1. Instructions
Thank you very much for choosing the EOS series household energy storage system developed and
produced by our company. Please read and understand all contents of the Manual carefully before installing and
using the product. If you have any suggestions during the use, please do not hesitate to give us feedback.
1.1 Range of Application
The installation and user manual of SR-EOS series is applicable to the installation and use of the following
products:
No
Model
Rated energy
1
SR-EOS05B
5.12kWh
2
SR-EOS10B
10.24kWh
The product should be used in compliance with local standards, laws and regulations, because any non-
compliance with the use may lead to personal injuries and property loss.
The drawings provided in this Manual are used to explain the concepts related to the product, including
product information, installation guide, electrical connection, system debugging, safety information, common
problems and maintenance, etc.
The internal parameters of this product have been adjusted before delivery. No internal parameters can be
changed without permission. Any unauthorized changes to the settings will invalidate the warranty, and the
Company will not be liable for any loss resulting therefrom.
This Manual and other related documents are an integral part of the product and should be kept properly for
onsite installation personnel and related technical personnel to consult.
1.2 Meaning of Abbreviations
AC
Alternating Current
DC
Direct Current
PV
Photovoltaic
BMS
Battery Management System
PCS
Power Conversion System
RJ45
Registered Jack 45
SOC
State Of Charge
C
Charge C-rate
RS485
RS485 Communication Interface
CAN
Controller Area Network

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 3 of 37
File version: V1.5
1.3 Symbol Stipulations
There may be following symbols herein, and their meanings are as follows.
Symbols
Description
DANGER!
Indicate a hazard with a high level of risk which, if not avoided, will result in
death or serious injuries.
CAUTION
Indicate a hazard with a medium level of risk which, if not avoided, could
result in death or serious injuries.
ATTENTION
Indicate a hazard with a low level of risk which, if not avoided, could result in
minor or moderate injuries.
NOTICE
Warning information about device or environment safety. If not avoided,
equipment damage, data loss, performance degradation or other
unanticipated results may be resulted in. The "NOTICE" does not involve
any personal injuries.
2 Safety Precautions
2.1 Safety Symbols
This product contains the following symbols, please pay attention to identifying.
Symbols
Description
Observe enclosed documentation
Danger.
Risk of electric shock!
Danger of high voltages.
Danger to life due to high voltages in the Energy storage system
Hot surface
CE certification
Do not touch the product in 5mins after shutdown
Comply with RoHS standard
The Energy storage system should not be disposed together with the
household waste.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 4 of 37
File version: V1.5
2.1 General Safety
2.1.1 Important Notice
Before installing, operating and maintaining the device, please read this Manual first and follow the symbols
on the device and all the safety precautions in this Manual.
The matters indicated with "DANGER", "CAUTION", "ATTENTION" and "NOTICE" in this Manual do not
represent all the safety matters to be observed, but are only the supplements to all the safety precautions. The
Company will not be liable for any violation of general safety operating requirements, or any violation of safety
standards for the design, production and use of the device. The device must be used in an environment that
meets the requirements of the design specifications. Otherwise, the device may fail, and the abnormal device
function or component damage, personal safety accident, and property loss arising from this are not covered
within the quality assurance scope of the device. When installing, operating, and maintaining the device, the
local laws, regulations, and codes shall be followed. The safety precautions in this Manual are only supplements
to local laws, regulations, and codes. The Company shall not be liable for any of the following circumstances.
● The device is not run under the conditions of operating described in this Manual.
● The installation and operating environment is beyond the requirements of relevant international or
national standards.
● The product is disassembled or changed, or the software code is modified without authorization.
● The operation instructions and safety warnings related with the product and in the documents are not
followed.
● Damage of the device is caused by abnormal natural environment (force majeure, such as earthquake,
fire, and storm).
● Transportation damage is caused during customer's own transportation.
● The storage condition does not meet the requirements of the product related documents and causes
damage.
