ToughTested TT-SOLAR User manual

TT-SOLAR
SOLAR POWERED
BATTERY PACK
USER MANUAL
Bloc-piles à énergie solaire guide d’utilisation
Batería de recarga con energía solar manual del usuario

Thank you for purchasing the TT-SOLAR battery pack.
Your battery pack is 6000 mAh. Take it off-road anywhere to charge mobile phones, tablets, action cams,
GPSs and other portable devices.
The TT-SOLAR battery pack is designed to give you endless charges on your adventure by replenishing
itself from natural sunlight.

01
Package contents ......................................................................................................................................
Charging your TT-SOLAR battery pack .......................................................................................................
Working with the led lights ........................................................................................................................
Charging your devices with the TT-SOLAR battery pack ............................................................................
Using the optimized USB ports ..................................................................................................................
Charging chart ..........................................................................................................................................
How to mount your solar battery ................................................................................................................
Safety & general information .....................................................................................................................
Specifications ............................................................................................................................................
Care and maintenance of the windshield mount/dashboard mount .............................................................
Limited Warranty. .......................................................................................................................................
02
03
05
06
07
08
09
10
11
12
13
TABLE OF CONTENTS

02 PACKAGE CONTENTS
Features:
• High capacity 6000 mAh solar battery
• Dual USB output, special for iPad and Android tablets.
• Multiple safety protection system to ensure device’s
safety: over charge protection.
• Over voltage, over current and short circuit protection.
• Smart LED displays remaining power
• High quality case with carabiner
• Windshield/dashboard mounts.
Package Includes:
1X 6000 mAh solar battery
1X ToughTested®case with carabiner
1X suction cup windshield/dashboard mount
1X micro USB charging cable
1X USB car charger
1X manual
Solar battery Case with carabiner Windshield/dashboard
mount Micro USB
charging cable USB Car charger
Solar
USBI
USBS
INPUT
100% 75% 50% 25%
USBI
USBS
INPUT

03
CHARGING YOUR TT-SOLAR BATTERY PACK
Solar
USBI
USBS
INPUT
100% 75% 50% 25%
Charging your solar battery pack using a USB wall port
Note: • AC adapter (optional)
• Car charger (included)
• Micro USB charging cable (included)
Charging your solar battery pack via sunlight
Charging your solar battery pack using a USB car port
Charging your solar battery pack using a USB device port

04
Charging your solar powered battery pack using a USB wall, USB car or USB Computer port:
Charge your battery to full capacity. Using the micro cable provided, connect the cable to the middle port
between the two USB outputs (see illustration on page 4). Connect the other end of the cable to your
computer’s USB port, a wall charger (optional) or car charger (included).
• It will take 4-6 hours to fully charge your TT-SOLAR battery pack from a wall outlet or computer.
Replenish your solar battery pack via sunlight:
To charge the battery using the solar panels, expose the face of the solar panel to sunlight (solar indicators
will begin to ash green). The time required to fully charge the battery will depend on the quality of available
sunlight – the stronger the sunlight, the faster the charge. You can also charge the solar battery through
incandescent light; however, indoor lighting only gives 1/10th the power of direct sunlight.
Solar battery replenishing time:
• 50%-100% = 6hrs
• 75%-100% = 4hrs
CHARGING YOUR TT-SOLAR BATTERY PACK

05
WORKING WITH THE LED LIGHTS
Solar
USB I
USB S
INPUT
100%75%50%25%
To check that your TT-SOLAR is fully charged, press the power button – the blue power level indicator will
light 25%-100%. If all lights are blue on the power level indicators, battery has a full charge.
• When all 4 LED lights are on = 100% battery charge
• When only 3 LED lights are on = 75% battery charge
• When only 2 LED lights are on = 50% battery charge
• When only 1 LED light is on = 25% or less battery charge
Solar indicator
Power button
Power level indicator

06
Charging your portable devices
• Using your USB charging cable that came with your phone, plug it into the USB I or USB S port (see
illustration under “Using optimized USB ports” on page 8).
• The Micro USB charging cable included in the box can also be used with your devices that use Micro USB
to charge.
• Hold the power button for 3-5 seconds until the LED light comes on.
• To shut off the device, press down the power button for 3-5 seconds until the LED light turns off.
CHARGING YOUR DEVICES WITH THE TT-SOLAR BATTERY PACK
Solar
USBI
USBS
INPUT
100%75%50%25%

07
USING THE OPTIMIZED USB PORTS
Charging your portable devices
The two ports are labeled as USB I and USB S.
USB S is optimized for charging Android, Blackberry and windows Smartphones and tablets. It will also charge
iPods and iPhones but at a slightly lower rate. An iPad will not charge from this port.
USBI is optimized for optimal charging of Apple devices including iPads. It will also charge Android and other devices.
For all other USB devices not mentioned above the best performance will be achieved using the USBS charge port.
The high powered TT-SOLAR battery pack is designed for both USB ports to be used at the same time. Either
port will provide up to 2.1 Amp to a single device. When two devices are plugged in at the same time the
output will be 1 Amp each.
USB I
• iPad - Fast charge
• iPhone - Fast charge
• Smartphone - Fast charge
• E-book - Fast charge
• iPhone - Regular charge
• Blackberry - Fast charge
• Smartphone - Fast charge
• E-book - Fast charge
INPUT USB S
(Blue color USB)

