Stages cycling StagesPower User manual

English
Français
Español
TM

2 3
Stages Cycling™ LLC
www.stagescycling.com
[email protected]
1-800-778-7218
Oces:
Sales, Accounting and Administrative: 1732 NW Quimby, Ste 250,
Portland, OR 97209
Design, Manufacturing and Tech. Support: 3090 Sterling Cir, Ste 102,
Boulder, CO 80301
Specications
• Battery CR2032 – service life, approximately 200 hours
• Wireless transmission: 2.4GHz, ANT+™ and Bluetooth® Smart (4.0)
• Accuracy: +/-2% of measured power
• Weight: adds only 20g to weight of left crank arm
• Power measurement range: (watts): 0 – 1999
• Cadence range (RPM): 30-220
• Water resistance rating: IPX7
This product is ANT+ cer d and complies with the following spe d
ANT+ Device Pro:
www.thisisant.com/directory
Training with a power meter is the best way to guarantee improvements in
your functional threshold power, overall tness and of course speed. We all
want to ride faster with less eort and using a power meter will help you to
determine your strengths and weaknesses, create the proper training zones
and easily understand your progress. As the co-author of“Training and Racing
with a Power Meter”, I have written extensively on the subject of power
training and coached some of the best riders in the world to greater success
using the principles of power training. Training with your new power meter
puts you in charge of the training stress that you need to create in order to
help you adapt, get stronger and ultimately achieve your cycling dream goals.
Hunter Allen
Founder-Peaks Coaching Group
Co-developer- TrainingPeaks WKO+ power analysis software
Co-author- Training and Racing with a Power meter.

4 5
Fig 1 Fig 2
Fig 3
Fig 5
Fig 4
Fig 6
fig 7
fig

6 7
Water resistance notice
The Stages™ power meter is designed to provide excellent water resistance
and tested to resist water ingress to the IPX7 standard (up to 1 meter). This
provides outstanding water resistance for cycling conditions on-road and o,
including stream crossing and heavy rain. Please keep in mind this is an
electronic device not a submarine; as such, there are limits to the water
resistance.
Do not subject the power meter to direct spray from a high pressure
sprayer. Water exiting a sprayer can reach hundreds and sometimes
thousands of pounds of pressure per square inch. This may be equivalent
to the pressure found at ocean depths of 1000 feet or more! It is possible
for water to be forced past the o-ring seal under these conditions and
damage to the electronics may occur.
Battery installation or replacement
1. The power meter uses a CR2032 battery that can be installed or replaced
by hand without the need for additional tools.
2. Referencing FIG 1 and 2; rotate the battery cover in the counter clockwise
direction to release the cover.
Do not attempt to use any tools to force or pry the battery door open.
3. Place the new CR2032 battery into the battery receptacle with the“+”side
facing out. It is critical that the battery is inserted in this orientation.
4. Before installing the battery cover take care to ensure the water seal o-ring
is seated properly in its groove as illustrated in FIG 4.
5. Replace the battery door as illustrated in FIG 5.
6. Once the battery door has been properly inserted and is even with the
surface of the power meter, use your nger to rmly rotate the door back
to the locked position as illustrated in FIG 6.
The power meter ships without a battery installed.
The battery must be installed before rst use.
Power meter (crank arm) installation
IMPORTANT NOTICE: to ensure power meter compatibility with the
frame and components, please follow these steps carefully and in the
specic order. Do not install the pedals until compatibility of the power
meter has been conrmed.
1. Attach the left crank arm to the bike following the instructions provided
by the crank arm manufacturer and supplied with your power meter.
Links to crank manufacturer's installation instructions may be found at
the Stages Cycling website:
http://www.stagescycling.com/support-general-instruction
2. Carefully and fully install the crank arm onto the bike but
DO NOT ATTACH THE PEDAL AT THIS TIME.
3. Carefully and slowly rotate the crank 1 full revolution to ensure there
is no contact between the power meter sensor housing and any part
of the frame or other components as illustrated in FIG 7.
4. If there is interference between the power meter and the frame or other
components, contact your retailer for technical assistance.
Contact Stages Cycling If the power meter was purchased from our online
store.
5. If no interference is found you may continue with the nal installation of
pedals according to the pedal manufacturer’s instructions.
Power meter wireless communication
The power meter is compatible with a wide range of display devices that utilize
the ANT+ or Bluetooth Smart (4.0) wireless communication systems. Many
leading brands of bicycle computers utilize the ANT+ “prole” for power
measurement and can be used to display the power (Watts) and cadence (RPM)
measured by the power meter and sent wirelessly to the computer. Bluetooth
Smart is a popular wireless communication system included with many of the
latest mobile phones. Utilizing Bluetooth Smart, a mobile phone running a
compatible App can be used to display the power (Watts) and cadence (RPM)
data within the App.