2.1.2 General Requirements
DANGER!
Operating when the power is on is strictly prohibited during installation.
DANGER!
It is strictly prohibited to install, use, and operate any outdoor equipment or cables (including but
not limited to transporting equipment, operating equipment and cables, plugging and removing
signal ports connected to the outdoor, working at altitude, and outdoor installation) in severe
weather, such as thunder, rain, snow, and gale level 6.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 5 of 37
File version: V1.5
DANGER!
In case of any fire, evacuate the building or equipment area and press the fire alarm bell or dial
the fire call. Under any circumstances, re-entry into a burning building is strictly prohibited.
CAUTION
Under no circumstances should the structure and installation sequence of the device be changed
without the manufacturer's permission.
CAUTION
The battery terminal components shall not be affected during transportation. And, the battery
terminal bolts shall not be lifted or transported.
ATTENTION
It is strictly prohibited to alter, damage or block the marks and nameplates on the device.
ATTENTION
The composition and working principle of the entire photovoltaic power generation system, as well
as the relevant standards of the country/region where the project is located shall be known fully.
NOTICE
After the device is installed, the empty packing materials, such as cartons, foam, plastics, and
cable ties, shall be removed from the device area.
2.1.3 Personnel Safety
● When operating the device, appropriate personal protective equipment shall be worn. If any fault that may
lead to personal injury or damage of the device is found, immediately terminate the operation, report to
the responsible person, and take effective protective measures.
● Before using any tools, learn the correct method of using the tool to avoid injuries and damage of the
device.
● When the device is running, the temperature of the case is high, which may cause burns. Therefore, do
not touch the case.
● In order to ensure personal safety and normal use, reliable grounding should be carried out before use.
● Do not open or damage the battery. The electrolyte released is harmful to skin and eyes, so avoid touch it.
● Do not place irrelevant items on the top of the device or insert them into any part of the device.
● Do not place flammable items around the device.
● Never place the battery in the fire to avoid explosion and prevent the personal safety from being
endangered.
● Do not place the battery module in water or other liquids.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 6 of 37
File version: V1.5
● Do not short-circuit the battery terminals, because short-circuiting of the battery may cause combustion.
● The battery may pose a risk of causing electric shocks and large short-circuit currents. When using the
battery, the following precautions should be paid attention to:
a) The metal objects, such as watch and rings, shall be removed.
b) Tools with insulated handles should be used.
c) Rubber gloves and shoes should be worn.
d) The charging power supply shall be disconnected before connecting or disconnecting terminals of
the battery.
e) Check whether the battery is accidentally grounded. If the battery is accidentally grounded, remove
the power supply from the ground.
● Do not clean the internal and external electrical components of the cabinet with water or detergent.
● Do not stand, lean or sit on the device.
● Do not damage any modules of the device.
2.2 Personnel Requirements
● The personnel in charge of installation and maintenance must be strictly trained to understand all safety
precautions and master proper operation methods.
● Only qualified professionals or trained personnel are allowed to install, operate and maintain the device.
● The personnel who operate the device, including the operators, trained personnel and professionals,
must have special operation qualifications required by the local country, such as high voltage operation,
working high above the ground, and special equipment operation qualification.
● The replacement of device or components (including software) must be carried out by professionals or
authorized personnel.
2.3 Electrical Safety
2.3.1 General Requirements
DANGER!
DANGER!
Before carrying out electrical connections, ensure that the device is not
damaged, or an electric shock or fire may occur.
Never install or remove any power cables when the power is on. The electric arcs or sparks
may be generated at the moment when the power cable contacts with the conductor, which
may cause fire or personal injuries.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 7 of 37
File version: V1.5
● All the electrical connections must meet the electrical standards of the country/region where the project is
located.
● The cables prepared by users themselves shall comply with local laws and regulations.
● Special insulating tools should be used in high-voltage operations.
● Before connecting the power cord, ensure that the label identification on the power cord is correct.
