StarTech.com DK31C2DHSPD User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: February 18, 2021
Product Diagram (DK31C2DHSPD and DK31C2DHSPDUE)
Front View
Port Specications and Installation
1Power LED Indicator • Solid White LED indicates the Docking Station is
receiving power and is powered ON
23.5mm Audio Port • Connect an Audio Device
• 4 Position Audio Jack for Headset use
3USB-C Charging Port
• SuperSpeed USB 10Gbps (USB 3.2 Gen 2)
• Supports charging of up to 5V/3A
• Connect the Docking Station to a SuperSpeed USB
10Gbps Peripheral or Storage Device (e.g. ash
drive), using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 2) Cable
4USB-C Charging Port
• SuperSpeed USB 10Gbps (USB 3.2 Gen 2)
• USB Power Deliver (PD) 3.0
• Supports charging of up to 5V/3A
• Connect the Docking Station to a SuperSpeed USB
10Gbps Peripheral or Storage Device (e.g. ash
drive), using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 2) Cable
5SD Card Slot
• Secure Digital (SD) 4.0 UHS-II, SD 3.0, 2.0, 1.1, and 1.0
compatibility
• Push an SD Card, label side up, into the SD Card Slot
until it clicks into place
Note: The Host Computer’s Operating System (OS)
will automatically detect the SD Card and install the
required driver software.
• Push then pull the SD Card to remove
USB-C™ 10Gbps Gen 2 Triple Monitor Docking Station - 2x DP + HDMI - 100W PD - DP 1.4 MST
Left Side View
Port Specications and Installation
6Power Button
• Powered ON by default
• Press and release the Power Button to power OFF the
Docking Station
Right Side View
Port Specications and Installation
7Nano Lock Slot • Secure the Docking Station to a stationary object
8Lock Slot • Secure the Docking Station to a stationary object
Rear View
Port Specications and Installation
9USB-A Device Ports
• SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
• Connect the Docking Station to two SuperSpeed
USB 5Gbps Peripherals or Storage Devices (e.g. ash
drives), using SuperSpeed USB 5Gbps (USB 3.2
Gen 1) Cables
10 USB-A Device Ports
• USB 2.0
• Minimum 2.5W (5V/0.5A) power output
• Connect the Docking Station to two USB-A
Peripherals and/or Storage Devices (e.g. ash drives),
using USB Cables
234
15
6
7 8
913 15
14
10 11 12

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void
the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Crescent
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Road
Brackmills,
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Package Contents
• USB-C Dock x 1
• Power Cable (NA/JP & ANZ) x 2
• USB-C Cable (1 m) x 1
• Quick-Start Guide x 1
Requirements
For the latest requirements, please visit:
www.startech.com/DK31C2DHSPD or www.startech.com/DK31C2DHSPDUE
• Host Computer
• USB PD Support
• USB-C Port
• DP alt mode
Installation
Notes: Installation is automatic for all modern Operating Systems. If the drivers do
not auto-install, please visit www.startech.com/DK31C2DHSPD to locate the latest
drivers.
Operation
RJ45 Port LED Indicators
LED Color Status Indication
Green Solid • Link speed is 1000Mbps
Amber Solid • Link speed is 100Mbps
None O • Link speed is 10Mbps
11 RJ45 Port
• 10/100/1000 Mbps
• Connect the Docking Station to a Network Device,
using a Network Cable
12 Video 1-2 DisplayPort
Ports
• DP 1.4
• HDCP 1.4 and HDCP 2.2
• High Dynamic Range (HDR) support
• DSC support
• Video 1 (Left) and Video 2 (Right)
• Connect the Docking Station to two DisplayPort
Enabled Display Devices, using DisplayPort Cables
13 Video 3 HDMI Port
• HDMI 2.0a version
• YCbCr 4:4:4, 4:2:2 and 4:2:0 chroma subsampling
• HDCP 1.4 and HDCP 2.2 compliant
• High Dynamic Range (HDR) support
• Connect the Docking Station to an HDMI Enabled
Display Device, using an HDMI Cable
14 USB-C Host Port
• USB 3.1 Gen 2
• USB Power Delivery 3.0 (PD 3.0)
• Capability of charging the Host Computer up to 100W
• USB Power Delivery (PD) pass-through:
1. Connect the Docking Station to a Power Source,
using the Universal Power Adapter
2. Connect the Docking Station to the Host Laptop,
using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 1) Cable
15 DC 20V Port • Connect the Docking Station to a Power Source,
using the Universal Power Adapter
