StarTech.com SV565UTP User manual

KVM Console Extender over
Cat5 UTP
USB PS/2 KVM Console
Extender over Cat5 UTP
SV565UTP
Instruction Manual

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an en-
dorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this doc-
ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,
service marks, and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.

i
Table of Contents
Introduction..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Installation....................................................................... 1
Preparing Your Site......................................................................2
Installing the Host Unit.................................................................3
Installing the Remote Unit ...........................................................4
Driver Installation.........................................................................5
Video Compensation ...................................................... 5
Using the SV565UTP KVM Extender.............................. 6
Using the Host Unit......................................................................6
Using the Remote Unit ................................................................9
Specifications.................................................................. 12
RJ-45 Connector Pinout ................................................. 12
Technical Support........................................................... 13
Warranty Information...................................................... 13

1
Introduction
Packaging Contents
1 x SV565UTP Host Unit•
1 x SV565UTP Remote Unit•
1 x Instruction Manual•
2 x Power adapter•
2 x Set of rubber mounting feet•
System Requirements
Integrated KVM cable for the host and remote computers (not•
provided) StarTech.com ID: SVECONx (PS/2), SVECONUSx (USB)
Standard 104-key PS/2 keyboard•
Standard 3-button PS/2 mouse•
VGA capable display•
Installation
This product is composed of two different units: the Host Unit and
the Remote Unit. The Host Unit takes input controls from a computer
(using a PS/2 or USB integrated KVM cable) and allows access to
them via the Remote Unit over Category 5 UTP cable. The remote
computer also connects to the Remote Unit using an integrated KVM
cable (again, either PS/2 or USB) and allows the user at the remote
site to control that computer or the host computer using keyboard
hotkey commands.
A PS/2 mouse and keyboard and a VGA monitor are connected to the
Remote Unit (the console). You can also connect console peripherals
to the Host Unit if you need direct as well as remote access to that
computer.

2
Preparing Your Site
Before you can install the the product, you need to prepare your site.
Determine where the host computer will be located and set up the1.
computer.
Determine where the console devices (mouse, keyboard, monitor)2.
will be located and place them appropriately.
If you are using surface cabling, ensure you have enough Category3.
5 unshielded twisted pair (UTP) network cabling to connect the Host
Unit to the Remote Unit’s location, and that each end is terminated
with a RJ-45 connector.
OR
If you are using premises cabling, ensure that the Category 54.
unshielded twisted pair (UTP) network cabling between the Host
Unit and the Remote Unit has been properly terminated in a wall
outlet in each location and there is a patch cable long enough
to connect the Remote Unit and the Host Unit to their respective
outlets.

3
Installing the Host Unit
Place the Host Unit near the computer.1.
Switch off the computer and disconnect any existing VGA and input2.
connections.
Using a StarTech.com integrated KVM cable (see page 8 for part3.
numbers), connect the end of the cable that has two (USB) or three
(PS/2) connectors to the VGA Out connector and the USB or mouse
and keyboard PS/2 connectors on the computer as appropriate. (The
PS/2 version of the cable is color-coded.) Connect the opposite end
of the cable with a single connector to the gray-coded connector
marked COMPUTER on the Host Unit of the KVM extender.
If you wish to have console access to the host computer, connect a4.
PS/2 mouse, keyboard, and VGA monitor to the indicators marked
as CONSOLE on the Host Unit.
Connect the UTP cable connection for Remote Unit to the5.
NETWORK RJ-45 connector on the Host Unit. Connect the opposite
end to a terminated wall outlet (if you are using premises cabling).
PS/2 keyboard/
mouse and VGA
console
Host Computer
(KVM cable)
Power
Connector
UTP Cable

4
Installing the Remote Unit
Place the Remote Unit near the computer.1.
Switch off the computer and disconnect any existing VGA and input2.
connections.
Using a StarTech.com integrated KVM cable (see page 8 for part3.
numbers), connect the end of the cable that has two (USB) or three
(PS/2) connectors to the VGA Out connector and the USB or mouse
and keyboard PS/2 connectors on the computer as appropriate. (The
PS/2 version of the cable is color-coded.) Connect the opposite end
of the cable with a single connector to the gray-coded connector
marked COMPUTER on the Remote Unit of the KVM extender.
Connect a PS/2 mouse, keyboard, and VGA monitor to the indicators4.
marked as CONSOLE on the Remote Unit.
Connect the UTP cable connection for Remote Unit to the5.
NETWORK RJ-45 connector on the Remote Unit. Connect the
opposite end to a terminated wall outlet (if using premises cabling).
CAUTION: The UTP network cables that connect the Host and Remote
PS/2 keyboard/
mouse and VGA
console
Remote
Computer
(KVM cable) Power
Connector
UTP Cable

