StarTech.com StarView SV211KA Manual

StarView KVM with Audio
SV211KA
SV411KA Instruction Guide
The Professionals’ Source For Hard-to-Find Computer Parts
KKVVMMSSWWIITTCCHH
* Actual product may vary from photo
* SV411KA shown

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

1
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Using Your KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2
Introduction
Thank you for purchasing a StarTech.com two or four port StarView KVM switch with
audio. You can now connect your computers to a single keyboard, mouse, monitor,
microphone, and speakers, sparing you the clutter of extra consoles or peripherals. The
switch is up and running with only a few simple cable connections, and switching
between computers is as easy as a push button or hot-key combination.
Features
•Supports most microphones and speakers
•Supports hot-plugging of PS/2 keyboards or mice
•Works with M/S Intellimouse (Pro), Explorer, optical mice
•Performs sequential auto-scan of all computers
•Saves and restores keyboard states when switching computers
•Acts independently of operating system
•Supports high VGA resolution of 1920x1440 (DDC2B compatible)
•Backed by StarTech.com's one year warranty
Before You Begin
To ensure a quick and easy switch installation, please read through this section carefully
before attempting to install the switch.
System Requirements
•IBM compatible computers
•One monitor (must be capable of synchronizing with each computer's video signal.
Check your monitor's user manual for more information)
•One PS/2 keyboard and mouse
•One set of speakers
•One microphone
Contents
This package should contain:
•1x KVM switch
•SV211KA: 2 x 6 ft (1.8m) 3-in-1 cable set, 4 x 6 ft (1.8m) custom audio cable set
•SV411KA: 4 x 6 ft (1.8m) 3-in-1 cable set, 8 x 6 ft (1.8m) custom audio cable set

3
Installation
This section will guide you through the installation of your KVM switch. Please read
through the instructions carefully and complete each step in the order listed.
NOTE: Make sure that all devices are turned off before beginning installation.
Connecting the switch
1. Plug your monitor into the labeled HDB-15 port on the left side of the back of the
switch.
2. Plug your PS/2 keyboard and mouse into the labeled mini-DIN-6 ports on the right
side of the switch.
3. Plug your speakers and microphone into the labeled ports on the left side of the back
of the switch.
Back
Monitor
Speaker Microphone PC Speaker
Cable PC Microphone
Cable
PC Monitor
Cable
Side
Mouse Keyboard Power Supply
(Optional)

4
Connecting the computers
1. Connect the single end of the 3-in-1 cable into an open HDB-15 port on the back of
the switch.
2. Plug the blue monitor, purple keyboard, and green mouse cables into the ports on the
back of the computer.
3. Plug one end of the pink microphone cord into the mic port on the switch and the
other end into the mic port on your computer.
4. Plug one end of the green speaker cord into the speaker port on the switch and the
other end into the speaker port on your computer.
Repeat steps 1-4 for any other computers you want to connect to the switch. Your KVM
switch is now ready for use.
Using Your KVM Switch
NOTE: Only the LEFT Control key works for hot-key sequences.
Switching Computers
The LEDs on the front panel of the switch indicate which computer is active. To switch
between computers, either use the push-button on the front of the switch to scroll
through the computers, or hit the left Control key twice followed by the port number (for
example, to select the computer plugged into port 2, type left Ctrl + left Ctrl + 2).
Using Auto Scan
When auto scan mode is started, the switch will automatically scan through the attached
computers at user-defined intervals. Any keyboard or mouse activity will suspend the
auto scan, but once the activity ceases, auto scan will begin again.
•To start auto scan, type left Ctrl + left Ctrl + F1.
• To end auto scan, type left Ctrl + left Ctrl.
•To adjust the scan rate, type left Ctrl + left Ctrl + F3 and choose between 3 (default),
8, 15, or 30 seconds.
Manual Scan
To manually scan back and forth between computers, type left Ctrl + left Ctrl + F2. Use
the up and down arrow keys to select the previous or next computer. Pressing any other
key will abort the manual scan.
Keyboard Rates
To adjust the keyboard typematic rate, type left Ctrl + left Ctrl + F4 and select from 10
(default), 15, 20, or 30 characters/second.
NOTE: This will override the typematic rate set in your BIOS or operating system.

5
Troubleshooting
If you encounter any problems, first make sure all cables are firmly seated at both ends
and connected to their proper ports.
Problem: Keyboard or mouse doesn't work.
Cause: Improper power-up sequence. Keyboard or mouse has not initialized properly.
Solution: Press and hold the push-button for 3 seconds. This switch will reinitialize the
device. If the problem persists, unplug the device, wait a few seconds, and plug it
back in. Also remember that the switch does not support serial mice.
Problem: Keyboard error while booting up.
Cause: Loose keyboard connection.
Solution: Make sure keyboard cables are well-seated and in its proper ports.
Problem: Keyboard strokes are shifted.
Cause: The computer was in a shifted state when last switched.
Solution: Press both Shift keys.
Problem: The switch occasionally fails to function.
Cause: Computers are not supplying enough power.
Solution: Connect a DC 9V 500mA power adapter (not included) to output jack.
Problem: Scan or Typematic rate has changed.
Cause: All connecting computers were turned off and the switch has reset to default
settings.
Solution: Manually set the rates again and keep at least one computer on at all times.

6
Product Specifications
SV211KA SV411KA
Console ports 1 1
Computer ports 2 4
Port selection button 1 1
Hot plug-and-play Yes Yes
Hot-key control Yes Yes
VGA 1920 x 1440, DDC2B 1920 x 1440, DDC2B
Computer connector HDB-15 x 2, Stereo jack x 4 HDB-15 x 4, Stereo jack x 8
Console connector Keyboard: PS/2 Keyboard: PS/2
Mouse: PS/2 Mouse: PS/2
Monitor: HDB15 Monitor: HDB15
Speaker/Mic: Stereo jack x 2 Speaker/Mic: Stereo jack x 2
Auto scan interval 3, 8, 15, 30 seconds 3, 8, 15, 30 seconds
KVM cable length 6 ft (1.8m) 6 ft (1.8m)
Audio cable length 6 ft (1.8m) 6 ft (1.8m)
Power free operation Yes Yes

7
Technical Support
The following technical resources are available for this StarTech.com product:
On-line help:
We are constantly adding new information to the Tech Support section of our web site. To
access this page, click the Tech Support link on our homepage, www.startech.com. In the
tech support section there are a number of options that can provide assistance with this
card.
Knowledge Base - This tool allows you to search for answers to common issues using
key words that describe the product and your issue.
FAQ - This tool provides quick answers to the top questions asked by our customers.
Downloads - This selection takes you to our driver download page where you can
find the latest drivers for this product.
Call StarTech.com tech support for help: 1-519-455-4931
Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)
Warranty Information
This product is backed by a one-year warranty. In addition StarTech.com warrants its
products against defects in materials and workmanship for the periods noted below,
following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not warrant its products
from defects or damages arising from misuse, abuse, alteration, or normal wear and
tear.
Limitation of Liability
In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive incidental,
consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,
arising out of related to the use of the product exceed the actual price paid for
the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.

Revised: June 9, 2003
