Universal Charge & Sync Cabinet for Tablets/iPads®
- 10 Slot Charging Station with Lock and Fan
ST10CSU2A
* This page is an addendum to the warning
label found on the product.
The Warning Label (250V/5A) is required to satisfy
a Regulatory Requirement for maximum input
power source availability, due to the internal,
replaceable, protection fuse implementation.
This version of product has been congured
to accommodate a standard North American
60Hz; 115V AC, 15A power source line cord.

Manual Revision: 04/24/2015
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Universal Charge & Sync Cabinet for Tablets/iPads®
- 10 Slot Charging Station with Lock and Fan
*actual product may vary from photos
ST10CSU2A

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s
authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
Product Diagram ....................................................................................2
Front View .................................................................................................................................................... 2
Rear View...................................................................................................................................................... 2
LED Indicators............................................................................................................................................. 3
Charge / Sync Toggle Button ................................................................................................................ 3
Installation ..............................................................................................3
Operation ................................................................................................5
Charge Mode .............................................................................................................................................. 5
Sync Mode ................................................................................................................................................... 5
Security and Surface-Mounting...........................................................5
Security Bracket......................................................................................................................................... 5
Surface-Mounting Method 1: ............................................................................................................... 5
Surface-Mounting Method 2: ............................................................................................................... 6
Stacking Multiple Units.........................................................................6
Specications..........................................................................................8
Technical Support ..................................................................................9
Warranty Information............................................................................9

Instruction Manual
1
Introduction
Packaging Contents
• 1x Charge & Sync Cabinet
• 1x USB A – B Cable (4ft)
• 2x Keys
• 1x Desk Mount Bracket (w/ Screws)
• 4x Stacking Screws
• 1x Power Cord - North American (6ft)
• 1x Instruction Manual
System Requirements
• Available AC electrical outlet
• USB-enabled host computer (for syncing purposes)
• USB cable for each tablet device connected

Instruction Manual
2
Product Diagram
Front View
1. Charge and Sync Toggle Button
2. USB A Ports
3. LED Status Lights x10
4. Slots for Tablets x10
5. Adjustable Trays with
Cable Management grooves
6. Slide-In Door
Rear View
1. Power Connector
2. Power Switch
3. USB B Host Port
4. Fan
5. Slide-Out Bracket for Cable Locks
6. Slide-Out Bracket for Surface
Mounting (Lock Mechanism for
separate Desk-Mount Bracket)
1
2
3
3
4
4
5
5
6
61
2

Instruction Manual
3
LED Indicators
LED Status Indication
O No device is connected to the
corresponding USB port
Red Connected device is charging
Green Connected device is charged - charging
complete
Green and Red Flashing Connected device is in sync mode – sync in
process with host computer
Charge / Sync Toggle Button
Charge Mode - Button is in the “up”
position (sync disabled)
Sync Mode - Button is in the “down”
position
Installation
1. For each tablet to be connected to the ST10CSU2A, rst connect your tablet
device(s) directly to your host computer to ensure the computer detects and installs
the device drivers to your host operating system.
2. Place the ST10CSU2A on a at surface, and ensure the Power Switch is set to the
“O” position.
3. Connect the provided Power Cord into the power connector on the rear of the
ST10CSU2A, then connect the Power Cord the to an available AC electrical outlet.
4. Connect your tablet device USB cable(s) (eg: Micro USB cable, Lightning cable, 30-
Pin dock connector, etc.) into the USB Ports on the ST10CSU2A as desired.
5. Insert your tablet devices into the slots on the ST10CSU2A, and then connect the
tablets connector to the USB cables from step #4. The provided trays have grooves
for cable management, and can be adjusted to dierent heights as desired.
Note: The 9 provided adjustable trays can positioned at dierent heights depending
on the size/thickness of your connected tablets. Adjust the trays to the desired height
prior to inserting your tablet devices into the ST10CSU2A.

Instruction Manual
4
6. Connect the provided USB A – B Cable from the USB Host Port on the rear of the
ST10CSU2A, to a USB A Port on your host computer (for sync capabilities).
7. Switch the Power Switch on the rear of the unit to the “On” position.