5
Units carry electrical current and should not be plugged in to other
devices, as they may cause damage. We strongly recommend marking
the cables you are using with this product at both locations for easy
identification.
Driver Installation
No driver installation is required as the SV565UTP uses standard
keyboard/mouse drivers.
Video Compensation
Video Compensation allows the user to adjust the equalization on the
Remote Unit to optimize video performance based on the length of
cable being used, as well as other factors that may affect . There are
five segments of various lengths of CAT 5 cables from which to chose;
to achieve the best visibility, please refer to the section titled Keyboard
Shortcut Command Sequences, to adjust the video compensation.
First, note the length of CAT 5 cable you used. Then, use the hotkeys
to adjust the video compensation accordingly. You can use the hotkey
sequence as outlined in the section titled Keyboard Shortcut Command
Sequences.

6
Using the SV565UTP KVM Extender
This section details how to use your KVM extender at both the host and
remote locations.
Using the Host Unit
The Host Unit performs two functions: it allows a user at the Remote
Unit to assume control of the computer on the Host Unit (Computer A),
and it also permits the user at the Host Unit to use Computer A. It has
three modes that control which user may access the system at a given
time: Auto (the KVM extender looks for keyboard or mouse activity from
both Host and Remote and automatically accepts input from the active
console), Local (only the user seated at the Host Unit can access the
system), and Remote (only the user at the Remote Unit can access
Computer A).
You can use either keyboard shortcuts (if there is a keyboard and
mouse attached) or the mode switch on the top of the Host Unit to
control which user has access to Computer A. By default, the Host Unit
operates in Auto mode, and switches to the next mode in the sequence
each time the switch is pressed as follows:
Having a keyboard and mouse attached to the console ports on
the Host Unit is recommended since it offers access to a number of
extended features.
LED Indicators
Mode ‘A’ Indictor ‘B’ Indicator
Auto (Auto senses activity) Flashing Flashing
Local (User at Host Unit has control) ON OFF
Remote (User at Remote Unit has control) OFF ON
Local RemoteAuto

7
Keyboard Shortcut Command Sequences
Standard Hotkey Hotkey with
Compatibility Mode Description
[Ctrl] - [Ctrl] - [T] [Ctrl] - [Ctrl] - [T] Toggles control of Computer A between
Auto, Local, Remote modes
[Ctrl] - [Ctrl] - [Esc] [Ctrl] - [Ctrl] - [Esc] Cancels the hotkey sequence
[Ctrl] - [Ctrl] - [Alt]+[E] [Ctrl] - [Ctrl] - [Alt]+[E]
Enables (2 beeps) or disables (1 beep)
Compatibility Mode so that the KVM
extender will work with a KVM switch
that also uses a [Ctrl] hotkey sequence
[Ctrl] - [Ctrl] - [1] [Ctrl] - [Ctrl] - [E] - [1]
Local Mode: Allows the user at Host
Unit exclusive access to Computer A;
remote access from Remote Unit is
disabled
[Ctrl] - [Ctrl] - [2] [Ctrl] - [Ctrl] - [E] - [2]
Remote Mode: Allows the console
at Remote Unit exclusive access to
Computer A; access to Computer A from
the Host Unit is disabled
[Ctrl] - [Ctrl] - [3] [Ctrl] - [Ctrl] - [E] - [3] Auto Mode : Wait for console activity
[Ctrl] - [Ctrl] - [F3] [Ctrl] - [Ctrl] - [E] - [F3]
Sets the interval of inactivity in seconds
that the Host Unit will wait before
returning to Auto Mode
[Ctrl] - [Ctrl] - [F4] [Ctrl] - [Ctrl] - [E] - [F4] Adjusts the typematic rate for improved
keyboard responsiveness

