Star Micronics TSP700 Series Operating and maintenance manual

Thermal Printer
TSP700 Series
TSP800 Series
Programmer’s Manual

Notice
•All rights reserved. Reproduction of any part of this manual in any form whatsoever,
without STAR’s express permission is forbidden.
•The contents of this manual are subject to change without notice.
•Alleffortshavebeenmadetoensuretheaccuracyofthecontentsofthismanualatthetime
ofgoingtopress.However,shouldanyerrorsbedetected,STARwouldgreatlyappreciate
being informed of them.
•The above notwithstanding, STAR can assume no responsibility for any errors in this
manual.
©Copyright 2000 Star Micronics Co., LTD.

TABLE OF CONTENTS
1. OUTLINE............................................................................................1
2. STAR LINE MODE............................................................................2
2-1. Command Summary ....................................................................2
2-2. Command Specification...............................................................6
3. STAR PAGE MODE (TSP800 Only) ...............................................45
3-1. Command Summary ..................................................................45
3-2. Command Specification.............................................................47
4. DP8340 MODE (TSP800 Only)........................................................68
4-1. Command Summary ..................................................................68
4-2. Command Specification.............................................................69
5. ESC/POS MODE Command Summary (TSP700 Only)...................74
Appendix 1 : How to set various bar codes ...........................................76
Appendix 2 : Sensor adjustment mode ..................................................84
Appendix 3 : Character code tables .......................................................85
A3-1. STAR Line mode .............................................................85
A3-2. STAR Page mode (TSP800 Only) .................................100
A3-3. DP8340 mode (TSP800 Only) .......................................104

–1 –
1.OUTLINE
1-1. TSP700 Series
The details of each command are shown in the following sections.
The printer has two different software modes (STAR Line mode and ESC/POS
mode ) which can be selected using the DIP switch.
(Factory setting: STAR Line mode)
DIP Switch #1
1-1 Mode Selection
ON STAR Line mode
OFF ESC/POS mode
For the detailed functions and settings of the DIP switches, please refer to the
User's Manual.
1-2. TSP800 Series
The details of each command are shown in the following sections.
The printer has three different software modes (STAR Line mode, STAR Pege
mode, DP8340 mode and ESC/POS mode ) which can be selected using the DIP
switch.
(Factory setting: STAR Line mode)
DIP Switch #1
1-1 1-2 Mode Selection
ON ON STAR Line mode
OFF ON STAR Page mode
ON OFF DP8340 mode
For the detailed functions and settings of the DIP switches, please refer to the
User's Manual.

–2 –
LINE MODE
2-1. Command Summary
The details of each command are shown in the following sections.
Commands to Select Characters
Control codes Hexadecimal Function Page
codes
<ESC> “R”n1B 52 nSelect international character set 6
<ESC> “/”“1”1B 2F 31 Select slash zero 6
<ESC> “/”<1> 1B 2F 01
<ESC> “/”“0”1B 2F 30 Select normal zero 6
<ESC> “/”<0> 1B 2F 00
<ESC> “b”n1 n2 n3 n4 1B 62 n1 n2 n3 n4 Select bar code printing 7
d1 ... <RS> d1 ... 1E
<ESC> “M”1B 4D Select 12-dot pitch printing 11
<ESC> “p”1B 70 Select 14-dot pitch printing 11
<ESC> “P”1B 50 Select 15-dot pitch printing 11
<ESC> “:”1B 3A Select 16-dot pitch printing 11
<ESC> <SP> n1B 20 nSet character spacing 11
<SO> 0E Sets the printing magnified double in 12
character width.
<DC4> 14 Resets the printing magnified in 12
character width.
<ESC> “W”n1B 57 n Sets the magnification rate in character width. 12
<ESC> <SO> 1B 0E Sets the printing magnified double in 12
character height.
<ESC> <DC4> 1B 14 Resets the printing magnified in character 12
height.
<ESC> “h”n1B 68 n Sets the magnification rate in character height .13
<ESC> “i”n1 n2 1B 69 n1 n2 Sets the magnification rates in character 13
width and height.
<ESC> “–”“1”1B 2D 31 Select underlining 13
<ESC> “–”<1> 1B 2D 01
<ESC> “–”“0”1B 2D 30 Cancel underlining 13
<ESC> “–”<0> 1B 2D 00
<ESC> “_”“1”1B 5F 31 Select upperlining 14
<ESC> “_”<1> 1B 5F 01
<ESC> “_”“0”1B 5F 30 Cancel upperlining 14
<ESC> “_”<0> 1B 5F 00
2. STAR LINE MODE