Instruction Manual
5
Operation
After following the previous Installation instructions, the ST10CSU2A can be used in
“Charge” or “Sync” operating modes.
Charge Mode
Connected tablet devices will charge. Sync capabilities are disabled and you cannot
sync your tablet device with your host computer.
1. Toggle/push the Charge and Sync Button inside the ST10CSU2A, ensure the button
is in the “up” position to enable charge mode (sync is then disabled).
Sync Mode
Connected tablet devices will sync with your host computer.
1. Toggle/push the Charge and Sync Button inside the ST10CSU2A, ensure the button
is in the “down” position to enable sync mode.
Note: Most devices will still provide some level of charge capabilities to your
connected tablet devices while in sync mode, however, some devices cannot
simultaneously charge and sync. It is recommended you switch back to charge mode
once your syncing tasks are completed to continue to provide charge capabilities to
your connected devices.
Security and Surface-Mounting
Follow the below procedures for attaching a security cable, or for securing the
ST10CSU2A to a surface.
Note: Do not attempt to secure or mount the ST10CSU2A while your tablet devices
are connected or stored inside. Ensure the Power Switch is set to the“O” position and
remove the Power Cord from the ST10CSU2A.
Security Bracket
The ST10CSU2A features a slide-out Security Bracket on the rear upper-center position
of the unit. This bracket can be used with cable locks to secure the ST10CSU2A as
desired.
Surface-Mounting Method 1:
The ST10CSU2A features a slide-out Surface Mounting bracket on the rear lower-center
position of the unit. This bracket can be used with the provided screws to secure the
ST10CSU2A to a desk surface. Pull the bracket outward, insert the screws, and secure
the unit to a desk surface as desired.

Instruction Manual
6
Surface-Mounting Method 2:
The ST10CSU2A also includes a separate Desk Mount Bracket.
1. Secure the Desk Mount Bracket to a surface as desired using the included screws.
2. Align the bottom of the ST10CSU2A over the secured bracket, and gently slide the
bracket into the indent on the bottom of the ST10CSU2A.
3. Once in position, the integrated bracket on the rear-lower center position of the
ST10CSU2A (Mentioned in Method 1) can be pushed inward, locking the Desk
Mount Bracket rmly into place with the ST10CSU2A.
4. Attach a lock to the integrated bracket by looping it through the hole. This prevents
the bracket from sliding backward, ensuring the bottom Desk Mount Bracket
remains in a locked position and attached to the ST10CSU2A.
5. For easy removal, disconnect your lock, pull the integrated bracket outward, and the
Desk Mount Bracket will become dislodged from the bottom of the ST10CSU2A.
Stacking Multiple Units
The ST10CSU2A includes 4x Stacking Screws, which allow you to horizontally or
vertically stack multiple units together.
Note: Do not attempt to stack the ST10CSU2A while your tablet devices are connected
or stored inside. Ensure the Power Switch is set to the “O” position and remove the
Power Cord from the ST10CSU2A.
1. Gently lift and remove the gray protective layer on the top surface of the

Instruction Manual
7
ST10CSU2A.
2. Align the 2x ST10CSU2A units either horizontally or vertically, top to bottom.
3. Align the 4 pilot holes on the top and bottom of the 2x ST10CSU2A.
4. Insert the 4 provided Stacking Screws through the bottom of one ST10CSU2A, and
using a screwdriver, rmly secure the screws to the top of the 2nd ST10CSU2A.

Instruction Manual
8
Specications
Compatibility USB Battery Charging Specication Rev. 1.2
Storage Capacity 10/8/6 tablet devices (adjustable trays) -
Apple® iPad® or other tablets
Dimensions (W x D x H) 400mm x 350mm x 430mm
Weight Net Weight: 15.6 kg
LED Indicators 10
Voltage Input: 110/220V, 50/60Hz
Output: DC 5V, 2.3A for each USB port

Instruction Manual
9
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
