SSC-LUXon TWEO Quick reference guide

Assembly/operating instructions for SSC-LUXon surface-mounted wall lights TWEO & GIRI
1. Intended use
This product is for lighting purposes only and:
- can be installed indoors and outdoors / protection type IP54,
- must not be exposed to strong mechanical loads or heavy soiling,
- may not be operated after damp or dirty storage until after a condition check,
- may not be changed or modied, otherwise the operating permit and conformity will expire with immediate eect!
It is not allowed to remove the type plate.
 If the aforementioned points are not observed, a short circuit or electric shock may occur! There is danger to life!
2.General safety instructions
The complete installation may only be carried out by an authorized electrician who is familiar with the applicable guidelines. Hereinafter
referred to as „qualied electrician“.
For safe handling of the product, the user must have read and understood the installation/operating instructions completely before using
the device for the rst time.
 The product may only be used if it is alright. If the device or parts of it are defective, it must be repaired by a qualied electrician.
This product is not a toy and is not allowed be stored or used within the reach of children.
 Safe operation of the product is only guaranteed if these instructions are followed. Therefore, keep these assembly/operating instructions.
SSC-LUXon GmbH accepts no liability if the instructions given here are not followed or the lamp is subjected to improper use.
3. Assembly & conguration
Caution: The connecting cable must be disconnected from the power supply before starting work (switch o the main switch/fuse)! Only use
parts which are supplied with the product or which are clearly marked as equipment! Otherwise the product may not be suciently safe!
 Connection may only be carried out by a qualied electrician.
When drilling, pay attention to cables and gas and water lines.
Always route the cable so that it does not touch the light.
3.1 Assembly location
The product may only be mounted on a stable, tilt-resistant and level surface. Do not cover the product under any circumstances, especially
not with insulating material! Fire hazard!
4. Operation, bulb replacement, faults & disorders
Never look directly into the light source!
What to do in case of error?
In case of an error, the device must be switched o immediately. The product may only be operated if it works correctly. The device may only
be put back into operation after it has been checked by a qualied electrician! This is the case if:
1. there is visible damage, 2. the product is not working corrctly, 3. there is smoke, steam, or audible crackling noises, 4. overheating can be
detected.
Caution: There is a danger to life! Repairs to the product or work on parts carrying mains voltage may only be carried out by qualied
electricians.
Avoidance of disturbances and re hazards:
It is not allowed to cover the product under any circumstances. Air circulation must be ensured. Nothing may be attached or hung on the
product, especially no decoration.
5. Cleaning & care instructions
The product may only be wiped dry or carefully with a slightly damp and lint-free cloth. The product is not allowed to be removed for this
purpose. Do not use abrasive or sharp objects or aggressive cleaning agents. Do not use solvents.
7. Assembly Instructions TWEO & GIRI
1. Disconnect the connecting cable from the power supply. (Abb. 1)
2. Remove the screws from the cover on the back. (Abb. 2)
3. Mark the drill holes with the help of the cover. (Abb. 3)
4. Insert the dowels into the drill holes. (Abb. 3)
5. Guide the connection cable through the opening on the cover.
6. Fix the cover to the wall using dowels and screws. (Abb. 4)
7. Connect the connecting cable to the light. (Abb. 5)
8. Now place the light on the cover and x it with the screws on the side. (Abb. 6)
9. Switch the connecting cable to voltage. The product is now ready for use. (Abb. 7)
Models: TWEO & GIRI
Type: Wall light
Voltage: 220-240V / 50-60 Hz
Protection type: IP54
Light source: Fixed
Material: Aluminium
Light colour: Warm white
Can be used
indoors and
outdoors
Measurements: TWEO: 90 x 115 x 30 mm, GIRI: 105 x 115 x 30 mm
Colour: Dark grey / anthracite
6. Technical data TWEO & GIRI
Important information
Protection class I
Installation only by qualied
electrician
Disconnect the device from the
mains power before starting
any work
Disposal instructions
Make sure to dispose
packaging in accordance
with the applicable guideli-
nes of your local authority.
Devices marked with
the crossed-out waste
garbage do not belong
in the household waste!
You are obliged to hand
in these devices at one of the free collection
points in your municipality. You can obtain
more information from your local authority,
the relevant town hall or a local or regional
waste disposal company.
Keep packaging material and small parts
away from children and animals. Danger of
suocation!
Notes on use indoors & outdoors
Protection type IP2X: Use only indoors
and dry, i.e. do not use in damp or dirty
rooms and in areas of high humidity
Protection type IP4X, IP5X & IP6X: Can be
used indoors and outdoors
Onlineshop:
www.led-lichtraum.de
Satised with your product?
Then we look forward to your
product review in our online store,
on Amazon or eBay!
SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen, Germany
E-Mail: [email protected]; Phone: +49 7633 - 988 3000
Vers. 05/2023
Note on the energy eciency class: This product contains a light source of energy eciency class F
8. General & notes

SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen, Germany
E-Mail: [email protected]; Phone: +49 7633 - 988 3000
01 02 03 04
05 06 07
TWEO & GIRI