8
[Ctrl] - [Ctrl] - [F6] [Ctrl] - [Ctrl] - [E] - [F6]
Privacy Setting:
A. Host Unit in Local mode ( LED B:
Off, LED A: On)
1 beep: Reset to Factory Default.
2/3 beeps: Disable the Host Unit video
output signal.
B. Host Unit in Auto mode ( LED A&B
flashes alternately)
1 beep: Reset to Factory Default.
2 beeps: Upon keyboard/mouse
activation, disables the Host Unit video
output temporarily. (Set for 5,15,30 or 60
second interval)
3 beeps: Upon keyboard/mouse
activation the Remote Unit or Host
Unit users can disable the output video
signal temporarily.
(The user can protect their privacy for
5,15,30,60 seconds)
[Ctrl] - [Ctrl] - [F12] Ctrl] - [Ctrl] - [E] - [F12] Resets PS/2 mouse synchronization
Beep Codes
Some of the keyboard command sequences you issue to the Host
Unit have multiple possible settings. The Unit will beep to indicate what
setting you have selected for the command you issued. (A short beep
followed by a long beep indicates an invalid command.)
[Ctrl] - [Ctrl] - [Alt]+[E] (Compatibility Mode)
1 beep: disabled
2 beeps: enabled
[Ctrl] - [Ctrl] - [F3] (Inactivity Interval for Auto Mode)
1 beep: 5 seconds
2 beeps: 15 seconds
3 beeps: 30 seconds
4 beeps: 60 seconds

9
[Ctrl] - [Ctrl] - [F4] (Typematic Rate)
1 beep: 6 characters/sec.
2 beeps: 12 characters/sec.
3 beeps: 20 characters/sec.
4 beeps: 30 characters/sec.
Note: Commands described in the [Key] - [Key] format are keys that
must be pressed in order on the keyboard. Commands described in the
[Key]+[Key] format must be pressed simultaneously.
Note: If the Num Lock, Caps Lock, and Scroll Lock lights are flashing in
unison on the keyboard, the other Unit has control of Computer A. You
will not be able to use the computer or issue commands until the other
unit has finished using the computer.
Note: If the Extender is operating in Compatability Mode ([Ctrl] - [Ctrl] -
[E] hotkey sequence), you must enter [Ctrl] - [Ctrl] - [E] - [E] to access
port E on the attached KVM switch.
Using the Remote Unit
Like the Host Unit, the Remote Unit performs two functions: it allows a
user at the Remote Unit to assume control of Computer A if the Host
Unit is set to Auto or Remote mode, and it also permits the user seated
at the Remote Unit to use a locally connected computer (Computer B)
as though the SV565UTP KVM extender was transparent.
You can use either keyboard shortcuts or the mode switch on the top
of the Remote Unit to alternate control between A and B. Unlike the
Host Unit, however, the switch on top of the Remote unit only offers two
selectable modes:
Local Remote

10
LED Indicators
Mode ‘A’ Indicator ‘B’ Indicator
Remote Access (Computer A) ON OFF
Local Access (Computer B) OFF ON
Keyboard Shortcut Command Sequences
Standard Hotkey Hotkey with Compatibility
Mode Description
[Ctrl] - [Ctrl] - [T] [Ctrl] - [Ctrl] - [T] Toggles console control between
Local Access and Remote Access
[Ctrl] - [Ctrl] - [Esc] [Ctrl] - [Ctrl] - [Esc] Cancels the hotkey sequence
[Ctrl] - [Ctrl] - [Alt]+[E] [Ctrl] - [Ctrl] - [Alt]+[E]
Enables (2 beeps) or disables (1
beep) Compatibility Mode so
that the KVM extender will work
with a KVM switch that also uses
a [Ctrl] hotkey sequence
[Ctrl] - [Ctrl] - [1] [Ctrl] - [Ctrl] - [E] - [1] Switches control to Computer B
[Ctrl] - [Ctrl] - [2] [Ctrl] - [Ctrl] - [E] - [2]
Switches control to Computer A
(input allowed only if the Host Unit
is in Remote or Auto mode)
[Ctrl] - [Ctrl] - [F2] [Ctrl] - [Ctrl] - [E] - [F2] Toggles console control between
Computer A and Computer B
[Ctrl] - [Ctrl] - [F4] [Ctrl] - [Ctrl] - [E] - [F4]
Adjusts the typematic rate
for improved keyboard
responsiveness ( PS/2 keyboard
only )
[Ctrl] - [Ctrl] - [F11] [Ctrl] - [Ctrl] - [E] - [F11]
Adjusts remote video quality
based on the length of UTP
cabling between the two
computers (available only when
switched to Computer A)
[Ctrl] - [Ctrl] - [F12] [Ctrl] - [Ctrl] - [E] - [F12] Resets PS/2 mouse
synchronization