–3 –
LINE MODE
Control codes Hexadecimal Function Page
codes
<ESC> “4”1B 34 Select highlight printing 14
<ESC> “5”1B 35 Cancel highlight printing 14
<SI> 0F Inverted printing 14
<DC2> 12 Cancel inverted printing 14
<ESC> “E”1B 45 Select emphasized printing 15
<ESC> “F”1B 46 Cancel emphasized printing 15
<ESC><GS> “t”n1B 1D 74 n Select character code table 15
Commands to Set the Page Format
Control codes Hexadecimal Function Page
codes
<ESC> “C”n1B 43 nSet page length in lines 16
<ESC> “C”<0> n1B 43 00 nSet page length in inches 16
<ESC> “N”n1B 4E nSet bottom margin 16
<ESC> “O”1B 4F Cancel bottom margin 17
<ESC> “l”n1B 6C nSet left margin 17
<ESC> “Q”n1B 51 nSet right margin 17
Commands to Move the Print Position
Control codes Hexadecimal Function Page
codes
<LF> 0A Line feed 18
<CR> 0D Carriage Return 18
<ESC> “a”n1B 61 nFeed paper nlines 18
<FF> 0C Form feed 18
<HT> 09 Horizontal tab 18
<VT> 0B Vertical tab 19
<ESC> “z”“1”1B 7A 31 Set line spacing to 4 mm 19
<ESC> “z”<1> 1B 7A 01
<ESC> “0”1B 30 Set line spacing to 3 mm 19
<ESC> “J”n 1B 4A nOne time n/4 mm feed 19
<ESC>“I”n 1B 49 nOne time n/8 mm feed 20
<ESC> “B”n1 n2 ... <0> 1B 42 n1 n2 ... 00 Set vertical tab stops 20
<ESC> “D”n1 n2 ... <0> 1B 44 n1 n2 ... 00 Set horizontal tab stops 20
<ESC> <GS>“A”n1 n2 1B 1D 41 n1 n2 Absolute position setting 21
<ESC> <GS>“R”n1 n2 1B 1D 52 n1 n2 Relative position setting 21
<ESC> <GS>“a”n1B 1D 61 nAlignment 22

–4 –
LINE MODE
Commands to Print Dot Graphics
Control codes Hexadecimal Function Page
codes
<ESC> “K”n<0> 1B 4B n00 m1 m2 Print normal density graphics 23
m1 m2 ... ...
<ESC> “L”n1 n2 1B 4C n1 n2 m1 m2 Print high density graphics 25
m1 m2 ... ...
<ESC> “k”n<0> d1 ... 1B 6B n00 d1 ... Print fine density graphics 26
<ESC> “X”n1 n2 d1 ... 1B 58 n1 n2 d1 ... Print fine density graphics 29
<ESC> <FS> “q”n1B 1C 71 n Define logo data 30
[x11 x12 y11 y12 d [k1]]1 ... [x11 x12 y11 y12 d [k1]]1 ...
<ESC> <FS>“p”nm1B 1C 70 nmPrint logo image 32
Commands to Print Download Characters
Control codes Hexadecimal Function Page
codes
<ESC> “&”<1> <1> 1B 26 01 01 nDefine download character 33
nm1 m2 ... m48 m1 m2 ... m48
<ESC> “&”<1> <0> n1B 26 01 00 nDelete a download character 34
<ESC> “%”“1”1B 25 31 Enable download character set 34
<ESC> “%”<1> 1B 25 01
<ESC> “%”“0”1B 25 30 Disable download character set 34
<ESC> “%”<0> 1B 25 00
Commands to Control Peripheral Devices
Control codes Hexadecimal Function Page
codes
<ESC> <BEL> n1 n2 1B 07 n1 n2 Define drive pulse width for peripheral 35
device
<BEL> 07 Control peripheral device #1 35
<FS> 1C Control peripheral device #1 35
<EM> 19 Control peripheral device #2 35
<SUB> 1A Control peripheral device #2 35
Commands to Control Auto Cutter
Control codes Hexadecimal Function Page
codes
<ESC> “d”“n”1B 64 nCut command to the auto cutter 36

