Staco Energy Unistar V User manual

Uninterruptible Power Supply
1/2/3 kVA
Single Phase, On-Line Double Conversion
(Universal Tower / Rack Mount)
USER MANUAL
003-2519 REV A

Table of Contents
1. Important Safety Warnings........................................................................................................................ 3
1-1. Transportation .................................................................................................................................... 3
1-2. Preparation ......................................................................................................................................... 3
1-3. Installation.......................................................................................................................................... 3
1-4. Operation............................................................................................................................................ 3
1-5. Maintenance, service and faults......................................................................................................... 4
2. Installation and setup................................................................................................................................. 5
2-1 Rear panel view................................................................................................................................... 5
2-2. Operating principle............................................................................................................................. 7
2-3. Install the UPS.................................................................................................................................... 7
2-4. Setup the UPS .................................................................................................................................... 9
2-5 Battery Replacement..........................................................................................................................11
2-6 Battery Kit Assembly (option) .............................................................................................................. 12
3. Operation................................................................................................................................................. 14
3-1. Button operation............................................................................................................................... 14
3-2. LCD Panel........................................................................................................................................ 15
3-3. Audible Alarm.................................................................................................................................. 16
3-4. LCD display wordings index ........................................................................................................... 16
3-5. UPS Settings..................................................................................................................................... 17
3-6. Operating Mode Description............................................................................................................ 19
3-7. Faults Reference Code ..................................................................................................................... 20
3-8. Warning indicator............................................................................................................................. 21
4. Troubleshooting....................................................................................................................................... 21
5. Storage and Maintenance......................................................................................................................... 23
6. Specifications .......................................................................................................................................... 24
Battery Pack Specification .......................................................................................................................... 26
page 2 / 26 003-2519

1. Important Safety Warnings
Please strictly comply with all warnings and operating instructions in this manual. Save this
manual and carefully read the following instructions before installing the unit. Do not operate this
unit before reading through all safety information and operating instructions carefully.
1-1. Transportation
Transport the UPS system only in the original package to protect against shock and
impact.
1-2. Preparation
Condensation may occur if the UPS system is moved directly from cold to warm
environment. The UPS system must be absolutely dry before being installed. Please
allow at least two hours for the UPS system to acclimate to the environment.
Do not install the UPS system near water or in moist environments.
Do not install the UPS system where it would be exposed to direct sunlight or near a
heater.
Do not block ventilation holes in the UPS housing.
1-3. Installation
Do not connect appliances or devices which would overload the UPS system (e.g. laser
printers) to the UPS output sockets.
Place cables in such a way that no one can step on or trip over them.
Do not connect domestic appliances such as hair dryers to UPS output sockets.
The UPS can be operated by individuals with no previous experience.
The UPS can be operated in TN&TT power distribution.
Connect the UPS system only to an earthed shockproof outlet which must be easily
accessible and close to the UPS system.
Please use only UL-tested, UL-marked power cables to connect the loads to the UPS
system.
When installing the equipment, ensure that the sum of the leakage current of the UPS
and the connected devices does not exceed 3.5mA.
Temperature Rating - Units are considered acceptable for use in a maximum ambient of
40°C (104°F).
For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment
and shall be easily accessible.
CAUTION: The unit is heavy. Lifting the unit requires a minimum of two people.
1-4. Operation
Do not disconnect the mains cable on the UPS system or the building wiring outlet
(shockproof socket outlet) during operations since this would cancel the protective earth
of the UPS system and of all connected loads.
The UPS system features its own internal current source (batteries). The UPS output
sockets or output terminal blocks may be electrically live even if the UPS system is not
connected to the building wiring outlet.
In order to fully disconnect the UPS system, first press the OFF/Enter button and
page 3 / 26 003-2519

