MAXIMUM COMFORT AND CONTROL IN HEATING
TSSHC - DPTS-24V-120F
THERMOSTAT INSTALLATION
REFER TO INSTALLATION MANUAL DURING SETUP (INCLUDED)
STEP #1
1. REMOVE BACK COVER
2. ACTUATE SWITCH #2 TO THE "ON" POSITION. THE SWITCH IS LOCATED ON THE BACK OF THE
CIRCUIT BOARD.
3. INSTALL BATTERIES PER MANUAL.
STEP #2
1. WIRE PER "HEAT ONLY" DIAGRAM (SEE ATTACHED)
STEP #3 INSTALLER MENU SETUP
1. TAP CLOCK AND MODE SELECTIONS SIMULTANEOUSLY AND HOLD FOR 5 SECONDS
MINIMUM.
MENU #1 PROGRAM SCHEDULE
2. PRESS UP-DOWN ARROWS AND SELECT (THEN PRESS NEXT)
"O" (MANUAL MODE) or"7" (7 DAY SCHEDULE)
MENU #2 DAILY PROGRAM SCHEDULE
3. PRESS UP-DOWN ARROWS AND SELECT (THEN PRESS NEXT)
"2" (2 SCHEDULES PER DAY) OR "4" (4 SCHEDULES PER DAY)
MENU #3 FUNCTION SELECTION MODE
4. PRESS UP-DOWN ARROWS AND SELECT "2" HEATING ONLY (THEN PRESS NEXT)
MENU #4 PROGAMMABLE FAN OPTIONS
5. USE FACTORY DEFAULT "O" FOR PROGRAMMABLE FAN (THEN PRESS NEXT)
MENU #5 ASSIGNING CONTACT OPTIONS
6. USE FACTORY DEFAULT "1" FOR AUXILLARY CONTACT (THEN PRESS NEXT)
SSHC,
INC.
ENERJOY RADIANT PEOPLEHEATER

TSSHC
-
DPTS
-
24V
-
120F
Installation Procedures

SSHC, Inc., PO Box 769, Old Saybrook, CT 06475 [phone] [phone] [phone](fax)
MENU "6" TOUCHSCREEN LOCK OPTIONS
7. PRESS ARROWS AND SELECT
"O" ALL FUNCTIONS UNLOCKED OR "1" ALL FUNCTIONS LOCKED EXCEPT TEMPERATURE SET
POINT OR "2" ALL FUNCTIONS LOCKED (THEN PRESS NEXT)
MENU "7" COOLING SET POINT OPTION
8. LEAVE AT FACTORY DEFAULT POINT "50" (THEN PRESS NEXT)
MENU #8 HEATING SET POINT LIMIT
9. PRESS ARROWS AND SELECT MAXIMUM HEATING SET POINT (THEN PRESS NEXT)
MENU #9 BACK LIGHT OPTION
10. PRESS ARROWS AND SELECT "O" BACK LIGHT ON "1" ON HIGH (THEN PRESS NEXT)
MENU #10 ADAPTIVE RECOVERY OPTION
11. ADAPTIVE RECOVER RATE WILL BRING ROOM UP TO SET TEMPERATURE POINT BY THE
SCHEDULED START TIME.
SELECT "O" OFF AND "1" ON IF IN 7 DAY PROGRAM MODE ONLY (RECOMMENDED).
(THEN PRESS NEXT)
MENU #11 HEATING DIFFERENTIAL OPTION
12. SELECT TEMPERATURE DIFFERENTIAL THAT WILL ENERGIZE THE RADIANT PANELS.
1= 1 DEGREE F DIFFERENTIAL
2= 2 DEGREE F DIFFERENTIAL (RECOMMENDED)
3= 3 DEGREE F DIFFERENTIAL
(THEN PRESS NEXT)
MENU #12 SECOND STAGE DIFFERENTIAL OPTION
13. SELECT TEMPERATURE DIFFERENTIAL THAT WILL DE-ENERGIZE THE RADIANT PANELS. THE
FACTORY DEFAULT IS 2 (RECOMMENDED) (THEN PRESS NEXT)
MENU #13 NOT REQUIRED
MENU #14 EQUIPMENT STAGING OPTION
14. USE FACTORY DEFAULT SETTING "O" = DEMAND STAGING (THEN PRESS NEXT)
MENU #15, #16, #17 USE FACTORY DEFAULT SETTINGS