–5 –
LINE MODE
Other Commands
Control codes Hexadecimal Function Page
codes
<CAN> 18 Cancel last line & Initialize printer 37
<ESC> “#N, n1 n2 n3 n4”
1B 23 N 2C n1 n2 n3 n4
Set memory switch 37
<LF> <NUL> 0A 00
<ESC> “@”1B 40 Initialize printer 40
<ENQ> 05 Request status 40
<EOT> 04 Request status 41
<ESC> <ACK> <SOH> 1B 06 01 Request status 41
<ESC> <RS> “a”n1B 1E 61 nSet status transmission condition 44
<ESC> “?”<LF> <NUL> 1B 3F 0A 00 Reset printer hardware 44

–6 –
LINE MODE
2-2. Command Specification
Commands to Select Characters
FUNCTION
Select international character set
CODE
<ESC> “R”n
HEX
1B 52 n
REMARKS
Selects an international character set according to the value of n,
as shown below:
nCharacter set nCharacter set
0 U.S.A. 8 Japan
1 France 9 Norway
2 Germany 10 Denmark II
3 England 11 Spain II
4 Denmark I 12 Latin America
5 Sweden 13 Korea
6 Italy 14 Ireland
7 Spain I 64 Legal
FUNCTION
Select zero style
CODE
<ESC> “/”n
HEX
1B 2F n
REMARKS
Causessubsequentzero characterstobeprintedwith a slashwhen
n is 1, and without a slash when n is 0.
The value of ncan be set to 0(00H) or “0”(30H), or 1(01H) or
“1”(31H).

–7 –
LINE MODE
FUNCTION
Select bar code printing
CODE
<ESC> “b”n1 n2 n3 n4 di ... dk <RS>
HEX
1B 62 n1 n2 n3 n4 di ... dk 1E
REMARKS
Prints bar code according to the value of n1, as shown below:
n1: Type of bar code
0 UPC-E
1 UPC-A
2 JAN/EAN-8
3 JAN/EAN-13
4 CODE 39
5 ITF
6 CODE 128
7 CODE 93
8 NW-7
The value of n1 can be set to 1(00H) or 8(08H) or “1”(30H) to
“8”(38H).
n2: Printing character below bar code or line feed
1 Character below bar code is not printed, Line feed is
performed after execution of command.
2 Character below bar code is printed, Line feed is
performed after execution of command.
3 Character below bar code is not printed, Line feed is
not performed after execution of command.
4 Character below bar code is printed, Line feed is not
performed after execution of command.
The value of n2 can be set to 1(01H) to 4(04H) or “1”(31H) to
“4”(34H).
n3: Mode of bar code
UPC-E, UPC-A, JAN/EAN-8, JAN/EAN-13, CODE 128,
CODE 93
1 Minimum module 2 dots
2 Minimum module 3 dots
3 Minimum module 4 dots

–8 –
LINE MODE
CODE 39, NW-7, ITF CODE 39, NW-7 ITF
1 Narrow : wide 2:6 dots 2:5 dots
2 Narrow : wide 3:9 dots 4:10 dots
3 Narrow : wide 4:12 dots 6:15 dots
4 Narrow : wide 2:5 dots 2:4 dots
5 Narrow : wide 3:8 dots 4:8 dots
6 Narrow : wide 4:10 dots 6:12 dots
7 Narrow : wide 2:4 dots 2:6 dots
8 Narrow : wide 3:6 dots 3:9 dots
9 Narrow : wide 4:8 dots 4:12 dots
When either of UPC-E, UPC-A, JAN/EAN-8, JAN/EAN-13,
CODE128 or CODE93 is selected, 1(01H) to 3(03H) or “1”(31H)
to “3”(33H) can be set. When either of CODE39, NW-7 or ITF is
selected, 1(01H) to 9(09H) or “1”(31H) to “9”(39H) can be set.
n4: Height of bar code
Can be up to 255 dots (31.9mm).
If the bar code height is larger than the line feed amount, the
line feed amount is automatically multiplied by an integer.
di...dk: Bar code data
UPC-E: k = 11 (or 12)
The check digit at the 12th digit is automatically added,
and ignored even if it is specified.
If the data cannot be abbreviated, the command is
ignored. Data conversion to the abbreviation is auto-
matically executed.
UPC-A: k = 11 (or 12)
The check digit at the 12th digit is automatically added,
and ignored even if it is specified.
JAN/EAN-8: k = 7 (or 8)
The check digit at the 8th digit is automatically added,
and ignored even if it is specified.
JAN/EAN-13: k = 12 (or 13)
The check digit at the 13th digit is automatically added,
and ignored even if it is specified.