8 9
Pairing the power meter
The power meter must be connected or “paired” to the cycle computer or
mobile device (collectively referred to as display units) according to the display
manufacturer’s instructions. Each power meter has a unique ANT+ device ID
and a unique Bluetooth ID. During the pairing process the applicable device ID
is recorded by the display and will be used to communicate with the
corresponding power meter. The ANT+ ID number is printed on the back of
the power meter and also supplied with the documentation. The Bluetooth ID
is recognized and displayed by the Bluetooth device during the pairing
process. Once paired to the power meter, ride data (Watts and RPM) will be
transmitted from the power meter to the display unit. Other important
functions such as resetting the power meter’s zero oset will also be enabled
through the display unit. Both the ANT+ and Bluetooth IDs are
permanently assigned to the power meter and are not aected by
changing the power meter battery.
ANT+: Ensure the power meter has a fully charged CR2032 battery properly
installed. Rotate the crank arm one time to ensure the power meter is awake
and ready to communicate. Follow the ANT+ device manufacturer’s
instructions for pairing a power meter to the display unit. The procedures may
vary between manufacturers.
Bluetooth Smart: Ensure the power meter has a fully charged CR2032 battery
properly installed. Rotate the crank arm one time to ensure the power meter is
awake and ready to communicate. Follow the Bluetooth Smart Ready (4.0)
device manufacturer’s instructions for pairing a power meter to the display
unit. The procedures may vary between manufacturers.
Zero oset calibration
The zero oset calibration is an important feature of the power meter that
resets the zero oset value for the power meter sensors. There are physical and
environmental conditions that may aect the zero oset value and there are
methods both manual and automatic that will adjust this value to
accommodate for the changing physical and environmental condition. The
zero oset of the power meter is essentially the sensor reading or values
measured when the power meter has no pedaling load (torque) applied. The
act of calibrating the zero oset causes the power meter to measure the value
at zero load and then records this value as the baseline for power
measurement. Loads applied while pedaling will then be measured as torque
and used by the sensor to determine power in Watts. The zero oset value can
be aected by the installation of the crank arm and the tightening of the
securing hardware. The torque applied to the securing hardware can impart
some strain into the crank material that is easily accounted for by manually
calibrating the zero oset. Any time the power meter is removed from the bike
and reinstalled the zero oset should be calibrated.
Ambient temperature shifts can also aect the zero oset to some extent. To
ensure maximum accuracy it is advisable to manually calibrate the zero oset
before each ride. The power meter utilizes automatic temperature sensors to
compensate for temperature changes that take place during the ride. This is
done automatically while you ride and you need not take any further steps to
calibrate the sensor during the ride.
How to calibrate the zero oset
Calibrating the zero oset is a function controlled by the cycle computer or
mobile device (display units) paired to the power meter. Please note that some
device manufacturers refer to the step of resetting the zero oset as
“calibration”. When paired to a compatible ANT+ cycle computer or Bluetooth
Smart mobile device, the power meter and display units are in two-way
communication. The display unit can send a command to the power meter to
calibrate the zero oset value and in some cases the resulting zero oset value
will be sent back from the power meter to the display unit and be shown on the
screen. Please note the displayed zero oset value will NOT be zero but rather
a number that corresponds to the measurement taken by the sensor.The
display units will also indicate if the procedure was successful or failed.

