2. Introduction
Mechanical shock pulses are often analysed in terms of shock response spectrum. The shock response
spectrum assumes that the shock pulse is applied as a base input to an array of independent
single-degree-of-freedom systems. SDOF system assumes that each system has its own natural
frequency. The shock response spectrum gives the peak response of each system.
3. Shock response spectrum model
The shock response spectrum is a calculated function based on the acceleration time history. It applies
an acceleration time history as an excitation to an array of single degree-of freedom (SDOF) systems.
Each system is assumed to have no mass-loading effect on the base input.
Figure 1: Shock response spectrum model
Ÿis the base input for each system, and Ẍis the absolute response of each system to the input
(double-dot denotes the acceleration). M is the mass, C is the damping coefficient, and K is the stiffness
for each system. Natural frequency for each system is marked with f.
4. DewesoftX ® SRS plugin
a) Input signal
The input signal in the SRS plugin is an impulse shock time signal, usually measured with an
accelerometer.
SRS Shock Response Spectrum V21-1 3/17

SRS Quick Start
SOFTWARE USER MANUAL
b) Calculation parameters
Start and end frequency define the calculation range for the frequency spectrum. The upper limit is set
to 1/2 of MAX sampling rate.
Velocity DC filter removes the DC component of the calculated time signal
“InputChannel”/VelocityHistory.
Frequency division (octave) defines the resolution of the spectrum in frequency domain. Higher the
number, better the resolution.
SRS Shock Response Spectrum V21-1 4/17

SRS Quick Start
SOFTWARE USER MANUAL
Different damping factors produce different SRSs for the same shock waveform. Zero damping will
produce a maximum response and very high damping produces a horizontal line. The standard value for
relative damping of 5% results in a Q (quality factor) of 10.
Remove DC offset (in milliseconds) removes the DC component of the input time signal. The DC will be
calculated the defined time interval behind the position of the first cursor.
SRS Shock Response Spectrum V21-1 5/17

SRS Quick Start
SOFTWARE USER MANUAL
Noise floor (in milliseconds) will calculate the noise floor of the input time signal. The noise floor will be
calculated the defined time interval behind the position of the first cursor
c) Results
The results in frequency domain spectrum can be shown as acceleration, velocity or displacement.
SRS Shock Response Spectrum V21-1 6/17

SRS Quick Start
SOFTWARE USER MANUAL
d) Output channels
As a result, we show absolute maximum, maximum and minimum of
acceleration/velocity/displacement. All of those values are calculated in three different sections: during
shock, after shock and during the whole measurement
●Absolute max (whole measurement) – composite/maximax (the worst-case extrema for both
instances). The composite shock response for the absolute maxima is the maximax.
●Max (whole measurement) - composite/maximax (the worst-case extrema for both instances).
The composite shock response for the absolute maxima is the maximax
●Min (whole measurement) - composite/maximax (the worst-case extrema for both instances).
The composite shock response for the absolute maxima is the maximax.
●Absolute max during shock - primary (forced response, computation during the shock)
●Max during shock - primary (forced response, computation during the shock)
●Min during shock - primary (forced response, computation during the shock)
●Absolute max after shock - residual (free vibration, computation after the shock)
●Max after shock - residual (free vibration, computation after the shock)
●Min after shock - residual (free vibration, computation after the shock)
4.1 Results
a) Placing the cursors
For the right calculation, we have to place the cursors at the right positions on the recorder.
The first cursor (I) has to be placed on the noise floor signal, before the shock. Second cursor (II) has to be
placed also on the noise floor, but after the shock.
SRS Shock Response Spectrum V21-1 7/17

SRS Quick Start
SOFTWARE USER MANUAL
After that, the cursors I and II need to be locked with the click on the buttons:
After the cursors are locked, they change the colour in the recorder.
SRS Shock Response Spectrum V21-1 8/17

SRS Quick Start
SOFTWARE USER MANUAL
The channel cursor (yellow cursor) that indicates our position in the timeline of the datafile has to be
placed at the beginning of the shock.
b) Setup the calculation parameters
The next step is to define the calculation parameters (frequency range, damping factor, output
channels, …).
SRS Shock Response Spectrum V21-1 9/17

SRS Quick Start
SOFTWARE USER MANUAL
After the parameters and cursors are set, we need to Recalculate the data.
c) Displaying the results
The results of the spectrum are calculated in frequency domain and can be displayed on 2D graph
(“ChannelName/VelocityHistory”is a time channel, displayed on the recorder). Under the channel list you
can select the displayed channels.
SRS Shock Response Spectrum V21-1 10/17

SRS Quick Start
SOFTWARE USER MANUAL
SRS Shock Response Spectrum V21-1 11/17

SRS Quick Start
SOFTWARE USER MANUAL
