StarTech.com USBthere USB204EXT User manual

USBthere - 4 Port 330 Foot (100 Meter) Powered USB Extender Extender
StarTech ID: USB204EXT
Boost the distance of your USB connection with the USBthere, a four-port USB extender from StarTech.com.
You’ll be able to place your USB devices up to 330 feet (100m) away from your computer, an incredible 20
times greater than normal USB length restrictions. The Local and Remote units connect using standard
Cat 5e Ethernet Cable and there’s no need to buy additional hubs, repeaters or software, you just
plug in and go.
Perfect for security and surveillance devices like USB video cameras, digital recorders and
other monitoring equipment, the USBthere maintains the USB 1.1 standard with data transfer rates
of up to 12 Mbits/sec. With the USBthere, extending the range of your USB devices has never been
easier.
Applications and Solutions
> Ideal for use with remote digital recorders, security/surveillance/monitoring equipment, POS devices, printers, scanners and most other USB devices
> Allows users to extend the distance of existing USB devices up to 100 meters by using Cat 5 UTP cables
Features
> Allows you to connect multiple USB devices by cascading up to 4 USB hubs

> Compliant with USB 1.1 specifications
> Data transfer rate of up to 12 Mbits/sec
> Extends the range of one USB device up to 100 meters using ethernet cables
> Uses standard Cat 5 UTP Ethernet cables
> Uses standard Cat 5e UTP Ethernet cables
Specifications
> Color Black
> Enclosure Type Steel
> Product Height 1.34 in [34 mm]
> Product Length 4.21 in [107 mm]
> Maximum Cable Length 328 ft [100 m]
> Number of Ports 4
> Power Adapter Included Yes
> Power Adapter - Amperage 1A
> Power Adapter - DC Voltage 15V
> Carton Quantity 30
> Remote Unit Connectors 1 - USB A Female
> Remote Unit Connectors 1 - RJ45 Female
> Industry Standards USB 1.1
> Shipping (Package) Weight 2.34 lb [1.06 kg]
> Product Weight 10.59 oz [300 g]
> Product Width 3.31 in [84 mm]
> Distance 330 ft (100 m)
> Data Transfer Rate Up to 12 Mbits/sec
> Standards USB 1.1
> Connectors
> Local Unit Connectors
> Upstream: 1 x 4 pin USB (Type B)
> Downstream: 1 x RJ-45
> Remote Unit Connectors
> Upstream: 1 x RJ-45
> Downstream: 4 x 6 pin USB (Type A)
> OS compatibility 98SE/2000/ME & XP
> USB hub support up to 4 hubs
> Dimensions

> Width: 4.2 Inches (107 mm)
> Depth: 3.3 Inches (84 mm)
> Height: 1.3 Inches (34 mm)
> Weight 0.6 lb (300 grams)
> Safety Standards FCC & CE
> Package Contents
> 1 x Local Extender unit
> 1 x Remote Extender unit
> 1 x 6 ft USB Cable
> 1 x Power Adapter
> 1 x User’s Guide
