STAVIOR UVC-TMS 360 User manual
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
Welcome!
We congratulate you for purchasing the Robotic Mobile Sterilizer UVC-TMS360. We are sure
that this product will safeguard the Air for so many years to come, whether it is inside your
home (or) the facility wherever you will utilize this sterilizer. This Robotic mobile Sterilizer will keep
the good health of all your family members, by helping them breathe decontaminated air all the time.
Index Table
S.no
Content
Page no
1
Important Safety Precautions
3
2
Package Contents
4
3
Introduction to Robotic Sterilizer UVC-TMS360
5
4
Parts of Robotic UV-Sterilizer
6
5
Components of Robotic UV-Sterilizer
7
6
Technical Specifications of Robotic Sterilizer UVC-TMS360
9
7
Applications of Robotic UV Sterilizer
10
8
How does it work
11
9
Troubleshooting
12
10
Aftersales Service
14
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
1. Important Safety Precautions
Note : READ all the safety instructions and other sections of this document before switching
the Robotic Sterilizer “ON”
1. This device has to be used by properly trained adults for operation. Untrained personnel
shall not handle this device at all.
2. Do not operate on uneven surfaces like, stairs, or slopes, etc.
3. Do not enter the sterilization chamber while the UV Lamps are in “ON” condition.
4. This device operates on single phase 230 Volts power supply. Therefore, do not connect
this device to higher voltages.
5. This device performs well while all the lights are switched off.
6. Do not use any kinds of fluids, oils, or grease for lubricating any part of the Robotic
Sterilizer.
7. Keep the kids/infants/pets away from the device and the sterilization room. We (the
manufacturer or Seller) is not responsible for the losses or damage that occurs due to
improper handling of the device.
8. Do not touch the surface of the UV Lamps due to the fragility of the Lamp Glass. The
glass can crack or leave the finger prints on the glass surface.
9. Do not attempt to open the parts of the Robotic Sterilizer. Warranty will be void and it
can cause more damage to the unit externally as well as internally.
10. Operate the control switches of the R C Transmitter smoothly & safely to avoid any
damage. That also ensures smooth motion of the Robotic Sterilizer.
11. Do not look into the UV-Lamp light directly or indirectly. It is a bio hazard and can cause
loss of eye sight. It is also dangerous if the light is exposed to the skin. So do not enter
the sterilization room.
12. Keep the device away from humidity and water. To avoid electric shocks and sparks &
internal component failure.
13. The RC Transmitter circuit runs on 4 nos AAA batteries. To replace the battery of the RC
Transmitter, turn it over, press and remove the battery cover. Now remove the old
batteries. Place the new non-rechargeable AAA batteries with the correct polarity. Re-
assemble the cover.
14. Before and during the usage of the robotic sterilizer –you must note down the start
time, and ensure that the sterilization work has to be completed before the draining
time of the battery backup. (45 mins)
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
2. Package Contents
S.no
Package Item Description
Qty
1
Robotic Mobile Sterilizer Unit
1
2
R C Transmitter with AAA Batteries (4 nos)
1
3
Power Cord for Battery Charging of Robotic Sterilizer Unit
1
4
User Manual
1
5
Warranty Card
1
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
3. Introduction to Robotic Sterilizer UVC-TMS360
In the modern lifestyle that we live today, Safe air has become a very vital requirement of our
daily life. Today, as diseases strike the world, and pandemics prevail in many parts of the world,
a healthy living environment has become a necessity.
As a counter solution to this problem, Cenaura Technologies has innovatively designed an Air
Sterilizer UVC-TMS360 that can kill Bacteria, Virus and Fungus and Algae in the air.
This device is also very effective in disrupting the genetic component and kills the microbes
such as E.coli bacteria, human influenza virus, and SARS covid2/Covid-19 virus.
The UV-C light aids in surface and aerosol sterilization by disrupting the genetic backbone
resulting in DNA damage, and instantaneous cell death of both bacterial and viral agents.
The Mobile Robotic UV Sterilizer is a completely autonomous model that can operate on its
own and can carry out its sterilization work moving around which ever room it is placed in.
The smart sterilizer provides an effective 360° decontamination method for inactivation of
aerosol-based microorganism and contaminated surfaces.
This Topline mobile sterilizer operates independently and responds to obstacles with minimum
human intervention.
The wavelength of the UV-C is most effective energy segment guaranteeing a reliable and
effective decontamination technology that destroys aerial microbes.
This Robotic Sterilizer can guarantee 99.9% disinfection rate for a safe environment for the
occupants.
This is one of the best Sterilizer Device innovated to suit todays pressing need of the society for
a safe, sterilized, clean air inside any room.