11
Beep Codes
Some of the keyboard command sequences you issue to the Remote
Unit have multiple possible settings. The Unit will beep to indicate what
setting you have selected for the command you issued. (A short beep
followed by a long beep indicates an invalid command.)
[Ctrl] - [Ctrl] - [Alt]+[E] (Compatibility Mode)
1 beep: disabled
2 beeps: enabled
[Ctrl] - [Ctrl] - [F11] (Remote Image Quality Adjustment)
1 beep: 0 ~ 100 feet (0 ~ 30 meters) of UTP cable length
2 beeps: 100 ~ 200 feet (30 ~ 60 meters) of UTP cable length
3 beeps: 200 ~ 300 feet (60 ~ 90 meters) of UTP cable length
4 beeps: 300 ~ 400 feet (90 ~ 120 meters) of UTP cable length
5 beeps: 400 ~ 500 feet (120 ~ 150 meters) of UTP cable length
[Ctrl] - [Ctrl] - [F4] (Typematic Rate)
1 beep: 6 characters/sec.
2 beeps: 12 characters/sec.
3 beeps: 20 characters/sec.
4 beeps: 30 characters/sec.
Note: Commands described in the [Key] - [Key] format are keys that
must be pressed in order on the keyboard. Commands described in the
[Key]+[Key] format must be pressed simultaneously.
Note: If the Num Lock, Caps Lock, and Scroll Lock lights are flashing
in unison on the keyboard, the other Unit has control of Computer A.
You will not be able to use A until the other Unit releases access to that
computer.
Note: If the Extender is operating in Compatability Mode ([Ctrl] - [Ctrl] -
[E] hotkey sequence), you must enter [Ctrl] - [Ctrl] - [E] - [E] to access
port E on the attached KVM switch.

12
Specications
Connectors (Host Unit)
1 x DE-15 VGA video
2 x PS/2 keyboard/mouse
1 x RJ45 port
1 x DE-15 KVM cable port
Connectors (Remote Unit)
1 x DE-15 VGA video
2 x PS/2 keyboard/mouse
1 x RJ45 port
1 x DE-15 KVM cable port
Maximum Distance 150m/500ft
Maximum Video Resolution 1024x768
Power Adapter 9V DC, 600mA, center positive
Dimensions (per unit) 75.0mm x 155.0mm x 20.0mm
Weight (per unit) 299g
RJ-45 Connector Pinout
Pin Color Pair Function
1 White/Orange 2 T
2 Orange 2 R
3 White/Green 3 T
4 Blue 1 R
5 White/Blue 1 T
6 Green 3 R
7 White/Brown 4 T
8 Brown 4 R

13
Technical Support
StarTech.com’s lifetime technical support is an integral part of our com-
mit-ment to provide industry-leading solutions. If you ever need help
with your product, visit www.startech.com/support and access our com-
prehensive selection of online tools, documentation, and downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in
materials and workmanship for the periods noted, following the initial
date of purchase. During this period, the products may be returned for
repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not war-
rant its products from defects or damages arising from misuse, abuse,
alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com
USA LLP (or their officers, directors, employees or agents) for any dam-
ages (whether direct or indirect, special, punitive, incidental, consequen-
tial, or otherwise), loss of profits, loss of business, or any pecuniary loss,
arising out of or related to the use of the product exceed the actual price
paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limita-
tions or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-find easy” since 1985,
providing high quality solutions to a diverse IT and A/V customer
base that spans many channels, including government, education
and industrial facilities to name just a few. We offer an unmatched
selection of computer parts, cables, A/V products, KVM and Serv-
er Management solutions, serving a worldwide market through our
locations in the United States, Canada, the United Kingdom and
Taiwan.
Visit www.startech.com today for complete information about all
our products and to access exclusive interactive tools such as the
Cable Finder, Parts Finder and the KVM Reference Guide.
