ASSEMBLY
MANUAL
8-TRx
Core Health & Fitness
Star Trac

Page 1
9-9251 - 110V, 18AMP
9-9252 - 220V, UL/FCC
9-9254 - 220V, 10AMP. CE
9-9201 - 110V, 18AMP, CSA/UL/FCC
9-9202 - 220V, UL
9-9204 - 220V, CE 8-TRx
Overall Weight Width Length Height Max User Weight
475 lbs (167.5 kg) 38.6 in (98 cm) 85.9 in (218.2 cm) 31.7 in (80.5 cm) 0-350 lbs (0-159 kg)
All products may be covered by US and Foreign Patents and Patents Pending.
PRODUCT SPOTLIGHT

Page 2
SKU Description
701-0002-XX RAIL, SIDE, LT, E-TRx
701-0003-XX RAIL, SIDE, RT, E-TRx
020-7528 GROMMET, HANDRAIL, LEFT, E-TRX, TEARDROP
020-7527 GROMMET, HANDRAIL, RIGHT, E-TRX, TEARDROP
110-3416 SCREW, 5/16-18 X 1, SHC, HE, AS, BO, NP
120-0496 WASHER, LOCK, SPLIT, 0.58 OD, 0.32 ID, 0.078
THK, CS, ZP
120-0490 WASHER, 5/16 SAE FLAT, 11/16”OD X 11/32” ID,
.06 THICK
020-7528 GROMMET, HANDRAIL, LEFT, E-TRX, TEARDROP
715-4034-XX ASSY, NECK, E-TRxe
110-3126 SCREW, 5/16-18x3.0, FULL THD, SHC, HE, CS, ZI,
G2
715-4032-XX NECK SPACER, RAIL SHAPE
715-4031-XX RAIL SPACER, TEAR-DROP SHAPE
715-4137-XX ASSY, HANDRAIL, W/HB, 8TRx/TC
110-0506 SCREW, 1/4-28, 3/8, BHC, HK, AS, BO, NP
740-4588 Screw, M8x1.25, 16mm, BHC, HK, SS
731-0561 WASHER,M8,1MM THK
020-7034-XX Shroud Motor, E-TRx
715-3959-XX COVER, PLASTIC, RAIL, LEFT
715-3862-XX COVER, PLASTIC, RAIL, RIGHT
110-3450 Screw, 10-24, 3/4”, THM, PH, CS, ZP
020-7232-XX CAP MOTOR SHROUD , E-TRx
140-3428 GROMMET NECK 6”X2” , OX
020-7460-XX PLASTICS, DISPLAY, MAIN REAR, TM-TC
701-0210-XX PLASTIC, DISPLAY, LCD, DECORATIVE, QKS,
TREAD, W/ INSERTS
Required Tools:
• 1/4” Allen Key
• 5/32” Allen Key
• #2 Phillips Screwdriver

Page 3
1. Use a 1/4” allen key to install the left side rail
(701-0002-XX) to the frame using three (3) pieces
each of the 5/16” x 1”socket head cap screw
(110-3416), 5/16” split lock washer (120-0496),
and 5/16” at washer (120-0490). Once the
handrail is installed, slide the left side handrail
grommet (020-7528) onto the rail - be careful of
orientation of the grommet.
2. Repeat Step 1 for the right side rail (701-0003-XX)
and rail grommet (020-7527).
DO NOT FULLY TIGHTEN
3. Use a 1/4” allen key to install the mast (715-4034-
XX) to the frame using two (2) pieces each of the
5/16” x 1” and 5/16” x 3” (110-3126)socket head
cap screws, and four (4) pieces each of the 5/16”
split lock washer and 5/16” at washer.
DO NOT FULLY TIGHTEN
4. Ensure that the supplementary power cable is
connected to the J20 port on the MCB and the
main data cable is connected to the J1 port on
the MCB.
J20 -
Supplementary
Power
J1 -
Main
Data
Cable
5. Install the mast beauty ring (715-4032-XX) onto
the mast, ensure that the tab on the ring is facing
in towards the rear of the unit.
6. Install one (1) rail beauty ring (715-4031-XX)
onto both the left and right rails. Ensure that the
small cutout on the bottom of the ring is facing
forward to the front of the machine.

Page 4
7. Install the upper handrail assembly (715-4137-
XX) onto the mast and the left and right rails,
then use 5/32” allen key to secure the upper
handrail to the rails using four (4) pieces of the
1/4” x 3/8” button head cap screw (110-0506).
8. Secure the upper handrail to the mast using four
(4) pieces each of the M8 x 16mm button head
cap screw (740-4588) and M8 at washer (731-
0561).
9. Use a 1/4” allen key to fully tighten the hardware
from Steps 1-3.
10. Install the motor shroud(020-7034-XX), left side
deck cover(715-3959-XX), and right side deck
cover (715-3862-XX) onto the frame, then use a
#2 phillips screwdriver to secure the shrouds to
the frame using four (4) pieces of the 10-24 x 3/4”
pan head machine screw (110-3450).
11. Use a #2 phillips screwdriver to nish securing
the motor shroud to the frame using two (2)
pieces of the 10-24 x 3/4” pan head machine
screw, then slide the motor shroud cap (020-
7232-XX) into place. Finally, install the mast
grommet (140-3428) ensuring a tight seat
between the mast, motor shroud, and motor
shroud cap.

Page 5
12. Use a #2 phillips screwdriver to secure the back
console shroud (020-7460-XX) to the console
weldment using ten (10) pieces each of the #8-18
x 3/4” screw (110-3402) and M4 washer (120-
3307).
13. Refer to the documentation contained inside the
console box in order to connect the console to
the unit.
NOTE: Depending on which console was purchased,
the install instructions could dier.
14. Use a #2 phillips screwdriver to secure the
console front (701-0210-XX) to the back shroud
using ten (10) pieces of the #8-18 x 3/4”screw.
15. Plug the power cable into the power inlet on
the bottom of the machine, then route the cable
through the power cord retention brackets and
tighten with a #2 phillips screwdriver to secure
the cord.

Page 6
The Support website provides a wealth of resources to help you get the best experience from your
unit. It is important to check the website periodically for Owner’s Manual and Installation Instruc-
tions, Service Bulletins, and other information. The resources include:
• Contact number and email for Technical Support
Go to https://support.corehandf.com/ for support information and information on all
Startrac products.
• Warranty information is available at: https://corehandf.com/warranty
• Updated Owner’s Manual, Assembly Manual, Service Manual, Service Bulletins,
Instructional Videos, and other information are at: https://support.corehandf.com/8TRX
Contact Information
CORE HEALTH & FITNESS
4400 NE 77th Avenue, Suite 300
Vancouver, WA 98662
Telephone: [phone]
http://www.corehandf.com
Customer Support
Contact your local distributor, or Core Health &
Fitness directly at: 1-800-503-1221
[e-mail]
Please supply the serial number of your unit and the date of purchase when you call. Use the space
in the boxes below to write down this information.
Serial Number
Date of Purchase
You may download the latest version of the Installation Guide, as well as view instructional videos,
by visiting the support website at:
https://support.corehandf.com/8TRX
SUPPORT AND SERVICE

© 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8379, REV C
