SSI Fluid-Trac DFT-110 Operating and safety instructions

ssi-sensors.com1
Product Overview
Copyright © 2019, SSI Technologies, LLC Doc. DT-AN5 — Rev. 01
DFT-110 Product Overview
Product Overview
Digital Fluid-Trac®Model DFT-110 multi unit drum level gauge is a cost competitive non-contact liquid
level drum gauge. The DFT-110 drum gauge was designed for usage on ANSI MH2-2004 vertical drums
(≤ 32 inch depths). The DFT-110 drum gauge allows the user to easily select between the following
vertical drum settings: 15 gallon, 30 gallon, 55 gallon, 57 liter, 114 liter, and 208 liter.
Product Features
• Display Resolution: ± 0.5 gallon or ± 1 liter *
• Accuracy: ± 2.5% (1.5 gallons or 6 liters) of full scale volume (55 gallons / 208 liters setting) *
• Automatic Shuto󰀨 Prolonging Battery Life
• NEMA 4 Packaging
• Static Display Useful for Usage Consumption Calculations: The static level reading can be used
for manual rate calculations – i.e. daily or weekly consumption.
• Low Level Warning Light: A red LED will ash once every second when the volume is at 10% or
below the maximum volume.
• Easy to install: Digital Fluid-Trac®DFT-110 has no components to protrude into the drum.
• Standard: Fits 2” NPT or ¾” NPS opening
• Deadband: 6” from top of barrel when using the optional ¾” adaptor
• More Reliable: No components to chemically corrode inside liquid media.
• Chemical compatibility: Digital Fluid-Trac® DFT-110 drum gauge works with a wide variety of media
such as water, waste water, motor oil, hydraulic uid and diesel fuel.
Note: The Digital Fluid-Trac™ is NOT intended for use with gasoline or other volatile liquids that produce
a vapor pressure under normal operating temperature (0 °C - 50 °C).
* Outside of stated dead band.

ssi-sensors.com2Copyright © 2019, SSI Technologies, LLC Doc. DT-AN5 — Rev. 01
Measurement Technology
The Digital Fluid-Trac® DFT-110 drum level gauge uses ultrasonic technology to generate a
highfrequency sound wave and measures the time for the echo to reect o󰀨 the target uid’s surface
and return. The distance from the Digital Fluid-Trac®’s sensor to the liquid is calculated based on the
speed of sound.
The Digital Fluid-Trac® DFT-110 has a LCD which displays the liquid level pictorially as well as in
gallon (or liter) units. The display shows the level reading from the last time the Refresh/Select button
was pressed.
When the Refresh/Select button is pressed and released, the DFT-110’s back-light is illuminated and
8.8.8. is displayed for 4 seconds to indicate the unit is in test mode. The unit continuously monitors the
media in the vertical drum for 7 seconds and then displays the liquid level. The level reading will remain
static until the Refresh/Select button is depressed again.
20 seconds after the button was pressed, the unit will go into a battery saver mode where the backlight is
shut o󰀨. The liquid level reading will be displayed for 5 minutes before the display turns o󰀨.
A low-level warning light (red LED located on the bottom left of the LCD display), will ash once every
second when the liquid level is ≤ 10% the maximum volume.
Note: This warning light does not operate once the unit has powered down in battery saver mode.
Electrical Interface
The Digital Fluid-Trac® DFT-110 drum gauge is powered by two 9 V batteries (not included). The unit can
run on alkaline or lithium batteries.
If the battery life is low (voltage is below 14.2 V), “LoB “will continuously ash to notify the user to
replace the batteries.
Displaying the DFT-110 Settings
1. Press and hold the Refresh/Select button down for 7 seconds. The drum size will be displayed.
And the selected units (Liters or Gallons) will be ashing.
2. Release the Refresh/Select button and the unit will automatically go back into test mode
(indicated by 8.8.8) in 20 seconds.

