Star Micronics NX-1020 User manual

NX-1020
RAINBOW
USERS MANUAL
NOT INTENDED FOR SALE

Federal Communications Commission
Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and at, the user is encouraged to try to correct the
interference by one or more of the following measures:
l Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
l Consult the dealer or an experienced radioDV technician for help.
Unauthorized modifications of this product by the user will void his authority to operate the equipment
unless expressly approved by the party responsible for compliance. -
For compliance with the Federal Noise Interference Standard, this equipment requires a shielded cable.
The above statement applies only to printers marketed in the V.SA.
Statement of
The Canadian Department of Communications
Radio Interference Regulations
This digitalapparatus does not exceed theClass B limits for radionoiseemissions from digitalapparatus
set out in the Radio Interference Regulations of the Canadian Department of Communications.
Le ptisent appareil numkique n’hen pas de bruits radioklectriques dCpassant les limites applicables
aux appareils numCriques de la classe B prescrites dans le Reglement sur le brouillage radio&cnique
Cdict6 par le miniske des Communications du Canada.
The above statement applies only IOprinters marketed in Canada.
Trademark Acknowledgements
NX-1020, NX-1000, LC-10, ND-lo/H: Star Micronics Co., Ltd.
IBM PC, PC-AT, PC-XT, Proprinter III, Proprinter II, PC-DOS: International Business Machines
Corp.
Microsoft BASIC, MS-DOS: Microsoft Corporation
FX-850, EX-800, LX-854 LX-810: Seiko Epson Corp.
-
NOTICE
l All rights reserved. Reproduction of any part of this manual in any form whatsoever without
STAR’s express permission is forbidden.
. The contents of this manual are subject to change without notice.
. All efforts have been made to ensure the accuracy of the contents of this manual at the time of
press. However, should any errors LXdetected, STAR would greatiy appreciate being informed
of them.
. The above notwithstanding, STAR can assume no responsibility for any errors in this manual.
0 Copyright 1990 Star Micronics Co., Ltd.

HOW TO USE THIS MANUAL
This manual is organized into nine chapters. To learn how to make the best
use of your printer you are urged to read through chapters 1through 3. The
remaining chapters may be treated as a reference guide for programming
operations, etc. It assumes a degree of knowledge of the operation of
computers (for instance, it assumes you know about hexadecimal numbers).
The chapters are as follows:
Chapter 1 - Setting up the printer
This chapter explains how to get the printer unpacked and set up. Read this
chapter before you do anything else.
Chapter 2 - Control panel operations
There are a number of controls on the front panel which perform various
functions related to paper handling, print modes and font selection.
After getting set up, read this chapter and try out the various procedures in
it to find out how the printer works.
Chapter 3 - Default settings
This chapter explains how to use the Electronic DIP Switch (EDS) mode to
make system settings on the printer.
Chapter 4 - Printer control commands
This chapter explains the different emulations provided by your printer, and
the software commands used to drive it. This section is of use if you are
writing or modifying programs to take advantage of the printer’s features.
Chapter 5 - Download characters
This chapter explains the procedures to create your own characters.

Chapter 6 - MS-DOS and your printer
Since the PC or PC-AT family of computers running under MS-DOS is
currently the most popular configuration of microcomputer, we have in-
cluded a few hints and tips to help you use your printer with such systems.
Since virtually all PCs are sold with aMicrosoft BASIC interpreter, we have
also included some hints, and a sample program in this language to
demonstrate the capabilities of the printer.
Chapter 7 - Troubleshooting and maintenance
This section gives achecklist of points to check if your printer isnot working
in the expected way. It also includes details of some routine maintenance
operations you can carry out yourself. It is not, however, acomplete service
manual. Call aqualified service engineer if you are unsure of your ability to
carry out any maintenance or servicing operations.
-
Chapter 8 - Specifications
This section gives the specifications of your printer.
Chapter 9 - Character sets
These charts show the different character sets available.

FEATURES OF THE PRINTER
This printer has afull complement of features, making it an excellent partner
for a personal computer. It supports the IBM/Epson printer commands and
character sets, enabling it to print just about anything your computer can
generate, both text and graphics. Some of itsmain features arethe following:
l Extensive software support
Since it is compatible with the Epson and IBM printers, it works with any
software that supports those printers. That includes most word-processing
and graphics programs, spread-sheets, and integrated software packages.
l Easy operation
Clearly understandable indicator displays and beep tones provide immedi-
ate feedback when you press the buttons on the control panel. The five
buttons can operate in combinations to perform a surprising variety of
functions, including micro-alignment.
l Easy care and maintenance
The ribbon cartridge can be replaced in seconds the print head in a few
minutes.
l Versatile paper handling
Single sheets, fanfold forms, and multi-part forms (up to quadruple-ply) are
all accepted, and you can use either push/pull tractor or friction feed. A
special feature enables you to keep fanfold forms parked in readiness while
printing on other paper.
l Large variety of fonts and sizes
The printerhas one draft font, one High-Speed Draft font and four NLQ fonts
(Courier, Sanserif, Orator and Script), italics for all styles, plus condensed
print, bold print, double-sized print, and quadruple-sized print.
