Celestron ThermoCharge User manual
Thank you for purchasing the Celestron ThermoCharge!
ThermoCharge is an essential multi-use tool designed to be
used in the elements. Its portable, high-capacity power pack can
supply power to your cell phone, MP3 player, and many other
USB-powered devices. A built-in flashlight provides illumination
while the hand warmer keeps you comfortable in cold conditions.
WARNING: Read all instructions and warnings thoroughly
before using ThermoCharge. Improper use of this
product may result in product damage, excess
heat, toxic fumes, fire or explosion. Do not allow
children to use this product without proper adult
supervision.
INCLUDED IN THE BOX ARE:
1 - FireCel
1 - USB cable with Mini USB connection
1 - Carry strap
1 - Soft carrying bag
1 - Upper silicone protective cap
1 - Lower silicone protective cap
THERMOCHARGE
1. Mini USB port
2. Green/red LED status indicators
a. Green indicates ThermoCharge is charging an external
device
b. Red indicates hand warmer mode is on
c. Blue indicates ThermoCharge’s internal battery is charg-
ing
3. On/off button
4. 2.0 USB port
5. Top cap
6. Bottom cap
1. CHARGING THE INTERNAL LITHIUM
ION BATTERY
Your ThermoCharge 2-in-1 device has an internal, 4400 mAh
rechargeable lithium ion battery, which allows for up to 6 hours
of continuous use at a constant temperature of 40° to 45° Cel-
sius (104° to 113° Fahrenheit). Your ThermoCharge ships with a
partial charge, but you should charge it completely before using
it for the first time.
Follow these steps to charge the internal battery:
1. Attach the Mini USB connector end of the included USB cable
to the Mini USB “in” port (1) on your ThermoCharge.
2. Plug the standard USB plug end of the cable into a USB port
on a PC, laptop, car charger or USB 5V-500mA adapter plug.
3. Once plugged in, the blue LED (2c) will start to blink, indicat-
ing that charging is in progress.
4. Charging is complete when the blue LED (2c) stops blinking.
NOTE: The ThermoCharge is designed with overcharge protec-
tion to prevent damage to the internal battery
2. USING THE HAND WARMER FEATURE
• Press and release the on/off button (3). The unit will begin to
heat up. In minutes, it will reach its maximum temperature and
you will feel the heat being conducted through the aluminum
housing.
• Press the on/off button again to turn ThermoCharge off.
• Use the included caps when extra protection is needed. These
silicone caps help repel moisture and protect the device should
it be dropped on a hard surface.
3. CHARGING AN EXTERNAL DEVICE
• Plug your device’s USB charging cable into the USB 2.0 port
(4) on ThermoCharge.
• Press and release the on/off button (3) quickly, then press and
hold the on/off button to begin charging. Your device should
indicate it is charging.
• When charge is complete, ThermoCharge will automatically
power off.
4. SPECIFICATIONS
BATTERY: Rechargeable lithium polymer – (2) x 2200 mAh
INPUT: Mini USB Connector / 5V- 1A
OUTPUT: Standard 2.0 USB Connector / 5V- 1A
INTERNAL BATTERY CHARGE TIME: USB - 5 hours
MINIMUM NUMBER OF RECHARGES: >500
LED STATUS INDICATORS
(1) Green LED/Red LED -
• Green indicates charging external device
• Red indicates hand warmer mode
(1) Blue LED indicates internal battery charging
HAND WARMER TEMPERATURE RANGE
40° TO 45° Celsius (104° TO 113° Fahrenheit)
HAND WARMER CONTINUOUS USE TIME
At least 6 hours continuous use (based on fully charged battery)
OPERATING TEMPERATURE RANGE
0° to 45° Celsius ( 32° to 113° Fahrenheit)
STORAGE TEMPERATURE RANGE
68° to 77° Fahrenheit (optimal)
WEIGHT 5.22 oz. (148 grams)
DIMENSIONS
1.77 in x 3.74 in x .90 in (45 mm x 95 mm x 23 mm)
POWER DELIVERY CHART
iPhone 5 (1540 mAh) 1.7 to 1.8 hours
iPhone 4 (1400 mAh) 1.5 to 1.6 hours
iPhone3 /ipod (1200 mAh) 1.3 to 2.4 hours
MP3 (300 mAh) 30 minutes
NOTE: Storage of more than 6 months without use may have
detrimental effects on the condition of the lithium ion battery. It
is recommended that you discharge and recharge fully every 3-4
months to maintain optimal battery life.
WARNINGS:
Read all instructions and warnings prior to using this product.
Improper use of this product may result in product damage,
excess heat, toxic fumes, fire or explosion, for which damages
you (“Purchaser”), and not Smart Team or Celestron (collectively
“Manufacturer”) are responsible.
• Do not store battery in high temperature environment, including
intense sunlight.
• Do not place battery in fire or other excessively hot
environments.
• Be cautious of excessive drops, bumps, abrasions or other
impacts to this battery. If there is any damage to the battery
such as dents, punctures, tears, deformities or corrosion, due
to any cause, discontinue use and contact manufacturer or
dispose of it in an appropriate manner at your local battery
recycling center.
• Do not disassemble this battery or attempt to repair or modify
it in any manner.
• Do not expose this battery to moisture or submerge it in liquid.
Keep battery dry at all times.
• Do not attempt to charge battery using any method, apparatus
or connection other than the device’s USB connector. For
questions or instructions for the various ways to charge
ThermoCharge, refer to this manual.
• Do not attempt to replace any part of this battery.
• This battery is intended for adult use only. If this battery
is intended by Purchaser to be used by a minor, purchasing
adult agrees to provide detailed instructions and warnings to
any minor prior to use. Failure to do so is sole responsibility
of Purchaser, who agrees to indemnify Manufacturer for any
unintended use/misuse by a minor.
