup
Receiver (BLACKBOXTM).................................................................. 22
Controller (BLACKBOXTM-D) ............................................................. 24
REMOSTM Technology (TINY-PLUS, TINY-W3).................................... 21
Sound recording (camera) ........................................................... 27
External triggering (camera) ....................................................... 27
Table of contents
File transfer to a computer
Camera...................................................................................... 28
Receiver (BLACKBOXTM).................................................................. 29
Controller (BLACKBOXTM-D) ............................................................. 29
Troubleshooting
Camera...................................................................................... 30
Receiver (BLACKBOXTM).................................................................. 32
Controller (BLACKBOXTM-D) ............................................................. 33
Error messages
Camera...................................................................................... 31
Controller (BLACKBOXTM-D) ............................................................. 33
Available accessories
Camera...................................................................................... 34
Receiver (BLACKBOXTM).................................................................. 36
Controller (BLACKBOXTM-D) ............................................................. 37
Specications
TINY-7 ....................................................................................... 38
TINY-PLUS.................................................................................. 39
TINY-WBF .................................................................................... 40
TINY-W3..................................................................................... 42
Regulation (TINY-7, TINY-W3)......................................................... 44
Limited warranty ...................................................................... 45
Repair service........................................................................... 45

4
Package contents
USB
cable Audio-video
cable
Installation strap
(TINY-7, TINY-PLUS)
Camera
(TINY-7) Camera (TINY-PLUS,
TINY-WBF, TINY-W3)
BLACKBOXTM receiver
(TINY-WBF)BLACKBOXTM-D controller
(TINY-W3)
Installation straps
(TINY-WBF, TINY-W3)
Quick start guide
(camera)
Models:
TINY-PLUS
TINY-WBF
TINY-W3
TINY4G
Quick start guide
v1.0
P INTSPY INTPSPY
Surveillance camera
TINY series
Adventure series
Série aventure
Abenteuer-Serie
serie de aventura
serie di avventura
Expedition series
Série Expédition
Expedition Serie
Series expedición
Serie spedizione
Pro series
Série pro
Pro-Serie
Serie pro
Serie pro
Smart series
Série Smart
Smart serie
Smart serie
Smart serie
Live series
Série Live
Live-Serie
Series Live
Serie Live
Tiny series
Série Tiny
Tiny-Serie
Serie Tiny
Serie Tiny
Get started
Error messages
Settings
1
2
3
4Complete instructions
www.spypoint.com
COMPONENTS
3
4
5
6
1
2
1914 16 17 15 18 20 21
8
7 9
11
12
13
10
Get started
11Photo lens Image sensor and infrared lter.
2 Antenna
(if applicable) Allows wireless communication between
the camera and a BLACKBOXTM (receiver/
controller). For installation (if applicable),
remove the cap and screw the antenna on the
left side of the camera.
3Invisible LEDs Night lighting to obtain black and white
photos and videos.
4 Test light Flashes in TEST mode when there is detec-
tion and ashes 60 seconds in PHOTO/VIDEO
mode to allow the user to leave without being
photographed or recorded.
5 Side sensors
(2) Allows to prepare the camera so when the target passes through the central sensor,the
system is already pre triggered. When acti-
vated, the detection area is expanded.
6Fresnel lens
(in front of
the central
sensor)
Expands the detection area and increases the
sensitivity of the camera’s motion sensor.
7Holes for
cable lock Allows the user to install a cable lock (CL-6FT, sold separately).
8 Tripod mount Standard ¼-20” tripod mount.
9Holes for
installation
strap
Allows the user to install the camera using
the included installation strap.
10 Power button Allows the user to turn on/off the camera.
11 BUSY LED Lights up when the camera is recording.
12 Navigation
buttons Buttons to set the camera.
13 Viewing
screen Toaccess the main menu and to view photos/ videos.
14 Battery switch Allows the user to select the power source
according to the type of batteries used.
15 Microphone To record sound, lift the rubber cap and turn
it slightly to completely clear the microphone
receiver.
16 SD card slot An SD card is required to record videos/
photos. The camera is compatible with SD/
SDHC memory card, up to 32 GB capacity
(not included).
17 Removable
battery holder Insert 6 AA batteries (alkaline or lithium) or a rechargeable lithium battery pack (LIT-09/
LIT-C-8, sold separately).
18 USB port To transferphotos/videos to a computer.
19 1)12V power
jack
2)Solar panel
jack
1)This camera can be powered from an
external 12-volt DC input such as a 12V
battery or a 12V adapter, sold separately.
2)Allows the user to connect a solar panel
(SP-12V) to maintain the charge of the
lithium battery pack (LIT-09/LIT-C-8), sold
separately.
20 External
trigger jack 1/8” port which triggers the taking of pho- tos or videos using a normally open contact.
(Example: using a magnetic door switch con-
nected to an alarm system).
21 TV OUT To view or delete photos/videos directly on
TV.
BATTERY INSTALLATION
We recommend the use of new batteries to ensure a maximum
performance of the camera. Rechargeable AA batteries are not
recommended.
Battery switch position (depending on the power source)
Power source Battery switch position
• 6 AA
• 12V
• 12V + 6 AA ALK
• LIT-09*
• 12V + LIT-09*
• Solar panel + LIT-09*RECH
* Rechargeable lithium battery pack, sold separately (LIT-09) or with
a charger (LIT-C-8).
MEMORY CARD INSTALLATION
Insert an SD/SDHC memory card (up to 32 GB
capacity) in the card slot, gold contacts facing
up. The card is inserted correctly when a click
is heard.
Before inserting or removing a memory
card, always turn off the camera to
prevent loss or damage of the pictures already
recorded.
6 alkaline AA batteries Lithium battery pack
LIT-09/LIT-C-8
Connectors Connectors Insert connectors
rst
