ST-Lab C-221 User manual

1394a + USB 2.0 ExpressCard
User Manual
Ver. 1.00
All brand names and trademarks are properties of their
Respective owners.

MN7000000050Page2
Features and Benefits
General
zFully compliant with ExpressCard Specification 1.0
zExpressCard/34 Form Factor Module
zHot-swapping feature allows to connect or disconnect devices
without powering down system
zSupport Windows® 2000, XP/2003 32/64 bit, Vista 32/64 bit
IEEE 1394a
zCompliant with IEEE 1394-1995, 1394a-2000 and OHCI 1.1
standards
zProvides two external independent FireWire 400 ports
zData transfer speeds of 100, 200 and 400 Mbps are supported
USB 2.0
zFully supports EHCI and OHCI Compliant standards
zCompliant with Universal Serial Bus specification revision 2.0
zProvides one external USB2.0 high speed port
zSupports simultaneous operation of multiple USB 2.0 and USB
1.1 devices

MN7000000050Page3
zSupports data transfer rates of high-speed (480Mbps), full-speed
(12Mbps), and low-speed (1.5Mbps)
System Requirements
zWindows® 2000/XP/Server 2003 SP1 or above/Vista
zExpressCard-enabled system with an available ExpressCard slot
Package Contents
z1 x 1394a + USB 2.0 ExpressCard
z1 x User’s Manual
Optional Accessories
zUlead Video Studio CD
zIEEE 1394a Cable

Hardware Description
CAUTION:
Use only switching power adapter with following specifications:
zSwitching power adapter (Optional) DC 12V, 1A
Polarity: Outside negative voltage(-) & Inside positive voltage(+)
3.5mm power jack
MN7000000050Page4

MN7000000050Page5
Hardware Installation
General instructions for installing the card are provided below. Since
the design of system may vary, refer to your system’s reference manual
for further information, if needed.
Insert the Card into the ExpressCard slot of your system. Make sure it
is inserted all the way in for a solid connection.
Driver Installation
Important: If your system doesn’t boot to Windows properly with our
card installed, check with your system’s manufacturer for the latest
system firmware update.
For Windows® 2000/XP/Server 2003 SP1/Vista
Note: Server 2003 Server Pack 1 or above is required to install the
1394a + USB 2.0 ExpressCard successfully.
Windows® 2000/XP/Server 2003 SP1/Vista will automatically detect
and install the correct driver for the 1394a + USB 2.0 ExpressCard.

Inserting/Removing Devices
When inserting/removing your FireWire device, hold the ExpessCard
and make sure it does not move around inside the slot, otherwise, the
ExpressCard may loose connection or should be ejected from the
system.
