Product operation and storage
Please read and follow all instructions provided with this product, and operate for
intended use only. Do not attempt to open the product casing as this may cause
damage and will void warranty. Use only the power supply provided with this product.
When not in use, product should be stored in a dry location between -20°C and 70°C.
Introduction
This 1-port USB 2.0 extender lets you connect a USB peripheral device up to 100
m (330 ft.) away from your host computer. Now you can place your USB 2.0 device
exactly where you need it, and you can overcome the 16 ft. USB cable length limitation
to create a more exible and ecient workspace. Plus, for even greater placement
exibility, you can power the extender from either the local or the remote unit.
Packaging contents
• 1 x USB 2.0 extender local unit
• 1 x USB 2.0 extender remote unit
• 1 x USB 2.0 cable
• 1 x universal power adapter (NA, JP, UK, EU, ANZ)
• 1 x quick-start guide
Requirements
• A host computer with an available USB-A port
• An available AC electrical outlet
• An RJ45-terminated UTP Cat5e or better Ethernet cable
Requirements are subject to change. For the latest requirements, please visit
www.startech.com/USB2001EXT2P.
Instruction manual
1

Instruction manual
2
Product diagram
Front view
Rear view
USB Type-A port
Mode
button
RJ45 port DC power
input
RJ45 port
Mode button
DC power
input
Conguration
port
Conguration
port
USB Type-B host
port
LEDs LEDs
Remote extender Local extender

LED indicators
The USB2001EXT2P features four LEDs on both the local unit and the remote unit.
Mode button and Conguration port
• To enter Boot loader mode and update rmware, press the Mode button.
• To update rmware and collect data, use the Conguration port.
LED Status
Power The unit is powered.
Link
A link is established between the local
extender and the remote unit.
Host
The local extender is connected to a host
computer.
Activity
A USB device is connected to the remote
unit and activity is occurring.
Instruction manual
3
Installing the extender
The USB2001EXT2P features both a local and a remote extender unit. The local
extender connects to your host computer system, while the remote extender connects
to your remote USB device. Both devices are then connected together using standard
Cat5e cable. The provided power adapter must be connected to either the local or
remote unit for the extender to properly function.

Instruction Manual
4
Install the extender
1. Connect the USB 2.0 cable (included) to the local unit’s host port and to the host
computer’s USB-A port.
2. Connect a Cat5e Ethernet cable to the local unit’s RJ45 port and to the remote unit’s
RJ45 port.
3. Connect your USB peripheral device to the remote unit’s USB-A port.
4. Select the appropriate power cord for your region and connect it to the power
adapter.
5. Connect the power adapter to an AC electrical outlet and then plug it into the DC
(power input) port on either the local or remote unit.
Installation notes
• Do not route the Ethernet cable through any networking equipment (for example, a
router, or a switch).
• Make sure that your Ethernet cable is long enough to connect the local unit to the
remote unit (maximum extension distance is 100 m or 330ft.).

Instruction manual
5