08 CHARGING CHART
Device usage chart
Typical charging times using the TT-SOLAR battery pack:
Device usage chart
Below are examples of how your devices will run using the TT-SOLAR battery pack:
Time Smartphones Tablets
30 min 50% 30%
1 hr 70% 50%
1.5 hrs 100% 70%
Tablets Smartphones Action Cams Games GPS
Watch movies
3.5 hrs Shoot video 8.5 hrs Shoot video 8.5 hrs Playtime 20 hrs Navigation 30 hrs
Browse web
10 hrs Browse web 20 hrs Full charges 4 X Full charges 7 X Full charges 3 X
Full charges
1 X Full charges 4 X
Listen to music
120 hrs
GPS 18 hrs

09
HOW TO MOUNT YOUR SOLAR BATTERY
USBI
USBS
INPUT
Solar
100%75%50%25%
Solar
USBI
USBS
INPUT
100%75%50%25%
1) Slide the battery into the ToughTested®case.
2) Tuck the top flap of the case behind the battery.
3) Slide the ToughTested®case into the window/dashboard mount.
4) Make sure the solar panel faces outward so it’s able to charge.
1)
4)
2) 3)
on the window on the dashboard
USBI
USBS
INPUT
Solar
100%75%50%25%

10 SAFETY & GENERAL INFORMATION
1). Please read this user manual carefully and follow all instructions.
2). To avoid any damage or malfunction, DO NOT drop device from high places.
3). Keep device away from humidity, water or any other liquid. To avoid electrical shock, explosion, and injury
to the device or yourself, DO NOT operate the device if it is exposed to moisture or any form of liquid.
4). Keep away from children.
5). Do not place or keep this device near any heat sources – such as direct sunlight or extreme heat,
radiators, stoves or any other apparatus that produces heat – as this may cause an explosion, diminish the
device’s performance and/or reduce the battery life.
6). DO NOT leave device exposed for prolonged periods in a hot car.
7). DO NOT modify, repair or disassemble device, especially the battery – doing so will void the warranty.
8). DO NOT place heavy objects on the device.
9). Unplug this device during lightning storms.
10).The battery used in this device may present a risk of fire or chemical burn if mistreated.
FOR BEST RESULTS, TURN THE BATTERY OFF WHEN NOT IN USE.

11
SPECIFICATIONS
Battery type: Li-polymer
Capacity: 6000mAh/22 2Wh
Input: Micro 5V 1A (MAX)
Solar charger: 5V 150 mAh
Output: 2 USB ports with 5v 2.1A(max)
Dimensions: 5”X 3”X 6”
Weight: .50lbs
Temperature: Extreme tolerance –10˚F to 150˚F
Car charger: 1 Amp
Case material: Ballistic nylon
Windshield material: ABS plastic
Micro USB charging cable: 3 ft. fabric cable

12 CARE AND MAINTENANCE OF THE WINDSHIELD MOUNT/DASHBOARD MOUNT
Three suction cups:
To keep the suction cups adhered to the window, follow these simple maintenance instructions:
• Remove the mount from the windshield surface that it is on.
• Remove oil and dirt from the suction cups using a wet, soapy cloth.
• Dry the suction cups with a dry, lint-free cloth.
• Using a wet, soapy cloth, clean the surface that the suctions cups were stuck to, removing all traces of dirt
or oil. A dirty surface prevents the suction cups from sealing airtight.
• Rinse the soapy water off of the surface and then dry it with a lint-free towel.
Dashboard sticky mount:
• Remove the mount from the dashboard
• Dampen a cloth with warm water, wring it out, and then wipe the sticky pad.
• Dry with a lint-free cloth.
• Allow the sticky pad to air-dry completely before using it.
• Before placing the mount back on the dashboard, clean the dashboard with a lint-free cloth to remove any
dirt or residue.
Solar battery and panel maintenance:
• It is best to shut the battery off when not in use.
Cleaning the solar panel:
• With a dry, lint-free cloth, lightly wipe the surface to remove any dirt or dust.
• TO AVOID DAMAGE, DO NOT CLEAN THE SOLAR PANEL WITH HARD MATERIALS OR LIQUIDS.