disconnect the mains.
Prevent fluids or other foreign objects from getting inside the UPS system.
The EPO, RS-232 and USB circuits are IEC 60950 safety extra low voltage (SELV) circuits.
This circuit must be separated from any hazardous voltage circuits by reinforced
insulation.
1-5. Maintenance, service and faults
The UPS system operates with hazardous voltages. Repairs may be carried out only by
qualified maintenance personnel.
Caution - risk of electric shock. Even after the unit is disconnected from the mains
(building wiring outlet), components inside the UPS system are still connected to the
battery and electrically live and dangerous.
Before carrying out any kind of service and/or maintenance, disconnect the batteries and
verify that no current is present and no hazardous voltage exists in the terminals of high
capability capacitors such as BUS-capacitors.
To avoid electrical shock, turn off the unit and unplug it from the AC power source before
servicing the battery.
Only persons that are adequately familiar with batteries and with the required
precautionary measures may replace batteries and supervise operations. Unauthorized
persons must be kept well away from the batteries.
Caution - risk of electric shock. The battery circuit is not isolated from the input voltage.
Hazardous voltages may occur between the battery terminals and the ground. Before
touching, verify that no voltage is present!
When changing batteries, install the same number and same type of batteries.
Do not attempt to dispose of batteries by burning them. This could cause battery
explosion.
Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin and
eyes. It may be toxic.
When replacing batteries, replace with the same type and number of batteries or battery
packs.
Manufacturer
Type
Rated
Toplite (Guangzhou) Technology Battery Co Ltd
(MH29104)
NPW45-12
12 V dc, 9.0 Ah
NPW45-12 FR
12 V dc, 7.0 Ah
NPW36-12
12 V dc, 7.2 Ah
NPW36-12 FR
12 V dc, 7.0 Ah
CSB Battery Co Ltd (MH14533)
UPS 12360 7 FR
12 V dc, 7.1 Ah
UPS 12460 F2FR
12 V dc, 9.0 Ah
HR 1234W FR
12 V dc, 8.5 Ah
Yuasa Battery (Guangdong) Co Ltd (MH29616)
NPW45-12
12 V dc, 8.0 Ah
NPW45-12FR
12 V dc, 8.0 Ah
Do not dismantle the UPS system.
A battery can present a risk of electrical shock and high short-circuit current. The
following precautions should be observed when working on batteries:
a) Remove watches, rings, or other metal objects.
b) Use tools with insulated handles.
c) Wear rubber gloves and boots.
d) Do not lay tools or metal parts on top of batteries.
page 4 / 26 003-2519

e) Disconnect charging source prior to connecting or disconnecting battery terminals.
f) Determine if battery is inadvertently grounded. If inadvertently grounded, remove
source from ground. Contact with any part of a grounded battery can result in electrical
shock. The likelihood of such shock can be reduced if such grounds are removed during
installation and maintenance.
2. Installation and setup
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is
damaged. Please keep the original package in a safe place for future use.
NOTE: There are two different types of online UPS: standard and long-run models. Please refer to
the following model table.
Model No.
Type
Model No.
Type
SCV-1000x
Standard
Model
SCV-1000x-LB
Long-run
Model
SCV-2000x
SCV-2000x-LB
SCV-3000x
SCV-3000x-LB
2-1 Rear panel view
1 kVA
2 kVA
page 5 / 26 003-2519

3 kVA
1. Programmable outlets: connect to non-critical loads.
2. Output receptacles: connect to mission-critical loads.
3. AC input
4. Input circuit breaker
5. Emergency power off function connector (EPO)
6. USB communication port
7. RS-232 communication port
8. SNMP intelligent slot
9. External battery connector
10.Output circuit breaker
11.Modem/phone/network surge protection
page 6 / 26 003-2519

2-2. Operating principle
The operating principle of the UPS is shown as below.
The UPS is composed of mains input, TVSS
and EMI/RFI filters, rectifier/PFC, inverter,
battery charger, DC-to-DC converter, battery,
dynamic bypass and UPS output.
2-3. Install the UPS
For safety consideration, the UPS is shipped out from factory without connecting battery wires.
Before installing the UPS, please follow the below steps to re-connect battery wire.
Step 1
Step 2
Step 3
Remove front panel.
Remove battery panel and
re-connect battery wire.
Put battery panel and cover
back to the unit.
This UPS can be either displayed on the desk or mounted in the 19” rack chassis. Please choose
proper installation to position this UPS.
Rack-mount Installation
CAUTION – Do NOT use the mounting brackets to lift the unit. The mounting brackets are only
for securing the unit to the rack.
Install UPS alone
page 7 / 26 003-2519

