StarTech.com WIFI2HD2 User manual

Manual Revision: 05/15/2013
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
WIFI2HD2
WiFi to HDMI® Wireless Video Extender with Audio
*actual product may vary from photos

Instruction Manual 2
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and
Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual i
Table of Contents
Introduction.................................................................................................. 1
Packaging Contents.......................................................................................................................................1
System Requirements ...................................................................................................................................1
Front View..........................................................................................................................................................2
Rear View............................................................................................................................................................2
Installation .................................................................................................... 3
Software and Driver Installation................................................................................................................3
Hardware Installation ....................................................................................................................................4
Wireless Network Conguration ...............................................................................................................5
How to Use .................................................................................................... 6
Advanced Settings .........................................................................................................................................8
Web Interface Conguration......................................................................................................................9
UPnP Media Streaming.................................................................................................................................11
Troubleshooting........................................................................................... 12
UPnP Supported Formats ........................................................................... 18
Specications................................................................................................ 21
Technical Support ........................................................................................ 22
Warranty Information.................................................................................. 22

Instruction Manual 1
Introduction
Packaging Contents
• 1 x WiFi to HDMI Converter
• 1 x Universal Power Adapter
• 3 x Power Adapter Plugs (NA/ UK/ EU)
• 1 x Installation CD
• 1 x Instruction Manual
System Requirements
• CPU: 2nd Gen Intel® Core™ or better
• RAM: 2GB DDR2-800 or better
• IEEE 802.11N or G wireless network
• HDMI enabled display device (i.e. monitor, projector, HDTV, etc.) with HDMI cable
• Available AC electrical outlet
• Microsoft® Windows® 8, 7, Vista, XP (32/64-bit)

Instruction Manual 2
Front View
Rear View
USB connector Power Button
Power LED
3.5mm Audio connector
(Output) RJ45 Ethernet
connector
DC Power
connector HDMI connector (Output)
HDMI

Instruction Manual 3
Installation
Software and Driver Installation
1. Insert the included installation CD into the computer’s CD/DVD drive.
2. If AutoPlay runs, choose the option to browse/open the folder. Otherwise you
can access the les on the CD by going into My Computer and double-clicking
the CD/DVD drive.
*photos/screenshots for reference only
3. Run the PC2TV application to begin the driver/software installation wizard.
4. Proceed through the installation wizard until the benchmark application runs.
5. The Benchmark application will test the capabilities/performance of the
computer system to run the video extender software. It will provide a rating
out of 5 stars (see below for description). Click the “Analysis” button to begin.

Instruction Manual 4
Rating Description
1 Star CPU and graphics performance are below minimum recommended levels.
2 Star Music and Photo viewing and web surng are acceptable. Video playback at a very low
screen resolution may be possible.
3 Star Good Music playback and Photo viewing quality. Video playback may still lag.
4 Star Video playback should be smooth.
5 Star Best performance for video playback and all features.
6. After the benchmark is complete, reboot the computer.
7. After the computer has rebooted, there will be an icon for PC2TV that will launch
the software for the video extender.
Hardware Installation
1. Connect a male/male HDMI cable from the rear panel of the video extender
to the remote display.
2. Connect the included power adapter from an electrical outlet to the
video extender.
OPTIONAL: Connect a USB peripheral, such as keyboard/mouse, to the USB
hub port on the wireless video extender.
3. Turn on the remote display.
4. Turn on the video extender by pressing the power button on the front panel.
5. Wait at least 60 seconds for the remote display to show the ready screen from
the video extender.
6. You can now connect to the video extender over WiFi.
(SSID: WIFI2HD2)

Instruction Manual 5
Wireless Network Conguration
The video extender can operate in two wireless modes: Wireless Access Point
mode (AP) or Client Mode (STA).
• AP Mode (default): The video extender will act as a wireless access point (i.e.
wireless router) for other wireless enabled computers. This mode is useful if
there is no existing wireless network where the video extender will be used, or
you do not wish to have the video extender on your main network.
• Client Mode: The video extender will act as a regular wireless client and connect
to an existing wireless network. This mode is useful if there is an existing wireless
access point (i.e. wireless router) already setup or if the computers need Internet
access at the same time.
NOTE: The wireless AP must have DHCP enabled.
To set the video extender into Client mode:
1. By default, the wireless video extender will be set to AP Mode. Check your
computer’s wireless network settings for the network called“WIFI2HD2”.
2. Connect to the WIFI2HD2 network. No encryption/security should be
enabled yet.
3. Once connected, run the PC2TV application from the desktop icon.
4. Open the “Setting”menu and then click on the Conguration button.