13
LIMITED WARRANTY
Thank you for purchasing a ToughTested®product from Mizco international, Inc.
We want you to enjoy this product without any problems. However, in the unlikely event that it malfunctions,
we will either repair or replace it as part of the product’s limited warranty.
At the first sign of trouble and before returning the product, we encourage you to call the ToughTested®toll
free customer support line for assistance at 1-800-838-3200.
If the product has malfunctioned during normal use, the responsibility of ToughTested®is limited solely to the
repair or replacement, at its option, of the product. This warranty does not extend to damage or failure that
results from misuse, neglect, accidents, alteration, abuse, improper installation or maintenance.
All brands represented herein are registered trademarks of their respective manufacturers. Design and
specications are subject to change without notice.
©2014 Mizco International, Inc. All rights reserved.
All trade names are registered trademarks of the respective manufacturers listed.
Mizco International Inc., Avenel, NJ 07001
Tech Support: 1.800.266.4026
[email protected]
www.mizco.com

Merci d’avoir choisi le bloc-piles TT-SOLAR.
Ce bloc-piles est de 6000 mAh. Emportez-le n’importe où pour charger des téléphones mobiles, tablettes,
caméras d’action, GPS et autres appareils portables.
Le bloc-piles TT-SOLAR est conçu pour vous procurer un nombre infini de charges au cours de vos
aventures en se rechargeant lui-même avec la lumière naturelle du soleil.

15
Contenu de l’emballage ..............................................................................................................................
Chargement de votre bloc-piles TT-SOLAR ..................................................................................................
Signication des témoins lumineux .............................................................................................................
Chargement de vos appareils avec le bloc-piles TT-SOLAR .........................................................................
Utilisation des ports USB optimisés .............................................................................................................
Tableau de charge ......................................................................................................................................
Installation de votre bloc-piles solaire .........................................................................................................
Consignes de sécurité et renseignements généraux ...................................................................................
Caractéristiques techniques .......................................................................................................................
Soin et entretien du support de montage sur pare-brise/tableau de bord ....................................................
Garantie limitée. ..........................................................................................................................................
16
17
19
20
21
22
23
24
25
26
27
TABLE DES MATIÈRES

16 CONTENU DE L’EMBALLAGE
Caractéristiques :
• Bloc-piles solaire haute capacité de 6000 mAh
• Sortie USB double, spécialement conçue pour les
tablettes iPad et Android.
• Système de protection multiple des appareils :
protection contre les surcharges.
• Protection contre les surtensions, surintensités et
courts-circuits
• Témoin lumineux intelligent qui indique la charge restante
• Étui de haute qualité avec mousqueton
• Support de montage sur pare-brise/tableau de bord
Contenu de l’emballage :
1 bloc-piles à énergie solaire de 6000 mAh
1 étui ToughTested® avec mousqueton
1 support de montage sur pare-brise/tableau
de bord avec ventouses
1 câble de charge micro-USB
1 chargeur USB pour la voiture
1 guide d’utilisationl
Bloc-piles solaire Étui avec mousqueton Support de montage sur
pare-brise/tableau de bord Câble de charge micro-USB Chargeur USB pour la voiture
Solar
USBI
USBS
INPUT
100% 75% 50% 25%
USBI
USBS
INPUT

17
CHARGEMENT DE VOTRE BLOC-PILES TT-SOLAR
Solar
USBI
USBS
INPUT
100% 75% 50% 25%
Chargement de votre bloc-piles via un port mural USB
Remarque : • Adaptateur c.a. (facultatif)
• Chargeur pour la voiture (fourni)
• Câble de charge micro-USB (fourni)
Chargement de votre bloc-piles via la lumière du soleil
Chargement de votre bloc-piles via un port USB dans la voiture
Chargement de votre bloc-piles via un port USB sur un appareil

18
Chargement de votre bloc-piles à énergie solaire via un port USB mural, dans une voiture
ou sur un ordinateur :
Chargez votre bloc-piles à sa pleine capacité. Branchez une extrémité du micro-câble fourni dans le port
INPUT situé entre les deux sorties USB (voir l’illustration à la page 4). Branchez l’autre extrémité du câble dans
un port USB sur votre ordinateur, sur un chargeur mural (facultatif) ou le chargeur pour la voiture (fourni).
• Il faut compter de 4 à 6 heures pour charger complètement votre bloc-piles TT-SOLAR via une prise murale
ou un ordinateur.
Chargement de votre bloc-piles via la lumière du soleil :
Pour charger le bloc-piles via le panneau solaire, exposez le panneau à la lumière du soleil (les témoins
lumineux commenceront à clignoter en vert). Le temps nécessaire pour une charge complète dépendra de
la qualité de l’ensoleillement – plus la lumière du soleil sera forte, plus la charge sera rapide. Vous pouvez
également le charger à partir d’une lumière incandescente; cependant, un éclairage intérieur ne procure que
le dixième environ de la puissance de la lumière directe du soleil.
Temps de recharge du bloc-piles solaire :
• 50%-100% = 6 h
• 75%-100% = 4 h
CHARGEMENT DE VOTRE BLOC-PILES TT-SOLAR