● Operations on the device are allowed only five minutes after the device is completely powered off.
● The insulation layer of the cable may be aged or damaged when the cable is used in a high temperature
environment. Therefore, the distance between the cable and the heat source must be at least 30mm.
● Cables of the same type should be bundled together. Whereas, the cables of different types should be
routed at least 30mm apart, and shall not be wrapped together or crossed.
2.3.2 Grounding Requirements
● When installing the device to be grounded, the protective grounding wire must be installed first; when
removing the device, the protective grounding wire must be removed at last.
● It is forbidden to destroy the grounding conductor.
● It is forbidden to operate the device without a grounding conductor installed.
● The device shall be permanently connected to the protective grounding wire. Before operating the device,
electrical connection of the device shall be checked to ensure that the device is reliably grounded.
2.4 Installation Environment Requirements
● Do not install or use this product in an environment where the temperature is lower than -10 ℃ or higher
than 50 ℃.
● It should be installed in a dry and well-ventilated environment to ensure good heat dissipation
performance.
● The product can be installed at a maximum altitude of 2,000m.
● The installation position should be away from the fire source.
● The product should be installed and used away from children and animals.
● The installation position should be far away from water sources, such as faucets, sewer pipes, and
sprinklers, to avoid entering of water.
● The device should be placed on a firm and flat supporting surface.
● Do not place any inflammable or explosive items around the device.
● When the device is running, do not block the ventilation vent or heat dissipation system to prevent fire
caused by high temperature.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 8 of 37
File version: V1.5
CAUTION
3 Product Introduction
3.1 Battery Specifications
Product model
SR-EOS05B
SR-EOS10B
Rated voltage
51.2V
51.2V
Rated capacity
100Ah
200Ah
Rated energy
5.12kWh
10.24kWh
Weight
47kg
88kg
Dimentions(L*W*H)
725*460*100mm
1014*620*205mm
Max. charging current
100A
150A
Max. discharging current
100A
200A
Peak charging current
110A(3S)
200A(3S)
Peak discharging current
110A(3S)
220A(3S)
Screen
LCD Screen
Touch Screen
Battery type
LFP
Life time(25℃)
20 Years
Life cycles(80% DOD,0.5C,25℃)
6000 Cycles
Max.charging voltage
57.6V
Over discharge voltage
44.8V
Max.Number of parallel
9
Communication interfaces
CAN/RS485/USB/WIFI/Bluetooth
Lithium Battery Standard
UN38.3,MSDS,EN55032,EN55024,
EN61000-3-2,EN61000-3-3
Storage time / temperature
6 months @25℃;3 months @35℃;1 months @45℃;
Charging temperature range
0~45℃
The operation and service life of the energy storage is related to the operating temperature.
The energy storage should be installed at a temperature equal to or better than the ambient
temperature.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 9 of 37
File version: V1.5
Discharging temperature range
-10~45℃
Cooling method
Natural cooling
Enclosure protection rating
IP30
IP65
Operation Environment
Indoor
Indoor&Outdoor
3.2 Model Coding
The model coding of the energy storage battery is as follows:
SR-EOS10B
① ② ③
Identifier
Meaning
Value
①
Product type
EOH: horizontally-mounted
EOV: vertically-mounted
EOS: wall-mounted
②
Energy storage capacity
level
05: The battery capacity is 5kWh
10: The battery capacity is 10kWh
③
Product category
B: Energy storage battery
C: Power conversion module
S: Energy storage system
3.3 Appearance Description

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 10 of 37
File version: V1.5
①RS485
(Connect other battery)
②Battery Negative
③Battery Positive
④Fixed accessories
⑤LCD Touch Screen
⑥LED(ALM)
⑦LED(RUM)
⑧Turn On/Off
⑨Reset
⑩RS485/CAN
(Connect inverter)
⑪Battery Positive
⑫Battery Negative
⑬RS485
(Connect other battery)
⑭Address
⑮USB
(Connect PC)
⑯SOC
(State of Capacity)
⑰Waterproof Cover
⑱Handle
⑲Mounting Frame
⑳Grounding screw

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 11 of 37
File version: V1.5
Communication interface definition
Number
Communication
Interface Type
instruction
①⑬
RS485
RJ45
1-RS485-B
2-RS485-A
7-RS485-A
8-RS485-B
⑩
RS485/CAN
RJ45
1-RS485-B
2-RS485-A
3-GND
4-CAN-H
5-CAN-L
6-GND
7-RS485-A
8-RS485-B
4 Application Scenarios
The lithium iron phosphate batteries with high performance and long service life are used in the energy
storage module. Meanwhile, the modular structure design is adopted. Each energy storage module is internally
integrated with the intelligent BMS system, which can be easily expanded and can be combined into 60Kwh
battery pack at most.