Install UPS and external battery
Tower Installation
Install UPS alone
Install UPS and external battery
NOTE: When installing the UPS or battery pack with feet, keep 2.76in distance from the edge of
the unit.
page 8 / 26 003-2519

2-4. Setup the UPS
Step 1: UPS input connection
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords.
CAUTION: For 1 and 2 kVA models, to reduce the risk of fire, connect only to a circuit provided
with 20 amperes maximum branch circuit overcurrent protection in accordance with the National
Electric Code, ANSI/NFPA 70.
CAUTION:For 3 kVA models, to reduce the risk of fire, connect only to a circuit provided with 30
amperes maximum branch circuit overcurrent protection in accordance with the National Electric
Code, ANSI/NFPA 70.
Step 2: UPS output connection
There two kinds of outputs: programmable outlets and general outlets. Connect non-critical
devices to the programmable outlets and critical devices to the general outlets. During power
failure, you may extend the backup time to critical devices by setting shorter backup time for
non-critical devices.
Step 3: Communication connection
Communication port:
USB port RS-232 port Intelligent slot
To allow for unattended UPS shutdown/start-up and status monitoring, connect one end of the
communication cable to the USB/RS-232 port and the other end to the communication port of
your PC. With the monitoring software installed, you can schedule UPS shutdown/start-up and
monitor UPS status through PC.
The UPS is equipped with an intelligent slot perfect for either a SNMP or an AS400 card. Installing
either a SNMP or AS400 card in the UPS will provide advanced communication and monitoring
options.
NOTE: USB port and RS-232 port can’t work at the same time.
Step 4: Network connection
Network/Fax/Phone surge port
Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the
UPS unit. Connect from “OUT” outlet to the equipment with another modem/fax/phone line cable.
page 9 / 26 003-2519

Step 5: Disable and enable EPO function
Keep pin 1 and pin 2 closed for UPS normal operation. To activate EPO function, cut the wire
between pin 1 and pin 2.
Step 6: External battery connection
Connect one end of external battery cable to UPS unit and the other end to battery pack. See
below chart for detailed connection.
CAUTION: Connection to External Battery shall be installed by SERVICE PERSONNEL only.
CAUTION – Risk of fire hazard.
Step 7: Turn on the UPS
Press the ON/Mute button on the front panel for two seconds to power on the UPS.
Note: The battery charges fully during the first five hours of normal operation. Do not expect
full battery run capability during this initial charge period.
Step 8: Install software
Install UPS monitoring software to fully configure UPS shutdown. Follow the steps below to
download and install monitoring software:
1. Go to the website http://www.power-software-download.com
2. Click ViewPower software icon and then choose your required OS to download the software.
3. Follow the on-screen instructions to install the software.
External Battery Pack
External Battery Pack
UPS
Short terminals for UPS
normal operation.
page 10 / 26 003-2519

4. When your computer restarts, the monitoring software will appear as an orange plug icon
located in the system tray, near the clock.
2-5 Battery Replacement
NOTICE: This UPS is equipped with internal batteries and only service personnel can replace the
batteries.
CAUTION!! Consider all warnings, cautions, and notes before replacing batteries.
NOTE: Upon battery disconnection, equipment is not protected from power outages.
Step 1
Step 2
Step 3
Remove front panel.
Disconnect battery wire and
remove battery panel.
Pull out the battery box.
Step 4
Step 5
Step 6
Remove the top cover of
battery box and replace the
inside batteries.
After replacing the
batteries, put the battery
box back to original location
and screw in tightly.
Re-connect the battery wire and
screw battery panel back on the
unit.
page 11 / 26 003-2519

Step 7
Put the front panel back on the unit.
2-6 Battery Kit Assembly (option)
NOTICE: Replacement battery pack comes fully assembled from the factory. Consult factory for
details.
2-battery kit – 1 kVA
Step 1: Remove adhesive tapes.
Step 2: Connect all battery terminals by
following below picture.
Step 3: Put assembled battery packs on
one side of plastic shells.
Step 4: Cover the other side of plastic shell as
shown below. Then, battery kit is fully
assembled.
4-battery kit – 2 kVA
Step 1: Remove adhesive tapes.
Step 2: Connect all battery terminals by
following below picture.
Tapes
Tapes
Tapes
page 12 / 26 003-2519

