St Helens GH722 Manual

GH722
Hose Cart
Fixing and Maintenance Instructions
IMPORTANT
BEFORE USE
PRODUCT SAFETY
PARTS
A B C D
E F
G
I
J K
H
PARTS LIST
Installer and users please note:
Please read the entire instruction manual before using the product and then save it for future
reference. We reserve the right for any errors in text or images and any necessary changes made
to technical data.
Inspect the product for any signs of damage. If the product is damaged, DO NOT use it, and
contact your supplier immediately.
Prior to the installation of this product, the installation instructions should be read and completely
understood. The installation instructions must be read to prevent personal injury and property
damage. Keep these installation instructions in an easily accessible location for future reference.
Before assembly or
installation make sure
that all parts are present.
If any parts are missing
DO NOT attempt to
assemble, contact your
dealer.
A - Reel
B - Side Panel
C - Side Panel
D - Leg (Wheels)
E - Leg
F - Inner Reel
G - Handle
H - Hose Pipe
I -
J - Reel Handle
K - Angled Connector
L - Hose Attachments
M - Hose Connectors

STEP 3
STEP 5 STEP 6
STEP 4
STEP 2
Connect angled connector set (J)
through reel (A) & side panel (C)
Connect reel handle (I) through side
panel (B) and reel (A)
Connect Inner Reel (E) to both sides
of the reel (A)
Click Handle (F) into inserts on side
panels (B) & (C)
Insert end of Hose pipe (H) into Connector (L)
and screw connector to lock hose in place
Click Legs (D) into inserts on side panels (B) & (C)
STEP 1
(A)
(C)

STEP 7
Connect Hose (G) to angled
connector (I)
Rotate Reel handle (H) to wind in the
hose pipe (G)
STEP 8
SERVICE WARRANTY
Electrovision guarantees the product free from defects in materials and workmanship for a period of one year.
Should this unit be operated under conditions other than those recommended, at voltages other than the voltage indicat-
ed on the unit, or any attempts made to service or modify the unit, then the warranty will be rendered void.
The product you buy may sometimes dier slightly from illustrations. This warranty is in addition to, and does not aect,
your statutory rights.
Electrovision Ltd., Lancots Lane, Sutton Oak, St. Helens, Merseyside WA9 3EX
website: www.electrovision.co.uk