Instruction Manual 6
5. From the Conguration window, click on the “STA Mode” tab then click the
“Enable” option. Enter the required information for connecting to your existing
wireless network (i.e. SSID, encryption type and network key). Click the SAVE
button once complete.
NOTE: Client/STA mode does not support static IP addresses. The wireless AP
must have DHCP enabled.
OPTIONAL: If connecting multiple wireless video adapters to this network, be
sure to set a unique Device Name for each one for easy identication under the
“Device” tab.
6. Restart the wireless video adapter by unplugging and reconnecting the power.
How to Use
NOTE: It is recommended to turn o the screensaver on your computer when
using this product
1. Double-click the PC2TV icon from the desktop.

Instruction Manual 7
2. At this point, a security alert may pop up on your system, please check to allow
the device to communicate on both Private and Public networks.
3. Once the PC2TV application is ready to connect to the wireless video extender,
the “Play” button will appear.
4. Clicking the “Play” button will automatically begin streaming the computer
desktop to the remote display.
NOTE: Additional users may connect to the wireless video extender at any time.
This will cause the currently connected user to be automatically disconnected.
5. To stop the video streaming, click “Play” once more on the PC2TV application.

Instruction Manual 8
Advanced Settings
Advanced Settings can be accessed by clicking on the “Setting”button at the
bottom of the PC2TV application window. Click the “Apply” button to set changes.
• Device List: Displays the name of the detected wireless video extender(s). If
multiple are listed, double-click the one you wish to connect to.
• Optimized For: Optimizes the streaming video based on what you will be doing
on the host computer. By default, this is set for“PC”, which should be used when
running regular applications, such as web browsers or spreadsheets. Setting the
slider bar in the middle should be used when viewing video/movies. If video
performance is still not ideal, the slider can be set all the way to “Movie”.
• PC Audio: By default, when connected to the wireless video extender, audio on
the host computer is disabled. Audio will instead be streamed to the wireless
video extender only. By enabling this option, audio on the host computer will be
restored, while still being streamed to the wireless video adapter.
• Virtual Extend: Click the icon above the text to create an extended desktop
screen that will be streamed to the extender instead of the main desktop screen.
Click the text “Virtual Extend” if problems arise while streaming the extended
desktop. NOTE: Compatible with Windows 7/8 only
• Auto Play: Automatically starts video streaming once the PC2TV application is
launched and the device is detected. Click the icon to enable/disable.
• Auto Start: Automatically starts the PC2TV application on Windows startup.
Click the icon to enable/disable.

Instruction Manual 9
Web Interface Conguration
The web interface for the wireless display adapter can be accessed by clicking the
Conguration button in the PC2TV Advanced Setting window.
The web interface is divided into several sections that control dierent settings for
the wireless display adapter.
Device: Set the name/identier for the wireless video extender, for easy
identication if multiple extenders are present.

Instruction Manual 10
Overscan: Adjust the overall width and height of the streaming image to better t
on the remote display.
AP Mode/ STA Mode: Select between AP Mode and Client Mode (STA Mode) and
set any network settings required for each.