Step 3: Put assembled battery packs on
one side of plastic shells.
Step 4: Cover the other side of plastic shell as
shown below. Then, battery kit is fully
assembled.
6-battery kit – 3 kVA
Step 1: Remove adhesive tapes.
Step 2: Connect all battery terminals by
following below picture.
Step 3: Put assembled battery packs on
one side of plastic shells.
Step 4: Cover the other side of plastic shell as
shown below. Then, battery kit is fully
assembled.
Tapes
Tapes
page 13 / 26 003-2519

3. Operation
3-1. Button operation
Button View
Button Function
ON/Mute Button

Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds
to turn on the UPS.
Mute the alarm: After the UPS is turned on in battery mode, press and
hold this button for at least 5 seconds to disable or enable the alarm
system.
Up key: Press this button to display previous selection in UPS setting
mode.
Switch to UPS self-test mode: Press ON/Mute button for 5 seconds to
enter UPS self-testing while in AC mode, ECO mode, AECO mode, or
converter mode.
OFF/Enter Button

Turn off the UPS: Press and hold this button at least 2 seconds to turn
off the UPS in battery mode. UPS will be in standby mode under power
normal or transfer to bypass mode if the Bypass is enabled.
Confirm selection key: Press this button to confirm selection in UPS
setting mode.
Select Button

Switch LCD message: Press this button to change the LCD message for
input voltage, input frequency, battery voltage, output voltage, output
frequency.
Setting mode: Press and hold this button for 5 seconds to enter UPS
setting mode when in Standby and Bypass mode.
Down key: Press this button to display next selection in UPS setting
mode.
ON/Mute + Select
Button

Switch to bypass mode: When the main power is normal, press
ON/Mute and Select buttons simultaneously for 5 seconds. UPS will
enter bypass mode. This action will be ineffective when the input
voltage is out of acceptable range.
page 14 / 26 003-2519

3-2. LCD Panel
Display
Function
Remaining backup time information
Indicates the remaining backup time in pie chart.
Indicates the remaining backup time in numbers.
H: hours, M: minute, S: second
Fault information
Indicates that warning and fault occurred.
Indicates the warning and fault codes. The codes are listed in detail
in section 3-5.
Mute operation
Indicates that the UPS alarm is disabled.
Output & Battery voltage information
Indicates the output voltage, frequency or battery voltage.
Vac: output voltage, Vdc: battery voltage, Hz: frequency
Load information
Indicates the load level by 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates overload.
Indicates the load or the UPS output is short circuit.
Mode operation information
Indicates the UPS is connected to the mains.
Indicates the battery is working.
Indicates the bypass circuit is working.
Indicates the ECO mode is enabled.
Indicates the Inverter circuit is working.
Indicates the output is working.
Programmable outlets information
Indicates that programmable outlets have output voltage.
page 15 / 26 003-2519

Battery information
Indicates the Battery level by 0-25%, 26-50%, 51-75%, and
76-100%.
Indicates the battery is at fault.
Indicates low battery level and low battery voltage.
Input & Battery voltage information
Indicates the input voltage or frequency or battery voltage.
Vac: Input voltage, Vdc: battery voltage, Hz: input frequency
3-3. Audible Alarm
Battery Mode Sounding every 4 seconds
Low Battery Sounding every second
Overload Sounding twice every second
Fault Continuously sounding
3-4. LCD display wordings index
Abbreviation Display content Meaning
ENA Enable
DIS Disable
ESC Escape
HLS High loss
LLS Low loss
BAT Battery
CF Converter
TP Temperature
CH Charger
SF Site Fault
EP EPO
FU Bypass frequency unstable
EE EEPROM error
page 16 / 26 003-2519