10 11
Before attempting to calibrate the zero oset value of the power meter,
ensure that a working battery is in use. Rotate the power meter one revolu-
tion to ensure the power meter is awake and ready to communicate.
The left crank arm with power meter MUST be positioned straight down (6
o’clock position) and ensure there is no load on the pedals and the bike is
stable. See FIG 8 for a visual reference. If the left crank arm is not straight
down the reset procedure for zero oset will fail.
Although the process for calibrating the zero oset will vary depending on
the display manufacturer, it should roughly follow these general steps;
however, consult your display unit’s manual for specic steps:
1. Ensure the power meter has been paired to and is communicating with
the display unit.
2. Position the crank straight down (6 o’clock position) FG 8, and the bike is
stable.
Note: please see error code #32 in the troubleshooting section below.
The power meter sensor will determine if the crank is positioned in an
acceptable orientation during the zero reset process.
3. Access the settings function of the wireless display.
4. Select the power sensor (many times the power sensor is located within a
“BIKE”setting).
5. Select the “CALIBRATE”or “Zero” function.
6. Calibration of the zero oset will begin and take only a few seconds to
complete.
7. Upon completion the display will show a message indicating success or
failure of the procedure.
Troubleshooting
Calibration time out
When using a Garmin®display unit with the heart rate (HR) sensor enabled, it
is possible the calibration process will take too long and time out before
completion. To resolve this either turn o the HR sensor on your Garmin while
you calibrate your power meter (you can turn it back on once the power
meter is calibrated) or put the HR strap on and ensure it has been detected by
the display before you attempt to calibrate the zero oset.
If no power (watts) or cadence (RPM) signal is being received by your
compatible display unit when riding the bike, please conrm the following
items:
1. Conrm that a working CR2032 battery is properly installed in the
power meter according to the reference FIGs 1-6 of this manual.
2. Ride the bike with a pedaling cadence of greater than 30 RPM. Your
Stages Power meter will not send cadence or wattage to the display
unless a true pedaling force is applied. If you pedal your bicycle in the
work stand the display will not show cadence or watts — this is not a
problem — as soon as you ride the bike you will see your
cadence and power values displayed.
3. Ensure that the power meter has been successfully paired to the display
unit being used according the manufacturer’s specic instructions.
4. For further assistance with Troubleshooting, FAQs, videos and useful tips,
please visit our website at: www.stagescycling.com/support
Error Codes
An error code may be displayed if resetting the zero oset fails.
Please note the possible error codes below and corrective action that
should be taken.
Code #s Corrective Action
1,2,4,16
Simply attempt zero reset again. If code remains after several
attempts please contact
Stages Cycling – Technical Support.
32
Power meter crank not in proper position (straight down) see FIG 8.
The StagesPower App may be used to conrm device communication, verify
and update the rmware release via Bluetooth Smart and ANT+ (requires
Wahoo™ ANT+ key). Vist www.stagescycling.com/support-app for
additional information and links to the app store.

