StarTech.com 110VDSLEXT User manual

VDSL Ethernet LAN Extender
10/100 VDSL Ethernet
LAN Extender Kit
110VDSLEXT
110VDSLEXTGB
110VDSLEXTEU
Instruction Manual

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an en-
dorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this doc-
ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,
service marks, and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.

i
Table of Contents
Installation....................................................................... 1
Operation......................................................................... 1
LED Displays...........................................................................1
DIP Switch Settings.................................................................2
Connector Architecture ...............................................................5
Specifications.................................................................. 6
Technical Support........................................................... 7
Warranty Information...................................................... 7

1
Installation
Package Contents
1 x Extender•
1 x Receiver•
2 x RJ-45 to VDSL Cable•
1 x Instruction Manual•
2 x Power Adapter•
Hardware Installation
To install the 110VDSLEXT, all four of the DIP switches must be in1.
the upwards (OFF) position.
Plug the DC power adapter into the port on the rear panel of the2.
unit, and then into an available AC outlet.
Plug in an RJ45 Ethernet cable to the RJ45 port on the 110VD-3.
SLEXT.
Plug a phone cable into the VDSL port of the 110VDSLEXT.4.
Operation
LED Displays
LAN LED Display
LED Blinking ON OFF
1Activity Link up Link down
2100 Mbps 10 Mbps
3Full duplex Half duplex

2
VDSL LED Display
DIP Switch Settings
The 110VDSLEXT has a 4-position DIP switch for configuration of
Side, Channel, Rate Limit, and SNR.
Pin 1 - CO, CPE Switch
OFF: If Pin 1 is in the OFF position, the 110VDSLEXT will operate in
Central Office (CO) mode.
ON: If Pin 1 is in the ON position, the 110VDSLEXT will operate in
Customer Premise Equipment (CPE) mode.
Pin 2 - Interleave Noise Protection
LED Blinking ON OFF
1Activity Device
Power On
Device Power Off
2-CPE Mode CO Mode
3Slowly: Idle
Quickly: Training Linked Offline

3
OFF: If Pin 2 is in the OFF position, the 110VDSLEXT will operate in
Interleave mode, with communication protection for up to 250ms of
impulse noise with latency less than 6 ms
ON: If Pin 2 is in the ON position, the 110VDSLEXT will operate in Fast
mode, with direct data transmissions having less than 1ms of latency.
Pin 3 - Band Plan
OFF: If Pin 3 is in the OFF position, the 110VDSLEXT will operate in
Symmetric mode, with both downstream and upstream transmissions
operating on the G.997 band plan.
ON: If Pin 3 is in the ON position, the 110VDSLEXT will operate in
Asymmetric mode, with asymmetric short range transmissions operat-
ing at the highest available line rate.

4
Pin 4 - General Protection
OFF: If Pin 4 is in the OFF position, the 110VDSLEXT will operate with
a SNR ratio up to 9 dB.

5
ON: If Pin 4 is in the ON position, the 110VDSLEXT will operate with a
SNR ratio of 6 dB.
Connector Architecture
Ethernet Port
VDSL Port
Pin Number Assignment (MDI-X)
1RX+; Receive data +
2RX-; Receive data -
3TX+; Transmit data +
4Not used
5Not used
6TX-; Transmit Data -
7Not used
8Not used
Pin Number Assignment (MDI-X)
1Not used
2Not used
3Not used
4ANALOG Input/Output
5ANALOG Input/Output
6Not used
7Not used
8Not used

6
Specications
LAN Interface
RJ-45 connector
Complies with IEEE
802.3/802.3u/802.3x
10/100 Base-T Auto-Negotiation,
Auto-MDI/MDI-X
VDSL Interface
RJ-45 connector
DMT Encoding
Complies with ITU-T
G993.1/993.2
On-board surge protection
DIP Switch 4 position
LED
LAN: ACT/LNK, 10/100 Mbps,
Half/Full Duplex
VDSL: Power On/Off, CO/CPE,
Idle/Trained/Link
Power Supply DC single 12 Volt over 35mm DC
jack
Power Consumption 4.2 Watt maximum
Dimensions 95.5 x 69.4 x 22mm