3-5. UPS Settings
Parameter 3
Parameter 1
Parameter 2
There are three parameters to set up the UPS.
Parameter 1: P
rogram alternatives. Refer to below
table.
Parameter 2 and Parameter 3 are the setting
options or values for each program.
01: Output voltage setting
Interface
Setting
For 200/208/220/230/240 VAC models, you may choose
the following output voltage:
200: presents output voltage is 200Vac
208: presents output voltage is 208Vac
220: presents output voltage is 220Vac
230: presents output voltage is 230Vac
240: presents output voltage is 240Vac
For 100/110/115/120VAC models, you may choose the
following output voltage:
100: presents output voltage is 100Vac
110: presents output voltage is 110Vac
115: presents output voltage is 115Vac
120: presents output voltage is 120Vac
02: Frequency Converter enable/disable
Interface
Setting
CF ENA: converter mode enable
CF DIS: converter mode disable(Default)
03: Output frequency setting
Interface
Setting
You may set the initial frequency on battery mode:
BAT 50: presents output frequency is 50Hz
BAT 60: presents output frequency is 60Hz
If converter mode enable, you may choose the following output
frequency:
CF 50: presents output frequency is 50Hz
CF 60: presents output frequency is 60Hz
page 17 / 26 003-2519

04: ECO enable/disable
Interface
Setting
ENA: ECO mode enable
DIS: ECO mode disable(Default)
05: AECO enable/disable
Interface
Setting
ENA: Advanced ECO mode enable
DIS: Advanced ECO mode disable(Default)
06: Bypass mode enable/disable when UPS is off
Interface
Setting
ENA: Bypass mode is enabled when UPS is off
DIS: Bypass mode is disabled when UPS is off (Default)
07: Programmable outlets enable/disable
Interface
Setting
ENA: Programmable outlets enable
DIS: Programmable outlets disable(Default)
08: Programmable outlets setting
Interface
Setting
0-999: setting the backup time limits in minutes from 0-999
for programmable outlets which connect to non-critical
devices on battery mode.
page 18 / 26 003-2519

09: Acceptable input voltage range setting
Interface
Setting
For 200/208/220/230/240 VAC models, you may choose the
following selection for acceptable input voltage range:
110/300 flashing in turns: The acceptable input voltage range
is from 110V to 300V.
160/260 flashing in turns: The acceptable input voltage range
is from 160V to 260V.
170/270 flashing in turns: The acceptable input voltage range
is from 170V to 270V.
For 100/110/115/120 VAC models, you may choose the
following selection for acceptable input voltage range:
55/150 flashing in turns: The acceptable input voltage range is
from 55V to 150V.
80/130 flashing in turns: The acceptable input voltage range is
from 80V to 130V.
85/135 flashing in turns: The acceptable input voltage range is
from 85V to 135V.
00: Exit setting
3-6. Operating Mode Description
Operating
mode
Description
LCD display
Online mode
When the input voltage is within acceptable
range, UPS will provide pure and stable AC
power to output. The UPS will also charge
the battery in online mode.
ECO mode
(Efficiency
Corrective
Optimizer)
When the input voltage is within setting
range (±3%Vo max), UPS will bypass
voltage to output for energy saving. PFC
and INVERTER are still active in this mode.
AECO mode
(Advanced
Efficiency
Corrective
Optimizer)
When the input voltage is within setting
range (±3%Vo max), UPS will bypass
voltage to output for energy saving. PFC
and INVERTER are off in this mode.
page 19 / 26 003-2519

Frequency
Converter mode
When input frequency is within 40 Hz to 70
Hz, the UPS can be set at a constant
output frequency, 50 Hz or 60 Hz. The
UPS will still charge battery under this
mode.
Battery mode
When the input voltage is beyond the
acceptable range or power failure occurs
and alarm is sounding every 4 seconds,
UPS will backup power from battery.
Bypass mode
When input voltage is within acceptable
range but UPS is in overload, UPS will
enter bypass mode or bypass mode can be
set by front panel. Alarm sounds every 10
seconds.
Standby mode
UPS is powered off and without output
power, but the battery still can be charged.
Fault mode
The UPS is in fault mode when no output
power is supplied from the UPS and the
fault icon flashes on the LCD display,
although the UPS information can be
displayed on the screen.
3-7. Faults Reference Code
Fault event
Fault code
Icon
Fault event
Fault code
Icon
Bus start fail
01
x
Inverter voltage Low
13
x
Bus over
02
x
Inverter output short
14
Bus under
03
x
Battery voltage too high
27
Bus unbalance
04
x
Battery voltage too low
28
Bus short circuited
05
x
Over temperature
41
x
Inverter soft start fail
11
x
Over load
43
Inverter voltage high
12
x
page 20 / 26 003-2519