–9 –
LINE MODE
CODE39: The value of k is optional, and the maximum
value also differs according to the modes (21
digits maximum in mode 7).
The start/stop code (“*”) is automatically added.
ITF: The value of k is optional, and the maximum
value also differs according to the modes (40
digits maximum in mode 4).
If the data is number of an odd digits, 0 is
automatically added at the beginning of the data.
CODE 128:The value of k is optional, and the maximum
value also differs according to the modes and the
typesofcharacternumber(51digitsmaximumin
mode 1).
The check character is automatically added.
CODE93: Thevalueofkisoptional,andthemaximumvalue
also differs according to the modes and the types
of character (30 digits maximum in mode 1).
Thecheckcharacters(CandK)areautomatically
added.
NW-7: The value of k is optional, and the maximum
value also differs according to the modes and the
typesofcharacternumber(29digitsmaximumin
mode 7).
Thestart/stopcodeisalsocontainedinthedata(it
is not automatically added).
The bar code printing start position is at the upper end of the
current line.
If the bar code is positioned beyond the right margin, neither
the bar code nor the character below the bar code will be
printed.
Data of CODE 128 and CODE 93
When<LF>isusedinacommand,somekindsofcontrolcode
cannotbesentbythehostPC.Thecontrolcode shouldbesent
as the data as shown below:
•When sending the following data, express as a set of two
characters.

–10 –
LINE MODE
Control codes
CODE FORMAT
NUL 00H %@ 25H 40H
SOH 01H %A 25H 41H
STX 02H %B 25H 42H
ETX 03H %C 25H 43H
EOT 04H %D 25H 44H
ENQ 05H %E 25H 45H
ACK 06H %F 25H 46H
BEL 07H %G 25H 47H
BS 08H %H 25H 48H
HT 09H %I 25H 49H
LF 0AH %J 25H 4AH
VT 0BH %K 25H 4BH
FF 0CH %L 25H 4CH
CR 0DH %M 25H 4DH
SO 0EH %N 25H 4EH
SI 0FH %O 25H 4FH
DLE 10H %P 25H 50H
DC1 11H %Q 25H 51H
DC2 12H %R 25H 52H
DC3 13H %S 25H 53H
DC4 14H %T 25H 54H
NAK 15H %U 25H 55H
SYN 16H %V 25H 56H
ETB 17H %W 25H 57H
CAN 18H %X 25H 58H
EM 19H %Y 25H 59H
SUB 1AH %Z 25H 5AH
ESC 1BH %[ 25H 5BH
FC 1CH %¥25H 5CH
GS 1DH %] 25H 5DH
RS 1EH %^ 25H 5EH
US 1FH %_ 25H 5FH
DEL 7FH %5 25H 35H
Special code
CODE FORMAT
% 25H %0 25H 30H
Function codes
CODE FORMAT
FNC1 %1 25H 31H
FNC2 %2 25H 32H
FNC3 %3 25H 33H
FNC4 %4 25H 34H
✩
✩
✩
✩
Start codes
CODE FORMAT
START A %6 25H 36H
START B %7 25H 37H
START C %8 25H 38H
✩
✩
✩
✩For CODE 128 only.
Express “% (25H)”as “%0 (25H30H)”.
Add“40H-5FH”after“%”forthecontrolcodes(00H-1FH).
Express the control code (7FH) as “%5(25H35H)”.
Add “1 - 4 (31H - 34H)”after “%”for the function code.
Add “6 - 8 (36H - 38H)”after “%”for the start code.
3) 2-character codes

–11 –
LINE MODE
FUNCTION
Select 12-dot pitch printing
CODE
<ESC> “M”
HEX
1B 4D
REMARKS
Prints 12-dot pitch characters without an extra space.
FUNCTION
Select 14-dot pitch printing
CODE
<ESC> “p”
HEX
1B 70
REMARKS
Prints 12-dot pitch characters with 2-dot spacing between charac-
ters.
FUNCTION
Select 15-dot pitch printing
CODE
<ESC> “P”
HEX
1B 50
REMARKS
Prints 12-dot pitch characters with 3-dot spacing between charac-
ters.
FUNCTION
Select 16-dot pitch printing
CODE
<ESC> “:”
HEX
1B 3A
REMARKS
Prints 12-dot pitch characters with 4-dot spacing between charac-
ters.
FUNCTION
Set the character spacing
CODE
<ESC> <SP> n
HEX
1B 20 n
REMARKS
Sets the space between characters to ndots, where nis a number
from 0 to 15.
When the value of nis 0 to 9, 0(00H) to 9(09H) or “0”(30H) to
“9”(39H) can be set. When the value of nis 10 to 15, 10(0AH) to
15(0FH) or “A”(41H) to “F”(46H) can be set.