ssi-sensors.com3Copyright © 2019, SSI Technologies, LLC Doc. DT-AN5 — Rev. 01
Selecting the Display Units
The Digital Fluid-Trac® DFT-110 multi-unit drum gauge can set to display the level reading in one of six
di󰀨erent congurations - gallons (15, 30, 55) or liters (57, 114, 208).
1. Enter the Select Mode: Press and hold the Refresh/Select button down for 7 seconds to enter the
Select Mode. The unit will display Liter and Gallon. One of the units will be ashing.
Note: If you release the button too soon, the DFT-110 will be in test mode.
2. Switch the Desired Units: Press and release the Refresh/Select button to switch between the units.
3. Select the Desired Units: When the units (Liters or Gallons) desired is ashing, press and hold the
Refresh/Select button for 7 seconds to select the units. The units will stop ashing and the drum size
will start ashing.
4. Switch the Desired Drum Size: Press and release the Refresh/Select button to switch between
the drum sizes.
5. Select the Desired Drum Size: When the drum size desired is ashing, press and hold the
Refresh/Select button for 7 seconds to select the drum size. The drum size will stop ashing.
6. Return to Test Mode: Press and hold the button until 8.8.8. is displayed – this indicates test mode.
Testing With the DFT-110
1. After you have selected the proper units and drum size for your application, Press and release the
Refresh/Select button.
2. The DFT-110’s back-light is illuminated and 8.8.8. is displayed for 4 seconds to indicate the unit is
in test mode.
3. The DFT-110 continuously monitors the media in the vertical drum for 7 seconds and then displays
this liquid level.
4. Battery Saver Mode: 20 seconds after the button was pressed, the back-light is shut o󰀨. The static
liquid level reading will be displayed for 5 minutes before the display turns o󰀨.
Note: This liquid level displayed is a static value. You must depress the Refresh/Select button to up-
date the liquid level reading.
5. A low-level warning light (red LED located on the bottom left of the LCD display), will ash once
every second when the liquid level is <= 10% the maximum volume.
Note: This warning light does not operate once the unit has powered down in battery saver mode.

ssi-sensors.com4Copyright © 2019, SSI Technologies, LLC Doc. DT-AN5 — Rev. 01
Mounting
Digital Fluid-Trac® works well on ANSI MH2 standard 55 gallon drums as it mates with closedhead
standardized bunghole arrangements. The 55 gallon drum gauge mounts on top of the drum with a
standard 2” NPT thread connector. A ¾ inch NPS threaded adapter is included with each
Digital FluidTrac® Model DFT-110 so either bung opening can be used on the drums.
When using the Digital Fluid-Trac®, it is important to keep the mounting perpendicular to the liquid level
by storing the drums in an upright position.
Material Specications
Incorrect Correct
Electrical Specications
* Battery Life will vary dependant on operator’s usage.
Battery specication is based on two level readings per day.
** Outside of stated dead band
Resolution (Gallons) ** 0.5 gallons
Resolution (Liters) ** 1 Liter
Operating Temperature 0 °C to 50 °C
Battery Life * 6 months alkaline, 1 year lithium
Low Level Warning Activation (Red LED) ≤ 10% Max Volume
Low Battery Level (Lob) ≤ 14.2 Volts Combined
Description Material
Display housing / threaded adaptor (blue plastic) PBT (Polybutylene terephthalate), 15% glass lled
Transducer housing (black plastic inside threaded adaptor) HDPE (High Density Polyethylene)

Contact
SSI Technologies, LLC
3200 Palmer Drive, Janesville, WI 53546
ssi-sensors.com
1 [phone]
5Copyright © 2019, SSI Technologies, LLC
Warranty
LIMITED WARRANTY: All SSI products are warranted against defective materials and workmanship for a period of one (1)
year from the date of delivery to the original purchaser. Any product that is found to be defective within the one year period will
be replaced at the discretion of SSI. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, PERFORMANCE, OR OTHERWISE. SSI is not an ex-
pert in the customer's technical eld and therefore does not warrant the suitability of its products for the applications selected
by the customer. SSI accepts no responsibility for misuse, misapplication or unauthorized modication of its products.
LIMITATION OF LIABILITY: SSI's obligation under this limited warranty is strictly and exclusively limited to the repair or
replacement free of charge of such articles as are found to be defective in material or workmanship on the condition that the
purchaser gives prompt written notice to SSI of any claim to breach of warranty within the warranty period, and, if
requested, returns the defective articles to SSI. SSI will not assume any expenses or liability for repairs made to its articles
outside of its plant, without its prior written consent. SSI reserves the right to satisfy its warranty obligation in full, with respect
to defective articles, by the payment to the purchaser of all sums paid by the purchaser to SSI for such articles. IN NO
EVENT SHALL SSI BE LIABLE FOR CLAIMS (BASED UPON BREACH OF EXPRESS OR IMPLIED WARRANTY, NEG-
LIGENCE OR OTHERWISE) FOR ANY DAMAGES, WHETHER DIRECT, IMMEDIATE, INCIDENTAL, FORESEEABLE,
CONSEQUENTIAL, OR SPECIAL.
Terms & Conditions
Please visit [https://www.ssi-sensors.com/contact/supplier-portal] for information regarding the SSI Technologies, LLC Terms &
Conditions.
Doc. DT-AN5 — Rev. 01 — 06/17/2019
Note: Specs are subject to change without notice.
Made In USA
SSI Technologies, LLC is an Amphenol Advanced Sensors company.