The battery storage can be combined with SRNE brand inverter to form an off-grid photovoltaic system,
which can solve the problem of electricity consumption in areas without electricity.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 12 of 37
File version: V1.5
5 System Installation
5.1 Inspections before Installation
Inspection of outer package
Before opening outer package of the energy storage, check if there is any visible damage on the outer
package, such as holes, cracks or other signs of possible internal damage, and check the type of energy storage.
If there is any abnormality on the package or model of the energy storage is inconsistent, do not open it and
contact us as soon as possible.
Inspection of deliverables
After opening outer package of the energy storage, check if the deliverable is complete and whether there is
any visible external damage. If any items are missing or damaged, please contact us.
NO.
Item
Quantity
Specification
1
Battery Pack
1
51.2V,10.24kWh
2
Mounting Frame
3
580*85.8*30mm
3
Mounting Frame
Connecting Strip
1
375*39*12mm
4
Screw
6
M4*10
5
Mounting Frame Screw
12
M8*60 expansion bolt
6
Side fastener
2
80*40*36mm
7
Screw
4
M5*12

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 13 of 37
File version: V1.5
8
Power Cable
2
1.5m
9
Signal cable
1
RJ45,1.5m
10
RJ45 waterproof connector
2
M25*37mm
11
Installation auxiliary board
1
500*500mm
12
USB communication cable
1
Type-B,1m
5.2 Preparation of Tools and Meters
Types
Tools and meters
Installation tool
Personal protective
equipment

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 14 of 37
File version: V1.5
5.3 Selection of Installation Location
5.3.1 Basic Requirements
● When the energy storage is running, the temperature of the case and the radiator will be high. Therefore,
do not install them in a place that is easy to touch.
● Do not install in areas where flammable and explosive materials are stored.
● If the energy storage is installed in areas with salt damage, it will be corroded and may cause fire.
Therefore, do not install it outdoors in areas with salt damage. The areas with salt damage are defined as
the areas which are not 500m away from shore or will be affected by sea breezes. The areas affected by
the sea breezes vary depending on meteorological conditions (e.g. typhoons, monsoons) or topographical
conditions (dams, hills).
● Do not install in the place where children can touch.
● The energy storage cannot be installed forwardly, horizontally, inversely, backwardly or sideways.
● When drilling holes on walls or ground, the goggles and protective gloves shall be worn.
● During drilling, the device should be shielded to prevent debris from falling into the device. After drilling,
the debris shall be cleaned up in time.
● When handling any heavy objects, you should be prepared to bear loads to avoid being crushed or
sprained.
● When handling the device by hand, wear protective gloves to avoid injury.
5.3.2 Installation Space Requirements
Floor Mount: The battery should be placed in the right position first, and the installation site should be
smooth and the wall should be solid, and the distance between the batteries should be greater than 200-350mm.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 15 of 37
File version: V1.5
Wall mount: The battery should be placed in the right position first, and the installation site should be
smooth and the wall should be solid, and the device is 200mm away from the ground,the distance between the
batteries should be greater than 200-350mm.