–12 –
LINE MODE
FUNCTION
Sets the printing magnified double in character width.
CODE
<SO>
HEX
0E
REMARKS
Prints the subsequent data including a character spacing set by
<ESC><SP> n, magnified double in character width.
FUNCTION
Resets the printing magnified in character width.
CODE
<DC4>
HEX
14
REMARKS
Resets the printing magnified in character width set by <SO>,
<ESC>“W”nand <ESC>“i”n1n2.
FUNCTION
Sets the magnification rate in character width.
CODE
<ESC> “W”n
HEX
1B 57 n
REMARKS
Prints the subsequent data including a character spacing set by
<ESC><SP>n,magnifiedincharacterwidthbyaratespecifiedby
the value of n.
nCharacter width nCharacter width
0 Unmagnify 3 Quadruple
1 Double 4 Quintuple
2 Triple 5 Sextuple
The value of ncan be set to 0(00H) to 5(05H) or “0”(30H) to
“5”(35H).
FUNCTION
Sets the printing magnified double in character height.
CODE
<ESC><SO>
HEX
1B 0E
REMARKS
Prints the subsequent data magnified double in character height.
FUNCTION
Resets the printing magnified in character height.
CODE
<ESC><DC4>
HEX
1B 14
REMARKS
Resets the printing magnified in character height set by
<ESC><SO>, <ESC>“h”nand <ESC>“i”n1n2.

–13 –
LINE MODE
FUNCTION
Sets the magnification rate in character height.
CODE
<ESC> “h”n
HEX
1B 68 n
REMARKS
Prints the subsequent data magnified in character height by a rate
specified by the value of n.
nCharacter height nCharacter height
0 Unmagnify 3 Quadruple
1 Double 4 Quintuple
2 Triple 5 Sextuple
The value of ncan be set to 0(00H) to 5(05H) or “0”(30H) to
“5”(35H).
FUNCTION
Sets the magnification rates in character width and height.
CODE
<ESC> “i”n1 n2
HEX
1B 69 n1 n2
REMARKS
Prints the subsequent data in the size specified by n1, n2.
n1 indicates the height magnification and n2 indicates the width
magnification.
n1 (n2) = 0 Normal height (or width) size.
1 Double height (or width) size.
2 Triple height (or width) size.
3 Quadruple height (or width) size.
4 Quintuple height (or width) size.
5 Sextuple height (or width) size.
The values of n1, n2 are 0(00H) to 5(05H) or “0”(30H)”to
“5”(35H).
FUNCTION
Underlining
CODE
<ESC> “–” n
HEX
1B 2D n
REMARKS
Whenthevalue of nis 1, underlines the subsequentdataincluding
a character spacing set by <ESC><SP> n.
The part to be skipped by the horizontal tab setting and the block
graphic characters are not underlined.
Resets the underline mode when the value of nis 0.
The value of ncan be set to 0(00H) or “0”(30H), or 1(01H) or
“1”(31H).

–14 –
LINE MODE
FUNCTION
Upperlining
CODE
<ESC> “_”n
HEX
1B 5F n
REMARKS
When the value of nis 1, overlines the subsequent data including
a character spacing set by <ESC><SP> n.
The part to be skipped by the horizontal tab setting and the block
graphic characters are not upperlined.
Resets the upperline mode when the value of nis 0.
The value of ncan be set to 0(00H) or “0”(30H), or 1(01H) or
“1”(31H).
FUNCTION
Select highlight printing
CODE
<ESC> “4”
HEX
1B 34
REMARKS
Prints the subsequent data including a character spacing set by
<ESC><SP> nhighlighted.
The part to be skipped by the horizontal tab setting is not high-
lighted.
FUNCTION
Cancel highlight printing
CODE
<ESC> “5”
HEX
1B 35
REMARKS
Cancels highlight printing.
FUNCTION
Inverted printing
CODE
<SI>
HEX
0F
REMARKS
Causes subsequent characters to be inverted.
FUNCTION
Cancel inverted printing
CODE
<DC2>
HEX
12
REMARKS
Cancels inverted printing.

