SriHome NVS003 User manual

16-Channel
Network Video Recorder
USER MANUAL
NVS003

1
1. Product Introduction
IconSN
POWER1
2
3
4
5
VGA
HDMI
USB
LAN
Function
For Power Supply.
Outputs analog video signal. This connects to the monitor to view analog video.
High definition audio and video signal output port. It transmits uncompressed high definition
video and multiple channel data to the HDMI port of the display device.
USB2.0 port. Connect a mouse, USB storage device, USB burner, etc.
10M/100Mbps self-adaptive Ethernet port. Connects to the network. Such as Router ,Switch etc.
14523
Front Panel
Rear Panel

2
1
2
3
Install your hard drive, the following is needed:
A medium sized (regular) Phillips-head screwdriver - not included.
Four hard drive fastening screws - included.
A hard drive - not included.
Note: Disconnect the NVR power before installing the hard disk, Hard disk maximum support 8TB.
1. Loosen the screws on the upper cover
and side panel.
2. Place the HDD in accordance with the
four holes on the bottom of the casing.
3. Tighten the HDD screws firmly to the
bottom of the NVR.
4. Place the cover back onto the NVR,
Secure the screws on the rear and
side panels.
2. Hard Drive Installation
1
2
3
4

3
LAN WAN
IP Camera
4G
Internet
1
1
1
2
3
4
5
2
3
4
5
Connect the Mouse to USB port.
Connect a Monitor or TV screen to your NVR via HDMI or VGA cable.
Connect the Router or Switch to NVR with a Ethernet cable.
Connect the NVR to power 12V.
Connect the camera to the Switch or Router.
Connection as followings
Note:
For non-PoE cameras: Connect the power adapter to the power port attached to the camera.
For PoE cameras: Connect the PoE camera to a PoE compatible router or switch that is on the
same network as the NVR. PoE cameras can either be powered with a PoE connection or with
a standard power adapter (sold separately).
3. NVR Connection
Smart phone Tablet
Router or Switch
USB Mouse
12V Adapter
Monitor / TV

4
Complete login settings according to the NVR boot wizard.
(the default password for the NVR is: 888888)
admin
Login
Auto Login
NVR
Note: This NVR Supports:
Video Input: 16CH 5MP Recording or 8CH of 8MP Recording.
Video Output: HDMI (4K) & VGA (1080P).
4. NVR Login

Right Click the Screen-Camera--Search -- Add -- OK
5
6. Add the Camera
5. Network Setting
Enter Desktop
When the network shows an abnormal state , double-click to open the network
settings-check whether that the video recorder IP address is the same as the router, if not in
the same network segment, can be set automatic acquisition IP or manually change it to be
consistent as the router segment.
X
Network
Net Card
192. 168. 1. 126
192. 168. 1. 1
183. 2. 1. 197
345865
80
1400MTU
8. 2. 4. 3
255. 266. 255 0
DHCP Enable
Network Testing
IP Address
Subnet Mask
Gateway
Primary DNS
Secondary DNS
TCP Port
HTTP Port
HS Download
Transfer Policy
AllProtocol
OK Cancel
OK Cancel
My Device PlayBack
Control Panel
Intemet
Record
Alarm
Camera
Camera
Online Equipment
IP Address
IP Address
Manual Add
Search
192.168.189 6688 ONVIF a4:7b:9f:b5:04:18
192.168.189
Port
Port
Protocol
Protocol
Add Edit
Edit
MAC
1
Added device
Add Quick Add Quick Modify IP
1
Channel
ONVIF6688
1
1 1
+
Connect
Network
Delete
Delete
1
2
!
Netcard Perferred
Netcard Perferred

7. SriHome APP Setup
6
Android iOS
Step 3. Add the Device to App
Device
3-1
Add
Next
888888
home
N0*******
Input the device’s ID
Please name the device
Input password (Default:888888)
3-2
Input device name to search device
You can scan the QR code or
input the Device ID manually
WiFi NVR
ID: N0***********
Password: 888888
Power: 12V
RoHS
The label is attached on
the NVR
Add
WiFi QR Connect
1
2
3
Step 1 . SriHome App Installation
Method 2: Search“SriHome”on Google Play or iOS App Store.
Method 1: Scan the QR code to download “SriHome” App.
Step 2. Register & Login on SriHome App

B. Enter Desktop /Main Menu--My Device--Version- Serial NO.
Enter Desktop>Control Panel>Restore>Please select setting entries that you want to default.
8. Reset
7
Enter Desktop
My Device
X
X
Version
Record Channel 16
Display software version and build date.
System 1.03.06720672.87020171.T000.22
Extra Info 1.15.205254565
Build Date 2021-03-05 16: 55:25
MAC C8:24:02:3e:ca:cf
SerialNo N382565RHDRU
OK
Enter Desktop
Control Panel
X
X
Restore
Please select setting entries that you want to default
Select all
General
Record Alarm Set
Net Service
Account
Network
Output Settings
RS232
APPUser
ALL Configuration
Cancel
OK
Note: A. The ID of the device is stick on the label of the video recorder shell
My Device PlayBack
Control Panel
Intemet
Record
Alarm
Camera
My Device PlayBack
Control Panel
Intemet
Record
Alarm
Camera
Restore system parameters to the factory default.