12 13
Firmware
Firmware is the programming that operates the power meter’s computer.
The power meter has been designed to allow over-the-air (OTA) rmware
updates. Updated rmware may be developed and released by Stages
Cycling to provide added or improved functionality. Firmware updates
may be sent to the power meter by way of the Stages Cycling Utility App
for Apple® iOS devices using a Bluetooth Smart compatible (BLE 4.0) model
such as the iPhone® 4s, 5 or newer and iPad® 3, Mini or newer. At the time
of printing, Android™ Apps supporting Bluetooth OTA updates of the
power meter rmware are not yet available; however, these may be
developed and released at a later date. Please check our website at:
www.stagescycling.com/support-app for links to the available utility
Apps hosted in the App stores as well as instructions on how to utilize the
App for rmware update and other procedures.
Maintenance and cleaning
The only items of the power meter that can be serviced by the owner are the
battery, battery cover and o-ring. No other items are serviceable and no
attempt should be made to adjust or alter any other items.
The power meter uses a custom 0-ring and is lubricated to with o-ring grease.
The grease protects the 0-ring from abrasions and environmental conditions
and is critical to ensure proper water resistance. When servicing the o-ring
ensure it is well coated with a grease designed for use on o-rings which may
be obtained at most hardware stores.
When cleaning the power meter use only water dampened cloth to wipe o
dirt and debris. Never use any harsh cleaning chemicals that may damage
the plastic housing. Inspect the battery compartment to ensure the batter
contact is clean of any corrosion.
Never directly spray the power meter or battery door with high
pressure water. The water pressure from sprayers can reach thousands
of pounds per square inch and may force water past the o-ring
damaging the power meter electronics.
Warranty procedures
Complete warranty details are available in our Important Product
Information document and at our website FAQ page:
http://www.stagescycling.com/support
The Stages power meter is considered to be the entire left crank arm, not just
the electronics and housing mounted to the crank arm. As such customers are
instructed to contact their retailer or Stages Cycling directly for all warranty
claims related to the left crank arm power meter. Do not contact the crank arm
manufacturer for warranty concerns regarding the left arm as they are not in a
position to provide service for this product once the power meter electronics
have been permanently integrated.
To pursue a warranty claim please contact the retailer that sold the power
meter. If the power meter was purchased directly from Stages Cycling please
contact us directly via email or phone:
[email protected]om
1-800-778-7218 (M-F 8am-5pm PST)
In all cases a Return Authorization Number (RA#) must be issued by
Stages Cycling before any product is returned for warranty inspections
and service.

14 15
The Stages Power™ device may be protected by USA or foreign patents or
patents pending.
This document may contain trademarks or registered trademarks of Stages
Cycling LLC as represented by the use of ™ and ® respectively.
ANT+™ is a trademark of Dynastream Innovations Inc.
Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
Apple®, iPhone®, iPad® are registered trademarks of Apple Inc.
Android™ is a trademark of Google Inc.
Garmin ® is a registered trademark of Garmin Corporation
Wahoo ™ is a trademark of Wahoo Fitness LLC
Copyright ©Stages Cycling LLC, 2013
Stages Cycling™
Important Product Information
Contact Information:
Stages Cycling LLC
1732 NW Quimby
Suite 250
Portland, OR 97209
www.stagescycling.com
[email protected]om
Product Name: Stages Power™
Model Name: SPM1
FCC ID: PADWF105
IC ID: 10563A-WF0105
California Proposition 65
The enclosed hardware and its packaging contain chemicals the State of
California has found to cause cancer, birth defects or reproductive harm.
RoHS
Stages Cycling certies that this product and its packaging are in compliance
with European Union Directive 2011/65/EU on the Restriction of the Use of
Certain Hazardous Substances in Electrical and Electronics Equipment,
commonly known as RoHS.
FCC Rules Part 15
The enclosed hardware device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not
cause harmful interference and (2) it must accept any interference received,
including interference that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to comply with limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in residential
installations. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause interference to radio or television equipment
reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help

16 17
To assure continued compliance, any changes or modications not expressly
approved by the party responsible for compliance could void the user’s
authority to operate this equipment. (Example- use only shielded interface
cables when connecting to a computer or peripheral devices).
Caution! The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modications to this equipment. Such
modications could void the users authority to operate the equipment.
IC Statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. The device
meets the exemption from the routine evaluation limits in section 2.5 of RSS
103 and users can obtain Canadian information on RF exposure and
compliance.
Le présent appareil est conforme_aux CNR_d'Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Le dispositif rencontre l'exemption des limites_courantes d’évaluation dans la
section 2.5 de RSS102 et les utilisateurs peuvent obtenir l’information
canadienne sur l'exposition et la conformité de rf.
CE statement：
Europe – EU Declaration of Conformity This device complies with the
essential requirements of the R&TTE Directive 1999/5/EC. The following test
methods have been applied in order to prove presumption of conformity
with the essential requirements of the R&TTE Directive 1999/5/EC:
EN 60950-1:2006+A12:2011
EN 55022+EN 55024(2010)
EN 301 489-1 V1.8.1(2008-04)
EN 301 489-3V1.4.1(2002-08)
EN 300 440-2 V1.3.1(2009-03)
This device is a 2.4 GHz wideband transmission system (transceiver),
intended for use in all EU member states and EFTA countries, except in
France and Italy where restrictive use applies. In Italy the end-user should
apply for a license at the national spectrum authorities in order to obtain
authorization to use the device for setting up outdoor radio links and/or for
supplying public access to telecommunications and/or network services.
This device may not be used for setting up outdoor radio links in France and
in some areas the RF output power may be limited to 10 mW EIRP in the
frequency range of 2454 – 2483.5 MHz. For detailed information the
end-user should contact the national spectrum authority in France. Hereby,
Stages Cycling declares that these products are in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.

