SSC-LUXon ClickConnect Basic Quick reference guide

SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen,
Germany – E-Mail: [e-mail]; Phone: +49 7633 - 988 3000
Assembly/operating instructions / technical data for ClickConnect Set Basic
The "ClickConnect Set Basic" is an intelligent installation set for lighting systems / luminaire systems at 230V with GU10 socket. Both LED
and halogen light sources with GU10 sockets can be connected to the system.
1. INTENDED USE
This product is only for connecting GU10 light sources and: -may only be installed indoors -only be operated in dry rooms, i.e.
not in damp rooms or rooms where there is a risk of dirt and in the area of high humidity -must not be exposed to strong
mechanical loads or heavy soiling -may not be operated after damp or dirty storage until after a condition check
-may not be changed or modified, otherwise the operating permit and conformity will expire with immediate effect!
If the aforementioned points are not observed, a short circuit or electric shock may occur! There is danger to life!
2. GENERAL SAFETY INSTRUCTIONS
The complete installation may only be carried out by an authorized electrician who is familiar with the applicable
guidelines. Hereinafter referred to as „qualified electrician“.
For safe handling of the product, the user must have read and understood the installation/operating instructions
completely before using the device for the first time.
The product may only be used if it is alright. If the device or parts of it are defective, it must be repaired by a qualified
electrician.
This product is not a toy and is not allowed be stored or used within the reach of children.
The max. current (for cascade connection) must not exceed 7 amperes.
Safe operation of the product is only guaranteed if these instructions are followed. Therefore, keep these
assembly/operating instructions. SSC-LUXon GmbH accepts no liability if the instructions given here are not followed or
the lamp is subjected to improper use.
3. TECHNICAL DATA / EXPLANATION OF SYMBOLS
Model:ClickConnect Colour:White Protection class II
Voltage: 230V AC / 50Hz 4-fold distributor:100cm Only suitable for indoor use
Designation:Installation set Extension:150cm
Installation only by qualified
electrician
Protection type: IP20 GU10 socket:15cm
Disconnect the device from the
mains power before starting
any work
CE Conformity: Yes
Importer: SSC-LUXon GmbH
4. ASSEMBLY & CONFIGURATION
Caution: The connecting cable must be disconnected from the power supply before starting work (switch off the main
switch/fuse)! Only use parts which are supplied with the product or which are clearly marked as equipment! Otherwise the
product may not be sufficiently safe!
The cable routing shown in the illustrations is for simplified purposes only. They in no way represent a recommendation
for connection! The connection may only be carried out by a qualified electrician.
When drilling, pay attention to cables and gas and water lines.
Notes on plug connections:
Plugs & sockets are processed in such a way that only one plug connection is possible at a time (Poka Yoke). It is therefore
not possible to connect the connectors incorrectly!
The GU10 lampholders can also be connected directly to the 4-way distributor.
You can also connect several extensions together to cover longer distances.
Connection instructions:
1. Disconnect the connecting cable from the power supply (switch off the main switch/fuse).
2. Connect the GU10 sockets to the extension cables.
3. The connection is made with plug & socket. Make sure that the clip is correctly engaged. This is the case when the click
of the connection is audible.
4. Connect the extensions to the 4-way distributor. Here, too, the clicking sound must be audible when it engages.
5. Insert the light sources into the GU10 socket & install the light (e.g. recessed spotlight).
6. Connect the cable end of the 4-way distributor (L / N) to your mains supply (230V / 50Hz). Luster terminals or Wago
terminals are suitable for this. Pay attention to the colour of the cables (usually blue & brown).
7. Switch on the voltage again (switch on the main switch/fuse).
The product is now ready for use.
5. OPERATION, FAULTS & DISORDERS
In case of an error, the device must be switched off immediately. The product may only be operated if it works correctly. The
device may only be put back into operation after it has been checked by a qualified electrician! This is the case if:
1. there is visible damage, 2. the product is not working corrctly, 3. there is smoke, steam, or audible crackling noises, 4.
overheating can be detected.
Caution: There is a danger to life - repairs to the product or work on parts carrying mains voltage may only be carried out
by qualified electricians.
6. DISPOSAL INSTRUCTIONS
Keep packaging material and small parts away from children and animals. Danger of suffocation!
Make sure to dispose packaging in accordance with the applicable guidelines of your local authority. Devices
marked with the crossed-out waste garbage do not belong in the household waste! You are obliged to hand in
these devices at one of the free collection points in your municipality. You can obtain more information from your
local authority, the relevant town hall or a local or regional waste disposal company.

Connection representation
4-fold distributor
Extension 1,5m
Connection cable GU10 Socket
Dimensions & data
4-fold distributor
ClickConnect plug
ClickConnect jack
