StarTech.com 35BAYFWUSB Manual

2 Firewire 4 USB 3.5 Bay
Front Panel Hub
35BAYFWUSB
Instruction Guide
The Professionals’ Source For Hard-to-Find Computer Parts
USB HUB
* Actual product may vary from photo

1
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Introduction
Tired of the hassle and inconvenience of connecting your favorite USB and FireWire
device to the back of your PC? Then the StarTech.com 35BAYFWUSB FireWire/USB 3.5”
internal bay hub device is the right product for you. It has a unique panel design that
allows it to be simply inserted into a front 3.5" bay, giving easy access to four USB and
two IEEE 1394 FireWire ports. Up to 127 USB devices (including mouse, keyboard,
joystick, camera, scanner, printer etc) and up to 63 FireWire IEEE 1394 devices
(including hard drive, DV camera, printer etc) may be connected from the front.
Features
• Four USB ports and two IEEE 1394 ports
• Easy insertion into a 3.5” front bay
• No software driver required
• Fully compatible with USB OHCI specification and USB v1.1
• Data transfer rate of 12 Mbits/sec from USB ports
• Supports up to 127 USB devices
• OHCI-Link and PHY 100/200/400 Mbits/sec from IEEE 1394 ports
• All IEEE 1394 ports provide up to 15W of power
• Supports up to 63 IEEE 1394 devices
Getting Started
This section is designed to help you prepare the 35BAYFWUSB for installation. Please
read through this section carefully before attempting to install the hub.
Unpacking the 35BAYFWUSB
This package should contain:
1 x 2 FireWire 4 USB 3.5 bay front panel hub
1 x IEEE 1394 A type cable
1 x USB A type cable
1 x Y power cable
1 x rear bay bracket
4 x small screws (for panel), 2 x medium screws (for cables) and 1 x large screw (for
attaching rear bracket)
2 x plastic cable holders
Software Requirements
• A PC running Windows 98SE, Windows 2000, Windows ME, Windows XP
This product is not compatible with Macintosh computers!
2

Installation
Panel
1. Ensure that your computer is turned off.
2. Remove the computer case and remove a 3.5” front bay cover.
3. Insert the 35BAYFWUSB panel into the empty slot and secure it into place using the
4 small screws provided.
4. Follow the cable connection instructions listed below.
2 IEEE-1394 Ports 4 USB A Type Ports
External Ports
Internal Connectors
USB1394 V1.0
1394 Port USB B Type Power Jack
3

Cable Connection
Caution!!! Please take special care when inserting the cables onto the internal connectors at the
back of the panel. It is very important that the instructions below are followed carefully. Incorrect
insertion could lead to a device or motherboard short circuit.
Cable Color Diagram
1. Remove one of the brackets from the rear of the computer case. This will allow the
cables to be passed through and connected to the rear USB and IEEE 1394 ports.
2. IEEE 1394 cable: Connect the cable to the internal IEEE 1394 connector on the panel.
The connector fits on only one way, with the white wire to the right. Pass the cable
to the rear of the computer case and out the empty bracket space. Connect it to an
IEEE 1394 port on the back of the computer case.
3. USB cable: Connect the cable to the internal USB connector on the panel. The
connector fits on only one way, with the red wire to the right. Pass the cable to the
rear of the computer case and out the empty bracket space. Connect it to a USB port on
the back of the computer case.
4. Y power cable: Connect the cable to the internal power connector on the panel. Be sure
that the colored wires of the cable (from left to right) are yellow, black, black and red.
Connect one end of the connector to the power supply and the other end can be used
to attach another device.
5. Once the cables have been connected and passed through the computer case, put the
cables into the cutout slots on the bracket. Insert the bracket using the large screw
provided.
6. Once the cables have been connected to their respective rear ports, the cables can be
fixed more securely onto the panel by using the supplied screws and plastic cable
holders. Place the holder around the cable and fix it to the panel using the medium
screws provided.
7. Replace the computer case and turn on the computer.
8. Follow the software instructions as below.
1394 Port USB B Type Power Jack
White Red Yellow Black Black Red
4

Software Installation
1. After you have turned on the computer, Windows will automatically detect that a
Generic USB hub has been added and the Add New Hardware Wizard will appear.
Press “Next.”
2. The Add New Hardware Wizard will suggest that it searches for the most suitable
driver. Press “Next.”
3. Check the “Location” box C:\WINDOWS\system and press “Next.”
4. Windows will find the best driver for this device and install it automatically. Press
“Next.”
5. When the installation is complete, press “Finish.”
6. Attach an IEEE 1394 device to one of the IEEE 1394 ports on the panel. The IEEE 1394
ports can only be installed after an IEEE 1394 device has been connected.
7. Windows will automatically detect that an IEEE 1394 device has been added, and the
Add New Hardware Wizard will appear. Press “Next.”
8. The Add New Hardware Wizard will suggest that it searched for the most suitable
driver. Press “Next” to agree.
9. Check the “Location” box C:WINDOWS\system and press “Next.”
10. Windows will find the best driver for this device and install it automatically.
Press “Next.”
11.After the installation is complete, press “Finish.”
12. Re-start Windows.
5

6
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
Warranty Information
This product is backed by a one-year warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted below,
following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not warrant its products
from defects or damages arising from misuse, abuse, alteration, or normal wear and
tear.
Limitation of Liability
In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive incidental,
consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,
arising out of related to the use of the product exceed the actual price paid for
the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.

Revised: June 11, 2003