5.4 Device Installation
5.4.1 Wall mount
5.4.1.1 Installation Location Selection
Determine the installation position, put the installation auxiliary board in the proper position, and mark the
place where the holes need to be punched.
5.4.1.2 Install Expansion Bolts
DANGER!
CAUTION
Drill 12 holes according to the hole position, it is φ8 with depth of 45~50mm.Hammer the M8 screws to the
above holes, and screw the nut.
In order to avoid electrical shock or other injury, inspect existing electronic or plumbing
installations before drilling holes.
Choose suitable firm wall with thickness greater than 80mm.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 16 of 37
File version: V1.5
5.4.1.3 Install Bracket Screws
Secure the mounting bracket with 6 screws.
5.4.1.4 Fix Mounting Frame
Make the convex side outward and fix the mounting frame to the 12 screws.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 17 of 37
File version: V1.5
5.4.1.5 Install Battery Pack
CAUTION
Keep the battery balanced, and then slowly hang the battery on the frame through the match hooks.
5.4.2 Floor Mount
5.4.2.1 Install Expansion Bolts
DANGER!
Drill 2 holes according to the hole position, it is φ8 with depth of 45~50mm.Hammer the M8 screws to the
above holes, and screw the nut.
The battery pack is very heavy, which requires multiple people to install.
In order to avoid electrical shock or other injury, inspect existing electronic or plumbing
installations before drilling holes.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 18 of 37
File version: V1.5
5.4.2.2 Install Battery Pack
Place the battery on a flat, firm floor and install the fixing accessories.
6 Electrical Connection
DANGER!
CAUTION
6.1 Preparation of Cables
No.
Cables
Description
Recommended
specifications
Source
1
Power Cable
Power cable between the storage
battery and inverter
Provide with the
product together
2
Signal line
Signal cable between battery
modules or between battery and
inverter
Provide with the
product together
3
Ground wire
Ground cable between the storage
battery modules
Provide with the
product together
4
Photovoltaic
input line
Cable between the photovoltaic panel
and power module
Cable diameter
6mm2/10AWG
Prepare by the user
itself
5
AC input line
Cable between AC input and power
module
Cable diameter
10mm2/7AWG
Prepare by the user
itself
6
AC output line
Cable between AC output and power
module
Cable diameter
10mm2/7AWG
Prepare by the user
itself
Before electrical connection, please ensure that the switches of the energy storage are in the
"OFF" state. Otherwise, the high voltage of the device may cause electric shock.
The operations related to electrical connections must be carried out by professional electrical
technicians. When carrying out electrical connections, the operator must wear personal
protective articles.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 19 of 37
File version: V1.5
6.2 Electrical Connection Of One Battery Module
6.2.1 Connecting Grounding Wire
Each energy storage battery module shall be connected with the grounding wire provided with the product
together.
6.2.2 Connecting Power Cord
When connecting the battery wiring, please make sure that the battery switch is off and the indicator light is
off.

SRNE Solar Co., Ltd.
4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China
T: +86 0755-26458295
F: +86 0755-27325578
E: maste[email protected]
W: www.srnesolar.com
Page 20 of 37
File version: V1.5
6.2.3 Connecting Signal Line
The signal line shall be used to connect RS485-Inverter interface for battery module and inverter.
The communication port of the SRNE brand inverter needs to be connected to the RS485-2 interface.
DANGER!
NOTICE
If you use a standard network cable to
connect the inverter of the srne brand
PIN1
White-orange
cut off
PIN2
Orange
cut off
PIN3
White-green
PIN4
Blue
CAN-H
PIN5
White-blue
CAN-L
PIN6
Green
PIN7
White-brown
RS485-A
PIN8
Brown
RS485-B
When connecting the inverter, the communication line must be connected and the
communication protocol must be consistent.
The communication cable connected to the SRNE brand inverter is not a standard network
cable. If you use a standard network cable, please cut off pins 1 and 2 for connection.