18 19
STAGES CYCLING LLC (1) One Year Limited Warranty
HOW CONSUMER LAW RELATES TO THIS WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS THAT VARY FROM STATE TO STATE (OR BY COUNTRY OR
PROVINCE). OTHER THAN AS PERMITTED BY LAW, STAGES CYCLING DOES NOT
EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS YOU MAY HAVE. FOR A FULL
UNDERSTANDING OF YOUR RIGHTS YOU SHOULD CONSULT THE LAWS OF
YOUR COUNTRY, PROVINCE OR STATE.
WARRANTY LIMITATIONS THAT MAY AFFECT CONSUMER LAW
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE REMEDIES SET
FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES
AND CONDITIONS, WHETHER ORAL, WRITTEN, STATUTORY, EXPRESS OR
IMPLIED. STAGES CYCLING DISCLAIMS ALL STATUTORY AND IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND
WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE EXTENT
PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT BE
DISCLAIMED, STAGES CYCLING LIMITS THE DURATION AND REMEDIES OF
SUCH WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
STAGES CYCLING'S OPTION, THE REPAIR OR REPLACEMENT SERVICES
DESCRIBED BELOW. IN NO EVENT WILL THE VALUE OF THE WARRANTY
PROVIDED EXCEED THE ORIGINAL PURCHSE PRICE. SOME STATES (COUNTRIES
AND PROVINCES) DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY (OR CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED
ABOVE MAY NOT APPLY TO YOU.
WHAT IS COVERED BY THIS WARRANTY?
Stages Cycling warrants the Stages Cycling-branded hardware product and
accessories contained in the original packaging ("Stages Cycling Product")
against defects in materials and workmanship when used normally in
accordance with Stages Cycling's published guidelines for a period of ONE (1)
YEAR from the date of original retail purchase by the end-user purchaser
("Warranty Period"). This warranty only applies to the original owner and is not
transferable.
WHAT IS NOT COVERED BY THIS WARRANTY?
This warranty applies to Stages Cycling branded products including
but not limited to crank arms when packaged or sold with Stages
Cycling hardware. Manufacturers, suppliers, or publishers, other than
Stages Cycling, may provide their own warranties to you but Stages
Cycling, in so far as permitted by law, provides their products "AS IS".
Stages Cycling does not warrant that the operation of the Stages
Cycling Product will be uninterrupted or error-free. Stages Cycling is
not responsible for damage arising from failure to follow instructions
relating to the Stages Cycling Product's use. Stages Cycling's
published guidelines include but are not limited to information
contained in technical specications, user manuals and service
communications.
This warranty does not apply: (a) to consumable parts, such as
batteries or protective coatings that are designed to diminish over
time, unless failure has occurred due to a defect in materials or
workmanship; (b) to cosmetic damage, including but not limited to
scratches and dents; (c) to damage caused by use with another
product; (d) to damage caused by accident, impact, abuse, misuse,
re, earthquake or other external cause; (e) to damage caused by
operating the Stages Cycling Product outside Stages Cycling's
published guidelines; (f) to damage caused by service,
modications or alterations performed by anyone other than
Stages Cycling or an authorized Stages Cycling Service Provider (h)
to defects caused by normal wear and tear or otherwise due to the
normal aging of the Stages Cycling Product, or (i) if any serial
number has been removed or defaced from the Stages Cycling
Product.
IMPORTANT RESTRICTION
Stages Cycling may restrict warranty service to the country where
Stages Cycling or its Authorized Distributors originally sold the
Stages Cycling Product.