This Robotic UV-C Air Sterilizer has a proven efficacy against CORONA VIRUS. The tests were
conducted at ATAL Incubation Center for Cellular and Molecular Biology, Hyderabad.
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
5. Components of Mobile Robotic UV –Sterilizer
S.no
Component
Function
1
Human Sensor
The Human Sensor is an important safety component of the
Robotic Sterilizer. It detects whether any human is present
in the room and then automatically shuts down the UV
Lamps. Later when the room is fully clear without any
humans, then the lamps start automatically.
2
UV-C Lamp Tower
The Lamp Tower holds the UV-C Lamps in position tightly
and provides rigidity.
3
Safety Handle
(for TMS 360 only)
The safety handle is used by the operating personal or
technicians while handling or positioning the Robotic
Sterilizer. It assures safety as the UVC lamps remain
untouched all the times.
4
Component Housing
This housing holds inside all the crucial components of this
device. Protecting them from Air, Water and Mechanical
disturbances.
5
Wheels
The base of the robot has 4 wheels for movement and
direction changes. These are internally controlled by the
controller boards.
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
6
Object avoidance sensor
This sensor detects the presence of an object or any
obstacle in its view and, it either stops the robot or enables
it to change its direction.
7
Motor driver board
This driver gives the input signal to the motors and helps it
drive in particular direction and speed.
8
Controller Board
This board is the heart of the Robotic Sterilizer Unit, that
takes charge of the complete control of operations related
to Lamps, Motors, Sensor Inputs, Direction & Speed control
etc.
9
Battery - Inverter Setup
The Battery-Inverter setup is the electric segment that
drives the power to carry out all the operations in this
Robotic Sterilizer unit
10
RC Transmitter Module
The transmitter module is joystick controller operable by
hand that transmits operational signals to the controller
board inside the inside the component housing.
11
RC Receiver
This module receives the signal from the RC Transmitter and
further propagates to the controller board for device
operations.
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
6. Technical Specifications
S.no
Component
Specifications
1
Dimension
47 x 20 x 12 (Inches)
2
Battery
Charging Time - 2 Hours
Operation Time –45 min
3
Human detection Range
360°
10 meters (30 ft)
4
Object avoidance range
1 meter (3 ft) –5 meters (15ft)
5
Lamp UV-C
36 W x 8 = 288 W
6
Lamp Life
9000 Hrs
7
Time required for Virus
Deactivation
100 Seconds (50 Sq ft area)
200 Seconds (100 Sq ft area)
7 mins (225 Sq ft area)
13 mins (400 Sq ft area)
8
Transmitter Range
500 meters
9
Voltage
230 Volts
10
Frequency
50/60 Hz
11
Fluence rate
1152 µw/ cm²
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
12
Human detection sensor
Yes
7. Applications of Robotic UV Sterilizer UVC-TMS360
S.no
Application area
Description
1
Healthcare Industry
Decontamination of Air, opens surfaces,
equipment surfaces in the hospital is of utmost
importance to avoid Hospital Acquired
Infections
2
Hotels/Restaurants/Malls/Theaters
Furnitures, Beds, Chairs, Tables, Walls, and Air
space decontamination ensures customer
safety and business profitability.
3
Education Sectors
(Schools/Colleges/Universities)
Sterilizing the doors, windows, classrooms,
benches, chair, tables, desks, boards, common
facilities, sports equipment, cafeteria, teaching
and learning aids, ensures life safety to
students.
4
Transportation Sector
Regular sterilization of surfaces in multi modal
transport systems like metros, railways, buses,
Airlines, Cars etc helps commuters from
infections
5
Food processing Industry
Food processing industry can be
decontaminated from pathogens like E.Coli,
Salmonella, Influenza, and SARS, Corona etc
6
Offices/pubs/cafeteria/discos
Offices, Entertainment centers can be
decontaminated and thus protection is assured
for common public
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
7
Gyms/Health Centers/Yoga/Aerobic
centers/ Sports clubs
Health and Fitness Industries tend to use lot of
sterilization / decontamination units to ensure
people safety
8. How does it work
The Robotic Mobile Sterilizer works by destroying the genetic material inside bacteria, virus,
yeast, fungus, and parasites. The UV-C light breaks down the DNA (or) RNA structure in the cells
of the Micro-organism. This subsequently breaks the cells genetic material chain. Thereafter the
Nucleic acids and Proteins get damaged killing the regenerative pathogen cells.
Effective Sterilization - destroys air borne and surface-based pathogens. This Robotic sterilizer
works with the help of a Transmitter Control. First the transmitter must have all its switches in
Position “1”and the left throttle must be in lower position. Now switch the transmitter “ON”.