Instruction Manual 11
UPnP Media Streaming
The WIFI2HD2 device is designed to be a UPnP-DMR (Digital Media Renderer) so
you are able to stream contents from a PC (Windows 7/8 Media Sharing), Mac,
smart phone, and Tablet-PC to your TV through this device.
Usage of UPnP in Windows 7/8
Before streaming a le to the DMR of WIFI2HD2 device using Windows 7/8, you
have to connect the device with your PC and then turn on the media streaming rst.
Note: Every time the device is disconnected with the PC, you will need to perform
these steps again before streaming a le to the DMR through Windows 7/8.
1. Click the “Share Media” icon under
“PC2TV” from “All Programs” ->
”VideoHome”.
2. Click “Turn on media streaming”to allow
media streaming from your PC. The
WIFI2HD2 device’s default DMR name
is “WIFI2HD2”.
3. After you’ve turned on media sharing, open the folder with the media le(s)
you wish to play.
4. Right-click on the le and select “Play to”, then select the WIFI2HD2 device.

Instruction Manual 12
Troubleshooting
The WIFI2HD2 software (PC2TV) must rst be “allowed”in any system rewalls
before the device can function. Steps to“allow” the software in Windows Firewall
are listed below. For additional support, or support for dierent rewalls, please
contact the respective rewall developer.
1. Open Windows Firewall by selecting: Windows 8: Control Panel –System and
Security –Windows Firewall from the Windows 8 Metro. Windows 7/Vista: Start: –
Control Panel –System and Security –Windows Firewall for Windows 7/Vista/XP.
2. In the left hand Panel of the Windows Firewall select “Allow a Program or
feature through Windows Firewall”.

Instruction Manual 13
3. Search for PC2TV under the heading “Allowed Programs and features:”. If this
program is listed please skip to step 5. If the program is not listed click the “Allow
another program…” button.
4. Locate and select PC2TV in the list of programs, and click the “Add” button.

Instruction Manual 14
5. Ensure that a check mark is placed in the box next to “PC2TV”, and under the
“Home/Work (Private)”, and “Public” sections for PC2TV. Then click “OK”.
6. Your Windows Firewall is now congured to allow PC2TV.

Instruction Manual 15
NetDispLib error pops up when launching the PC2TV application.
The SSDP Discovery service may be disabled, or failed to start.
1. To check the SSDP Discovery service, from the main desktop, right-click on
Computer, then select “Manage”. In the new Computer Management window,
select “Service” under the “Service and Applications”heading.
2. Locate SSDP Discovery in the list of services and make sure that it is set to start
Automatically. Then make sure that the service is started.
3. Go into the Firewall (by selecting: Windows 8: Control Panel –System and
Security –Windows Firewall from the Windows 8 Metro. Windows 7/Vista:
Start: – Control Panel –System and Security) and allow for Network Discovery for
both Private and Public networks. This setting can be found via “Control Panel”,
“Windows Firewall”, then “Allowed Programs”.

Instruction Manual 16
Poor quality video playback/ choppy video
Make sure the optimization for the PC2TV application is set appropriately in the
Advanced Setting menu. For video playback, the slider bar should set in the
middle, and all the way to “Movie”if problems are still encountered. Click the
“Apply” button to conrm the setting.
AP Mode: If the “Channel” setting in the web interface is set for Auto, select a
permanent channel.
PC Video / Resolution Settings
1. Windows Vista/ 7: If using an Aero® theme, change the desktop theme
to one under the “Basic and High
Contrast” section.
2. Change the screen resolution size to a lower setting. Also make sure the
resolution is one of the supported sizes.
3. Update the drivers for the computer’s video card.

Instruction Manual 17
Cannot Achieve 1080p Video Resolution
1080p video resolution is only supported on Intel® Family Graphics Chipsets. If
using a dierent type of Graphics Card default video resolution will be limited to
720p. In a dual graphics card conguration (i.e. Intel and AMD, or Intel and NVidia),
the non-Intel graphics card can be disabled in the Device Manager to achieve
1080p resolution.
For assistance with disabling graphics adapters, please contact your systems
manufacturer.
No Sound
The audio devices on your PC.
1. Open the “Sound” properties window from the “Control Panel”.
2. The “Speakers”on the “Playback” tab should be “WonderMedia SmartStream Audio”.
3. If your PC speakers are currently selected instead, select the WonderMedia
speakers and click “OK” or “Apply” to save the setting.
4. Close your media player and restart it.