–15 –
LINE MODE
FUNCTION
Select emphasized printing
CODE
<ESC> “E”
HEX
1B 45
REMARKS
Causes subsequent characters to be emphasized.
FUNCTION
Cancel emphasized printing
CODE
<ESC> “F”
HEX
1B 46
REMARKS
Cancels emphasized printing.
FUNCTION
Select character code table
CODE
<ESC> <GS> “t”n
HEX
1B 1D 74 n
REMARKS
Selects code page according to the value of n, as shown below:
n (Hex) Character Table n(Hex) Character Table
(00)H Normal* (15)H Codepage 874 (Thai)
(01)H CodePage437 (20)H Codepage 1252 (Windows Latin-1)
(02)H Katakana (21)H Codepage 1250 (Windows Latin-2)
(03)H CodePage437 (22)H Codepage 1251 (Windows Cyrillic)
(04)H Codepage 858 (Multilingual) (40)H Codepage 3840 (IBM-Russian)
(05)H Codepage 852 (Latin-2) (41)H Codepage 3841 (Gost)
(06)H Codepage 860 (Portuguese) (42)H Codepage 3843 (Polish)
(07)H Codepage 861 (Icelandic) (43)H Codepage 3844 (CS2)
(08)H Codepage 863 (Canadian French) (44)H Codepage 3845 (Hungarian)
(09)H Codepage 865 (Nordic) (45)H Codepgae 3846 (Turkish)
(0A)H Codepage 866 (Cyrillic Russian) (46)H Codepage 3847 (Brazil-ABNT)
(0B)H Codepage 855 (Cyrillic Bulgarian) (47)H Codepage 3848 (Brazil-ABICOMP)
(0C)H Codepage 857 (Turkish) (48)H Codepage 1001 (Arabic)
(0D)H Codepage 862 (Hebrew) (49)H Codepage 2001 (Lithuanian-KBL)
(0E)H Codepage 864 (Arabic) (4A)H Codepage 3001 (Estonian-1)
(0F)H Codepage 737 (Greek) (4B)H Codepage 3002 (Estonian-2)
(10)H Codepage 851 (Greek) (4C)H Codepage 3011 (Latvian-1)
(11)H Codepage 869 (Greek) (4D)H Codepage 3012 (Latvian-2)
(12)H Codepage 928 (Greek) (4E)H Codepage 3021 (Bulgarian)
(13)H Codepage 772 (Lithuanian) (4F)H Codepage 3041 (Maltese)
(14)H Codepage 774 (Lithuanian) (FF)H User Setting (Blank Code Page)

–16 –
LINE MODE
Commands to Set the Page Format
FUNCTION
Set page length in lines
CODE
<ESC> “C”n
HEX
1B 43 n
REMARKS
Sets the page length using the current line spacing, where nis
between 1 and 127.
Changing the line spacing later does not alter the physical page
length.
The current line becomes the top of the page.
Resets the bottom margin.
Invalid when start position detect is ON.
FUNCTION
Set page length in inches
CODE
<ESC> “C”<0> n
HEX
1B 43 00 n
REMARKS
Sets the page length to n × 24 mm, where nis between 1 and 22.
Changing the line spacing later does not alter the physical page
length.
The current line becomes the top of the page.
Resets the bottom margin.
Invalid when start position detect is ON.
FUNCTION
Set bottom margin
CODE
<ESC> “N”n
HEX
1B 4E n
REMARKS
Setsthebottommargintonlinesatthecurrentlinespacing,where
nis between 0 and 255.
Changing the line spacing later does not alter the bottom margin.
Bottom margin is reset when you change the page length.
Setting is invalid if the printing area on one page is 36 mm or less.
Invalid when start position detect is ON.

–17 –
LINE MODE
FUNCTION
Cancel bottom margin
CODE
<ESC> “O”
HEX
1B 4F
REMARKS
Cancels the bottom margin.
Invalid when start position detect is ON.
FUNCTION
Set left margin
CODE
<ESC> “l”n
HEX
1B 6C n
REMARKS
Sets the left margin at column n(where nis between 0 and 255) at
the current character pitch.
The left margin does not move if the character pitch is changed
later.
Setting is invalid if the printing area for one line would be 36mm
or less.
FUNCTION
Set right margin
CODE
<ESC> “Q”n
HEX
1B 51 n
REMARKS
Sets the right margin at column n(where nis between 1 and 255)
at the current character pitch.
The right margin does not move if the character pitch is changed
later.
Setting is invalid if the printing area for one line would be 36mm
or less.