The display is visible and the dash board helps to read the display data.
Now switch the Robot Sterilizer ON. Now the Transmitter switches can be used to turn the UV
Lamps ON-OFF. In the speed mode the Transmitter Switches can be used to either speed up or
slow down the robot.
A Human sensor is used as a safety device to protect human etc. The lamps will be on only
when there is no human in the room where the Robotic Sterilizer is placed. As soon as the
Human Sensor senses a human presence, lamps go Off instantly.
An object avoidance sensor is fitted to prevent dashing of robotic sterilizer against objects. It
ensures that there is no head on collision with walls or furniture or other objects in a room
while the Robotic Sterilizer is in motion.
LED INDICATOR : An LED strip is fixed at the bottom of the chassis. When the UV Lamps are ON,
it keeps blinking Red and Green every 1 second.
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
Battery INDICATOR : The LCD display indicates the battery status of Transmitter, Receiver in
the Transmitter Module. The battery status of the Robotic Mobile Sterilizer is displayed in the
LED display provided on the Mobile unit.
Buzzer : A buzzer is connected to indicate the switching ON Operation of the UV Lamps. It gets
off after 10 seconds and the UV Lamps are functionally in “ON” state.
9. Troubleshooting
S.no
Defect
Possible Cause
Solutions
1
Device does not start
The Robotic Sterilizer might not
be switched ON
Switch the Robotic Sterilizer ON
The RC Transmitter might be off
Switch the RC Transmitter ON
The RC Transmitter battery might
be weak
Try replacing the AAA batteries in
RC Terminator
2
Device stops moving all
of a sudden
A reset might be required
Switch OFF the Transmitter and the
Robotic Unit. Then follow the
procedure starting the Transmitter
first and then the Robotic Unit
Mobile Robot Battery might have
drained completely
Switch off the Device and RC
Transmitter. Connect the power
cord for charging the Robot.
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
RC Transmitter batteries might
have drained out
Try replacing the Transmitter AAA
batteries
Some hardware failure
Call the manufacturer
3
Device stops or gets
stuck while in operation
Hardware failure
Call the manufacturer
Weak battery may be the cause
Try replacing the batteries
4
RC Transmitter does not
get connected to the RC
Receiver even though
the battery status is full
Error in the Transmitter module
or the Receiver module hardware
Call the manufacturer
5
UV Lamps blinking
continuously
Hardware failure
Call the manufacturer
6
UV Lamps do not glow
Some moving object or fan may
still be running in the room
Switch off all fans and remove or
stop all moving objects
Hard ware failure
Call the manufacturer
Connection failure
Call the manufacturer
Battery failure
Try replacing the batteries
7
UV Lamps do not switch
off when Human/Pets
enter the room
Human sensor failure
Call the manufacturer
Hardware failure
Call the manufacturer
Cenaura Technologies Pvt Ltd. 201 Sree Homes. Plot NO 51. MB Society. Madhapur. Hyderabad. Telangana.
8
Robotic Sterilizer keeps
colliding with object on
its way
Hardware failure
Call the manufacturer
9
Robotic Sterilizer keeps
moving erratically
Controller Failure
Call the manufacturer
10. After Sales Service
1. Our Sales Coordinator / Technicians will be available all the time to resolve your queries
related to the operation, maintenance, and management of the Robotic Mobile
Sterilizer.
2. Before beginning (or) during the Robotic Sterilizer Operation, our engineers will give you
a step-by-step guidance/demo on operation/control /maintenance.
3. Our solution services are also offered through live video conference calls if needed.
This manual suits for next models
3
Table of contents
Popular Laboratory Equipment manuals by other brands
Thermo Scientific
Thermo Scientific EASY-nLC 1200 Troubleshooting and maintenance guide
LTE
LTE Touchclave Ecotech Series user manual
Nordson EFD
Nordson EFD E2V operating manual
SCP SCIENCE
SCP SCIENCE DigiPREP HP user manual
IKA
IKA Mini MR standard operating instructions
Germozap
Germozap L100254 Instruction guide
Thermo Scientific
Thermo Scientific MEGA-PURE 680 D440046 Series Operation manual and parts list
Thermo Scientific
Thermo Scientific iCAP RQ ICP-MS Pre-installation requirements guide
Kodak
Kodak CARESTREAM DRYVIEW 5850 user guide
Buchi
Buchi C-660 Operation manual
Thermo Scientific
Thermo Scientific Labofuge 200 Operating lnstructions
EDG
EDG Fieldscope quick start guide
